AXLE LUBRICANTS AND CAPACITIES

LubricantSpecificationCapacity
SAE 75W-140 Synthetic Rear Axle LubricantWSL-M2C192-A XY-75W140 QL1.25 liters (2.6 pints)

AXLE LUBRICANTS AND CAPACITIES

GENERAL SPECIFICATION

ItemSpecification
Lubricants and Sealants
Premium Long-Life Grease XG-1-CESA-M1C75-B
Pipe Sealant with Teflon® D8AZ-19554-AWSK-M2G350-A2
Epoxy SealerM-3D35A (E)
Threadlock 262 E2FZ-19554-BWSK-M2G351-A6
Stud and Bearing Mount E0AZ-19554-BAWSK-M2G349-A1
Rear Axle
Backlash between ring gear and pinion teeth0.208-0.304 mm (0.008-0.012 in)
Ring gear maximum variation between teeth0.076 mm (0.003 in)
Differential case maximum runout0.076 mm (0.003 in)
Pinion bearing preload1.8-3.3 N.m (16-29 lb-in)
Handle (adapter)2.2 N.m (20 lb-in)
Pinion stem maximum radial runout in assembly0.25 mm (0.010 in)
Maximum carrier spread0.75 mm (0.030 in)
Available drive pinion bearing adjustment shim in steps of 0.25 mm (0.010 in)0.254 mm (0.010 in) - 0.965 mm (0.038 in)

GENERAL SPECIFICATION

TORQUE SPECIFICATION

DescriptionN.m
Flex coupling bolts81
Center bearing bolts43
Rear axle differential front pinion insulator bolt70
Axle differential rear insulator bolt103
Axle filler plug34
Axle ring gear bolt120
Rear axle bearing cap bolt105
Rear differential housing cover bolt32
Rear axle hub nut retainer275
Rear tow link pinch bolt80
Rear upper ball joint pinch bolt80
Brake caliper guide pin bolt33
Front upper ball joint nut69

TORQUE SPECIFICATION

BALANCE NUTS SPECIFICATION

Kit Part NumberColorWeight (grams)
XW4Z-4613-AARed1.23
XW4Z-4613-AASilver2.75
XW4Z-4613-AAGreen5.6
XW4Z-4613-AABlack4.0

BALANCE NUTS SPECIFICATION

The drivetrain's power is generated by the engine and delivered to the transmission. The driveline transfers the engine torque through the driveshaft to the axle.

The driveshaft is connected to the output shaft flange on the transmission and to the axle pinion flange. Flex couplers and alignment bushings are used at the ends of the driveshaft to allow for any angular motion. The two-piece driveshaft has a slip spline, the spline connects the driveshaft halves and is supported by a center bearing. Engine torque enters the axle through the drive pinion, which rotates the ring gear. The ring gear is mounted to the differential case, which contains the gears that transmit power to the axle halfshafts. The differential case is retained by two differential carrier bearings. There is one differential bearing cap while the right carrier bearing is enclosed by the differential housing. A selective snap ring is used instead of shims on the right side of the differential housing. The axle halfshafts rotate the drive wheels.

The engine angle is built into the engine mounts. If the flex coupler operating angles are out of specification, the engine mounts must be inspected for damage.

Scheme 1

Scheme 1: Vehicle Certification (VC) Label Example

The vehicle certification (VC) label is located in the driver door jamb. The first two digits of the axle code indicate the axle and ratio. For additional information on the VC label, refer to IDENTIFICATION CODES .

A metal axle identification tag is attached to the differential by a housing cover bolt.

Scheme 2

Scheme 2
CAUTIONThe axle identification tag is the official service identifier. Do not damage the tag. Always reinstall the tag after removing it for axle inspection/repair.

The axle identification tag identifies a particular axle design and a specific ratio. In addition, the plant code will not change as long as that particular axle assembly never undergoes an external design change. If, however, an internal design change takes place during the production life of the axle and that internal change affects parts interchangeability, a dash and numerical suffix is added to the plant code. This means that as an assembly both axles are interchangeable; however, internally they are different. Therefore, each requires different internal parts at the time of repair.

Scheme 3

Scheme 3: Special Tool(s)
