Cap

WARNINGNever remove the pressure relief cap under any conditions while the engine is operating. Failure to follow these instructions can result in damage to the cooling system or engine and/or personal injury. To avoid having scalding hot coolant or steam blow out of the cooling system, use extreme care when removing the pressure relief cap from a hot degas bottle. Wait until the engine has cooled, then wrap a thick cloth around the pressure relief cap and turn it slowly one turn (counterclockwise). Step back while the pressure is released from the cooling system. When certain all the pressure has been released, remove the pressure relief cap (still with a cloth).
  1. Remove the pressure relief cap from the degas bottle.
  2. Immerse the pressure relief cap in water and install it on the shallow filler neck of the Radiator/Heater Core Pressure Tester and the Radiator Cap Adapter, part of the Radiator/Heater Core Pressure Tester.
  3. Immerse the filler neck seal in water and install it in the filler neck adapter.
  4. Install the filler neck adapter with the filler neck seal to the Radiator Cap Adapter.
  5. Connect the female quick-connect fitting of the pressure test pump to the male quick-connect fitting of the filler neck adapter.
  6. Slowly depress the plunger of the pressure test pump until the pressure gauge reading stops increasing and note the highest pressure reading obtained.
  7. Release the pressure by turning the relief screw counterclockwise. Then tighten the pressure relief screw and repeat Step 6 (at least twice) to make sure the reading is repeatable within the specifications of the pressure relief cap.
  8. If the pressure test gauge readings are not within specifications, install a new pressure relief cap. If the pressure test gauge readings are within specifications, carry out the cooling system Pressure Test.

Thermostat

A new thermostat should be installed only after the following electrical and mechanical tests have been carried out.

Thermostat - Electrical Test

Note. The electrical thermostat test is most accurate if carried out indoors at less than 37.8°C (100°F) ambient air. This test can be carried out with or without the hood open and with the engine warm or cold.

  1. Check the engine coolant level. Fill as needed.
  2. With the ignition OFF, attach the Rotunda 73 Digital Multimeter to the cylinder head temperature (CHT) sensor. It may be used to monitor sensor voltage values between 0-5 volts.
  3. Place the transmission in PARK (P) or NEUTRAL (N).
  4. Start the engine and allow the engine to idle throughout this test. Allow the engine to run for two minutes, then record the CHT voltage. Record the CHT voltage every 60 seconds. When the CHT voltage trend changes direction or only changes slightly (0.03 volt or less) from the previous reading, record this as the thermostat opening voltage. Use the voltage and corresponding coolant temperature chart listed below. See «COOLANT TEMPERATURE SPECIFICATION»(ref-207554-S08956696802005113000000) . COOLANT TEMPERATURE SPECIFICATION Coolant Temp °C (°F) CHT Min (Volts) CHT Nom (Volts) CHT Max (Volts) 0 (32) 4.7714 4.8032 4.8723 25 (77) 4.3428 4.4148 4.4727 50 (122) 3.5354 3.6495 3.7473 80 (176) 2.3049 2.4201 2.5260 110 (230) 1.3021 1.3808 1.4562 140 (284) 0.6960 0.7414 0.7857 170 (338) 0.3784 0.4024 0.4261
  5. If the thermostat opening temperatures are not between 89°C (192°F) and 104°C (219°F) or the corresponding voltages shown on the chart, install a new thermostat.
  6. If the thermostat opening temperatures and voltages are within the specified range, the thermostat is good and a new thermostat is not required. GO to the «SYMPTOM CHART»(ref-207554-S31411344822005113000000) .

Thermostat-Mechanical Test

  1. Remove the thermostat housing.
  2. Immerse the thermostat housing and thermostat in a boiling antifreeze and water mixture.
  3. See the «GENERAL SPECIFICATIONS»(ref-207554-S42695114122005113000000) chart for thermostat opening temperatures.

Cooling Fan Motor and Shroud

  1. Inspect the fan blade and shroud for any foreign materials. Clear the obstruction and continue the test procedure.
  2. Rotate the fan to see if any contact between the shroud and blade exists. If contact is observed, install a new fan shroud assembly.
  3. Rotate the fan by hand. The fan should rotate freely (no resistance should be felt, the fan will free wheel with minimum effort). If any resistance is present, install a new fan assembly.

Scheme 4

Scheme 4: Special Tool(s)
Scheme 4: Special Tool(s)

Material

ItemSpecification
Motorcraft Premium Gold Engine Coolant VC-7-A (in California and Oregon, VC-7 B, in Canada, VC-7-C) or equivalentWSS-M97B51-A1

ITEM SPECIFICATION

Filling and Bleeding With RADKITPLUS

  1. Using the special tool, install the RADKITPLUS and follow the RADKITPLUS manufacturer's instructions to fill and bleed the cooling system.

Filling and Bleeding Without RADKITPLUS

WARNINGDo not open the cooling system while it is hot or the engine is running. Failure to follow these instructions can result in personal injury.
CAUTIONEngine coolant provides freeze protection, boil protection, cooling efficiency and corrosion protection to the engine and cooling components. In order to obtain these protections, the engine coolant must be maintained at the correct concentration and fluid level in the degas bottle. When adding engine coolant, use a 50/50 mixture of engine coolant and clean, drinkable water. To maintain the integrity of the coolant and the cooling system: Add Motorcraft Premium Gold Engine Coolant VC-7-A (in California and Oregon VC-7-B, in Canada, VC-7-C) or equivalent meeting Ford specification WSS-M97B51-A1 (yellow color). Use the same coolant that was drained from the cooling system. Do not mix coolant types. Do not add Motorcraft Speciality Orange Engine Coolant VC-2 meeting Ford specification WSS-M97B44-D (orange color). Mixing coolants can degrade the coolant's corrosion protection. Do not add alcohol, methanol, brine or any engine coolants mixed with alcohol or methanol antifreeze. These can cause engine damage from overheating or freezing. Ford Motor Company does NOT recommend the use of recycled engine coolant in vehicles originally equipped with Motorcraft Premium Gold Engine Coolant since a Ford-approved recycling process is not yet available.

3.9L Engines

Pinpoint Test C

C1 3.0L Engines
  1. 3.0L Engines
C2 All Engines
  1. All Engines
C4 3.0L Engines
  1. 3.0L Engines
C5 All Engines
  1. All Engines
C6 3.9L Engines
  1. 3.9L Engines
  2. CAUTION: Care must be taken to make sure the accessory drive belt does not become contaminated with engine coolant.
C8 All Engines
  1. All Engines
C12 3.9L Engines
  1. 3.9L Engines
C14 3.0L Engines
  1. 3.0L Engines
C16 All Engines
  1. All Engines

Scheme 5

Scheme 5: Special Tool(s)
Scheme 5: Special Tool(s)
ItemSpecification
Motorcraft Premium Cooling System Flush VC-1ESR-M14P7-A

ITEM SPECIFICATION

  1. Once pressure is released, remove the pressure relief cap.
  2. Drain the cooling system. For additional information, refer to «COOLING SYSTEM DRAINING, FILLING AND BLEEDING»(ref-207554-S15116975712005113000000) .
  3. Remove the thermostat. For additional information, refer to «THERMOSTAT AND THERMOSTAT HOUSING - 3.0L (4V)»(ref-207554-S16741197102005113000000) or «THERMOSTAT HOUSING - 3.9L»(ref-207554-S18843466392005113000000) in this section.
  4. Install the water hose connection without the thermostat.
  5. Use cooling system Pro Flush and Fill, Coolant Flush Kit and Drain Kit to flush the engine and radiator.
  6. Install the thermostat.
  7. Backflush the heater core. For additional information, refer to «HEATER CORE BACKFLUSHING»(ref-207554-S05761881862005113000000) .
  8. Fill the cooling system. For additional information, refer to «COOLING SYSTEM DRAINING, FILLING AND BLEEDING»(ref-207554-S15116975712005113000000) in this section.

Scheme 6

Scheme 6: Special Tool(s)
Scheme 6: Special Tool(s)
ItemSpecification
Motorcraft Premium Cooling System Flush VC-1ESR-M14P7-A

ITEM SPECIFICATION

  1. Once pressure is released, remove the pressure relief cap.
  2. Drain the cooling system. For additional information, refer to «COOLING SYSTEM DRAINING, FILLING AND BLEEDING»(ref-207554-S15116975712005113000000) in this section.
  3. Use cooling system Pro Flush and Fill, Flush Kit and Drain Kit to backflush the heater core.
  4. Fill and bleed the cooling system. For additional information, refer to «COOLING SYSTEM DRAINING, FILLING AND BLEEDING»(ref-207554-S15116975712005113000000) in this section.
ItemSpecification
Motorcraft Premium Engine Coolant VC-7-A (in Oregon VC-7-B) or equivalent (yellow color)WSS-M97B51-A1

ITEM SPECIFICATION

Scheme 7

Scheme 7
Scheme 7
  1. Drain the cooling system. For additional information, refer to «COOLING SYSTEM DRAINING, FILLING AND BLEEDING»(ref-207554-S15116975712005113000000) in this section.
  2. Remove the air cleaner outlet tube. For additional information, refer to «INTAKE AIR, FUEL CHARGING, STARTING & ENGINE ELECTRONICS - 3.0L (4V)»(ref-207555) .
  3. Remove the components in the order listed in the following illustration and table.
  4. To install, reverse the removal procedure.
  5. Fill and bleed the cooling system. For additional information, refer to «COOLING SYSTEM DRAINING, FILLING AND BLEEDING»(ref-207554-S15116975712005113000000) in this section.
ItemSpecification
Motorcraft Premium Gold Engine Coolant VC-7-A (in Oregon VC-7-B) or equivalent (yellow color)WSS-M97B51-A1

ITEM SPECIFICATION

Scheme 8

Scheme 8
Scheme 8

Scheme 9

Scheme 9
Scheme 9
  1. Drain the cooling system. For additional information, refer to «COOLING SYSTEM DRAINING, FILLING AND BLEEDING»(ref-207554-S15116975712005113000000) in this section.
  2. Remove the engine appearance cover.
  3. Remove the air cleaner outlet tube. For additional information, refer to «INTAKE AIR, FUEL CHARGING, STARTING & ENGINE ELECTRONICS - 3.9L»(ref-207555).
  4. To remove individual components, only carry out the listed steps. COMPONENT STEPS Component Steps Thermostat housing and thermostat 1-8 Thermostat 1-12
  5. Illustration 1 of 2. Remove the components in the order indicated in the following illustration and table. (Scheme 15)
  6. Illustration 2 of 2. Remove the components in the order indicated in the following illustration and table. (Scheme 16)
  7. To install, reverse the removal procedure.
  8. Fill and bleed the cooling system. For additional information, refer to «COOLING SYSTEM DRAINING, FILLING AND BLEEDING»(ref-207554-S15116975712005113000000) in this section.
ItemSpecification
Motorcraft Premium Gold Engine Coolant VC-7-A (in Oregon VC-7-B) or equivalent (yellow color)WSS-M97B51-A1

ITEM SPECIFICATION

Scheme 10

Scheme 10: Removal and Installation
Scheme 10: Removal and Installation
  1. Drain the cooling system. For additional information, refer to «COOLING SYSTEM DRAINING, FILLING AND BLEEDING»(ref-207554-S15116975712005113000000) in this section.
  2. Remove the electric cooling fan. For additional information, refer to «RADIATOR, COOLING FAN AND SHROUD»(ref-207554-S13298135762005113000000) in this section.
  3. Remove the accessory drive belt. For additional information, refer to «ENGINE - 3.0L (4V)»(ref-207552) .
  4. Remove the components in the order indicated in the following illustration and table.
  5. To install, reverse the removal procedure.
ItemSpecification
Motorcraft Premium Gold Engine Coolant VC-7-A (in Oregon VC-7-B) or equivalent (yellow color)WSS-M97B51-A1

ITEM SPECIFICATION

Scheme 11

Scheme 11: Removal and Installation
Scheme 11: Removal and Installation
  1. Drain the cooling system. For additional information, refer to «COOLING SYSTEM DRAINING, FILLING AND BLEEDING»(ref-207554-S15116975712005113000000) in this section.
  2. Remove the thermostat housing. For additional information, refer to «THERMOSTAT HOUSING - 3.9L»(ref-207554-S18843466392005113000000) in this section.
  3. Remove the accessory drive belt. For additional information, refer to «ENGINE - 3.9L»(ref-207553) .
  4. Remove the components in the order indicated in the following illustration and table.
  5. To install, reverse the removal procedure.
  6. Fill and bleed the cooling system. For additional information, refer to «COOLING SYSTEM DRAINING, FILLING AND BLEEDING»(ref-207554-S15116975712005113000000) in this section.

Item 4: Coolant Pump Installation Note

  1. Install a new gasket and inspect and lubricate the O-ring seal with clean engine coolant before installing the pump.

Item 3: Coolant Pump Bolts Installation Note

  1. Tighten the bolts to 8 N.m (71 lb-in), then rotate an additional 90 degrees.

Item 1: Coolant Pump Pulley Bolts Installation Note

  1. Tighten the bolts to 10 N.m (89 lb-in), then rotate an additional 45 degrees.
ItemSpecification
Motorcraft Premium Gold Engine Coolant VC-7-A (in Oregon VC-7-B) or equivalent (yellow color)WSS-M97B51-A1

ITEM SPECIFICATION

Scheme 12

Scheme 12: Removal and Installation
Scheme 12: Removal and Installation
  1. Remove the LH cylinder head. For additional information, refer to «ENGINE - 3.0L (4V)»(ref-207552) .
  2. Remove the components in the order indicated in the following illustration and table.
  3. To install, reverse the removal procedure.
  4. Fill and bleed the cooling system. For additional information, refer to «COOLING SYSTEM DRAINING, FILLING AND BLEEDING»(ref-207554-S15116975712005113000000) in this section.
ItemSpecification
Motorcraft Premium Gold Engine Coolant VC-7-A (in Oregon VC-7-B) or equivalent (yellow color)WSS-M97B51-A1

ITEM SPECIFICATION

Scheme 13

Scheme 13: Removal and Installation
Scheme 13: Removal and Installation
  1. Drain the cooling system. For additional information, refer to «COOLING SYSTEM DRAINING, FILLING AND BLEEDING»(ref-207554-S15116975712005113000000) in this section.
  2. Remove the air cleaner outlet tube. For additional information, refer to «INTAKE AIR, FUEL CHARGING, STARTING & ENGINE ELECTRONICS - 3.0L (4V)»(ref-207555).
  3. Remove the components in the order indicated in the following illustration and table. see scheme 22
  4. To install, reverse the removal procedure.
  5. Fill and bleed the cooling system. For additional information, refer to «COOLING SYSTEM DRAINING, FILLING AND BLEEDING»(ref-207554-S15116975712005113000000) in this section.
ItemSpecification
Motorcraft Premium Gold Engine Coolant VC-7-A (in Oregon VC-7-B) or equivalent (yellow color)WSS-M97B51-A1

ITEM SPECIFICATION

Scheme 14

Scheme 14
Scheme 14
  1. Drain the cooling system. For additional information, refer to «COOLING SYSTEM DRAINING, FILLING AND BLEEDING»(ref-207554-S15116975712005113000000) in this section.
  2. Remove the thermostat housing. For additional information, refer to «THERMOSTAT HOUSING - 3.9L»(ref-207554-S18843466392005113000000) in this section.
  3. Remove the components in the order indicated in the following illustration and table. see scheme 23
  4. To install, reverse the removal procedure.
  5. Fill and bleed the cooling system. For additional information, refer to «COOLING SYSTEM DRAINING, FILLING AND BLEEDING»(ref-207554-S15116975712005113000000) in this section.
ItemSpecification
Motorcraft Premium Gold Engine Coolant VC-7-A (in Oregon VC-7-B) or equivalent (yellow color)WSS-M97B51-A

ITEM SPECIFICATION

Scheme 15

Scheme 15
Scheme 15

Scheme 16

Scheme 16
Scheme 16

Scheme 17

Scheme 17
Scheme 17
  1. With the vehicle in NEUTRAL, position it on a hoist.
  2. Disconnect the battery ground cable.
  3. Drain the cooling system. For additional information, refer to «COOLING SYSTEM DRAINING, FILLING AND BLEEDING»(ref-207554-S15116975712005113000000) in this section.
  4. Remove the air cleaner outlet tube. For additional information, refer to «INTAKE AIR, FUEL CHARGING, STARTING & ENGINE ELECTRONICS - 3.0L (4V)»(ref-207555). or «INTAKE AIR, FUEL CHARGING, STARTING & ENGINE ELECTRONICS - 3.9L»(ref-207555).
  5. Remove the upper radiator sight shield.
  6. To remove individual components, only carry out the listed steps. COMPONENT STEPS Component Steps Electric cooling fan and shroud 1-16 Radiator 1-25
  7. Illustration 1 of 2. Remove the components in the order indicated in the following illustration and table. see scheme 25
  8. Illustration 2 of 2. Remove the components in the order indicated in the following illustration and table. see scheme 26
  9. To install, reverse the removal procedure.
  10. Fill and bleed the cooling system. For additional information, refer to «COOLING SYSTEM DRAINING, FILLING AND BLEEDING»(ref-207554-S15116975712005113000000) in this section.

Item 20: A/C Condenser Removal Note

  1. Lower the A/C condenser to gain access to the A/C condenser-to-radiator bolts.

Item 23: Combination Cooler Bolts Removal Note

  1. It may be necessary to lean the radiator forward to gain access to the combination cooler bolts.

Item 24: Combination Cooler Removal Note

  1. Lift the combination cooler up and forward to release it from the radiator retaining clips.

Item 25: Radiator Removal Note

Scheme 18

Scheme 18
Scheme 18

Scheme 19

Scheme 19
Scheme 19
  1. Remove the three bolts and position the shield down.
  2. Release the clips and position the radiator shield down.

Item 24: Combination Cooler Installation Note

  1. Make sure that the combination cooler is seated in the radiator retaining clips.
ItemSpecification
Motorcraft Premium Gold Engine Coolant VC-7-A (in Oregon VC-7-B) or equivalent (yellow color)WSS-M97B51-A1

ITEM SPECIFICATION

Scheme 20

Scheme 20: Removal and Installation
Scheme 20: Removal and Installation
  1. Drain the cooling system. For additional information, refer to «COOLING SYSTEM DRAINING, FILLING AND BLEEDING»(ref-207554-S15116975712005113000000) in this section.
  2. Remove the cowl vent screen. For additional information, refer to «EXTERIOR TRIM»(ref-207571).
  3. Remove the components in the order indicated in the following illustration and table. see scheme 29
  4. To install, reverse the removal procedure.
  5. Fill and bleed the cooling system. For additional information, refer to «COOLING SYSTEM DRAINING, FILLING AND BLEEDING»(ref-207554-S15116975712005113000000) in this section.
