Engine Cooling: Maintenance Lincoln LS I

Cooling Fan 11 illustrations ~557 words

Draining

WARNINGNever remove the pressure relief cap while the engine is operating or when the cooling system is hot. Failure to follow these instructions can result in damage to the cooling system or engine or personal injury. To avoid having scalding hot coolant or steam blow out of the degas bottle when removing the pressure relief cap, wait until the engine has cooled, then wrap a thick cloth around the pressure relief cap and turn it slowly. Step back while the pressure is released from the cooling system. When you are sure all the pressure has been released, (still with a cloth) turn and remove the pressure relief cap.
CAUTIONThe coolant must be recovered in a suitable, clean container for reuse. If the coolant is contaminated it must be recycled or disposed of correctly.
CAUTIONCare must be taken to ensure the accessory drive belt does not become contaminated with engine coolant.
CAUTIONSome vehicle cooling systems are filled with Motorcraft Premium Engine Coolant VC-4-A (in Oregon VC-5, in Canada CXC-10) or equivalent meeting Ford specifications ESE-M97B44-A (green color). Others are filled with Motorcraft Premium Gold Engine Coolant VC-7-A or equivalent meeting Ford specification WSS-M97B51-A1 (yellow color). Always refill the cooling system with the same coolant that was drained from the system. Do not mix coolant types.
  1. Release the pressure in the cooling system by slowly turning the pressure relief cap one half turn counterclockwise. When the pressure is released, remove the pressure relief cap.
  2. Place a suitable container below the radiator draincock. If equipped, disconnect the coolant return hose at the oil cooler. Close the radiator draincock when finished.

Filling-Bleeding

CAUTIONEngine coolant provides freeze protection, boil protection, cooling efficiency and corrosion protection to the engine and cooling components. In order to obtain these protections, the engine coolant must be maintained at the correct concentration and fluid level in the degas bottle. When adding engine coolant, use a 50/50 mixture of engine coolant and clean, drinkable water. To maintain the integrity of the coolant and the cooling system: Add Motorcraft Premium Engine Coolant VC-4-A (VC-5 in Oregon, CXC-10 in Canada) or equivalent meeting Ford specification ESE-M97B44-A (green color), or Motorcraft Premium Gold Engine Coolant VC-7-A or equivalent meeting Ford specification WSS-M97B51-A1 (yellow color). Use the same coolant that was drained from the cooling system. Do not mix coolant types. Do not add orange-colored Motorcraft Speciality Orange Engine Coolant VC-2 meeting Ford specification WSS-M97B44-D. Mixing coolants may degrade the coolant's corrosion protection. Do not add alcohol, methanol, brine or any engine coolants mixed with alcohol or methanol antifreeze. These can cause engine damage from overheating or freezing. Do not mix recycled coolant unless it meets the requirements of Ford specification ESE-M97B44-A or WSS-M97B51-A1. Not all coolant recycling processes meet these Ford specifications. Use of such a coolant may harm the engine and cooling system components.

On 3.9L engines

Pinpoint Test C

C1 On 3.0L engines
  1. On 3.0L engines
C2 On all engines
  1. On all engines
C4 On 3.0L engines
  1. On 3.0L engines
C5 On all engines
  1. On all engines
C6 On 3.9L engines
  1. CAUTION: Care must be taken to ensure the accessory drive belt does not become contaminated with engine coolant.
  2. On 3.9L engines
C8 On all engines
  1. On all engines
C12 On 3.9L engines
  1. On 3.9L engines
C14 On 3.0L engines
  1. On 3.0L engines
C16 On all engines
  1. On all engines

Scheme 116

Scheme 116: Hydraulic Cooling Fan System Filling and Bleeding

Scheme 117

Scheme 117

Note. It is not uncommon to repeat this procedure three times.

Scheme 118

Scheme 118
  1. Fill the hydraulic cooling fan reservoir to the MAX level. Use Motorcraft MERCON® Multi-Purpose (ATF) Transmission Fluid.
  2. Apply vacuum for two to three minutes. Remove the vacuum pump
  3. Start the engine and turn the A/C on MAX. This will run the hydraulic fan. If a whining noise is heard, repeat the procedure.

Scheme 119

Scheme 119: Engine and Radiator Flushing

Scheme 120

Scheme 120
  1. When you are sure all the pressure has been released, (still with a cloth) turn and remove the pressure relief cap. Once pressure is released, remove the pressure relief cap.
  2. Drain the cooling system. For additional information, see «COOLING SYSTEM DRAINING, FILLING AND BLEEDING»(ref-177126-S33156574382005062000000) .
  3. Remove the water thermostat. For additional information, see «THERMOSTAT HOUSING - 3.0L»(ref-177126-S02997499292005062000000) or «THERMOSTAT HOUSING - 3.9L»(ref-177126-S28434305152005062000000) .
  4. Install the water hose connection without the water thermostat.
  5. Use cooling system Pro Flush and Fill, Coolant Flush Kit and Drain Kit to flush the engine and radiator.
  6. Install the water thermostat.
  7. Backflush the heater core. For additional information, see «HEATER CORE BACKFLUSHING»(ref-177126-S16263740372005062000000) .
  8. Fill the cooling system. For additional information, see «COOLING SYSTEM DRAINING, FILLING AND BLEEDING»(ref-177126-S33156574382005062000000) .

Scheme 121

Scheme 121: Heater Core Backflushing

Scheme 122

Scheme 122
  1. Once pressure is released, remove the pressure relief cap.
  2. Partially drain the cooling system. For additional information, see «COOLING SYSTEM DRAINING, FILLING AND BLEEDING»(ref-177126-S33156574382005062000000) .
  3. Use cooling system Pro Flush and Fill, Flush Kit and Drain Kit to backflush the heater core.
  4. Fill the cooling system. For additional information, see «COOLING SYSTEM DRAINING, FILLING AND BLEEDING»(ref-177126-S33156574382005062000000) .

Scheme 123

Scheme 123: Removal

Scheme 124

Scheme 124

Scheme 125

Scheme 125

Scheme 126

Scheme 126
  1. Drain the engine cooling system. For additional information, see «COOLING SYSTEM DRAINING, FILLING AND BLEEDING»(ref-177126-S33156574382005062000000) .
  2. Remove the air cleaner outlet tube.
  3. Disconnect the hose.
  4. Disconnect the hose.
  5. Disconnect the hose and remove the thermostat housing assembly.
  6. Remove the bolts, separate the housing and remove the thermostat and seal.
