SPECIFICATIONS
| Application | Specification |
|---|
| Compressor Type | Ford FVS90 Variable Scroll |
| Compressor Belt Tension | (1) |
| System Oil Capacity | (2) 7 ozs. |
| Refrigerant (R-134a) Capacity | 28 ozs. |
| System Operating Pressures (3) |
| High-Side | 125-230 psi (8.8-16.1 kg/cm 2 ) |
| Low-Side | 22-45 psi (1.5-3.1 kg/cm 2 ) |
| (1) Tension is automatically adjusted. Wear indicator should be between MIN and MAX marks on automatic tensioner. (2) Use YN-12-C PAG Refrigerant Oil (Part No. F7AZ-19589-AD). (3) Operating pressures at ambient temperature of 80°F (27°C). |
| (1) | Tension is automatically adjusted. Wear indicator should be between MIN and MAX marks on automatic tensioner. |
| (2) | Use YN-12-C PAG Refrigerant Oil (Part No. F7AZ-19589-AD). |
| (3) | Operating pressures at ambient temperature of 80°F (27°C). |
TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) |
|---|
| Compressor Mounting Bolts | 18 (25) |
| Compressor Mounting Bracket Bolts | 37 (50) |
| Cross Vehicle Support Bolts | 18 (24) |
| Instrument Panel Side Bolts & Nuts | 15 (20) |
| Instrument Panel Reinforcement Bolts | 15 (20) |
| Instrument Panel Tunnel Brace Bolts | 15 (20) |
| Intermediate Shaft-To-Steering Column Pinch Bolt | 26 (35) |
| Manifold & Tube Bolt | 15 (20) |
| Thermostatic Expansion Valve Fittings | 18 (24) |
| Thermostatic Expansion Valve Mounting Bolt | 15 (20) |
| INCH Lbs. (N.m) |
| A/C Cycling Switch | 89 (10) |
| Auxiliary Coolant Pump Mounting Bolts | 52 (6) |
| Cabin Air Plenum Bolts | 53 (6) |
| Condenser Retaining Nuts | 89 (10) |
| Coolant Valve Assembly Mounting Bolts | 80 (9) |
| Coolant Valve Mounting Bracket Bolt | 80 (9) |
| Driver's Air Bag Retaining Bolts | 106 (12) |
| Evaporator Housing |
| Mounting Nut & Washer Assembly | 62 (7) |
| Cowl Top Attachment Bolt | 62 (7) |
| Evaporator Housing Attachment Bolt | 44 (5) |
| Floor Console Assembly Rear Screws | 27 (3) |
| Glove Box Door Bolts | 53 (6) |
| Hose Assembly Mounting Bolt | 80 (9) |
| Hood Release Handle Screws | 18 (2) |
| Instrument Panel |
| Bulkhead Electrical Connector Bolt | 27 (3) |
| Cowl Side Top Screws | 27 (3) |
| Peanut Fittings | 71 (8) |
| Pressure Relief Valve | 80 (9) |
| Receiver-Drier Mounting Bracket Clamp Bolt | 62 (7) |
| Receiver-Drier Mounting Nut | 71 (8) |
| Thermostatic Expansion Valve Fitting Nut | 80 (9) |
Automatic A/C-Heater System Wiring Diagram (2000-01 LS - 1 Of 2). Scheme 21
Scheme 21: Automatic A/C-Heater System Wiring Diagram (2000-01 LS - 1 Of 2)
Automatic A/C-Heater System Wiring Diagram (2000-01 LS - 2 Of 2). Scheme 22
Scheme 22: Automatic A/C-Heater System Wiring Diagram (2000-01 LS - 2 Of 2)
