Fuse & Circuit Breaker Identification
- 1 - 10 Amp Lighting Control Module: Anti-Theft Indicator Lamp, PWM Dimming Output, Illumination Lamps For Microphone, RR & LR Door Ashtrays, Heated Seat Switches, Rear Defrost Control Switch, EATC Control Panel, Message Center Switches, Speed Control Switches, Cigar Lighter, Console & Ashtray
- 2 - 10 Amp Data Link Connector, Powertrain Control Module
- 3 - 15 Amp Multi-Function Switch, Cornering Lamps, High Beam & Turn Signal Input To LCM
- 4 - 10 Amp Power Door Locks, Power Windows Switch Backlights, Radio, Mobile Telephone Transceiver, Lighting Control Module, (RUN/ACC Sense), RESCU, Electronic Day/Night Mirror
- 5 - 10 Amp Virtual Image Instrument Cluster, Lighting Control Module (LCM RUN/START Sense), Autolamp Light Sensor
- 6 - 10 Amp Virtual Image Instrument Cluster, RF Park/Turn Lamp
- 7 - 20 Amp Power Point
- 8 - 20 Amp Fuel Filler Door Release Switch, Trunk Lid Relay
- 9 - 10 Amp Blower Motor Relay, EATC Module, Airbag Diagnostic Monitor
- 10 - 30 Amp Windshield Wiper Motor & Control Module
- 11 - 10 Amp PCM Power Relay, Ignition Coils, Radio Interference Capacitor, Passive Anti-Theft System (PATS) Tranciever
- 12 - 10 Amp Lighting Control Module
- 13 - 15 Amp Right Front Turn Lamp, Right Turn Indicator (VIC), Right Rear Side Marker Lamps, Tail Lamps, License Lamps, Clock Illumination
- 14 - 20 Amp Cigar Lighter
- 15 - 10 Amp ABS Evac & Fill Connector
- 16 - 30 Amp Moonroof Switch
- 17 - Not Used
- 18 - 10 Amp Lighting Control Module
- 19 - 10 Amp Left Headlamp, Daytime Running Lights (DRL), Lighting Control Module
- 20 - 15 Amp Flash To Pass, Hazard Warning Input To LCM, Multi-Function Switch
- 21 - Not Used
- 22 - Not Used
- 23 - 10 Amp Digital Transmission Range Sensor
- 24 - 10 Amp Virtual Image Cluster, Left Hand Turn Indicator & Signal
- 25 - 10 Amp Lighting Control Module: Right Headlamp
- 26 - 10 Amp Virtual Image Instrument Cluster, EATC Module
- 27 - Not Used
- 28 - 10 Amp Shift Lock Actuator, Vehicle Dynamic Module, Virtual Image Instrument Cluster, Rear Defrost Control, Heated Seat Switch Assembly, Low Tire Pressure Module
- 29 - 10 Amp Radio
- 30 - 10 Amp Heated Mirrors
- 31 - 15 Amp FCU, Electronic Day/Night Mirror, RH & LH I/P Courtesy Lamps, Door Courtesy Lamps, RH & LH Map Lamps, Right & Left Rear Reading Lamps, Visor lamps, Storage Bin Lamp, Trunk Lid Lamp, Glove Box Lamp
- 32 - 15 Amp Speed Control BEAC Switch, Brake ON/OFF (Boo) Switch
- 33 - Not Used
- 34 - 15 Amp Console Shift Illumination, A/C Clutch Cycling Pressure Switch, A/C Clutch Relay Sensor, Intake Manifold Runner Controls, Back-Up Lamps
- 35 - Not Used
- 36 - Not Used
- 37 - 30 Amp Subwoofer Amplifier, Radio
- 38 - 10 Amp Analog Clock, CD Player, Mobile Phone Transceiver, RESCU
- 39 - 10 Amp Power Door Locks, Power Seats, Power Mirrors, Keyless Entry, Memory Seat/Mirrors, Left Front Seat Module, Left Front Door Module
- 40 - 10 Amp Cornering Lamps
- 41 - 20 Amp Door Locks
Scheme 1
Scheme 1: FUSE BLOCK IDENTIFICATION - UNDERHOOD
Scheme 2
| WARNING | Always disconnect battery ground cable before servicing "high-current fuses. It is recommended that "high-current" fuses be replaced by a qualified technician. |
- 175 Amp - Generator/Voltage Regulator
- 1 - 30 Amp Generator Voltage Regulator
- 2 - 30 Amp Driver's Seat Module
- 3 - 40 Amp Ignition Switch
- 4 - 40 Amp Ignition Switch
- 5 - 40 Amp Driver Window
- 6 - Not Used
- 7 - 30 Amp PCM Power
- 8 - 40 Amp Rear Window Defrost Control
- 9 - 60 Amp I/P Fuse Panel
- 10 - 60 Amp LCM Power
- 11 - 60 Amp Compressor Relay
- 12 - 60 Amp Anti-Lock Brake Control Module, ABS EVAC & Fill Connector
- 13 - 40 Amp Blower Motor Relay
- 14 - 60 Amp Dual Auxiliary Relay Box
- 1 - 30 Amp PCM CAM
- 2 - 20 Amp ALT SENSE
- 3 - 30 Amp Rear Passenger Window
- 4 - 30 Amp Air Suspension
- 5 - 10 Amp Air Bag
- 6 - 20 Amp Horns
- 7 - 15 Amp High Beam
- 8 - 30 Amp Front Passenger Window
- 1 - Diode A/C Diode
- 2 - Diode PCM Diode
