TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) | ||
|---|---|---|---|
| Front Suspension | |||
| Axle Shaft Nut | 170-202 (230-274) | ||
| Brake Caliper Pin & Anchor Bracket Bolt | 65-87 (88-118) | ||
| Lower Control Arm Ball Joint Nut | 50-68 (68-92) | ||
| Lower Control Arm Pivot Bolt | 73-97 (99-132) | ||
| Power Steering Gear-To-Subframe | 85-112 (113-153) | ||
| Stabilizer Bar Bracket Bolt | 23-29 (31-39) | ||
| Stabilizer Bar Link Nut | |||
| At Stabilizer Bar | 35-47 (47-64) | ||
| At Strut | 67-77 (91-104) | ||
| Strut Flange Nut | 63-71 (85-96) | ||
| Strut-To-Body Nut | 23-29 (31-39) | ||
| Strut-To-Steering Knuckle Nut | 72-98 (98-133) | ||
| Subframe-To-Body Bolt | 57-75 (77-103) | ||
| Tension Strut-To-Lower Control Arm Nut | 72-98 (98-133) | ||
| Tension Strut-To-Subframe | 72-98 (98-133) | ||
| Tie Rod Nut | 23-34 (31-46) | ||
| Transaxle Mount-To-Subframe | 64-88 (87-119) | ||
| Wheel Hub Retaining Bolt | 61-79 (83-107) | ||
| Wheel Lug Nut | 85-104 (115-141) | ||
| Rear Suspension | |||
| Brake Adapter-To-Caliper Bolt | 64-88 (87-119) | ||
| Hub Bearing Nut | 188-254 (255-344) | ||
| Lower Control Arm-To-Body Bolt | 59 (80) | ||
| Lower Control Arm-To-Spindle Bolt | 59 (80) | ||
| Upper Ball Joint Nut | 59 (80) | ||
| Upper Control Arm-To-Body Nut | 85 (115) | ||
| Shock Absorber | |||
| Lower Mounting Bolt | 559 (80) | ||
| Upper Mounting Nut | 30 (40) | ||
| Stabilizer Bar Bracket-To-Body Bolt | 22 (30) | ||
| Stabilizer Bar Link-To-Stabilizer Bar Nut | 22 (30) | ||
| Stabilizer Bar Link-To-Lower Control Arm Nut | 30 (40) | ||
| Tension Strut-To-Body Bolt | 77 (105) | ||
| Tension Strut-To-Spindle Nut | 41 (55) | ||
| Wheel Lug Nut | 85-105 (115-142) | ||
| INCH Lbs. (N.m) | |||
| Air System & Electrical | |||
| Air Compressor Bolt | 80-106 (9-12) | ||
| Front Suspension | |||
| Height Sensor Ball Stud Nut | 62-89 (7-10) | ||
