TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) |
|---|
| Aerostar, Explorer, Mountaineer & Ranger |
| Shift Cable Bracket Bolt | 15-21 (21-29) |
| Steering Column Nut | 10-12 (13-17) |
| Cougar, Mustang & Thunderbird |
| Shift Cable Bracket Bolt | 18-22 (24-31) |
| Steering Column Nut |
| Cougar & Thunderbird | 10-12 (13-17) |
| Mustang | 25-34 (34-46) |
| Crown Victoria, Grand Marquis, Sable & Taurus |
| Shift Cable Bracket Bolt | 15-19 (20-26) |
| Steering Column Absorber Nut | 10-12 (13-17) |
| Steering Column Nut | 10-12 (13-17) |
| Escort & Tracer |
| Gearshift Lever Assembly Nut | 12-16 (17-22) |
| Steering Column Nut | 10-12 (13-17) |
| "E" Series, Expedition, "F" Series & Navigator |
| Shift Cable Bracket Bolt (4R70W) |
| 4.2L Engine | 17-23 (23-32) |
| 4.6L Engine | 20-30 (27-41) |
| Shift Cable Bracket Bolt (E4OD) | 20-30 (27-41) |
| Shift Cable Bracket Nut | 12-15 (17-20) |
| Steering Column Nut | 10-12 (13-17) |
| Probe |
| Steering Column Nut | 10-12 (13-17) |
| Transmission Range Selector Nut | 12-16 (17-22) |
| Town Car |
| Shift Cable Bracket Bolt | 17-23 (23-32) |
| Steering Column Nut | 10-12 (13-17) |
| Windstar |
| Steering Column Absorber Nut | 17-23 (23-32) |
| Steering Column Nut | 10-12 (13-17) |
| INCH Lbs. (N.m) |
| Aerostar, Explorer, Mountaineer & Ranger |
| Shift Interlock Actuator Bolt | 62-97 (7-11) |
| Shift Selector Tube Bracket Bolt | 62-97 (7-11) |
| Aspire |
| Gearshift Lever Nut | 53-71 (6-8) |
| Shift Cable Bracket Bolt | 71-97 (8-11) |
| Shift Interlock Cable Bracket Locknut | 89-132 (10-15) |
| Continental |
| Shifter Interlock Actuator Bolt | 71-115 (8-13) |
| Contour & Mystique |
| Selector Lever Assembly Nut | 71-97 (8-11) |
| Cougar, Mustang & Thunderbird |
| Range Selector Lever Bolt | 54-71 (6-8) |
| Crown Victoria, Grand Marquis, Sable & Taurus |
| Shift Interlock Actuator Bolt | 17 (2) |
| Escort & Tracer |
| Cable Floorpan Bracket Bolt | 71-97 (8-11) |
| Dial Bezel Screw | 18-26 (2-3) |
| Selector Lever Cable Nut | 71-97 (8-11) |
| Selector Lever Knob Screw | 18-26 (2-3) |
| Shift Interlock Actuator Screw | 12-16 (1.3-1.8) |
| "E" Series, Expedition, "F" Series & Navigator |
| Shift Interlock Actuator Bolt | 62-97 (7-11) |
| Mark VIII |
| Gearshift Lever Assembly Bolt | 54-71 (6-8) |
| Shift Knob Bolt | 26 (3) |
| Probe |
| Shift Cable Bracket Bolt | 71-97 (8-11) |
| Shift Interlock Cable Bracket Locknut | 89-132 (10-15) |
| Town Car |
| Shift Interlock Actuator Bolt | 62-97 (7-11) |
| Villager |
| Shift Interlock Actuator Bolt | 62-97 (7-11) |
Shift Interlock System Wiring Diagram (1997 Aerostar). Scheme 74
Scheme 74: Shift Interlock System Wiring Diagram (1997 Aerostar)
Shift Interlock System Wiring Diagram (1997 Aspire). Scheme 75
Scheme 75: Shift Interlock System Wiring Diagram (1997 Aspire)
Shift Interlock System Wiring Diagram (1997 Continental). Scheme 76
Scheme 76: Shift Interlock System Wiring Diagram (1997 Continental)
Shift Interlock System Wiring Diagram (1997 Contour & Mystique). Scheme 77
Scheme 77: Shift Interlock System Wiring Diagram (1997 Contour & Mystique)
Shift Interlock System Wiring Diagram (1997 Cougar & Thunderbird). Scheme 78
Scheme 78: Shift Interlock System Wiring Diagram (1997 Cougar & Thunderbird)
Shift Interlock System Wiring Diagram (1997-98 Crown Victoria & Grand Marquis). Scheme 79
Scheme 79: Shift Interlock System Wiring Diagram (1997-98 Crown Victoria & Grand Marquis)
Shift Interlock System Wiring Diagram (1997-98 Escort & Tracer). Scheme 80
Scheme 80: Shift Interlock System Wiring Diagram (1997-98 Escort & Tracer)
Shift Interlock System Wiring Diagram (1997-98 "E" Series). Scheme 81
Scheme 81: Shift Interlock System Wiring Diagram (1997-98 "E" Series)
Shift Interlock System Wiring Diagram (1997-98 Expedition & 1998 Navigator). Scheme 82
Scheme 82: Shift Interlock System Wiring Diagram (1997-98 Expedition & 1998 Navigator)
Shift Interlock System Wiring Diagram (1997 Explorer & Mountaineer). Scheme 83
Scheme 83: Shift Interlock System Wiring Diagram (1997 Explorer & Mountaineer)
Shift Interlock System Wiring Diagram (1997-98 Mark VIII). Scheme 84
Scheme 84: Shift Interlock System Wiring Diagram (1997-98 Mark VIII)
Shift Interlock System Wiring Diagram (1997-98 Mustang). Scheme 85
Scheme 85: Shift Interlock System Wiring Diagram (1997-98 Mustang)
Shift Interlock System Wiring Diagram (1997-98 F150/250 Light Duty). Scheme 86
Scheme 86: Shift Interlock System Wiring Diagram (1997-98 F150/250 Light Duty)
Shift Interlock System Wiring Diagram (1997-98 F250/350 Heavy/Super Duty). Scheme 87
Scheme 87: Shift Interlock System Wiring Diagram (1997-98 F250/350 Heavy/Super Duty)
Shift Interlock System Wiring Diagram (1997 Probe). Scheme 88
Scheme 88: Shift Interlock System Wiring Diagram (1997 Probe)
Shift Interlock System Wiring Diagram (1997 Ranger). Scheme 89
Scheme 89: Shift Interlock System Wiring Diagram (1997 Ranger)
Shift Interlock System Wiring Diagram (1997-98 Sable & Taurus). Scheme 90
Scheme 90: Shift Interlock System Wiring Diagram (1997-98 Sable & Taurus)
Shift Interlock System Wiring Diagram (1997 Town Car). Scheme 91
Scheme 91: Shift Interlock System Wiring Diagram (1997 Town Car)
Shift Interlock System Wiring Diagram (1997-98 Villager). Scheme 92
Scheme 92: Shift Interlock System Wiring Diagram (1997-98 Villager)
Shift Interlock System Wiring Diagram (1997-98 Windstar). Scheme 93
Scheme 93: Shift Interlock System Wiring Diagram (1997-98 Windstar)
Shift Interlock System Wiring Diagram (1998 Continental). Scheme 94
Scheme 94: Shift Interlock System Wiring Diagram (1998 Continental)
Shift Interlock System Wiring Diagram (1998 Contour & Mystique). Scheme 95
Scheme 95: Shift Interlock System Wiring Diagram (1998 Contour & Mystique)
Shift Interlock System Wiring Diagram (1998 Escort ZX2). Scheme 96
Scheme 96: Shift Interlock System Wiring Diagram (1998 Escort ZX2)
Shift Interlock System Wiring Diagram (1998 Explorer & Mountaineer). Scheme 97
Scheme 97: Shift Interlock System Wiring Diagram (1998 Explorer & Mountaineer)
Shift Interlock System Wiring Diagram (1998 Ranger). Scheme 98
Scheme 98: Shift Interlock System Wiring Diagram (1998 Ranger)
Shift Interlock System Wiring Diagram (1998 Town Car). Scheme 99
Scheme 99: Shift Interlock System Wiring Diagram (1998 Town Car)
