General Specifications
| General Specifications | |
|---|---|
| Item | Specification |
| Ride Height (4x2) | |
| Front | 14 mm (0.55 in) ± 8 mm (0.32 in) |
| Rear | 79 mm (3.11 in) ± 11 mm (0.44 in) |
| Ride Height (4x4) | |
| Front | 12 mm (0.48 in) ± 8 mm (0.32 in) |
| Rear (vehicles built before 12/02) | 78 mm (3.07 in) ± 11 mm (0.44 in) |
| Rear (vehicles built after 12/02) | 86 mm (3.38 in) ± 11 mm (.044 in) |
| Vehicle lean (side-to-side height differences) | |
| Front-maximum | 7 mm (0.28 in) |
| Rear-maximum | 8 mm (0.32 in) |
| Wheel Track | |
| Wheel track | 0.6 mm (0.02 in) |
| Dogtracking | |
| Dogtracking-maximum (centerline of front tires compared to centerline of rear tires) | 30 mm (1.18 in) |
| Ball joint end play | |
| Lower ball joint-maximum vertical | 0.8 mm (0.03 in) |
| Upper ball joint-maximum vertical | 0.8 mm (0.03 in) |
| Cleaners - Wheel | |
| Custom Bright Metal Cleaner 8A-19522-A | ESR-M5B194-B |
General Specifications (1 Of 2)
| Item | Specification |
|---|---|
| Tire balance weight | |
| Maximum balance weight (total of inner and outer wheel flange) | 170 g (6.0 oz) |
| Tire Inflation | |
| Tires | See safety certification sticker located on driver door jamb. |
General Specifications (2 Of 2)
Torque Specifications
| Description | Nm | Lb-ft | Lb-in |
|---|---|---|---|
| Wheel nuts | 135 | 100 | |
| Tire pressure monitoring sensor valve stem nut | 7 | 62 | |
| Tire pressure monitoring system module screws | 7 | 62 | |
| Front Suspension | |||
| Wheel hub-to-wheel knuckle bolts | 112 | 83 | |
| Tie-rod end nut | 70 | 52 | |
| Axle-to-wheel hub nut | 250 | 184 | |
| Upper ball joint nut | 55 | 41 | |
| Upper arm-to-frame nuts | 150 | 111 | |
| Lower ball joint nut | 150 | 111 | |
| Lower arm-to-frame flag bolt and nut (forward attachment) | 400 | 295 | |
| Lower arm-to-frame nuts (rearward attachment) | 200 | 148 | |
| Shock absorber upper mounting plate-to-frame nuts (M8) | 30 | 22 | |
| Shock absorber-to-lower arm bolt and flag nut | 350 | 258 | |
| Shock absorber-to-upper mounting plate nut (M12) | 50 | 37 | |
| Stabilizer bar bracket-to-frame bolts | 63 | 46 | |
| Stabilizer bar link nuts | 90 | 66 | |
| Anti-lock brake sensor bolt | 18 | 13 | |
| Caliper anchor plate-to-wheel knuckle bolts | 112 | 83 | |
| Caliper-to-anchor plate bolts | 32 | 24 | |
| Rear Suspension | |||
| Upper ball joint-to-wheel knuckle pinch bolt and nut | 90 | 66 | |
| Upper arm-to-frame bolt and nut | 133 | 98 | |
| Upper arm-to-frame bolts and flag nuts | 80 | 59 | |
| Upper arm bushing-to-upper arm nut | 120 | 89 | |
| Lower arm-to-frame flag bolts and nuts | 175 | 129 | |
| Lower arm-to-wheel knuckle bolt and nut | 150 | 111 | |
| Stabilizer bar-to-link nut | 25 | 18 | |
| Stabilizer bar bracket-to-frame nuts | 55 | 41 | |
| Shock absorber upper mounting plate-to-frame nuts (M8) | 30 | 22 | |
| Shock absorber-to-lower arm bolt and flag nut | 250 | 184 | |
| Shock absorber-to-upper mounting plate nut (M12) | 50 | 37 | |
| Toe link-to-frame nut | 80 | 59 | |
| Toe link-to-wheel knuckle pinch bolt and nut | 90 | 66 | |
| Toe link adjustment lock nut | 70 | 52 | |
| Parking brake cable bracket-to-lower arm bolt | 12 | 9 | |
| Axle-to-wheel hub retainer nut | 275 | 203 | |
| Rear caliper bolts | 32 | 24 | |
TORQUE SPECIFICATIONS
The front caster and camber are adjusted by means of removing set shims at the upper control arm to frame mounting bolts and installing washers (W-705040-S426) to allow the arm to be adjusted in the frame slots. A caster split adjustment can be made by removing the left side lower arm-to-frame rearward mounting bolt and installing a cam bolt kit (3B236). The cam bolt can be rotated to adjust the left side caster. Front toe is adjusted by the use of the front wheel spindle tie-rod. The rear camber is adjusted by removing the set shim from the rearward lower control arm to frame mounting bolt and installing a washer (W-705040-S426) to allow the arm to be adjusted in the frame slot. The rear toe is adjusted by the use of the rear toe link.
Scheme 1
Camber is the vertical tilt of the wheel when viewed from the front. Camber can be positive or negative and has a direct effect on tire wear.
Scheme 2
Caster is the deviation from vertical of an imaginary line drawn through the ball joints when viewed from the side. The caster specifications will give the vehicle the best directional stability characteristics when loaded and driven. The caster setting is not related to tire wear.
Scheme 3
Scheme 4
The vehicle toe setting
- affects tire wear and directional stability.
- must be checked after adding aftermarket equipment, such as a snowplow or body.
Scheme 5
Scheme 6
Scheme 7
Scheme 8
Dogtracking is the condition in which the rear axle is not square to the chassis. Heavily crowned roads can give the illusion of dogtracking.
