Scheme 1
Normal Operation
When the roof opening panel glass is completely closed, it is flush with the roof panel.
When the roof opening panel glass is completely closed, it is flush with the roof panel.
When the roof opening panel glass is completely closed, it is flush with the roof panel. All components should be secured correctly.
The roof opening panel operates smoothly while opening and closing.
The roof opening panel motor is energized by voltage on circuit 400 (LB/BK) and 1173 (BN/OG) when the key is in the ACC or RUN position. The roof opening panel motor is grounded through circuit 1205 (BK). When the roof opening panel switch is pressed it connects circuit 1205 (BK) to circuit 1174 (WH/RD) for open or circuit 1175 (TN/RD) for close.
