Lighting: Removal & Installation Lexus SC II рестайлинг

REMOVAL

HINT

1. Use the same procedures for the RH and LH side.
2. The procedures listed below are for the LH side.
3. A bolt without a torque specification is shown in the standard bolt chart (see «SPECIFIED TORQUE FOR STANDARD BOLTS»(ref-283151-S16561122892008041900000) ).

Scheme 159

1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation.
2. REMOVE RADIATOR GRILLE (See «REMOVAL»(ref-283191-S32047739492008041900000) )
3. REMOVE FRONT FENDER LINER LH (See «REMOVAL»(ref-283191-S32047739492008041900000) )
4. REMOVE FRONT FENDER LINER RH (See «REMOVAL»(ref-283191-S32047739492008041900000) )
5. REMOVE FRONT BUMPER ENERGY ABSORBER
6. REMOVE FRONT BUMPER COVER (See «REMOVAL»(ref-283191-S32047739492008041900000) )
7. REMOVE HEADLIGHT ASSEMBLY Remove the 2 bolts, nut and clip. Disconnect the connectors. (Scheme 159): Identifying Headlight Assembly Bolts And Clip Pull out the unit in the direction indicated by the arrow in the illustration.

INSTALLATION

HINT

1. The procedures listed below are for the LH side.
2. Use the same procedures for the RH and LH side.

Scheme 160

1. INSTALL HEADLIGHT ASSEMBLY Connect the connector. Install the unit with the 2 bolts, nut and clip. (Scheme 160): Identifying Headlight Assembly Bolts And Clip
2. INSTALL FRONT BUMPER ENERGY ABSORBER
3. INSTALL FRONT BUMPER COVER (See «INSTALLATION»(ref-283191-S17971414742008041900000) )
4. INSTALL FRONT FENDER LINER LH (See «INSTALLATION»(ref-283191-S17971414742008041900000) )
5. INSTALL FRONT FENDER LINER RH (See «INSTALLATION»(ref-283191-S17971414742008041900000) )
6. INSTALL RADIATOR GRILLE (See «INSTALLATION»(ref-283191-S17971414742008041900000) )
7. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
8. PERFORM INITIALIZATION Perform initialization (see «INITIALIZATION»(ref-283168-S15934672912008041900000) ). NOTE: Certain systems need to be initialized after disconnecting and reconnecting the cable from the negative (-) battery terminal.
9. ADJUST HEADLIGHT AIMING (See «ADJUSTMENT»(ref-283186-S18892395432008041900000) )

Identifying Front Side Marker Light Assembly Components. Scheme 161

HINT

1. Use the same procedures for the RH and LH side.
2. The procedures listed below are for the LH side.

Scheme 162

1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation.
2. REMOVE RADIATOR GRILLE (See «REMOVAL»(ref-283191-S32047739492008041900000) )
3. REMOVE FRONT FENDER LINER LH (See «REMOVAL»(ref-283191-S32047739492008041900000) )
4. REMOVE FRONT FENDER LINER RH (See «REMOVAL»(ref-283191-S32047739492008041900000) )
5. REMOVE FRONT BUMPER COVER (See «REMOVAL»(ref-283191-S32047739492008041900000) )
6. REMOVE FRONT MARKER LIGHT LENS LH Remove the screw and lens. (Scheme 162): Identifying Front Marker Light Lens Screw (LH)

Scheme 163

1. INSTALL FRONT MARKER LIGHT LENS LH Install the lens with the screw. (Scheme 163): Identifying Front Marker Light Lens Screw (LH)
2. INSTALL FRONT FENDER LINER LH (See «INSTALLATION»(ref-283191-S17971414742008041900000) )
3. INSTALL FRONT FENDER LINER RH (See «INSTALLATION»(ref-283191-S17971414742008041900000) )
4. INSTALL FRONT BUMPER COVER (See «INSTALLATION»(ref-283191-S17971414742008041900000) )
5. INSTALL RADIATOR GRILLE (See «INSTALLATION»(ref-283191-S17971414742008041900000) )
6. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
7. PERFORM INITIALIZATION Perform initialization (see «INITIALIZATION»(ref-283168-S15934672912008041900000) ). NOTE: Certain systems need to be initialized after disconnecting and reconnecting the cable from the negative (-) battery terminal.

Identifying Fog Light Assembly Components. Scheme 164

HINT

1. Use the same procedures for the RH and LH side.
2. The procedures listed below are for the LH side.
3. A bolt without a torque specification is shown in the standard bolt chart (see «SPECIFIED TORQUE FOR STANDARD BOLTS»(ref-283151-S16561122892008041900000) ).

1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation.
2. REMOVE RADIATOR GRILLE (See «REMOVAL»(ref-283191-S32047739492008041900000) )
3. REMOVE FRONT FENDER LINER LH (See «REMOVAL»(ref-283191-S32047739492008041900000) )
4. REMOVE FRONT FENDER LINER RH (See «REMOVAL»(ref-283191-S32047739492008041900000) )
5. REMOVE FRONT BUMPER COVER (See «REMOVAL»(ref-283191-S32047739492008041900000) )
6. REMOVE FOG LIGHT UNIT LH Remove the 3 bolts and fog light. Remove the screw and fog light bracket LH.

Scheme 165

1. REMOVE FOG LIGHT BULB Remove the bulb from the light unit. (Scheme 165): Locating Fog Light Unit Bolts

Scheme 166

1. ADJUST FOG LIGHT AIMING Make sure that the tire inflation pressure is the specified value (120 kPa (1.2 kgf/cm 2, 17 psi)). Start the engine. Insert the screwdriver tip into the hole in the front bumper and rotate the aiming screw while observing through the front bumper (vertical adjustment). (Scheme 166): Inserting Screwdriver Tip Into Hole In Front Bumper HINT: Rotating the screwdriver clockwise aims the fog light axis downward, and rotating counterclockwise aims it upward.

HINT

1. Use the same procedures for the RH and LH side.
2. The procedures listed below are for the LH side.

Scheme 167

Scheme 168

1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation.
2. REMOVE TONNEAU COVER STOPPER SUB-ASSEMBLY LH (See «DISASSEMBLY»(ref-283174-S25048354742008041900000) )
3. REMOVE REAR FLOOR FINISH PLATE (See «DISASSEMBLY»(ref-283174-S25048354742008041900000) )
4. REMOVE LUGGAGE COMPARTMENT FLOOR MAT (See «DISASSEMBLY»(ref-283174-S25048354742008041900000) )
5. REMOVE LUGGAGE COMPARTMENT TRIM COVER RH (See «DISASSEMBLY»(ref-283174-S25048354742008041900000) )
6. REMOVE LUGGAGE COMPARTMENT TRIM COVER LH (See «DISASSEMBLY»(ref-283174-S25048354742008041900000) )
7. REMOVE SPARE WHEEL COVER ASSEMBLY
8. REMOVE SPARE TIRE
9. REMOVE TOOL BOX COVER (See «DISASSEMBLY»(ref-283174-S25048354742008041900000) )
10. REMOVE LUGGAGE COMPARTMENT TRIM REAR COVER SUB-ASSEMBLY (See «DISASSEMBLY»(ref-283174-S25048354742008041900000) )
11. REMOVE TONNEAU COVER ASSEMBLY (See «DISASSEMBLY»(ref-283174-S25048354742008041900000) )
12. REMOVE LUGGAGE COMPARTMENT TRIM COVER INNER LOWER (See «DISASSEMBLY»(ref-283174-S25048354742008041900000) )
13. REMOVE REAR FLOOR FINISH SIDE PLATE LH (See «DISASSEMBLY»(ref-283174-S25048354742008041900000) )
14. REMOVE LUGGAGE COMPARTMENT TRIM COVER FRONT (See «DISASSEMBLY»(ref-283174-S25048354742008041900000) )
15. REMOVE LUGGAGE COMPARTMENT TRIM COVER SIDE LH (See «DISASSEMBLY»(ref-283174-S25048354742008041900000) )
16. REMOVE REAR LIGHT COVER LH Using a screwdriver, pry out the light cover. HINT: Tape the screwdriver tip before use.
17. REMOVE REAR COMBINATION LIGHT ASSEMBLY LH Disconnect the connector. (Scheme 167): Locating Rear Combination Light Connector Remove the bolt. Pull out the light, and then disconnect the 2 pins and light guide of the body side. (Scheme 168): Pulling Out Rear Combination Light Assembly

Scheme 169

1. REMOVE REAR COMBINATION LIGHT BULB Turn the bulb in the direction indicated by the arrow and pull to remove it. (Scheme 169): Removing Rear Combination Light Bulb

Scheme 170

1. INSTALL REAR COMBINATION LIGHT BULB Insert the bulb into the light, and turn it in the direction indicated by the arrow to install it. (Scheme 170): Installing Rear Combination Light Bulb

HINT

1. Use the same procedures for the RH and LH side.
2. The procedures listed below are for the LH side.

Scheme 171

Scheme 172

1. INSTALL REAR COMBINATION LIGHT ASSEMBLY LH Attach the rear combination light with the 2 pins and install the light guide of the body side. (Scheme 171): Identifying Rear Combination Light Pins Connect the connector. (Scheme 172): Locating Rear Combination Light Connector
2. INSTALL REAR LIGHT COVER LH
3. INSTALL LUGGAGE COMPARTMENT TRIM COVER SIDE LH (See «REASSEMBLY»(ref-283174-S27811360252008041900000) )
4. INSTALL REAR FLOOR FINISH SIDE PLATE LH (See «REASSEMBLY»(ref-283174-S27811360252008041900000) )
5. INSTALL LUGGAGE COMPARTMENT TRIM COVER FRONT (See «REASSEMBLY»(ref-283174-S27811360252008041900000) )
6. INSTALL LUGGAGE COMPARTMENT TRIM COVER INNER LOWER (See «REASSEMBLY»(ref-283174-S27811360252008041900000) )
7. INSTALL TONNEAU COVER ASSEMBLY (See «REASSEMBLY»(ref-283174-S27811360252008041900000) )
8. INSTALL LUGGAGE COMPARTMENT TRIM REAR COVER SUB-ASSEMBLY (See «REASSEMBLY»(ref-283174-S27811360252008041900000) )
9. INSTALL TOOL BOX COVER (See «REASSEMBLY»(ref-283174-S27811360252008041900000) )
10. INSTALL SPARE TIRE
11. INSTALL SPARE WHEEL COVER ASSEMBLY
12. INSTALL LUGGAGE COMPARTMENT TRIM COVER RH (See «REASSEMBLY»(ref-283174-S27811360252008041900000) )
13. INSTALL LUGGAGE COMPARTMENT TRIM COVER LH (See «REASSEMBLY»(ref-283174-S27811360252008041900000) )
14. INSTALL LUGGAGE COMPARTMENT FLOOR MAT
15. INSTALL REAR FLOOR FINISH PLATE (See «REASSEMBLY»(ref-283174-S27811360252008041900000) )
16. INSTALL TONNEAU COVER STOPPER SUB-ASSEMBLY LH (See «REASSEMBLY»(ref-283174-S27811360252008041900000) )
17. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
18. PERFORM INITIALIZATION Perform initialization (see «INITIALIZATION»(ref-283168-S15934672912008041900000) ). NOTE: Certain systems need to be initialized after disconnecting and reconnecting the cable from the negative (-) battery terminal.

Identifying Back-Up Light Lens LH. Scheme 173

HINT

1. Use the same procedures for the RH and LH side.
2. The procedures listed below are for the LH side.

Scheme 174

1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation.
2. REMOVE BACK-UP LIGHT LENS LH Disconnect the connector. Remove the 2 bolts and lens. (Scheme 174): Identifying Back-Up Light Lens Bolts

HINT

1. Use the same procedures for the RH and LH side.
2. The procedures listed below are for the LH side.

Scheme 175

1. INSTALL BACK-UP LIGHT LENS LH Install the lens with the 2 bolts. (Scheme 175): Identifying Back-Up Light Lens Bolts Connect the connector.
2. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
3. PERFORM INITIALIZATION Perform initialization (see «INITIALIZATION»(ref-283168-S15934672912008041900000) ). NOTE: Certain systems need to be initialized after disconnecting and reconnecting the cable from the negative (-) battery terminal.

Identifying License Plate Light Assembly Components (1 Of 2). Scheme 176

Identifying License Plate Light Assembly Components (2 Of 2). Scheme 177

Scheme 178

1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation.
2. REMOVE REAR FLOOR FINISH PLATE (See «DISASSEMBLY»(ref-283174-S25048354742008041900000) )
3. REMOVE SPARE WHEEL COVER ASSEMBLY
4. REMOVE SPARE TIRE
5. REMOVE LUGGAGE COMPARTMENT FLOOR MAT
6. REMOVE LUGGAGE COMPARTMENT TRIM COVER RH (See «DISASSEMBLY»(ref-283174-S25048354742008041900000) )
7. REMOVE LUGGAGE COMPARTMENT TRIM COVER LH (See «DISASSEMBLY»(ref-283174-S25048354742008041900000) )
8. REMOVE TOOL BOX COVER (See «DISASSEMBLY»(ref-283174-S25048354742008041900000) )
9. REMOVE LUGGAGE HOLD BELT STRIKER ASSEMBLY (See «DISASSEMBLY»(ref-283174-S25048354742008041900000) )
10. REMOVE LUGGAGE COMPARTMENT TRIM REAR COVER SUB-ASSEMBLY (See «DISASSEMBLY»(ref-283174-S25048354742008041900000) )
11. REMOVE TONNEAU COVER STOPPER SUB-ASSEMBLY RH (See «DISASSEMBLY»(ref-283174-S25048354742008041900000) )
12. REMOVE TONNEAU COVER STOPPER SUB-ASSEMBLY LH (See «DISASSEMBLY»(ref-283174-S25048354742008041900000) )
13. REMOVE TONNEAU COVER ASSEMBLY (See «DISASSEMBLY»(ref-283174-S25048354742008041900000) )
14. REMOVE LUGGAGE HOLD BELT STRIKER ASSEMBLY (See «DISASSEMBLY»(ref-283174-S25048354742008041900000) )
15. REMOVE LUGGAGE COMPARTMENT TRIM COVER INNER LOWER (See «DISASSEMBLY»(ref-283174-S25048354742008041900000) )
16. REMOVE REAR FLOOR FINISH SIDE PLATE RH (See «DISASSEMBLY»(ref-283174-S25048354742008041900000) )
17. REMOVE REAR FLOOR FINISH SIDE PLATE LH (See «DISASSEMBLY»(ref-283174-S25048354742008041900000) )
18. REMOVE LUGGAGE COMPARTMENT TRIM COVER FRONT (See «DISASSEMBLY»(ref-283174-S25048354742008041900000) )
19. REMOVE LUGGAGE COMPARTMENT TRIM COVER SIDE RH (See «DISASSEMBLY»(ref-283174-S25048354742008041900000) )
20. REMOVE LUGGAGE COMPARTMENT TRIM COVER SIDE LH (See «DISASSEMBLY»(ref-283174-S25048354742008041900000) )
21. REMOVE REAR BUMPER COVER (See «DISASSEMBLY»(ref-283191-S28213072792008041900000) )
22. REMOVE LICENSE PLATE LIGHT ASSEMBLY Detach the claw and remove the license plate light. (Scheme 178): Locating License Plate Light Claws

Scheme 179

1. INSTALL LICENSE PLATE LIGHT ASSEMBLY Attach the claw to install the license plate light. (Scheme 179): Locating License Plate Light Claws
2. INSTALL REAR BUMPER COVER (See «INSTALLATION»(ref-283191-S32248558452008041900000) )
3. INSTALL LUGGAGE COMPARTMENT TRIM COVER SIDE RH (See «REASSEMBLY»(ref-283174-S27811360252008041900000) )
4. INSTALL LUGGAGE COMPARTMENT TRIM COVER SIDE LH (See «REASSEMBLY»(ref-283174-S27811360252008041900000) )
5. INSTALL LUGGAGE COMPARTMENT TRIM COVER FRONT (See «REASSEMBLY»(ref-283174-S27811360252008041900000) )
6. INSTALL REAR FLOOR FINISH SIDE PLATE LH (See «REASSEMBLY»(ref-283174-S27811360252008041900000) )
7. INSTALL REAR FLOOR FINISH SIDE PLATE RH (See «REASSEMBLY»(ref-283174-S27811360252008041900000) )
8. INSTALL LUGGAGE COMPARTMENT TRIM COVER INNER LOWER (See «REASSEMBLY»(ref-283174-S27811360252008041900000) )
9. INSTALL TONNEAU COVER ASSEMBLY (See «REASSEMBLY»(ref-283174-S27811360252008041900000) )
10. INSTALL TONNEAU COVER STOPPER SUB-ASSEMBLY RH (See «REASSEMBLY»(ref-283174-S27811360252008041900000) )
11. INSTALL TONNEAU COVER STOPPER SUB-ASSEMBLY LH (See «REASSEMBLY»(ref-283174-S27811360252008041900000) )
12. INSTALL LUGGAGE COMPARTMENT TRIM REAR COVER SUB-ASSEMBLY (See «REASSEMBLY»(ref-283174-S27811360252008041900000) )
13. INSTALL LUGGAGE HOLD BELT STRIKER ASSEMBLY (See «REASSEMBLY»(ref-283174-S27811360252008041900000) )
14. INSTALL TOOL BOX COVER (See «REASSEMBLY»(ref-283174-S27811360252008041900000) )
15. INSTALL LUGGAGE COMPARTMENT TRIM COVER LH (See «REASSEMBLY»(ref-283174-S27811360252008041900000) )
16. INSTALL LUGGAGE COMPARTMENT TRIM COVER RH (See «REASSEMBLY»(ref-283174-S27811360252008041900000) )
17. INSTALL LUGGAGE COMPARTMENT FLOOR MAT
18. INSTALL SPARE TIRE
19. INSTALL SPARE WHEEL COVER ASSEMBLY
20. INSTALL REAR FLOOR FINISH PLATE (See «REASSEMBLY»(ref-283174-S27811360252008041900000) )
21. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
22. PERFORM INITIALIZATION Perform initialization (see «INITIALIZATION»(ref-283168-S15934672912008041900000) ). NOTE: Certain systems need to be initialized after disconnecting and reconnecting the cable from the negative (-) battery terminal.

Identifying High Mounted Stop Light Assembly Components. Scheme 180

HINT

When replacing the stop light, heat the body and stop light using a heat light.

Heating temperature

HEATING TEMPERATURE SPECIFICATION

Note. Do not heat the body and stop light excessively.

Scheme 181

Scheme 182

1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation.
2. REMOVE LUGGAGE COMPARTMENT DOOR ASSIST GRIP (See «DISASSEMBLY»(ref-283174-S24223257212008041900000) )
3. REMOVE LUGGAGE COMPARTMENT DOOR COVER (See «DISASSEMBLY»(ref-283174-S24223257212008041900000) )
4. REMOVE CENTER STOP LIGHT ASSEMBLY Disconnect the connector. Remove the tape and 2 nuts. (Scheme 181): Identifying Center Stop Light Nuts Apply protective tape to the vehicle body around the center stop light. Using a heat light, heat the center stop light. Tie objects that can serve as handles (for example, wooden blocks) to both wire ends. Cut through the double-sided tape by pulling the piano wire as shown in the illustration. NOTE: If reusing the center stop light, take care not to damage the center stop light. Do not damage the body. (Scheme 182): Pulling Piano Wire Remove the center stop light.

Scheme 183

Scheme 184

1. INSTALL CENTER STOP LIGHT ASSEMBLY Clean the vehicle body surface. Using a heat light, heat the vehicle body surface. Remove the double-sided tape from the vehicle body. Wipe off stains with cleaner. Remove the double-sided tape from the center stop light. Wipe off stains with cleaner. Install the center stop light. Apply new double-sided tape to the center stop light as shown in the illustration. Using a heat light, heat the vehicle body and center stop light. (Scheme 183): Identifying Double-Sided Tape Applying Area On Center Stop Light Install the center stop light with the 2 nuts. (Scheme 184): Identifying Center Stop Light Nuts
2. INSTALL LUGGAGE COMPARTMENT DOOR COVER (See «REASSEMBLY»(ref-283174-S16886290462008041900000) )
3. INSTALL LUGGAGE COMPARTMENT DOOR ASSIST GRIP
4. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
5. PERFORM INITIALIZATION Perform initialization (see «INITIALIZATION»(ref-283168-S15934672912008041900000) ). NOTE: Certain systems need to be initialized after disconnecting and reconnecting the cable from the negative (-) battery terminal.

Identifying Rear Side Marker Light Lens LH And Rear Bumper Cover. Scheme 185

HINT

1. Use the same procedures for the RH and LH side.
2. The procedures listed below are for the LH side.

Scheme 186

1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation.
2. REMOVE REAR BUMPER COVER Remove the rear bumper cover (see «REMOVAL»(ref-283191-S33402229792008041900000) ).
3. REMOVE REAR SIDE MARKER LIGHT LENS LH Remove the screw and lens. (Scheme 186): Identifying Rear Side Marker Light Lens Screw

HINT

1. Use the same procedures for the RH and LH side.
2. The procedures listed below are for the LH side.

Scheme 187

1. INSTALL REAR SIDE MARKER LIGHT LENS LH Install the lens with the screw. (Scheme 187): Identifying Rear Side Marker Light Lens Screw
2. INSTALL REAR BUMPER COVER Remove the rear bumper cover (see «INSTALLATION»(ref-283191-S32248558452008041900000) ).
3. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
4. PERFORM INITIALIZATION Perform initialization (see «INITIALIZATION»(ref-283168-S15934672912008041900000) ). NOTE: Certain systems need to be initialized after disconnecting and reconnecting the cable from the negative (-) battery terminal.

Identifying Turn Signal Light Switch Components. Scheme 188

Scheme 189

1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation.
2. REMOVE NO. 1 INSTRUMENT PANEL SAFETY PAD SUB-ASSEMBLY (See «REMOVAL»(ref-283177-S12462467572008041900000) )
3. REMOVE INSTRUMENT CLUSTER FINISH PANEL SUB-ASSEMBLY (See «REMOVAL»(ref-283177-S12462467572008041900000) )
4. REMOVE STEERING COLUMN COVER UPPER
5. REMOVE STEERING COLUMN COVER LOWER
6. REMOVE TURN SIGNAL SWITCH ASSEMBLY Disconnect the connector. Remove the 2 screws and switch. (Scheme 189): Identifying Turn Signal Switch Screws

Scheme 190

1. INSTALL TURN SIGNAL SWITCH ASSEMBLY Install the switch with the 2 screws. (Scheme 190): Identifying Turn Signal Switch Screws Connect the connector.
2. INSTALL STEERING COLUMN COVER LOWER
3. INSTALL STEERING COLUMN COVER UPPER
4. INSTALL INSTRUMENT CLUSTER FINISH PANEL SUB-ASSEMBLY (See «INSTALLATION»(ref-283177-S14297446472008041900000) )
5. INSTALL NO. 1 INSTRUMENT PANEL SAFETY PAD SUB-ASSEMBLY (See «INSTALLATION»(ref-283177-S14297446472008041900000) )
6. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
7. PERFORM INITIALIZATION Perform initialization (see «INITIALIZATION»(ref-283168-S15934672912008041900000) ). NOTE: Certain systems need to be initialized after disconnecting and reconnecting the cable from the negative (-) battery terminal.

Scheme 191

1. INSPECT HAZARD WARNING SWITCH Measure the resistance of the switch. Standard resistance RESISTANCE SPECIFICATION Tester Connection Switch Condition Specified Condition A9-12 - A10-14 Hazard warning switch ON Below 1 ohms A9-12 - A10-14 Hazard warning switch OFF 10 kohms or higher If the result is not as specified, replace the A/C control. (Scheme 191): Identifying Hazard Warning Switch Connector Terminals

Scheme 192

1. INSPECT AFS OFF SWITCH Measure the resistance of the switch. Standard resistance RESISTANCE SPECIFICATION Tester Connection Switch Condition Specified Condition 3 - 4 AFS OFF switch is pushed Below 1 ohms 3 - 4 AFS OFF switch is not pushed 10 kohms or higher If the result is not as specified, replace the switch. (Scheme 192): Identifying AFS OFF Switch Connector Terminals

Scheme 193

1. INSPECT STOP LIGHT SWITCH ASSEMBLY Measure the resistance of the switch. Standard resistance RESISTANCE SPECIFICATION Tester Connection Switch Condition Specified Condition 1 - 2 Pushed Below 1 ohms 1 - 2 Not pushed 10 kohms or higher If the result is not as specified, replace the switch assembly. (Scheme 193): Inspecting Stop Light Switch Assembly

Scheme 194

1. INSPECT FRONT DOOR COURTESY LIGHT SWITCH ASSEMBLY Measure the resistance of the switch. Standard resistance RESISTANCE SPECIFICATION Tester Connection Switch Condition Specified Condition 1 - Body ground Not pushed (ON) Below 1 ohms 1 - Body ground Pushed (OFF) 10 kohms or higher If the result is not as specified, replace the switch assembly. (Scheme 194): Inspecting Front Door Courtesy Light Switch Assembly

Identifying Front Height Control Sensor Sub-Assembly LH With Torque Specifications. Scheme 195

Scheme 196

1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation.
2. REMOVE FRONT WHEEL (See «REMOVAL»(ref-283147-S05550416272008041900000) )
3. REMOVE FRONT HEIGHT CONTROL SENSOR SUB-ASSEMBLY LH Disconnect the connector. Remove the nut and disconnect the sensor link. Remove the 2 bolts and sensor. (Scheme 196): Locating Front Height Control Sensor Bolts

Scheme 197

1. INSPECT FRONT HEIGHT CONTROL SENSOR SUBASSEMBLY Connect 3 dry cell batteries (1.5 V) in series. Connect the dry cell battery positive (+) terminal to terminal 1 (SHB) and the negative one to terminal 4 (SHG) to apply the voltage of 4.5 V between terminals 1 (SHB) and 4 (SHG). While slowly moving the link up and down with the voltage being applied, measure the voltage between terminals 2 (SHFL) and 4 (SHG). Standard voltage VOLTAGE SPECIFICATION Link Angle Specified Condition +45° (High) 4.5 V 0° (Normal) 2.5 V -45° (Low) 0.5 V If the result is not as specified, replace the sensor. (Scheme 197): Inspecting Inspect Front Height Control Sensor Sub-Assembly

Scheme 198

Scheme 199

1. ADJUST FRONT HEIGHT CONTROL SENSOR SUB-ASSEMBLY LH Adjust the link. Loosen the lock nut of the sensor link. While the vehicle is unloaded, adjust the length of the sensor's arm by rotating the link so that the arm is set in the neutral position. (Scheme 198): Adjusting Front Height Control Sensor Sub-Assembly Check that the length of the threaded part, dimension (A) in the illustration, is shorter than the standard value. (Scheme 199): Identifying Length Of Threaded Part Standard: A: 14 mm (0.55 in.) Tighten the look nut of the sensor link. Torque: 5.4 N*m (55 kgf*cm, 48 in.*lbf)
2. ADJUST HEADLIGHT AIMING (See «ADJUSTMENT»(ref-283186-S18892395432008041900000) )

Scheme 200

1. INSTALL FRONT HEIGHT CONTROL SENSOR SUB-ASSEMBLY LH Install the sensor with the 2 bolts. (Scheme 200): Locating Front Height Control Sensor Bolts Torque: 7.8 N*m (80 kgf*cm, 69 in.*lbf) Install the nut. Torque: 5.4 N*m (55 kgf*cm, 48 in.*lbf) Connect the connector.
2. INSTALL FRONT WHEEL (See «DISPOSAL»(ref-283147-S36988035622008041900000) )
3. ADJUST HEADLIGHT AIMING (See «ADJUSTMENT»(ref-283186-S18892395432008041900000) )

Identifying Rear Height Control Sensor Sub-Assembly LH With Torque Specification. Scheme 201

Scheme 202

Scheme 203

1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation.
2. REMOVE REAR HEIGHT CONTROL SENSOR SUB-ASSEMBLY LH Disconnect the connector. Place matchmarks on the link and bracket. Remove the nut and disconnect the sensor link. (Scheme 202): Identifying Matchmarks On Link And Bracket Remove the 2 bolts and sensor. (Scheme 203): Locating Rear Height Control Sensor Bolts

Scheme 204

1. INSPECT REAR HEIGHT CONTROL SENSOR SUBASSEMBLY Connect 3 dry cell batteries (1.5 V) in series. Connect the dry cell battery positive (+) terminal to terminal 3 (SHB) and the negative one to terminal 1 (SHG) to apply the voltage of 4.5 V between terminals 3 (SHB) and 1 (SHG). While slowly moving the link up and down with the voltage being applied, measure the voltage between terminals 2 (SHRL) and 1 (SHG). Standard voltage VOLTAGE SPECIFICATION Link Angle Specified Condition +45° (High) 4.5 V 0° (Normal) 2.5 V -45°(Low) 0.5 V If the result is not as specified, replace the sensor. (Scheme 204): Inspecting Rear Height Control Sensor Sub-Assembly

Scheme 205

Scheme 206

1. INSTALL REAR HEIGHT CONTROL SENSOR SUB-ASSEMBLY LH Install the sensor with the 2 bolts. Torque: 7.8 N*m (80 kgf*cm, 69 in.*lbf) (Scheme 205): Locating Rear Height Control Sensor Bolts Align the matchmarks on the sensor link and bracket. (Scheme 206): Identifying Matchmarks On Sensor Link And Bracket Install the nut. Torque: 5.4 N*m (55 kgf*cm, 48 in.*lbf) Connect the connector.
2. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
3. PERFORM INITIALIZATION Perform initialization (see «INITIALIZATION»(ref-283168-S15934672912008041900000) ). NOTE: Certain systems need to be initialized after disconnecting and reconnecting the cable from the negative (-) battery terminal.
4. ADJUST HEADLIGHT AIMING (See «ADJUSTMENT»(ref-283186-S18892395432008041900000) )

Identifying AFS ECU Components. Scheme 207

HINT

A bolt without a torque specification is shown in the standard bolt chart (see SPECIFIED TORQUE FOR STANDARD BOLTS ).

Scheme 208

1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation.
2. REMOVE DOOR SCUFF PLATE ASSEMBLY LH (See «REMOVAL»(ref-283177-S12462467572008041900000) )
3. REMOVE FRONT DOOR OPENING TRIM COVER LH (See «REMOVAL»(ref-283177-S12462467572008041900000) )
4. REMOVE HOOD LOCK CONTROL LEVER SUB-ASSEMBLY Remove the 2 bolts and hood control lever.
5. REMOVE NO. 1 INSTRUMENT PANEL SAFETY PAD SUB-ASSEMBLY (See «REMOVAL»(ref-283177-S12462467572008041900000) )
6. REMOVE AFS ECU Disconnect the ECU connector. Remove the 2 bolts and ECU. (Scheme 208): Identifying AFS ECU Bolts

Scheme 209

1. INSTALL AFS ECU Install the ECU with the 2 bolts. (Scheme 209): Identifying AFS ECU Bolts Connect the ECU connector.
2. INSTALL NO. 1 INSTRUMENT PANEL SAFETY PAD SUB-ASSEMBLY (See «INSTALLATION»(ref-283177-S14297446472008041900000) )
3. INSTALL HOOD LOCK CONTROL LEVER SUB-ASSEMBLY Install the hood lock control lever with the 2 bolts.
4. INSTALL FRONT DOOR OPENING TRIM COVER LH (See «INSTALLATION»(ref-283177-S14297446472008041900000) )
5. INSTALL DOOR SCUFF PLATE ASSEMBLY LH (See «INSTALLATION»(ref-283177-S14297446472008041900000) )
6. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
7. PERFORM INITIALIZATION Perform initialization (see «INITIALIZATION»(ref-283168-S15934672912008041900000) ). NOTE: Certain systems need to be initialized after disconnecting and reconnecting the cable from the negative (-) battery terminal.

Scheme 210

1. INSPECT HEADLIGHT RELAY (Marking: HEAD LP) Remove the HEAD LP relay from the engine room No. 1 relay block. Measure the resistance of the relay. (Scheme 210): Identifying Headlight Relay Connector Terminals Standard resistance RESISTANCE SPECIFICATION Tester Connection Specified Condition 1 - 2 10 kohms or higher 1 - 2 Below 1 ohms (when battery voltage is applied to terminals 3 and 4)

Scheme 211

1. INSPECT FOG LIGHT RELAY (Marking: FR FOG) Remove the FR FOG relay from the engine room No. 2 relay block. Measure the resistance of the relay. Standard resistance RESISTANCE SPECIFICATION Tester Connection Specified Condition 3 - 5 10 kohms or higher 3-5 Below 1 ohms (when battery voltage is applied to terminals 1 and 2) (Scheme 211): Identifying Fog Light Relay Connector Terminals
