PRECAUTION
Note. When disconnecting the cable from the negative (-) battery terminal, initialize the following systems after the cable is reconnected.
| System Name | See procedure |
|---|---|
| Front Power Seat Control System | INITIALIZATION |
| Combination Meter |
SYSTEM REFERENCE CHART
Scheme 240
Scheme 241
Scheme 242
- DO NOT HANDLE REFRIGERANT IN AN ENCLOSED AREA OR NEAR AN OPEN FLAME
- ALWAYS WEAR PROTECTIVE GLASSES (Scheme 240): Precaution For Protective Glass
- AVOID SKIN OR EYE CONTACT WITH LIQUID REFRIGERANT If liquid refrigerant comes in contact with your eyes or skin: Wash the area with a lot of cold water. CAUTION: Do not rub your eyes or skin. Apply clean petroleum jelly to the skin. Go immediately to a hospital or see a physician for professional treatment. (Scheme 241): Precaution For Avoid Skin Or Eye Contact With Liquid Refrigerant
- NEVER HEAT CONTAINER OR EXPOSE IT TO OPEN FLAME
- DO NOT DROP OR STRIKE CONTAINER OF REFRIGERANT
- DO NOT OPERATE COMPRESSOR WITHOUT ENOUGH REFRIGERANT IN REFRIGERANT SYSTEM If there is not enough refrigerant in the refrigerant system, oil lubrication will be insufficient and the compressor may burn out. Necessary care should be taken to avoid this.
- DO NOT OPEN HIGH PRESSURE MANIFOLD VALVE WHILE COMPRESSOR IS OPERATING Open and close only the low pressure valve. If the high pressure valve is opened, refrigerant flows in the reverse direction and causes the charging cylinder to rupture. (Scheme 242): Identifying Correct And Incorrect Pressure Value
- BE CAREFUL NOT TO OVERCHARGE SYSTEM WITH REFRIGERANT Overcharged refrigerant will cause problems such as insufficient cooling, poor fuel economy, engine overheating, etc.
- DO NOT OPERATE ENGINE AND COMPRESSOR WITHOUT REFRIGERANT IN REFRIGERANT SYSTEM NOTE: This may damage the inside of the compressor because the compressor parts always move regardless of whether the A/C system is on or off.
Air Condition System Diagram (1 Of 2). Scheme 243
Air Condition System Diagram (2 Of 2). Scheme 244
Scheme 245
Scheme 246
Scheme 247
Scheme 248
- MODE POSITION AND DAMPER OPERATION (Scheme 245): Mode Position And Damper Operation Chart DAMPER POSITION OPERATION CHART Control Damper Control Position Damper Position Operation Air Inlet Control Damper FRESH A Brings in fresh air. RECIRCULATION B Recirculates internal air. Air Mix Control Damper MAX COOL to MAX WARM (TEMPERATURE SETTING 18 to 32°C (64.4 to 89.6°F) C, D, E Varies mixture ratio of fresh air and recirculation air in order to regulate temperature continuously from HOT to COOL. Mode Control Damper FACE F, J Air blows out of center registers and side registers. BI-LEVEL G, J Air blows out of center register, side registers, and footwell register ducts. FOOT H, K Air blows out of footwell register ducts and side registers. Also, a little air blows out from front and side defrosters. FOOT/DEF H, L Air blows out from front and side defrosters and side registers to defog the windows, and also blows out from footwell register ducts. DEF H, M Air blows out from front and side defrosters and side registers to defog the windows. RETRACTABLE HARDTOP CONTROL SWITCH N When retractable hardtop is open, air blows out from lap-jet if the mode is not FACE or DEF.
- AIR OUTLETS AND AIR VOLUME RATIONS (Scheme 246): Air Outlets And Air Volume Rations Chart (1 Of 3) (Scheme 247): Air Outlets And Air Volume Rations Chart (2 Of 3) (Scheme 248): Air Outlets And Air Volume Rations Chart (3 Of 3) HINT: •: Available -: Not available The size of the white circle indicates the proportion of the airflow volume. There are 3 sizes. *: When the retractable hardtop is opened.
CUSTOMIZE PARAMETERS
- CUSTOMIZING FUNCTION WITH INTELLIGENT TESTER (REFERENCE) HINT: The following items can be customized. NOTE: When the customer requests a change in a function, first make sure that the function(s) can be customized. Be sure to record the current settings before customizing. When troubleshooting a function, first make sure that the function is set to the default setting. A/C amplifier CUSTOMIZE PARAMETERS Display (Item) Default Contents Setting SET TEMP SHIFT (Shift Set Temperature) NORMAL Function to control with shifted temperature against display temperature. +2C / +1C / NORMAL -1C / -2C AIR INLET MODE (Air Inlet Mode) AUTO When turning A/C ON when you desire to cool compartment down quickly, this function changes mode automatically to RECIRCULATED mode. MANUAL/AUTO COMPRESSOR MODE (Compressor Mode) AUTO Function to turn A/C ON automatically by pressing AUTO button when the blower is ON and the A/C is OFF. MANUAL/AUTO COMPRS/DEF OPER (Compressor / DEF Operation) LINK Function to turn A/C ON automatically linking with FRONT DEF button when A/C is OFF. NORMAL / LINK AIR INLET OPER (Air Inlet (PSVW LOCK) operation) LINK Function to change mode automatically to OUTSIDE AIR mode from RECIRCULATED mode linking with A/C button in case of A/C breakdown, etc. NORMAL / LINK GAS SENS SHIFT (Emission Gas Sensor Shift) NORMAL Function to change sensitivity of exhaust gas sensor. MU MORE / MORE / LI MORE / NORMAL / LI LESS / LESS / MU LESS FOOT AOUT OPER (Foot Air Out Operation) ON Function to turn air flow from lap-jet ON automatically when retractable hard top is housed OFF / ON FOOT/DEF MODE (FOOT/DEF Auto Mode) ON Function to turn air flow from FOOT / DEF ON automatically when AUTO MODE is ON OFF / ON
