TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) |
|---|
| Accumulator To Brake Booster Pump | 36 (54) |
| Brake Actuator Tube No. 1 | 11 (15) |
| Brake Booster Clevis Lock Nut | 19 (26) |
| Brake Union Bolt | 22 (30) |
| Disc Brake Front Caliper Installation Bolts | 25 (34) |
| Flexible Hose-To-Brake Caliper | 22 (30) |
| Front Brake Caliper Mounting | 87 (118) |
| Front Brake Caliper-To-Front Brake Caliper Mounting | 25 (34) |
| Master Cylinder Union Bolts | 23 (32) |
| Push Rod Lock Nut | 19 (26) |
| Wheel Lug Nuts | 76 (103) |
| Wheel Ornament Bolts | 15 (20) |
| INCH Lbs. (N.m) |
| Bleeder Screw | 97 (11) |
| Brake Actuator Bracket No. 1 | 75 (8.5) |
| Brake Actuator Bracket No. 3 | 69 (7.8) |
| Brake Booster Pump Bracket No. 1 | 69 (7.8) |
| Brake Booster Pump Bracket No. 2 | 69 (7.8) |
| Brake Booster Pump Bracket No. 3 | 106 (12) |
| Brake Booster Pump Bracket Bolt | 106 (12) |
| Brake Control Wire |
| Master Cylinder Side | 15 (1.7) |
| Booster Pump Side | 26 (2.9) |
| Brake Lines To Body | 43 (4.9) |
| Front Brake Line To Flexible Hose | 133 (15) |
| Brake Lines To Master Cylinder | 133 (15) |
| Master Cylinder Assembly Nuts | 133 (15) |
| Master Cylinder Reservoir Sub-Assembly | 15 (2) |
DISC BRAKE SPECIFICATIONS
| Application | In. (mm) |
|---|
| Brake Pad Thickness |
| Front |
| Standard | .433 (11) |
| Minimum | .039 (1.0) |
| Rear |
| Standard | .413 (10.5) |
| Minimum | .039 (1.0) |
| Front Disc |
| Standard Thickness | 1.260 (32) |
| Minimum Thickness | 1.181 (30) |
| Disc Runout (1) | .002 (.05) |
| Rear Disc |
| Standard Thickness | .472 (12) |
| Minimum Thickness | .413 (10.5) |
| Disc Runout (1) | .002 (.05) |
| Rear Disc Parking Brake Drum (2) |
| Brake Shoe-To-Lever Clearance | Less Than .0138 (.35) |
| Drum Diameter | 7.48 (190) |
| Maximum Diameter | 7.52 (191) |
| Parking Brake Shoe Lining Thickness (3) |
| Standard Thickness | .098 (2.5) |
| Minimum Thickness | .039 (1.0) |
| (1) Measured .39 in. (10 mm) from outer edge of rotor. (2) This is the drum for the parking brake on the inside of the rear disc. (3) This is brake lining for the parking brake on the inside of the rear disc. |
| (1) | Measured .39 in. (10 mm) from outer edge of rotor. |
| (2) | This is the drum for the parking brake on the inside of the rear disc. |
| (3) | This is brake lining for the parking brake on the inside of the rear disc. |
DISC BRAKE SPECIFICATIONS
Scheme 1
Scheme 2
