ADJUSTMENT
HINT
On the RH side, use the same procedures as on the LH side.
HINT
Since the centering bolt is used as a door hinge set bolt, the door can not be adjusted with it on. Substitute a bolt with washer for the centering bolt.
Scheme 7
Scheme 8
Scheme 9
Scheme 10
Scheme 11
- INSPECT FRONT DOOR Check that the clearance is within the standard value.
- ADJUST FRONT DOOR Using SST, adjust the door by loosening the body side hinge bolts forward/rearward and vertically. Tighten the body side hinge bolts after adjustment. Torque: 32.5 N.m (331 kgf.cm, 24 ft.lbf) Adjust the door by loosening the door side hinge bolts horizontally and vertically. Tighten the door side hinge bolts after adjustment. Torque: 32.5 N.m (331 kgf.cm, 24 ft.lbf) Using a screwdriver, remove the door lock striker cover. HINT: Tape the screwdriver tip before use. Adjust the striker position by slightly loosening the striker mounting screws and hitting the striker with a plastic hammer. Tighten the striker mounting screws after adjustment. Torque: 23 N.m (235 kgf.cm, 17 ft.lbf)
