Audio & Visual System: Removal & Installation Lexus SC II

Entertainment Systems 39 illustrations ~3877 words

Replacement

HINT

COMPONENTS: See COMPONENTS

Scheme 60

Scheme 60: Replacement
Scheme 60: Replacement

Scheme 61

Scheme 61
Scheme 61

Scheme 62

Scheme 62
Scheme 62

Scheme 63

Scheme 63
Scheme 63

Scheme 64

Scheme 64
Scheme 64

Scheme 65

Scheme 65
Scheme 65
  1. SHIP MODE SETTING Take out all of the CDs. NOTE: If they cannot be taken out, do not attempt to take out forcibly and send the unit for repair. While simultaneously pressing the "SEEK UP" and "DISC" switches, turn the ignition switch to ACC. HINT: The CD indicator light blinks during the mode setting and it remains lit after the setting is completed. When the mode setting is completed, "SHIP" appears on the display. Turn the ignition switch to OFF and disconnect the battery negative terminal. NOTE: Connecting the battery negative terminal automatically finishes the ship mode.
  2. REMOVE CONSOLE UPPER PANEL GARNISH REAR (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  3. REMOVE CONSOLE PANEL SUB-ASSY UPPER (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  4. REMOVE AIR CONDITIONER CONTROL ASSY (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  5. REMOVE INSTRUMENT CLUSTER FINISH PANEL SUB-ASSY LOWER CENTER Remove the 4 bolts. Disconnect the connector, then remove the radio receiver assy and instrument cluster finish panel sub-assy lower center.
  6. SHIP MODE CONFIRMATION See the back side of the radio receiver assy and check that the window provided for mode checking is red. NOTE: If not, perform the ship mode setting again.
  7. REMOVE RADIO RECEIVER ASSY Remove the 4 screws and 2 instrument panel finish panel retainers. Remove the 4 bolts at each side. Press the claw shown in the illustration to disengage it is meshing and remove the instrument cluster finish panel sub-assy lower center. NOTE: Pressing the claw hard breaks the claw. Remove the 2 screws and radio bracket No. 1. Remove the 2 screws and radio bracket No. 2.
  8. INSTALL INSTRUMENT CLUSTER FINISH PANEL SUB-ASSY LOWER CENTER Make sure that the battery negative terminal is disconnected. NOTE: For the radio receiver with CD changer, if the connector is installed with the battery connected, the system will start initializing operation. Vibration during initializing operation may cause trouble of the radio receiver assy.

HINT

COMPONENTS: See COMPONENTS

Scheme 66

Scheme 66: REPLACEMENT
Scheme 66: REPLACEMENT

Scheme 67

Scheme 67
Scheme 67

Scheme 68

Scheme 68
Scheme 68

Scheme 69

Scheme 69
Scheme 69
  1. REMOVE AIR CONDITIONER CONTROL ASSY (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  2. REMOVE INSTRUMENT PANEL SAFETY PAD GARNISH SUB-ASSY (W/ LEXUS NAVIGATION SYSTEM) (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  3. REMOVE INSTRUMENT PANEL GARNISH SUB-ASSY NO. 2 (W/ LEXUS NAVIGATION SYSTEM) (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  4. REMOVE INSTRUMENT CLUSTER FINISH PANEL SUB-ASSY CENTER (W/ LEXUS NAVIGATION SYSTEM) Remove the 2 bolts and 2 screws. Disconnect the connector, then remove the multi-display (CRT DISPLAY ) display and instrument cluster finish panel sub-assy center and clip.
  5. REMOVE MULTI-DISPLAY (CRT DISPLAY) DISPLAY Remove the 4 screws and instrument panel finish UPR panel. Remove the 6 screws and instrument panel finish panel No. 1 retainer. Remove the 5 screws and instrument panel finish panel No. 2 retainer. Remove the instrument cluster finish CTR LWR panel. Remove the 2 screws. Remove the 2 screws and wiring harness clamp. Disconnect the 4 connectors, then remove the clamp. Remove the multi-display (CRT DISPLAY) display.

HINT

COMPONENTS: See COMPONENTS

Scheme 70

Scheme 70: REPLACEMENT
Scheme 70: REPLACEMENT

Scheme 71

Scheme 71
Scheme 71

Scheme 72

Scheme 72
Scheme 72
  1. REMOVE REAR FLOOR FINISH PLATE (See «LUGGAGE COMPARTMENT DOOR»(ref-211406) )
  2. REMOVE LUGGAGE COMPARTMENT FLOOR MAT (See «LUGGAGE COMPARTMENT DOOR»(ref-211406) )
  3. REMOVE LUGGAGE COMPARTMENT TRIM COVER LH (See «LUGGAGE COMPARTMENT DOOR»(ref-211406) )
  4. REMOVE LUGGAGE COMPARTMENT TRIM COVER RH (See «LUGGAGE COMPARTMENT DOOR»(ref-211406) )
  5. REMOVE SPARE WHEEL COVER ASSY (See «LUGGAGE COMPARTMENT DOOR»(ref-211406) )
  6. REMOVE TOOL BOX COVER (See «LUGGAGE COMPARTMENT DOOR»(ref-211406) )
  7. REMOVE LUGGAGE COMPARTMENT TRIM COVER SUB-ASSY REAR (See «LUGGAGE COMPARTMENT DOOR»(ref-211406) )
  8. REMOVE TONNEAU COVER ASSY (See «LUGGAGE COMPARTMENT DOOR»(ref-211406) )
  9. REMOVE LUGGAGE COMPARTMENT TRIM COVER FRONT (See «LUGGAGE COMPARTMENT DOOR»(ref-211406) )
  10. REMOVE LUGGAGE COMPARTMENT TRAY BRACKET FRONT Remove the 2 bolts, 2 nuts and 2 luggage compartment tray bracket fronts.
  11. REMOVE NAVIGATION ECU Remove the bolt and 2 nuts. Disconnect the 3 connectors, then remove the navigation ECU.
  12. REMOVE DISC PLAYER BRACKET Remove the 2 screws and disc player bracket.
  13. REMOVE DISC PLAYER BRACKET NO. 2 Remove the 2 screws and disc player bracket No. 2.

HINT

COMPONENTS: See COMPONENTS

Scheme 73

Scheme 73: REPLACEMENT
Scheme 73: REPLACEMENT

Scheme 74

Scheme 74
Scheme 74

Scheme 75

Scheme 75
Scheme 75

Scheme 76

Scheme 76
Scheme 76
  1. REMOVE REAR FLOOR FINISH PLATE (See «LUGGAGE COMPARTMENT DOOR»(ref-211406) )
  2. REMOVE LUGGAGE COMPARTMENT FLOOR MAT (See «LUGGAGE COMPARTMENT DOOR»(ref-211406) )
  3. REMOVE LUGGAGE COMPARTMENT TRIM COVER LH (See «LUGGAGE COMPARTMENT DOOR»(ref-211406) )
  4. REMOVE LUGGAGE COMPARTMENT TRIM COVER RH (See «LUGGAGE COMPARTMENT DOOR»(ref-211406) )
  5. REMOVE SPARE WHEEL COVER ASSY (See «LUGGAGE COMPARTMENT DOOR»(ref-211406) )
  6. REMOVE TOOL BOX COVER (See «LUGGAGE COMPARTMENT DOOR»(ref-211406) )
  7. REMOVE LUGGAGE COMPARTMENT TRIM COVER SUB-ASSY REAR (See «LUGGAGE COMPARTMENT DOOR»(ref-211406) )
  8. REMOVE TONNEAU COVER ASSY (See «LUGGAGE COMPARTMENT DOOR»(ref-211406) )
  9. REMOVE LUGGAGE COMPARTMENT TRIM COVER INNER LOWER (See «LUGGAGE COMPARTMENT DOOR»(ref-211406) )
  10. REMOVE LUGGAGE COMPARTMENT FLOOR MAT Remove the 2 bolts, 2 nuts and 2 luggage compartment tray bracket fronts.
  11. REMOVE STEREO COMPONENT AMPLIFIER ASSY Remove the 2 bolts and nut. Disconnect the 2 connectors, then remove the stereo component amplifier assy.
  12. REMOVE AMPLIFIER BRACKET NO. 1 Remove the 2 screws and amplifier bracket No. 1.
  13. REMOVE AMPLIFIER BRACKET NO. 2 Remove the 2 screws and amplifier bracket No. 2.

HINT

COMPONENTS: See COMPONENTS

Scheme 77

Scheme 77: REPLACEMENT
Scheme 77: REPLACEMENT
  1. REMOVE POWER WINDOW REGULATOR MASTER SWITCH ASSY (See «OVERHAUL»(ref-211403-S27710106342005121700000) )
  2. REMOVE DOOR INSIDE HANDLE BEZEL NO. 2 LH (See «OVERHAUL»(ref-211403-S27710106342005121700000) )
  3. REMOVE FRONT DOOR WINDOW UPPER BRACKET GARNISH LH (See «OVERHAUL»(ref-211403-S27710106342005121700000) )
  4. REMOVE FRONT DOOR TRIM BOARD SUB-ASSY LH (See «OVERHAUL»(ref-211403-S27710106342005121700000) )
  5. REMOVE FRONT NO. 1 SPEAKER ASSY Disconnect the connector. Remove the bolt and front No. 1 speaker assy.

HINT

COMPONENTS: See COMPONENTS

Scheme 78

Scheme 78: REPLACEMENT
Scheme 78: REPLACEMENT
  1. REMOVE POWER WINDOW REGULATOR MASTER SWITCH ASSY (See «OVERHAUL»(ref-211403-S27710106342005121700000) )
  2. REMOVE DOOR INSIDE HANDLE BEZEL NO. 2 LH (See «OVERHAUL»(ref-211403-S27710106342005121700000) )
  3. REMOVE FRONT DOOR WINDOW UPPER BRACKET GARNISH LH (See «OVERHAUL»(ref-211403-S27710106342005121700000) )
  4. REMOVE FRONT DOOR TRIM BOARD SUB-ASSY LH (See «OVERHAUL»(ref-211403-S27710106342005121700000) )
  5. REMOVE FRONT NO. 2 SPEAKER ASSY Disconnect the 2 connectors. Remove the 2 screws and front No. 2 speaker assy.

HINT

COMPONENTS: See COMPONENTS

Scheme 79

Scheme 79: REPLACEMENT
Scheme 79: REPLACEMENT
  1. REMOVE POWER WINDOW REGULATOR MASTER SWITCH ASSY (See «OVERHAUL»(ref-211403-S27710106342005121700000) )
  2. REMOVE DOOR INSIDE HANDLE BEZEL NO. 2 LH (See «OVERHAUL»(ref-211403-S27710106342005121700000) )
  3. REMOVE FRONT DOOR WINDOW UPPER BRACKET GARNISH LH (See «OVERHAUL»(ref-211403-S27710106342005121700000) )
  4. REMOVE FRONT DOOR TRIM BOARD SUB-ASSY LH (See «OVERHAUL»(ref-211403-S27710106342005121700000) )
  5. REMOVE STEREO COMPONENT SPEAKER ASSY Disconnect the connector. Remove the 4 screws and stereo component speaker assy.

HINT

COMPONENTS: See COMPONENTS

Scheme 80

Scheme 80: REPLACEMENT
Scheme 80: REPLACEMENT
  1. REMOVE REAR SEAT CUSHION ASSY (See «OVERHAUL»(ref-211395-S00184599702005121700000) )
  2. REMOVE REAR SEAT HEADREST PLATE COVER (See «OVERHAUL»(ref-211395-S00184599702005121700000) )
  3. REMOVE WIND DEFLECTOR BOARD ASSY (See «OVERHAUL»(ref-211395-S00184599702005121700000) )
  4. REMOVE REAR SEAT HEADREST PLATE (See «OVERHAUL»(ref-211395-S00184599702005121700000) )
  5. REMOVE REAR SEAT HEADREST ASSY (See «OVERHAUL»(ref-211395-S00184599702005121700000) )
  6. REMOVE REAR SEAT BACK ASSY (See «OVERHAUL»(ref-211395-S00184599702005121700000) )
  7. REMOVE DOOR SCUFF PLATE ASSY LH (See «REPLACEMENT»(ref-211378-S29095997512005121700000) )
  8. REMOVE QUARTER TRIM PANEL ASSY FRONT LH (See «REPLACEMENT»(ref-211378-S29095997512005121700000) )
  9. REMOVE REAR SPEAKER ASSY Disconnect the connector. Remove the clamp. Remove the 3 screws and rear speaker assy.
  10. INSTALL REAR SEAT BACK ASSY (See «OVERHAUL»(ref-211395-S00184599702005121700000) )

HINT

COMPONENTS: See COMPONENTS

Scheme 81

Scheme 81: REPLACEMENT
Scheme 81: REPLACEMENT
  1. REMOVE REAR SEAT CUSHION ASSY (See «OVERHAUL»(ref-211395-S00184599702005121700000) )
  2. REMOVE REAR SEAT HEADREST PLATE COVER (See «OVERHAUL»(ref-211395-S00184599702005121700000) )
  3. REMOVE WIND DEFLECTOR BOARD ASSY (See «OVERHAUL»(ref-211395-S00184599702005121700000) )
  4. REMOVE REAR SEAT HEADREST PLATE (See «OVERHAUL»(ref-211395-S00184599702005121700000) )
  5. REMOVE REAR SEAT HEADREST ASSY (See «OVERHAUL»(ref-211395-S00184599702005121700000) )
  6. REMOVE REAR SEAT BACK ASSY (See «OVERHAUL»(ref-211395-S00184599702005121700000) )
  7. REMOVE REAR SPEAKER ASSY NO. 2 Disconnect the connector. Remove the 4 screws and rear speaker assy No. 2.
  8. INSTALL REAR SEAT BACK ASSY (See «OVERHAUL»(ref-211395-S00184599702005121700000) )

HINT

COMPONENTS: See COMPONENTS

Scheme 82

Scheme 82: REPLACEMENT
Scheme 82: REPLACEMENT

Scheme 83

Scheme 83
Scheme 83

Scheme 84

Scheme 84
Scheme 84
  1. TABLE OF BOLT,SCREW AND NUT (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  2. SHIP MODE SETTING (See «RADIO RECEIVER ASSY»(ref-234323-S19933089242006060800000) )
  3. SEPARATE BATTERY NEGATIVE TERMINAL (See «OVERHAUL»(ref-183295-S20392964432005081300000) )
  4. INSPECT CENTER FRONT WHEEL (See «OVERHAUL»(ref-183295-S20392964432005081300000) )
  5. REMOVE STEERING WHEEL COVER LOWER NO. 2 (See «OVERHAUL»(ref-183295-S20392964432005081300000) )
  6. REMOVE SWITCH & VOLUME CASE (See «REPLACEMENT»(ref-183312-S10376286562005081300000) )
  7. REMOVE STEERING PAD SWITCH MODULATOR (See «REPLACEMENT»(ref-183312-S10376286562005081300000) )
  8. REMOVE HORN BUTTON ASSY (See «OVERHAUL»(ref-183295-S20392964432005081300000) )
  9. REMOVE STEERING WHEEL ASSY (See «OVERHAUL»(ref-183295-S20392964432005081300000) ) SST 09950-50013 (09951-05010, 09952-05010, 09953-05020, 09954-05021)
  10. REMOVE DOOR SCUFF PLATE ASSY RH (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  11. REMOVE DOOR SCUFF PLATE ASSY LH (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  12. REMOVE FRONT DOOR OPENING TRIM COVER RH (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  13. REMOVE FRONT DOOR OPENING TRIM COVER LH (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  14. REMOVE INSTRUMENT PANEL SAFETY PAD SUB-ASSY NO. 1 (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  15. REMOVE INSTRUMENT CLUSTER FINISH PANEL SUB-ASSY (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  16. REMOVE STEERING COLUMN COVER LWR (See «OVERHAUL»(ref-183295-S20392964432005081300000) )
  17. REMOVE STEERING COLUMN COVER UPR (See «OVERHAUL»(ref-183295-S20392964432005081300000) )
  18. REMOVE TURN SIGNAL SWITCH ASSY (See «REPLACEMENT»(ref-234324-S41075015482006060800000) )
  19. REMOVE COMBINATION METER ASSY (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  20. REMOVE CONSOLE UPPER PANEL GARNISH REAR (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  21. REMOVE CONSOLE PANEL SUB-ASSY UPPER (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  22. REMOVE AIR CONDITIONER CONTROL ASSY (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  23. REMOVE INSTRUMENT CLUSTER FINISH PANEL SUB-ASSY LOWER CENTER (See «RADIO RECEIVER ASSY»(ref-234323-S19933089242006060800000) )
  24. SHIP MODE CONFIRMATION (See «RADIO RECEIVER ASSY»(ref-234323-S19933089242006060800000) )
  25. REMOVE INSTRUMENT PANEL SAFETY PAD GARNISH SUB-ASSY(W/O LEXUS NAVIGATION SYSTEM) (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  26. REMOVE INSTRUMENT PANEL SAFETY PAD GARNISH SUB-ASSY(W/ LEXUS NAVIGATION SYSTEM) (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  27. REMOVE INSTRUMENT PANEL GARNISH SUB-ASSY NO.2(W/ LEXUS NAVIGATION SYSTEM) (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  28. REMOVE INSTRUMENT CLUSTER FINISH PANEL SUB-ASSY CENTER (W/ LEXUS NAVIGATION SYSTEM) (See «MULTI-DISPLAY (CRT DISPLAY) DISPLAY»(ref-234323-S28087172972006060800000) )
  29. REMOVE INSTRUMENT PANEL UNDER COVER SUB-ASSY NO. 2 (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  30. REMOVE GLOVE COMPARTMENT DOOR ASSY (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  31. REMOVE CONSOLE BOX CARPET (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  32. REMOVE BOX PANEL NO. 3 (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  33. REMOVE CONSOLE BOX ASSY (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  34. REMOVE INSTRUMENT PANEL BRACE SUB-ASSY NO. 2 (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  35. REMOVE INSTRUMENT PANEL BRACE SUB-ASSY NO. 1 (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  36. REMOVE FRONT PILLAR GARNISH RH (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  37. REMOVE FRONT PILLAR GARNISH LH (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  38. REMOVE INSTRUMENT SIDE PANEL RH (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  39. REMOVE INSTRUMENT PANEL SAFETY PAD SUB-ASSY (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  40. REMOVE FR WIPER ARM RH (See «REPLACEMENT»(ref-183299-S15763306502005081300000) )
  41. REMOVE FR WIPER ARM LH (See «REPLACEMENT»(ref-183299-S15763306502005081300000) )
  42. REMOVE COWL TOP VENTILATOR LOUVER SUB-ASSY (See «REPLACEMENT»(ref-183299-S15763306502005081300000) )
  43. REMOVE ANTENNA CORD SUB-ASSY Disconnect the connector. Remove the 3 clamps. Remove the 2 nuts and antenna cord sub-assy.
  44. INSTALL FR WIPER ARM LH (See «REPLACEMENT»(ref-183299-S15763306502005081300000) )
  45. INSTALL FR WIPER ARM RH (See «REPLACEMENT»(ref-183299-S15763306502005081300000) )
  46. INSTALL INSTRUMENT PANEL SAFETY PAD SUB-ASSY (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  47. INSTALL INSTRUMENT PANEL BRACE SUB-ASSY NO. 2 (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  48. INSTALL INSTRUMENT PANEL BRACE SUB-ASSY NO. 1 (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  49. INSTALL CONSOLE BOX ASSY (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  50. CENTER SPIRAL CABLE (See «OVERHAUL»(ref-183295-S20392964432005081300000) )
  51. INSTALL STEERING WHEEL ASSY (See «OVERHAUL»(ref-183295-S20392964432005081300000) )
  52. INSPECT STEERING WHEEL CENTER POINT (See «OVERHAUL»(ref-183295-S20392964432005081300000) )
  53. INSPECT HORN BUTTON ASSY (See «OVERHAUL»(ref-183295-S20392964432005081300000) )
  54. INSTALL HORN BUTTON ASSY (See «OVERHAUL»(ref-183295-S20392964432005081300000) )
  55. INSPECT SRS WARNING LIGHT (See «SYSTEM OPERATION CHECK»(ref-160422-S23416595242004021000000) )

HINT

COMPONENTS: See COMPONENTS

Scheme 85

Scheme 85: REPLACEMENT
Scheme 85: REPLACEMENT

Scheme 86

Scheme 86
Scheme 86
  1. REMOVE CONSOLE UPPER PANEL GARNISH REAR (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  2. REMOVE CONSOLE PANEL SUB-ASSY UPPER (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  3. REMOVE AIR CONDITIONER CONTROL ASSY (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  4. REMOVE INSTRUMENT CLUSTER FINISH PANEL SUB-ASSY LOWER CENTER (See «RADIO RECEIVER ASSY»(ref-234323-S19933089242006060800000) )
  5. REMOVE CONSOLE BOX CARPET (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  6. REMOVE BOX PANEL NO. 3 (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  7. REMOVE CONSOLE BOX ASSY (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  8. REMOVE REAR SEAT CUSHION ASSY (See «OVERHAUL»(ref-211395-S00184599702005121700000) )
  9. REMOVE REAR SEAT HEADREST PLATE COVER (See «OVERHAUL»(ref-211395-S00184599702005121700000) )
  10. REMOVE WIND DEFLECTOR BOARD ASSY (See «OVERHAUL»(ref-211395-S00184599702005121700000) )
  11. REMOVE REAR SEAT HEADREST PLATE (See «OVERHAUL»(ref-211395-S00184599702005121700000) )
  12. REMOVE REAR SEAT HEADREST ASSY (See «OVERHAUL»(ref-211395-S00184599702005121700000) )
  13. REMOVE REAR SEAT BACK ASSY (See «OVERHAUL»(ref-211395-S00184599702005121700000) )
  14. REMOVE TONNEAU COVER STOPPER SUB-ASSY RH (See «LUGGAGE COMPARTMENT DOOR»(ref-211406) )
  15. REMOVE REAR FLOOR FINISH PLATE (See «LUGGAGE COMPARTMENT DOOR»(ref-211406) )
  16. REMOVE LUGGAGE COMPARTMENT FLOOR MAT (See «LUGGAGE COMPARTMENT DOOR»(ref-211406) )
  17. REMOVE LUGGAGE COMPARTMENT TRIM COVER LH (See «LUGGAGE COMPARTMENT DOOR»(ref-211406) )
  18. REMOVE LUGGAGE COMPARTMENT TRIM COVER RH (See «LUGGAGE COMPARTMENT DOOR»(ref-211406) )
  19. REMOVE SPARE WHEEL COVER ASSY (See «LUGGAGE COMPARTMENT DOOR»(ref-211406) )
  20. REMOVE TOOL BOX COVER (See «LUGGAGE COMPARTMENT DOOR»(ref-211406) )
  21. REMOVE LUGGAGE COMPARTMENT TRIM COVER SUB-ASSY REAR (See «LUGGAGE COMPARTMENT DOOR»(ref-211406) )
  22. REMOVE TONNEAU COVER ASSY (See «LUGGAGE COMPARTMENT DOOR»(ref-211406) )
  23. REMOVE LUGGAGE COMPARTMENT TRIM COVER INNER LOWER (See «LUGGAGE COMPARTMENT DOOR»(ref-211406) )
  24. REMOVE LUGGAGE COMPARTMENT TRIM COVER FRONT (See «LUGGAGE COMPARTMENT DOOR»(ref-211406) )
  25. REMOVE LUGGAGE COMPARTMENT TRIM COVER SIDE RH (See «LUGGAGE COMPARTMENT DOOR»(ref-211406) )
  26. REMOVE ANTENNA CORD SUB-ASSY NO. 3 w/ LEXUS Navigation system: Disconnect the 4 connectors. w/o LEXUS Navigation system: Disconnect the 2 connectors. Remove the bolt. w/ LEXUS Navigation system: Remove the 14 clamps and antenna cord sub-assy No. 3. w/o LEXUS Navigation system: Remove the 13 clamps and antenna cord sub-assy No Hole punch has destroyed the text.
  27. INSTALL REAR SEAT BACK ASSY (See «OVERHAUL»(ref-211395-S00184599702005121700000) )

HINT

COMPONENTS: See COMPONENTS

  1. REMOVE TONNEAU COVER STOPPER SUB-ASSY RH (See «LUGGAGE COMPARTMENT DOOR»(ref-211406) )
  2. REMOVE REAR FLOOR FINISH PLATE (See «LUGGAGE COMPARTMENT DOOR»(ref-211406) )
  3. REMOVE LUGGAGE COMPARTMENT FLOOR MAT (See «LUGGAGE COMPARTMENT DOOR»(ref-211406) )
  4. REMOVE LUGGAGE COMPARTMENT TRIM COVER LH (See «LUGGAGE COMPARTMENT DOOR»(ref-211406) )
  5. REMOVE LUGGAGE COMPARTMENT TRIM COVER RH (See «LUGGAGE COMPARTMENT DOOR»(ref-211406) )
  6. REMOVE SPARE WHEEL COVER ASSY (See «LUGGAGE COMPARTMENT DOOR»(ref-211406) )
  7. REMOVE TOOL BOX COVER (See «LUGGAGE COMPARTMENT DOOR»(ref-211406) )
  8. REMOVE LUGGAGE COMPARTMENT TRIM COVER SUB-ASSY REAR (See «LUGGAGE COMPARTMENT DOOR»(ref-211406) )
  9. REMOVE TONNEAU COVER ASSY (See «LUGGAGE COMPARTMENT DOOR»(ref-211406) )
  10. REMOVE LUGGAGE COMPARTMENT TRIM COVER INNER LOWER (See «LUGGAGE COMPARTMENT DOOR»(ref-211406) )
  11. REMOVE LUGGAGE COMPARTMENT TRIM COVER FRONT (See «LUGGAGE COMPARTMENT DOOR»(ref-211406) )
  12. REMOVE LUGGAGE COMPARTMENT TRIM COVER SIDE RH (See «LUGGAGE COMPARTMENT DOOR»(ref-211406) )
  13. REMOVE W/HOLDER ANTENNA ASSY

Scheme 87

Scheme 87
Scheme 87

Scheme 88

Scheme 88
Scheme 88
  1. Remove the antenna nut and antenna ornament.
  2. Disconnect the connector and antenna cord plug from the w/ holder antenna assy.
  3. Remove the nut and w/ holder antenna assy.

Note. This procedure should be performed by 2 people.

Scheme 89

Scheme 89: REPLACEMENT
Scheme 89: REPLACEMENT

Scheme 90

Scheme 90
Scheme 90
  1. Turn the ignition switch to LOCK.
  2. Remove the antenna nut and antenna ornament of the antenna assembly.
  3. Press AM and DISC simultaneously and turn the ignition switch to ACC. The radio display will show ANT and the antenna mast will extend to its maximum length. 1 AM Switch 2 DISC Switch
  4. Once extended to the maximum length, pull the antenna mast out from the antenna assembly. Leave the ignition switch in ACC.
  5. Insert the replacement antenna mast into the antenna assembly until it reaches the bottom. HINT: Orient the teeth on the antenna mast cable towards the rear of the vehicle. 1 Antenna Mast Cable 2 Rear of Vehicle
  6. Turn the ignition switch to LOCK and allow for the antenna mast to retract fully. HINT: If the cable is not properly oriented, the antenna mast may not fully retract even though the motor works. In this case, perform steps 1, 3, 5, and 6 again.
  7. Install the antenna ornament.
  8. Tighten the antenna nut of the antenna assembly.
  9. Confirm that the antenna mast retracts and extends correctly.

HINT

COMPONENTS: See COMPONENTS

Scheme 91

Scheme 91: REPLACEMENT
Scheme 91: REPLACEMENT
  1. TABLE OF BOLT, SCREW AND NUT (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  2. SHIP MODE SETTING (See «RADIO RECEIVER ASSY»(ref-234323-S19933089242006060800000) )
  3. SEPARATE BATTERY NEGATIVE TERMINAL (See «OVERHAUL»(ref-183295-S20392964432005081300000) )
  4. INSPECT CENTER FRONT WHEEL (See «OVERHAUL»(ref-183295-S20392964432005081300000) )
  5. REMOVE STEERING WHEEL COVER LOWER NO. 2 (See «OVERHAUL»(ref-183295-S20392964432005081300000) )
  6. REMOVE SWITCH & VOLUME CASE (See «REPLACEMENT»(ref-183312-S10376286562005081300000) )
  7. REMOVE STEERING PAD SWITCH MODULATOR (See «REPLACEMENT»(ref-183312-S10376286562005081300000) )
  8. REMOVE HORN BUTTON ASSY (See «OVERHAUL»(ref-183295-S20392964432005081300000) )
  9. REMOVE STEERING WHEEL ASSY (See «OVERHAUL»(ref-183295-S20392964432005081300000) ) SST 09950-50013 (09951-05010, 09952-05010, 09953-05020, 09954-05021)
  10. REMOVE DOOR SCUFF PLATE ASSY RH (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  11. REMOVE DOOR SCUFF PLATE ASSY LH (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  12. REMOVE FRONT DOOR OPENING TRIM COVER RH (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  13. REMOVE FRONT DOOR OPENING TRIM COVER LH (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  14. REMOVE INSTRUMENT PANEL SAFETY PAD SUB-ASSY NO. 1 (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  15. REMOVE INSTRUMENT CLUSTER FINISH PANEL SUB-ASSY (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  16. REMOVE STEERING COLUMN COVER LWR (See «OVERHAUL»(ref-183295-S20392964432005081300000) )
  17. REMOVE STEERING COLUMN COVER UPR (See «OVERHAUL»(ref-183295-S20392964432005081300000) )
  18. REMOVE TURN SIGNAL SWITCH ASSY (See «REPLACEMENT»(ref-234324-S41075015482006060800000) )
  19. REMOVE COMBINATION METER ASSY (See «OVERHAUL»(ref-183301-S01719745132005081300000) )
  20. REMOVE CONSOLE UPPER PANEL GARNISH REAR (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  21. REMOVE CONSOLE PANEL SUB-ASSY UPPER (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  22. REMOVE AIR CONDITIONER CONTROL ASSY (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  23. REMOVE INSTRUMENT CLUSTER FINISH PANEL SUB-ASSY LOWER CENTER (See «RADIO RECEIVER ASSY»(ref-234323-S19933089242006060800000) )
  24. SHIP MODE CONFIRMATION (See «RADIO RECEIVER ASSY»(ref-234323-S19933089242006060800000) )
  25. REMOVE INSTRUMENT PANEL SAFETY PAD GARNISH SUB-ASSY (W/ LEXUS NAVIGATION SYSTEM) (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  26. REMOVE INSTRUMENT PANEL GARNISH SUB-ASSY NO. 2 (W/ LEXUS NAVIGATION SYSTEM) (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  27. REMOVE INSTRUMENT CLUSTER FINISH PANEL SUB-ASSY CENTER (W/ LEXUS NAVIGATION SYSTEM) (See «MULTI-DISPLAY (CRT DISPLAY) DISPLAY»(ref-234323-S28087172972006060800000) )
  28. REMOVE INSTRUMENT PANEL UNDER COVER SUB-ASSY NO. 2 (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  29. REMOVE GLOVE COMPARTMENT DOOR ASSY (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  30. REMOVE CONSOLE BOX CARPET (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  31. REMOVE BOX PANEL NO. 3 (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  32. REMOVE CONSOLE BOX ASSY (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  33. REMOVE INSTRUMENT PANEL BRACE SUB-ASSY NO. 2 (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  34. REMOVE INSTRUMENT PANEL BRACE SUB-ASSY NO. 1 (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  35. REMOVE FRONT PILLAR GARNISH RH (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  36. REMOVE FRONT PILLAR GARNISH LH (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  37. REMOVE INSTRUMENT SIDE PANEL RH (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  38. REMOVE INSTRUMENT PANEL SAFETY PAD SUB-ASSY (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  39. REMOVE HEATER TO REGISTER DUCT NO. 4 (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  40. REMOVE STEERING COLUMN ASSY (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  41. REMOVE INSTRUMENT PANEL PIN NO. 1 (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  42. REMOVE DEFROSTER NOZZLE GARNISH NO. 1 (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  43. REMOVE SIDE DEFROSTER NOZZLE DUCT NO. 1 (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  44. REMOVE SIDE DEFROSTER NOZZLE DUCT NO. 2 (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  45. REMOVE DEFROSTER NOZZLE FRONT (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  46. REMOVE HEATER TO REGISTER DUCT NO. 1 (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  47. REMOVE HEATER TO REGISTER DUCT NO. 3 (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  48. REMOVE HEATER TO REGISTER DUCT NO. 2(See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  49. REMOVE INSTRUMENT PANEL REINFORCEMENT (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  50. REMOVE NAVIGATION ANTENNA ASSY Remove the 2 clamps. Remove the 2 screws and navigation antenna assy.
  51. INSTALL INSTRUMENT PANEL REINFORCEMENT (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  52. INSTALL STEERING COLUMN ASSY (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  53. INSTALL INSTRUMENT PANEL SAFETY PAD SUB-ASSY (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  54. INSTALL INSTRUMENT PANEL BRACE SUB-ASSY NO. 2 (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  55. INSTALL INSTRUMENT PANEL BRACE SUB-ASSY NO. 1 (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  56. INSTALL CONSOLE BOX ASSY (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  57. CENTER SPIRAL CABLE (See «OVERHAUL»(ref-183295-S20392964432005081300000) )
  58. INSTALL STEERING WHEEL ASSY (See «OVERHAUL»(ref-183295-S20392964432005081300000) )
  59. INSPECT STEERING WHEEL CENTER POINT (See «OVERHAUL»(ref-183295-S20392964432005081300000) )
  60. INSPECT HORN BUTTON ASSY (See «OVERHAUL»(ref-183295-S20392964432005081300000) )
  61. INSTALL HORN BUTTON ASSY (See «OVERHAUL»(ref-183295-S20392964432005081300000) )
  62. INSPECT SRS WARNING LIGHT (See «SYSTEM OPERATION CHECK»(ref-160422-S23416595242004021000000) )

HINT

COMPONENTS: See COMPONENTS

Scheme 92

Scheme 92: REPLACEMENT
Scheme 92: REPLACEMENT
  1. TABLE OF BOLT, SCREW AND NUT (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  2. SHIP MODE SETTING (See «RADIO RECEIVER ASSY»(ref-234323-S19933089242006060800000) )
  3. SEPARATE BATTERY NEGATIVE TERMINAL (See «OVERHAUL»(ref-183295-S20392964432005081300000) )
  4. INSPECT CENTER FRONT WHEEL (See «OVERHAUL»(ref-183295-S20392964432005081300000) )
  5. REMOVE STEERING WHEEL COVER LOWER NO. 2 (See «OVERHAUL»(ref-183295-S20392964432005081300000) )
  6. REMOVE SWITCH & VOLUME CASE (See «REPLACEMENT»(ref-183312-S10376286562005081300000) )
  7. REMOVE STEERING PAD SWITCH MODULATOR (See «REPLACEMENT»(ref-183312-S10376286562005081300000) )
  8. REMOVE HORN BUTTON ASSY (See «OVERHAUL»(ref-183295-S20392964432005081300000) )
  9. REMOVE STEERING WHEEL ASSY (See «OVERHAUL»(ref-183295-S20392964432005081300000) ) SST 09950-50013 (09951-05010, 09952-05010,09953-05020, 09954-05021)
  10. REMOVE DOOR SCUFF PLATE ASSY RH (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  11. REMOVE DOOR SCUFF PLATE ASSY LH (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  12. REMOVE FRONT DOOR OPENING TRIM COVER RH (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  13. REMOVE FRONT DOOR OPENING TRIM COVER LH (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  14. REMOVE INSTRUMENT PANEL SAFETY PAD SUB-ASSY NO. 1 (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  15. REMOVE INSTRUMENT CLUSTER FINISH PANEL SUB-ASSY (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  16. REMOVE STEERING COLUMN COVER LWR (See «OVERHAUL»(ref-183295-S20392964432005081300000) )
  17. REMOVE STEERING COLUMN COVER UPR (See «OVERHAUL»(ref-183295-S20392964432005081300000) )
  18. REMOVE TURN SIGNAL SWITCH ASSY (See «REPLACEMENT»(ref-234324-S41075015482006060800000) )
  19. REMOVE COMBINATION METER ASSY (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  20. REMOVE CONSOLE UPPER PANEL GARNISH REAR (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  21. REMOVE CONSOLE PANEL SUB-ASSY UPPER (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  22. REMOVE AIR CONDITIONER CONTROL ASSY (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  23. REMOVE INSTRUMENT CLUSTER FINISH PANEL SUB-ASSY LOWER CENTER (See «RADIO RECEIVER ASSY»(ref-234323-S19933089242006060800000) )
  24. SHIP MODE CONFIRMATION (See «RADIO RECEIVER ASSY»(ref-234323-S19933089242006060800000) )
  25. REMOVE INSTRUMENT PANEL SAFETY PAD GARNISH SUB-ASSY (W/O LEXUS NAVIGATION SYSTEM) (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  26. REMOVE INSTRUMENT PANEL SAFETY PAD GARNISH SUB-ASSY (W/ LEXUS NAVIGATION SYSTEM) (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  27. REMOVE INSTRUMENT PANEL GARNISH SUB-ASSY NO. 2 (W/ LEXUS NAVIGATION SYSTEM) (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  28. REMOVE INSTRUMENT CLUSTER FINISH PANEL SUB-ASSY CENTER (W/ LEXUS NAVIGATION SYSTEM) (See «MULTI-DISPLAY (CRT DISPLAY) DISPLAY»(ref-234323-S28087172972006060800000) )
  29. REMOVE INSTRUMENT PANEL UNDER COVER SUB-ASSY NO. 2 (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  30. REMOVE GLOVE COMPARTMENT DOOR ASSY (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  31. REMOVE CONSOLE BOX CARPET (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  32. REMOVE BOX PANEL NO. 3 (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  33. REMOVE CONSOLE BOX ASSY (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  34. REMOVE INSTRUMENT PANEL BRACE SUB-ASSY NO. 2 (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  35. REMOVE INSTRUMENT PANEL BRACE SUB-ASSY NO. 1 (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  36. REMOVE FRONT PILLAR GARNISH RH (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  37. REMOVE FRONT PILLAR GARNISH LH (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  38. REMOVE INSTRUMENT SIDE PANEL RH (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  39. REMOVE INSTRUMENT PANEL SAFETY PAD SUB-ASSY (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  40. REMOVE HEATER TO REGISTER DUCT NO. 4 (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  41. REMOVE STEERING COLUMN ASSY (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  42. REMOVE INSTRUMENT PANEL PIN NO. 1 (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  43. REMOVE DEFROSTER NOZZLE GARNISH NO. 1 (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  44. REMOVE SIDE DEFROSTER NOZZLE DUCT NO. 1 (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  45. REMOVE SIDE DEFROSTER NOZZLE DUCT NO. 2 (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  46. REMOVE DEFROSTER NOZZLE FRONT (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  47. REMOVE HEATER TO REGISTER DUCT NO. 1 (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  48. REMOVE HEATER TO REGISTER DUCT NO. 3 (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  49. REMOVE HEATER TO REGISTER DUCT NO. 2 (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  50. REMOVE INSTRUMENT PANEL REINFORCEMENT (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  51. REMOVE NETWORK GATEWAY ECU Remove the 2 screws and network gateway ECU.
  52. INSTALL INSTRUMENT PANEL REINFORCEMENT (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  53. INSTALL STEERING COLUMN ASSY (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  54. INSTALL INSTRUMENT PANEL SAFETY PAD SUB-ASSY (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  55. INSTALL INSTRUMENT PANEL BRACE SUB-ASSY NO. 2 (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  56. INSTALL INSTRUMENT PANEL BRACE SUB-ASSY NO. 1 (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  57. INSTALL CONSOLE BOX ASSY (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  58. CENTER SPIRAL CABLE (See «OVERHAUL»(ref-183295-S20392964432005081300000) )
  59. INSTALL STEERING WHEEL ASSY (See «OVERHAUL»(ref-183295-S20392964432005081300000) )
  60. INSPECT STEERING WHEEL CENTER POINT (See «OVERHAUL»(ref-183295-S20392964432005081300000) )
  61. INSPECT HORN BUTTON ASSY (See «OVERHAUL»(ref-183295-S20392964432005081300000) )
  62. INSTALL HORN BUTTON ASSY (See «OVERHAUL»(ref-183295-S20392964432005081300000) )
  63. INSPECT SRS WARNING LIGHT (See «SYSTEM OPERATION CHECK»(ref-160422-S23416595242004021000000) )

HINT

COMPONENTS: See COMPONENTS

Scheme 93

Scheme 93: REPLACEMENT
Scheme 93: REPLACEMENT
  1. REMOVE CONSOLE UPPER PANEL GARNISH REAR (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  2. REMOVE CONSOLE PANEL SUB-ASSY UPPER (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  3. REMOVE CIGARETTE LIGHTER ASSY Rotate the socket cap counterclockwise to remove it. Remove the cigarette lighter assy from the cigar-lighter hole bezel.
  4. INSTALL CIGARETTE LIGHTER ASSY
  1. Properly position the socket and ring at the cutout of the cigar-lighter hole bezel and insert them.
  2. Rotate the socket cap clockwise from the backside.

HINT

COMPONENTS: See COMPONENTS

Scheme 94

Scheme 94: REPLACEMENT
Scheme 94: REPLACEMENT
  1. REMOVE CONSOLE UPPER PANEL GARNISH REAR (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  2. REMOVE CONSOLE PANEL SUB-ASSY UPPER (See «REPLACEMENT»(ref-183301-S32999087612005081300000) )
  3. REMOVE POWER POINT SOCKET ASSY Pressing the claw of the power point socket assy in the direction of the arrow, push the power point socket assy toward the inside of the chamber and remove it.
  4. REMOVE POWER POINT SOCKET COVER Remove the power point socket cover from the console box assy.
  5. INSTALL POWER POINT SOCKET ASSY
  1. Align the claw of the power point socket assy with the cutout of the power point cover and fully Hole punch has destroyed the text it to install.

Scheme 95

Scheme 95: REPAIR
Scheme 95: REPAIR

Scheme 96

Scheme 96
Scheme 96
  1. INSPECT WINDOW GLASS (ANTENNA WIRE) NOTE: When cleaning the glass, use a soft, dry cloth, and wiper the glass in the direction of the wire. Take care not to damage the wires. Do not use detergents or glass cleaners with abrasive ingredients. When measuring voltage, wind a piece of tin foil around the top of the negative probe and press the foil against the wire with your finger, as shown in the illustration. Inspect the continuity, at the center of each antenna wire, as shown in the illustration.
  2. REPAIR WINDOW GLASS (ANTENNA WIRE)

Scheme 97

Scheme 97
Scheme 97

Scheme 98

Scheme 98
Scheme 98
  1. Clean the broken wire tips with a grease, wax and silicone remover.
  2. Place the masking tape along both sides of the wire to be repaired.
  3. Thoroughly mix the repair agent (DuPont paste No. 4817).
  4. Using a fine tip brush, apply a small amount to the wire.
  5. After a few minutes, remove the masking tape.
  6. Do not repair the defogger wire for at least 24 hours.

MEMO

More articles — Audio & Visual System
