Test Procedure No. 1
- Continuity should exist between terminals No. 1 and 2.
- Continuity should not exist between terminals No. 3 and 5.
- Apply battery voltage across terminals No. 1 and 2. Continuity should exist between terminals No. 3 and 5.
Test Procedure No. 2
- Continuity should exist between terminals ST and E1, and between terminals +B and FC.
- Continuity should not exist between terminals +B and FP.
- Apply battery voltage across terminals ST and E1. Continuity should exist between terminals +B and FP.
Test Procedure No. 3
- Continuity should exist between terminals No. 1 and 3.
- Continuity should not exist between terminals No. 2 and 4.
- Apply battery voltage across terminals No. 1 and 3. Continuity should exist between terminals No. 2 and 4.
Test Procedure No. 4
- Continuity should exist between terminals No. 1 and 2.
- Continuity should not exist between terminals No. 3 and 4.
- Apply battery voltage across terminals No. 1 and 2. Continuity should exist between terminals No. 3 and 4.
| Application | (1) Relay Type | Test Procedure No. |
| EFI Main | 4 | 3 |
| Starter | 1 | 1 |
| (1) (Scheme 13)-21. |
RELAY TYPE & TEST PROCEDURE NUMBER
Scheme 13
Scheme 14
Scheme 15
Scheme 16
Scheme 17
