TORQUE SPECIFICATIONS ES300
| Part tightened | N.m | Kgf.cm | Ft.lb |
|---|---|---|---|
| Bearing retainer x Drive end frame | 2.6 | 27 | 23 in.lb |
| Rectifier end frame x Drive end frame | 4.5 | 46 | 40 in.lb |
| Cord clamp x Rectifier end frame | 4.5 | 46 | 40 in.lb |
| Generator pulley x Rotor | 110 | 1,125 | 81 |
| Rectifier holder x Coil lead on rectifier end frame | 3.06 | 31 | 27 in.lb |
| Voltage regulator and brush holder x Rectifier end frame | 2.04 | 21 | 18 in.lb |
| Plate terminal x Rectifier holder | 3.82 | 39 | 34 in.lb |
| Rear end cover x Rectifier holder | 4.5 | 46 | 40 in.lb |
| Terminal insulator x Rectifier holder | 4.1 | 41.5 | 36 in.lb |
| Generator x Generator bracket | 56 | 570 | 41 |
| Generator x Adjusting bar | 18 | 180 | 13 |
TORQUE SPECIFICATIONS ES300
TORQUE SPECIFICATIONS SC300 & SC400
| Part tightened | N.m | Kgf.cm | Ft.lb |
|---|---|---|---|
| Rectifier end frame x Drive end frame | 4.5 | 46 | 40 in.lb |
| Generator pulley x Rotor | 110 | 1,125 | 81 |
| Rectifier holder x Coil lead on rectifier end frame | 2.94 | 29 | 26 in.lb |
| Plate terminal x Rectifier holder | 3.82 | 39 | 34 in.lb |
| Rear end cover x Rectifier holder | 4.5 | 46 | 40 in.lb |
| Terminal insulator x Rectifier holder | 6.5 | 66 | 58 in.lb |
| Generator x Water pump | 37 | 380 | 27 |
| Generator x Cylinder block | 37 | 380 | 27 |
TORQUE SPECIFICATIONS SC300 & SC400
