Navigation — Navigation circuit Lexus RX IV

Components on these wiring diagrams 45

Click a component to highlight it on every diagram it appears on.

• Antenna
• Can Cpu I/F
• Can L
• Combination Meter Assembly
• Computer Data
• Door Locks, Anti-Theft Systems
• Engine Room R/B2
• Front Speaker Assembly 3
• GPS Antenna
• Instrument Panel J/B Assembly
• Instrument — Cluster
• Left Front Speaker Assembly 1
• Left Front Speaker Assembly 2
• Left Headphone Terminal
• Left Quarter Side Speaker Assembly
• Left Rear Speaker Assembly
• Left Rear Speaker Assembly 2
• Left Steering Pad Switch
• Left Television Display Assembly
• Multi- Display Assembly
• On Hook
• Parking Assist ECU
• Radio Receiver Assembly3
• Rear Speaker Assembly 3
• Rear Television Camera Assembly
• Remote Operation Controller
• Right End Of Dash
• Right Front Speaker Assembly 1
• Right Front Speaker Assembly 2
• Right Headphone Terminal
• Right Quarter Side Speaker Assembly
• Right Rear Speaker Assembly
• Right Rear Speaker Assembly 2
• Right Television Display Assembly
• Sdars Antenna
• Shield6
• Spiral Cable Sub-Assembly
• Steering Pad Switch Assembly
• Stereo Component Amplifier Assembly
• Stereo Jack Adapter Assembly 1
• System
• Telephone Microphone Assembly
• Television Switch, Volume Assembly
• W/O Enform
• W/O Enform W/ Enform 9 Speaker
