Starting System (Service Information): Overview Lexus RX III facelift

Starter 5 illustrations ~271 words

Scheme 18

Scheme 18: ILLUSTRATION
Scheme 18: ILLUSTRATION

Scheme 19

Scheme 19: ILLUSTRATION
Scheme 19: ILLUSTRATION

Scheme 20

Scheme 20: ILLUSTRATION
Scheme 20: ILLUSTRATION

Scheme 21

Scheme 21: REMOVAL [03/2012 - 07/2012]
Scheme 21: REMOVAL [03/2012 - 07/2012]

Scheme 22

Scheme 22
Scheme 22
  1. PRECAUTION NOTE: After turning the engine switch off, waiting time may be required before disconnecting the cable from the negative (-) battery terminal. Therefore, make sure to read the disconnecting the cable from the negative (-) battery terminal notices before proceeding with work. Refer to «PRECAUTION [03/2012 - ]»(ref-602551-S11461672722014030500000).
  2. REMOVE WINDSHIELD WIPER MOTOR AND LINK ASSEMBLY Remove the windshield wiper motor and link assembly. Refer to «REMOVAL [03/2012 - ]»(ref-602723-S18485877112014030500000).
  3. REMOVE OUTER COWL TOP PANEL SUB-ASSEMBLY. Refer to «REMOVAL [03/2012 - 07/2012] - Step 9»(ref-602687-S03816836542014030500000)
  4. REMOVE V-BANK COVER SUB-ASSEMBLY. Refer to «REMOVAL [03/2012 - 07/2012] - Step 33»(ref-602689-S14087581402014030500000)
  5. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL WARNING: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to disable the SRS system. Refer to «PRECAUTION [03/2012 - 07/2012]»(ref-602724-S22259792752014030500000). NOTE: When disconnecting the cable, some systems need to be initialized after the cable is reconnected. Refer to «INITIALIZATION [03/2012 - 07/2012]»(ref-602551-S24591545042014030500000).
  6. REMOVE NO. 2 AIR CLEANER INLET. Refer to «REMOVAL [03/2012 - 07/2012] - Step 34»(ref-602689-S14087581402014030500000)
  7. REMOVE NO. 1 AIR CLEANER INLET. Refer to «REMOVAL [03/2012 - 07/2012] - Step 35»(ref-602689-S14087581402014030500000)
  8. REMOVE BATTERY. Refer to «REMOVAL [03/2012 - 07/2012] - Step 36»(ref-602689-S14087581402014030500000)
  9. REMOVE AIR CLEANER ASSEMBLY. Refer to «REMOVAL [03/2012 - 07/2012] - Step 11»(ref-602706-S04937148982014030500000)
  10. REMOVE AIR CLEANER BRACKET. Refer to «REMOVAL [03/2012 - 07/2012] - Step 38»(ref-602689-S14087581402014030500000)
  11. REMOVE STARTER ASSEMBLY Disconnect the starter connector. Turn back the terminal cap, remove the nut and disconnect the starter wire. Remove the 2 bolts and starter.
