Transfer Case (Service Information): Overview Lexus RX III рестайлинг

Scheme 22

Scheme 23

1. INSPECT TRANSFER OIL Remove the No. 1 transfer case plug and gasket. Check that the oil level is between 0 and 5 mm (0 and 0.197 in.) from the bottom lip of the case plug hole. NOTE: When inspecting the transfer oil, make sure that the vehicle is level. An excessively large or small amount of oil may cause damage. After adding oil, drive the vehicle and recheck the oil level. Check for oil leakage if the oil level is low. Install a new gasket onto the No. 1 transfer case plug and then tighten the plug. Torque: 49 N*m (500 kgf*cm, 36 ft.*lbf)
2. ADJUST TRANSFER OIL Remove the No. 1 transfer case plug and gasket. Add oil until the oil level is between 0 and 5 mm (0 and 0.197 in.) from the bottom lip of the case plug hole. NOTE: When adding transfer oil, make sure that the vehicle is level. Add oil slowly, waiting several minutes between each addition. An excessively large or small amount of oil may cause damage. After adding oil, drive the vehicle and recheck the oil level. HINT: Oil grade API GL-5 Viscosity SAE 75W-85 Capacity 0.8 liters (0.8 US qts, 0.7 lmp.qts) After waiting for approximately 5 minutes, recheck the oil level. Install a new gasket onto the No. 1 transfer case plug and then tighten the plug. Torque: 49 N*m (500 kgf*cm, 36 ft.*lbf)

Scheme 24

Scheme 25

Scheme 26

1. REMOVE TRANSFER ASSEMBLY Refer to «REMOVAL [03/2012 - 07/2012]».
2. REMOVE TRANSFER CASE FRONT OIL SEAL Using SST, remove the transfer case front oil seal from the transfer case. SST: 09308-00010 NOTE: Do not damage the oil seal contact surface on the case.
3. INSTALL TRANSFER CASE FRONT OIL SEAL Using SST, drive in a new transfer case front oil seal into the transfer case until it reaches the position shown in the illustration. SST: 09608-10010 SST: 09950-70010 09951-07150 Drive in depth 9.5 to 10.5 mm (0.374 to 0.413 in.) NOTE: Do not tilt the oil seal during installation. Apply a small amount of MP grease to the lip of the oil seal.
4. INSTALL TRANSFER ASSEMBLY Refer to «INSTALLATION [03/2012 - 07/2012]».
