Towing Socket (Service Information): Removal & Installation Lexus RX III рестайлинг

INSTALLATION [03/2012 - ]

1. INSTALL TOWING SOCKET Install the towing socket with the 2 bolts. Torque: 3.9 N*m (40 kgf*cm, 35 in.*lbf) Engage the 4 clamps. Connect the connector.
2. INSTALL REAR BUMPER ASSEMBLY . Refer to «INSTALLATION [03/2012 - ] - Step 1»(ref-602726-S34703361162014030500000)
3. INSTALL NO. 2 LUGGAGE COMPARTMENT SIDE COVER PROTECTOR . Refer to «INSTALLATION [03/2012 - ] - Step 2»(ref-602726-S34703361162014030500000)
4. INSTALL NO. 1 LUGGAGE COMPARTMENT SIDE COVER PROTECTOR . Refer to «INSTALLATION [03/2012 - ] - Step 3»(ref-602726-S34703361162014030500000)

Scheme 5

Scheme 6

Scheme 7

Scheme 8

Scheme 9

1. INSPECT TOWING CONVERTER RELAY HINT: Remove interior parts so that the towing converter relay can be seen. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition 1 (CTLB) - Body ground Light control switch off Below 1 V Light control switch in the tail position 11 to 14 V 2 (CTLS) - Body ground Turn signal switch off Below 1 V Turn signal switch on (left turn) Below 1 V <----> 11 to 14 V Brake pedal depressed 11 to 14 V Turn signal switch on (left turn) during brake pedal depressed Below 1 V <----> 11 to 14 V 3 (CTLA) - Body ground Light control switch off Below 1 V Light control switch in the tail position 11 to 14 V 4 (TRNL) - Body ground Turn signal switch off Below 1 V Turn signal switch on (left turn) Below 1 V <----> 11 to 14 V 6 (CTRS) - Body ground Turn signal switch off Below 1 V Turn signal switch on (right turn) Below 1 V <----> 11 to 14 V Brake pedal depressed 11 to 14 V Turn signal switch on (right turn) during brake pedal depressed Below 1 V <----> 11 to 14 V 8 (COB1) - Body ground Always 11 to 14 V 9 (COS1) - Body ground Brake pedal not depressed Below 1 V Brake pedal depressed 11 to 14 V 10 (TRNR) - Body ground Turn signal switch off Below 1 V Turn signal switch on (right turn) Below 1 V <----> 11 to 14 V TEXT IN ILLUSTRATION *1 Component with harness connected (Towing Converter Relay) HINT: If the result is not as specified, repair or replace the harness or connector. Disconnect the towing converter relay connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition P23-5 (COZ1) - Body ground Always Below 1 ohms TEXT IN ILLUSTRATION *1 Front view of wire harness connector (to Towing Converter Relay) HINT: If the result is not as specified, replace the towing converter relay. Refer to «REMOVAL [03/2012 - ]»(ref-602858-S07064806932014030500000) .

Scheme 10

1. REMOVE TONNEAU COVER ASSEMBLY . Refer to «REMOVAL [03/2012 - ] - Step 23»(ref-602734-S11710244312014030500000)
2. REMOVE DECK BOARD SUB-ASSEMBLY . Refer to «REMOVAL [03/2012 - ] - Step 17»(ref-602734-S11710244312014030500000)
3. REMOVE SPARE WHEEL COVER ASSEMBLY (for Compact Spare Tire) . Refer to «REMOVAL [03/2012 - ] - Step 18»(ref-602734-S11710244312014030500000)
4. REMOVE NO. 3 REAR FLOOR BOARD (for Compact Spare Tire) . Refer to «REMOVAL [03/2012 - ] - Step 21»(ref-602734-S11710244312014030500000)
5. REMOVE NO. 3 REAR FLOOR BOARD (for Full Size Spare Tire) . Refer to «REMOVAL [03/2012 - ] - Step 22»(ref-602734-S11710244312014030500000)
6. REMOVE DECK SIDE TRIM BOX RH (for Compact Spare Tire) . Refer to «REMOVAL [03/2012 - ] - Step 27»(ref-602734-S11710244312014030500000)
7. REMOVE DECK SIDE TRIM BOX RH (for Full Size Spare Tire) . Refer to «REMOVAL [03/2012 - ] - Step 28»(ref-602734-S11710244312014030500000)
8. REMOVE REAR SEAT ASSEMBLY RH Remove the rear seat assembly RH. Refer to «REMOVAL [03/2012 - 07/2012]»(ref-602733-S23482647352014030500000) .
9. REMOVE REAR DOOR SCUFF PLATE RH HINT: Use the same procedure for the RH side and the LH side. Refer to «REMOVAL [03/2012 - ] - Step 5»(ref-602734-S11710244312014030500000) .
10. REMOVE REAR FLOOR FINISH PLATE . Refer to «REMOVAL [03/2012 - ] - Step 30»(ref-602734-S11710244312014030500000)
11. REMOVE REAR FLOOR FINISH SIDE PLATE RH HINT: Use the same procedure for the RH side and the LH side. Refer to «REMOVAL [03/2012 - ] - Step 31»(ref-602734-S11710244312014030500000) .
12. REMOVE REAR SEAT SIDE COVER RH HINT: Use the same procedure for the RH side and the LH side. Refer to «REMOVAL [03/2012 - ] - Step 33»(ref-602734-S11710244312014030500000) .
13. REMOVE NO. 1 LUGGAGE COMPARTMENT TRIM HOOK RH . Refer to «REMOVAL [03/2012 - ] - Step 43»(ref-602734-S11710244312014030500000)
14. REMOVE ROPE HOOK ASSEMBLY RH HINT: Use the same procedure for the RH side and the LH side. Refer to «REMOVAL [03/2012 - ] - Step 35»(ref-602734-S11710244312014030500000) .
15. REMOVE RECLINING REMOTE CONTROL BEZEL RH HINT: Use the same procedure for the RH side and the LH side. Refer to «REMOVAL [03/2012 - ] - Step 36»(ref-602734-S11710244312014030500000) .
16. REMOVE DECK TRIM SIDE PANEL ASSEMBLY RH . Refer to «REMOVAL [03/2012 - ] - Step 46»(ref-602734-S11710244312014030500000)
17. REMOVE TOWING CONVERTER RELAY Disconnect the connector. Remove the bolt and towing converter relay.

1. INSTALL TOWING CONVERTER RELAY Install the towing converter relay with the bolt. Connect the connector.
2. INSTALL DECK TRIM SIDE PANEL ASSEMBLY RH . Refer to «INSTALLATION [03/2012 - ] - Step 30»(ref-602734-S41277548442014030500000)
3. INSTALL RECLINING REMOTE CONTROL BEZEL RH HINT: Use the same procedure for the RH side and the LH side. Refer to «INSTALLATION [03/2012 - ] - Step 22»(ref-602734-S41277548442014030500000) .
4. INSTALL ROPE HOOK ASSEMBLY RH HINT: Use the same procedure for the RH side and the LH side. Refer to «INSTALLATION [03/2012 - ] - Step 24»(ref-602734-S41277548442014030500000) .
5. INSTALL NO. 1 LUGGAGE COMPARTMENT TRIM HOOK RH . Refer to «INSTALLATION [03/2012 - ] - Step 32»(ref-602734-S41277548442014030500000)
6. INSTALL REAR SEAT SIDE COVER RH HINT: Use the same procedure for the RH side and the LH side. Refer to «INSTALLATION [03/2012 - ] - Step 25»(ref-602734-S41277548442014030500000) .
7. INSTALL REAR FLOOR FINISH SIDE PLATE RH HINT: Use the same procedure for the RH side and the LH side. Refer to «INSTALLATION [03/2012 - ] - Step 27»(ref-602734-S41277548442014030500000) .
8. INSTALL REAR FLOOR FINISH PLATE . Refer to «INSTALLATION [03/2012 - ] - Step 37»(ref-602734-S41277548442014030500000)
9. INSTALL REAR DOOR SCUFF PLATE RH HINT: Use the same procedure for the RH side and the LH side. Refer to «INSTALLATION [03/2012 - ] - Step 54»(ref-602734-S41277548442014030500000) .
10. INSTALL REAR SEAT ASSEMBLY RH Install the rear seat assembly RH. Refer to «INSTALLATION [03/2012 - 07/2012]»(ref-602733-S14932949482014030500000) .
11. INSTALL DECK SIDE TRIM BOX RH (for Compact Spare Tire) . Refer to «INSTALLATION [03/2012 - ] - Step 41»(ref-602734-S41277548442014030500000)
12. INSTALL DECK SIDE TRIM BOX RH (for Full Size Spare Tire) . Refer to «INSTALLATION [03/2012 - ] - Step 42»(ref-602734-S41277548442014030500000)
13. INSTALL NO. 3 REAR FLOOR BOARD (for Compact Spare Tire) . Refer to «INSTALLATION [03/2012 - ] - Step 45»(ref-602734-S41277548442014030500000)
14. INSTALL NO. 3 REAR FLOOR BOARD (for Full Size Spare Tire) . Refer to «INSTALLATION [03/2012 - ] - Step 46»(ref-602734-S41277548442014030500000)
15. INSTALL SPARE WHEEL COVER ASSEMBLY (for Compact Spare Tire) . Refer to «INSTALLATION [03/2012 - ] - Step 49»(ref-602734-S41277548442014030500000)
16. INSTALL DECK BOARD SUB-ASSEMBLY . Refer to «INSTALLATION [03/2012 - ] - Step 50»(ref-602734-S41277548442014030500000)
17. INSTALL TONNEAU COVER ASSEMBLY . Refer to «INSTALLATION [03/2012 - ] - Step 44»(ref-602734-S41277548442014030500000)
