SYSTEM DESCRIPTION [03/2012 - ]
- POWER MIRROR CONTROL SYSTEM DESCRIPTION This system has the following functions: automatic glare-resistant electrochromic (EC) mirror function, auto electric retract function, reverse shift-linked function, electrical remote control function, memory function and mirror heater function.
- FUNCTION OF MAIN COMPONENT Component Function Vertical mirror motor Receives a signal from the outer mirror control ECU assembly and adjusts the mirror surface position vertically. Horizontal mirror motor Receives a signal from the outer mirror control ECU assembly and adjusts the mirror surface position horizontally. Power retract mirror motor Receives a signal from the outer mirror control ECU assembly, and retracts and returns the outer rear view mirrors. Mirror heater Receives a signal from the outer mirror control ECU assembly and operates mirror heater EC mirror cell Varies reflection rate of the mirror through function of EC elements. Outer mirror retract switch Retracts and returns the outer rear view mirrors. Mirror retract and return signals are sent to each outer mirror control ECU assemblies from the main body ECU (multiplex network body ECU). Mirror auto retract switch Built into the multiplex network master switch and sends the mirror AUTO retract switch signal to the main body ECU (multiplex network body ECU) via LIN communication. Mirror select switch Consists of R and L switches. One must be chosen to operate the outer mirror switch assembly. Mirror adjust switch Mirror R and L signals are sent to each outer mirror control ECU assemblies from the mirror select switch. After selecting the R or L switch, the right, left, up and down control switches can be operated to change the angle of the mirror. Mirror position sensor Detects the mirror surface position. This data is detected by the outer mirror control ECU assembly. Seat memory switch When the seat memory M1, M2 or M3 switch are pressed while the SET switch is being pressed, or M1, M2 or M3 switch is pressed within 3 seconds after the SET switch being pressed, a signal is input to the outer mirror control ECU assembly (driver side), which records the mirror surface position. When the seat memory switch is pressed, a signal is input to the outer mirror control ECU assembly (driver side) and sent to main body ECU (multiplex network body ECU), which changes the mirror surface position to the recorded position. Outer mirror control ECU assembly Operates each mirror motor based on signals from the outer mirror retract switch, mirror select switch and mirror adjust switch. Based on information from the mirror position sensor, 3 different mirror surface positions can be stored. By operating a seat memory switch, the mirror surface moves to the stored position.
- SYSTEM OPERATION The remote control mirror has the following features. Function Outline Power retract mirror function Retracts and returns the outer rear view mirrors when the outer mirror retract switch is pressed. AUTO power retract mirror function Retracts and returns each outer rear view mirror together with the following operations while the mirror AUTO retract switch is on. Manual lock/unlock Key-linked lock/unlock Wireless door lock/unlock Wireless 30 seconds auto lock Entry lock/unlock Smart 30 seconds auto lock Reverse shift-linked function of mirrors Directs the mirror surface downward to improve visibility when driving in reverse and all the conditions below are met: The engine switch is on (IG). Shift lever is moved to R. The mirror select switch is in the R or L position. Electrical remote control mirror function When the outer mirror switch assembly is operated, this function moves the mirror surface vertically or horizontally to enable the driver to attain an optimal mirror angle. Setting the mirror select switch to the R position operates the right mirror, and setting it to the L position operates the left mirror. Memory and reactivation function Stores the adjusted mirror position in the outer mirror control ECU assembly. Automatic glare-resistant EC mirror function Reduces glare/reflection in the mirror during nighttime driving for safe driving conditions. Glare/reflection from vehicle headlights behind could blind driver and cause dangerous driving conditions. Mirror heater function Automatically turns on mirror heater when the rear window defogger switch is turned on. The rear window defogger and mirror heaters automatically turn off after 15 min.
SYSTEM DESCRIPTION
When the mirror adjust switch is operated, the multiplex network master switch assembly detects the switch operation and sends the mirror adjust switch signal to the main body ECU (multiplex network body ECU) via LIN communication. The main body ECU (multiplex network body ECU) then sends the mirror adjust switch signal to the outer mirror control ECU assembly (driver side) via CAN communication. On receiving the signal, the outer mirror control ECU assembly (driver side) operates the vertical and horizontal mirror motors, which are built into the outer rear view mirror assembly LH, to adjust the mirror surface position.
Scheme 8
When the mirror adjust switch is operated, the multiplex network master switch assembly detects the switch operation and sends the mirror adjust switch signal to the main body ECU (multiplex network body ECU) via LIN communication. The main body ECU (multiplex network body ECU) then sends the mirror adjust switch signal to the outer mirror control ECU assembly (driver side) via CAN communication. On receiving the signal, the outer mirror control ECU assembly (driver side) operates the vertical and horizontal mirror motors, which are built into the outer rear view mirror assembly LH, to adjust the mirror surface position.
When the mirror adjust switch is operated, the multiplex network master switch assembly detects the switch operation and sends the mirror adjust switch signal to the main body ECU (multiplex network body ECU) via LIN communication. The main body ECU (multiplex network body ECU) then sends the mirror adjust switch signal to the outer mirror control ECU assembly (front passenger side) via CAN communication. On receiving the signal, the outer mirror control ECU assembly (front passenger side) operates the vertical and horizontal mirror motors, which are built into the outer rear view mirror assembly RH, to adjust the mirror surface position.
Scheme 9
When the mirror adjust switch is operated, the multiplex network master switch assembly detects the switch operation and sends the mirror adjust switch signal to the main body ECU (multiplex network body ECU) via LIN communication. The main body ECU (multiplex network body ECU) then sends the mirror adjust switch signal to the outer mirror control ECU assembly (front passenger side) via CAN communication. On receiving the signal, the outer mirror control ECU assembly (front passenger side) operates the vertical and horizontal mirror motors, which are built into the outer rear view mirror assembly RH, to adjust the mirror surface position.
The multiplex network master switch assembly detects the mirror adjust switch status and sends the signal to the main body ECU (multiplex network body ECU) via LIN communication. The main body ECU (multiplex network body ECU) then sends the mirror adjust switch signal to each outer mirror control ECU assembly (both driver and front passenger sides) via CAN communication. On receiving the signal, each outer mirror control ECU assembly operates the vertical and horizontal mirror motors to adjust the mirror surface position.
Scheme 10
The multiplex network master switch assembly detects the mirror adjust switch status and sends the signal to the main body ECU (multiplex network body ECU) via LIN communication. The main body ECU (multiplex network body ECU) then sends the mirror adjust switch signal to each outer mirror control ECU assembly (both driver and front passenger sides) via CAN communication. On receiving the signal, each outer mirror control ECU assembly operates the vertical and horizontal mirror motors to adjust the mirror surface position.
DESCRIPTION
When the rear defogger switch is operated, the mirror heater signal is sent to the air conditioning amplifier assembly and then to each outer mirror control ECU assembly via CAN communication. Based on the signal, each outer mirror control ECU assembly operates the mirror heater.
Scheme 11
When the rear defogger switch is operated, the mirror heater signal is sent to the air conditioning amplifier assembly and then to each outer mirror control ECU assembly via CAN communication. Based on the signal, each outer mirror control ECU assembly operates the mirror heater.
The main body ECU (multiplex network body ECU) receives the outer mirror retract switch signal from the multiplex network master switch assembly via LIN communication. The main body ECU then sends the mirror retract/return signal to each outer mirror control ECU assembly via CAN communication. Based on the signal, each outer mirror control ECU assembly retracts or returns the outer rear view mirror assembly.
Scheme 12
The main body ECU (multiplex network body ECU) receives the outer mirror retract switch signal from the multiplex network master switch assembly via LIN communication. The main body ECU then sends the mirror retract/return signal to each outer mirror control ECU assembly via CAN communication. Based on the signal, each outer mirror control ECU assembly retracts or returns the outer rear view mirror assembly.
When the mirror AUTO retract switch of the multiplex network master switch assembly is on, the multiplex network master switch sends the mirror AUTO retract switch signal to the main body ECU (multiplex network body ECU) via LIN communication. When the doors are locked or unlocked while the engine switch is off, the main body ECU (multiplex network body ECU) sends the mirror retract/return signal to each outer mirror control ECU assembly via CAN communication. On receiving the mirror retract/return signal, each outer mirror control ECU assembly operates the power mirror retract motor of the outer rear view mirror assembly to retract or return the outer rear view mirror assembly.
Scheme 13
When the mirror AUTO retract switch of the multiplex network master switch assembly is on, the multiplex network master switch sends the mirror AUTO retract switch signal to the main body ECU (multiplex network body ECU) via LIN communication. When the doors are locked or unlocked while the engine switch is off, the main body ECU (multiplex network body ECU) sends the mirror retract/return signal to each outer mirror control ECU assembly via CAN communication. On receiving the mirror retract/return signal, each outer mirror control ECU assembly operates the power mirror retract motor of the outer rear view mirror assembly to retract or return the outer rear view mirror assembly.
If any of the M1, M2 or M3 seat memory switches is pressed, the outer mirror control ECU assembly (driver side) detects the switch operation and sends the seat memory switch signal to the main body ECU (multiplex network body ECU) via CAN communication. On receiving the seat memory switch signal, the main body ECU (multiplex network body ECU) sends the memory request signal to each outer mirror control ECU assembly via CAN communication. When receiving this signal, each outer mirror control ECU assembly stores the mirror surface position based on information from the mirror position sensor, which is built into the outer rear view mirror assembly.
HINT
Each outer rear view mirror has a built-in mirror vertical position sensor and mirror horizontal position sensor.
Note. The mirror surface position will not be memorized if the engine switch is not on (IG). The mirror surface position will not be stored if the seat memory SET switch and 2 or more of the seat memory switches (for example, M1 switch and M2 switch) are pressed simultaneously. If the operation fails, the mirror surface position will not be memorized until the seat memory SET switch is turned off. The mirror surface position will not be memorized when the mirror is operated manually.
Scheme 14
If any of the M1, M2 or M3 seat memory switches is pressed, the outer mirror control ECU assembly (driver side) detects the switch operation and sends the seat memory switch signal to the main body ECU (multiplex network body ECU) via CAN communication. On receiving the seat memory switch signal, the main body ECU (multiplex network body ECU) sends the memory request signal to each outer mirror control ECU assembly via CAN communication. When receiving this signal, each outer mirror control ECU assembly stores the mirror surface position based on information from the mirror position sensor, which is built into the outer rear view mirror assembly.
HINT
Each outer rear view mirror has a built-in mirror vertical position sensor and mirror horizontal position sensor.
Note. The mirror surface position will not be memorized if the engine switch is not on (IG). The mirror surface position will not be stored if the seat memory SET switch and 2 or more of the seat memory switches (for example, M1 switch and M2 switch) are pressed simultaneously. If the operation fails, the mirror surface position will not be memorized until the seat memory SET switch is turned off. The mirror surface position will not be memorized when the mirror is operated manually.
If any of the M1, M2 or M3 seat memory switches is pressed, the outer mirror control ECU assembly (driver side) detects the seat memory switch status and sends the switch signal to the main body ECU (multiplex network body ECU) via CAN communication. The main body ECU (multiplex network body ECU) sends back reproduction signals to each outer mirror control ECU assembly via CAN communication. When receiving the reproduction signals, each outer mirror control ECU assembly operates the vertical and horizontal mirror motors, which are built into the outer rear view mirror assembly, to adjust the mirror surface to the stored position.
If any of the M1, M2 or M3 seat memory switches is pressed, the outer mirror control ECU assembly (driver side) detects the seat memory switch status and sends the switch signal to the main body ECU (multiplex network body ECU) via CAN communication. The main body ECU (multiplex network body ECU) sends back reproduction signals to each outer mirror control ECU assembly via CAN communication. When receiving the reproduction signals, each outer mirror control ECU assembly operates the vertical and horizontal mirror motors, which are built into the outer rear view mirror assembly, to adjust the mirror surface to the stored position.
On receiving a reverse signal from the park/neutral position switch, the ECM sends the reverse signal to the main body ECU (multiplex network body ECU) via CAN communication. When receiving the reverse signal, the main body ECU (multiplex network body ECU) sends the reverse request signal to each outer mirror control ECU assembly. Each outer mirror control ECU assembly then performs control in response to the reverse signal.
HINT
The reverse shift-linked function will not activate when the mirror select switch is in the neutral position (off).
Scheme 15
On receiving a reverse signal from the park/neutral position switch, the ECM sends the reverse signal to the main body ECU (multiplex network body ECU) via CAN communication. When receiving the reverse signal, the main body ECU (multiplex network body ECU) sends the reverse request signal to each outer mirror control ECU assembly. Each outer mirror control ECU assembly then performs control in response to the reverse signal.
HINT
The reverse shift-linked function will not activate when the mirror select switch is in the neutral position (off).
The key ID can be registered to be linked with each of the M1, M2 and M3 seat memory switches. The key ID registration procedure should be performed while the electrical key transmitter is in the vehicle, the engine switch is on (IG), and the driver door is closed. When the registration is completed, the buzzer will sound as an answerback.
When the vehicle doors are unlocked through wireless unlock or entry unlock operation, the certification ECU (smart key ECU assembly) sends the key ID signal and smart memory call request signal to the main body ECU (multiplex network body ECU). When the main body ECU (multiplex network body ECU) receives the signal and the driver door is opened, the ECU sends the memory call command signal for the received key ID to each outer mirror control ECU assembly. On receiving the memory call command signal, each outer mirror control ECU assembly controls to move the mirror surface to the stored position.
