REPLACEMENT [03/2012 - ]

WARNINGProlonged and repeated contact with engine oil will result in the removal of natural oils from the skin, leading to dryness, irritation and dermatitis. In addition, used engine oil contains potentially harmful contaminants which may cause skin cancer. Precautions should be taken when replacing engine oil to minimize the risk of your skin making contact with used engine oil. Protective clothing and gloves that cannot be penetrated by oil should be worn. The skin should be washed with soap and water, or use waterless hand cleaner, to remove any used engine oil thoroughly. Do not use gasoline, thinners, or solvents. In order to preserve the environment, used oil and used oil filters must be disposed of at designated disposal sites.

Scheme 7

Scheme 7
Scheme 7

Scheme 8

Scheme 8
Scheme 8

Scheme 9

Scheme 9
Scheme 9

Scheme 10

Scheme 10
Scheme 10

Scheme 11

Scheme 11
Scheme 11

Scheme 12

Scheme 12
Scheme 12

Scheme 13

Scheme 13
Scheme 13

Scheme 14

Scheme 14
Scheme 14

Scheme 15

Scheme 15
Scheme 15
  1. DRAIN ENGINE OIL Remove the oil filler cap. Remove the oil pan drain plug and gasket, and drain the oil into a container. Clean the oil pan drain plug. Install the oil pan drain plug with a new gasket. Torque: 40 N*m (408 kgf*cm, 30 ft.*lbf)
  2. REMOVE OIL FILTER ELEMENT Connect the hose with an inside diameter of 15 mm (0.591 in.) to the pipe. TEXT IN ILLUSTRATION *1 Pipe *2 Hose Remove the oil filter drain plug from the oil filter cap. Insert the pipe with the hose into the oil filter cap. TEXT IN ILLUSTRATION *1 Cap *2 O-ring *3 Pipe NOTE: Be sure to insert the pipe with the O-ring installed on the oil filter cap side. HINT: Place the hose end into a container before draining oil from the hose. Make sure that oil is completely drained, and remove the pipe and O-ring. HINT: Be sure to turn the pipe in the direction of the arrow to remove it. Using SST, remove the oil filter cap. SST: 09228-06501 Remove the oil filter element and O-ring from the oil filter cap. TEXT IN ILLUSTRATION *1 Oil Filter Element *2 Oil Filter Cap *3 O-ring NOTE: Do not use any tools to remove the O-ring in order to prevent the cap from being damaged. Be sure to remove it by hand.
  3. INSTALL OIL FILTER ELEMENT Clean the inside of the oil filter cap, threads and O-ring groove. Apply a light coat of engine oil to a new O-ring and install it to the oil filter cap. TEXT IN ILLUSTRATION *1 O-ring *a CORRECT *b INCORRECT NOTE: Be sure to install the O-ring in the proper location, otherwise oil may leak. Do not twist the O-ring. Install a new oil filter element to the oil filter cap. Remove all dirt and foreign matter from the installation surface and the inside of the cap on the engine side. Apply a light coat of engine oil to the O-ring again and install the oil filter cap. NOTE: Make sure that the O-ring does not get caught between the parts. Using SST, install the oil filter cap. TEXT IN ILLUSTRATION *1 Oil Filter Cap *2 O-ring *3 Oil Filter Bracket *a No Gap SST: 09228-06501 Torque: 25 N*m (255 kgf*cm, 18 ft.*lbf) NOTE: After tightening the oil filter cap, make sure that there is no gap and that the O-ring is not protruding. Apply a light coat of engine oil to a new O-ring and install it to the oil filter cap. TEXT IN ILLUSTRATION *1 O-ring NOTE: Remove all dirt and foreign matter from the installation surface. Install the oil filter drain plug to the oil filter cap. Torque: 13 N*m (127 kgf*cm, 10 ft.*lbf) NOTE: Make sure that the O-ring does not get caught between the parts.
  4. ADD ENGINE OIL Add clean engine oil and install the oil filler cap. STANDARD OIL GRADE (FOR USA) Oil Grade Oil Viscosity (SAE) ILSAC multigrade engine oil 0W-20 STANDARD OIL GRADE (FOR CANADA) Oil Grade Oil Viscosity (SAE) ILSAC multigrade engine oil 0W-20 5W-20 STANDARD CAPACITY (W/ OIL COOLER) Item Standard Condition Drain and refill with oil filter change 6.1 liters (6.4 US qts, 5.4 lmp. qts) Drain and refill without oil filter change 5.7 liters (6.0 US qts, 5.0 lmp. qts) Dry fill 7.1 liters (7.5 US qts, 6.2 lmp. qts) STANDARD CAPACITY (W/O OIL COOLER) Item Standard Condition Drain and refill with oil filter change 6.1 liters (6.4 US qts, 5.4 lmp. qts) Drain and refill without oil filter change 5.7 liters (6.0 US qts, 5.0 lmp. qts) Dry fill 6.8 liters (7.2 US qts, 6.0 lmp. qts)
  5. INSPECT FOR ENGINE OIL LEAK Start the engine. Check for engine oil leaks from the connected parts of the oil filter cap and oil filter drain plug.

Scheme 16

Scheme 16: ILLUSTRATION
Scheme 16: ILLUSTRATION

Scheme 17

Scheme 17: ILLUSTRATION
Scheme 17: ILLUSTRATION

Scheme 18

Scheme 18: REMOVAL [03/2012 - 07/2012]
Scheme 18: REMOVAL [03/2012 - 07/2012]

Scheme 19

Scheme 19
Scheme 19
  1. REMOVE FRONT WHEEL RH (w/ Oil Cooler)
  2. REMOVE NO. 1 ENGINE UNDER COVER (w/o Oil Cooler)
  3. REMOVE FRONT FENDER LINER RH (w/ Oil Cooler)
  4. REMOVE FRONT FENDER APRON SEAL RH (w/ Oil Cooler) . Refer to «REMOVAL [03/2012 - 07/2012] - Step 16»(ref-602689-S14087581402014030500000)
  5. REMOVE ENGINE OIL PRESSURE SWITCH ASSEMBLY (w/o Oil Cooler) Disconnect the oil pressure switch assembly connector. Using a 24 mm deep socket wrench, remove the oil pressure switch.
  6. REMOVE ENGINE OIL PRESSURE SWITCH ASSEMBLY (w/ Oil Cooler) Disconnect the oil pressure switch assembly connector. Using a 24 mm deep socket wrench, remove the oil pressure switch.

REMOVAL [07/2012 - ]

  1. REMOVE FRONT WHEEL RH (w/ Oil Cooler)
  2. REMOVE NO. 1 ENGINE UNDER COVER (w/o Oil Cooler)
  3. REMOVE FRONT FENDER LINER RH (w/ Oil Cooler)
  4. REMOVE FRONT FENDER APRON SEAL RH (w/ Oil Cooler) . Refer to «REMOVAL [07/2012 - ] - Step 16»(ref-602689-S23172420682014030500000)
  5. REMOVE ENGINE OIL PRESSURE SWITCH ASSEMBLY (w/o Oil Cooler) Disconnect the oil pressure switch assembly connector. Using a 24 mm deep socket wrench, remove the oil pressure switch.
  6. REMOVE ENGINE OIL PRESSURE SWITCH ASSEMBLY (w/ Oil Cooler) Disconnect the oil pressure switch assembly connector. Using a 24 mm deep socket wrench, remove the oil pressure switch.

Scheme 20

Scheme 20: INSPECTION [03/2012 - ]
Scheme 20: INSPECTION [03/2012 - ]
  1. INSPECT ENGINE OIL PRESSURE SWITCH ASSEMBLY Disconnect the oil pressure switch assembly connector. Start the engine. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition B26-1 - Switch body Idling 10 kohms or higher B26-1 - Switch body Engine stopped Below 1 ohms If the result is not as specified, replace the oil pressure switch assembly. Reconnect the oil pressure switch assembly connector.

Scheme 21

Scheme 21: INSTALLATION [03/2012 - 07/2012]
Scheme 21: INSTALLATION [03/2012 - 07/2012]
  1. INSTALL ENGINE OIL PRESSURE SWITCH ASSEMBLY (w/o Oil Cooler) Apply adhesive to 2 or 3 threads of the oil pressure switch. TEXT IN ILLUSTRATION *1 Adhesive Adhesive Toyota Genuine Adhesive 1344, Three Bond 1344 or equivalent Using a 24 mm deep socket wrench, install the oil pressure switch. Torque: 15 N*m (153 kgf*cm, 11 ft.*lbf) NOTE: Do not start the engine for at least 1 hour after installation.
  2. INSTALL ENGINE OIL PRESSURE SWITCH ASSEMBLY (w/ Oil Cooler) Apply adhesive to 2 or 3 threads of the oil pressure switch. TEXT IN ILLUSTRATION *1 Adhesive Adhesive Toyota Genuine Adhesive 1344, Three Bond 1344 or equivalent Using a 24 mm deep socket wrench, install the oil pressure switch. Torque: 15 N*m (153 kgf*cm, 11 ft.*lbf) NOTE: Do not start the engine for at least 1 hour after installation. Connect the oil pressure switch assembly connector.
  3. INSPECT FOR OIL LEAK Start the engine. Check for engine oil leaks from the oil pressure switch assembly.
  4. INSTALL FRONT FENDER APRON SEAL RH (w/ Oil Cooler) . Refer to «INSTALLATION [03/2012 - 07/2012] - Step 110»(ref-602689-S39902766612014030500000)
  5. INSTALL FRONT FENDER LINER RH (w/ Oil Cooler)
  6. INSTALL NO. 1 ENGINE UNDER COVER (w/o Oil Cooler)
  7. INSTALL FRONT WHEEL RH (w/ Oil Cooler) Torque: 103 N*m (1050 kgf*cm, 76 ft.*lbf)

INSTALLATION [07/2012 - ]

  1. INSTALL ENGINE OIL PRESSURE SWITCH ASSEMBLY (w/o Oil Cooler) Apply adhesive to 2 or 3 threads of the oil pressure switch. TEXT IN ILLUSTRATION *1 Adhesive Adhesive Toyota Genuine Adhesive 1344, Three Bond 1344 or equivalent Using a 24 mm deep socket wrench, install the oil pressure switch. Torque: 15 N*m (153 kgf*cm, 11 ft.*lbf) NOTE: Do not start the engine for at least 1 hour after installation.
  2. INSTALL ENGINE OIL PRESSURE SWITCH ASSEMBLY (w/ Oil Cooler) Apply adhesive to 2 or 3 threads of the oil pressure switch. TEXT IN ILLUSTRATION *1 Adhesive Adhesive Toyota Genuine Adhesive 1344, Three Bond 1344 or equivalent Using a 24 mm deep socket wrench, install the oil pressure switch. Torque: 15 N*m (153 kgf*cm, 11 ft.*lbf) NOTE: Do not start the engine for at least 1 hour after installation. Connect the oil pressure switch assembly connector.
  3. INSPECT FOR OIL LEAK Start the engine. Check for engine oil leaks from the oil pressure switch assembly.
  4. INSTALL FRONT FENDER APRON SEAL RH (w/ Oil Cooler) . Refer to «INSTALLATION [07/2012 - ] - Step 115»(ref-602689-S30369469832014030500000)
  5. INSTALL FRONT FENDER LINER RH (w/ Oil Cooler)
  6. INSTALL NO. 1 ENGINE UNDER COVER (w/o Oil Cooler)
  7. INSTALL FRONT WHEEL RH (w/ Oil Cooler) Torque: 103 N*m (1050 kgf*cm, 76 ft.*lbf)

Scheme 22

Scheme 22: ILLUSTRATION
Scheme 22: ILLUSTRATION

Scheme 23

Scheme 23: ILLUSTRATION
Scheme 23: ILLUSTRATION

Scheme 24

Scheme 24: ILLUSTRATION
Scheme 24: ILLUSTRATION

Scheme 25

Scheme 25: ILLUSTRATION
Scheme 25: ILLUSTRATION

Scheme 26

Scheme 26: REMOVAL [03/2012 - 07/2012]
Scheme 26: REMOVAL [03/2012 - 07/2012]

Scheme 27

Scheme 27
Scheme 27

Scheme 28

Scheme 28
Scheme 28

Scheme 29

Scheme 29
Scheme 29

Scheme 30

Scheme 30
Scheme 30
  1. REMOVE ENGINE ASSEMBLY WITH TRANSAXLE HINT: Remove engine assembly with transaxle for 2WD. Refer to «REMOVAL [03/2012 - 07/2012] - Step 1»(ref-602716-S22997177662014030500000) . Remove engine assembly with transaxle for AWD. Refer to «REMOVAL [03/2012 - 07/2012] - Step 1»(ref-602717-S03452047192014030500000) .
  2. SECURE ENGINE
  3. REMOVE NO. 1 OIL PIPE . Refer to «DISASSEMBLY [03/2012 - 07/2012] - Step 8»(ref-602689-S12257874642014030500000)
  4. REMOVE OIL PIPE . Refer to «DISASSEMBLY [03/2012 - 07/2012] - Step 9»(ref-602689-S12257874642014030500000)
  5. REMOVE CRANKSHAFT PULLEY . Refer to «REMOVAL [03/2012 - 07/2012] - Step 5»(ref-602689-S28353429752014030500000)
  6. SEPARATE OIL COOLER PIPE (w/ Oil Cooler) Remove the bolt and 2 nuts, and disconnect the oil cooler pipe from the oil pan sub-assembly. Remove the gasket from the oil pan sub-assembly.
  7. REMOVE WATER INLET HOUSING . Refer to «DISASSEMBLY [03/2012 - 07/2012] - Step 17»(ref-602689-S12257874642014030500000)
  8. REMOVE CYLINDER HEAD COVER SUB-ASSEMBLY (for Bank 1) . Refer to «DISASSEMBLY [03/2012 - 07/2012] - Step 19»(ref-602689-S12257874642014030500000)
  9. REMOVE CYLINDER HEAD COVER SUB-ASSEMBLY (for Bank 2) . Refer to «DISASSEMBLY [03/2012 - 07/2012] - Step 20»(ref-602689-S12257874642014030500000)
  10. REMOVE NO. 2 OIL PAN SUB-ASSEMBLY . Refer to «DISASSEMBLY [03/2012 - 07/2012] - Step 21»(ref-602689-S12257874642014030500000)
  11. REMOVE OIL STRAINER SUB-ASSEMBLY . Refer to «DISASSEMBLY [03/2012 - 07/2012] - Step 22»(ref-602689-S12257874642014030500000)
  12. REMOVE OIL PAN SUB-ASSEMBLY . Refer to «DISASSEMBLY [03/2012 - 07/2012] - Step 23»(ref-602689-S12257874642014030500000)
  13. REMOVE TIMING CHAIN COVER SUB-ASSEMBLY Remove the 23 bolts and 2 nuts shown in the illustration. Remove the timing chain cover by prying between the timing chain cover and cylinder head or cylinder block with a screwdriver. TEXT IN ILLUSTRATION *1 Protective Tape NOTE: Be careful not to damage the contact surfaces of the cylinder head, cylinder block and chain cover. HINT: Tape the screwdriver tip before use. Remove the gasket.
  14. REMOVE TIMING CHAIN COVER OIL SEAL Using a screwdriver, pry out the oil seal. TEXT IN ILLUSTRATION *1 Protective Tape *2 Wooden Block HINT: Tape the screwdriver tip before use.
  1. REMOVE ENGINE ASSEMBLY WITH TRANSAXLE HINT: for U660E: Refer to «REMOVAL [07/2012 - ]»(ref-602716-S37924994172014030500000) for U660F: Refer to «REMOVAL [07/2012 - ]»(ref-602717-S25966124322014030500000) for U880F: Refer to «REMOVAL [07/2012 - ]»(ref-602718-S00289177742014030500000)
  2. INSTALL ENGINE ON ENGINE STAND . Refer to «REMOVAL [03/2012 - ] - Step 1»(ref-602689-S40231256012014030500000)
  3. REMOVE NO. 1 OIL PIPE . Refer to «DISASSEMBLY [07/2012 - ] - Step 8»(ref-602689-S26904166172014030500000)
  4. REMOVE OIL PIPE . Refer to «DISASSEMBLY [07/2012 - ] - Step 9»(ref-602689-S26904166172014030500000)
  5. REMOVE CRANKSHAFT PULLEY . Refer to «REMOVAL [07/2012 - ] - Step 5»(ref-602689-S19039171662014030500000)
  6. SEPARATE OIL COOLER PIPE (w/ Oil Cooler) Remove the bolt and 2 nuts, and disconnect the oil cooler pipe from the oil pan sub-assembly. Remove the gasket from the oil pan sub-assembly.
  7. REMOVE WATER INLET HOUSING . Refer to «DISASSEMBLY [07/2012 - ] - Step 17»(ref-602689-S26904166172014030500000)
  8. REMOVE CYLINDER HEAD COVER SUB-ASSEMBLY (for Bank 1) . Refer to «DISASSEMBLY [07/2012 - ] - Step 19»(ref-602689-S26904166172014030500000)
  9. REMOVE CYLINDER HEAD COVER SUB-ASSEMBLY (for Bank 2) . Refer to «DISASSEMBLY [07/2012 - ] - Step 20»(ref-602689-S26904166172014030500000)
  10. REMOVE NO. 2 OIL PAN SUB-ASSEMBLY . Refer to «DISASSEMBLY [07/2012 - ] - Step 21»(ref-602689-S26904166172014030500000)
  11. REMOVE OIL STRAINER SUB-ASSEMBLY . Refer to «DISASSEMBLY [07/2012 - ] - Step 22»(ref-602689-S26904166172014030500000)
  12. REMOVE OIL PAN SUB-ASSEMBLY . Refer to «DISASSEMBLY [07/2012 - ] - Step 23»(ref-602689-S26904166172014030500000)
  13. REMOVE TIMING CHAIN COVER SUB-ASSEMBLY Remove the 23 bolts and 2 nuts shown in the illustration. Remove the timing chain cover by prying between the timing chain cover and cylinder head or cylinder block with a screwdriver. TEXT IN ILLUSTRATION *1 Protective Tape NOTE: Be careful not to damage the contact surfaces of the cylinder head, cylinder block and chain cover. HINT: Tape the screwdriver tip before use. Remove the gasket.
  14. REMOVE TIMING CHAIN COVER OIL SEAL Using a screwdriver, pry out the oil seal. TEXT IN ILLUSTRATION *1 Protective Tape *2 Wooden Block HINT: Tape the screwdriver tip before use.

Scheme 31

Scheme 31: DISASSEMBLY [03/2012 - ]
Scheme 31: DISASSEMBLY [03/2012 - ]

Scheme 32

Scheme 32
Scheme 32
  1. REMOVE OIL PUMP RELIEF VALVE Using a 27 mm socket wrench, remove the relief valve plug. Remove the valve spring and oil pump relief valve.
  2. REMOVE OIL PUMP COVER Remove the 8 bolts, oil pump cover and oil pump rotor set.

Scheme 33

Scheme 33: INSPECTION [03/2012 - ]
Scheme 33: INSPECTION [03/2012 - ]

Scheme 34

Scheme 34
Scheme 34

Scheme 35

Scheme 35
Scheme 35

Scheme 36

Scheme 36
Scheme 36

Scheme 37

Scheme 37
Scheme 37
  1. INSPECT OIL PUMP RELIEF VALVE Coat the relief valve with engine oil and check that it falls smoothly into the valve hole by its own weight. If the valve does not fall smoothly, replace the relief valve. If necessary, replace the oil pump assembly.
  2. INSPECT OIL PUMP ROTOR SET Install the rotors to the timing chain cover with the rotors' marks facing up. Check that the rotors rotate smoothly. TEXT IN ILLUSTRATION *1 Mark Check the tip clearance. Using a feeler gauge, measure the clearance between the drive and driven rotor tips, as shown in the illustration. Tip Clearance Standard Maximum 0.060 to 0.160 mm (0.00236 to 0.00630 in.) 0.160 mm (0.00630 in.) If the tip clearance is greater than the maximum, replace the timing chain cover sub-assembly. Check the side clearance. Using a feeler gauge and precision straightedge, measure the clearance between the rotors and precision straightedge, as shown in the illustration. Side Clearance Standard Maximum 0.030 to 0.090 mm (0.00118 to 0.00354 in.) 0.090 mm (0.00354 in.) If the side clearance is greater than the maximum, replace the timing chain cover sub-assembly. Check the body clearance. Using a feeler gauge, measure the clearance between the timing chain cover and driven rotor, as shown in the illustration. Body Clearance Standard Maximum 0.250 to 0.325 mm (0.00984 to 0.0128 in.) 0.325 mm (0.0128 in.) If the body clearance is greater than the maximum, replace the timing chain cover sub-assembly.

Scheme 38

Scheme 38
Scheme 38
  1. INSTALL OIL PUMP COVER Coat the drive and driven rotors with engine oil and place them into the timing chain cover with the marks facing up (oil pump cover side). Check that the rotors rotate smoothly. TEXT IN ILLUSTRATION *1 Mark Install the oil pump cover with the 8 bolts. BOLT LENGTH Item Length Bolt A 22 mm (0.866 in.) Bolt B 40 mm (1.58 in.) Torque: 9.1 N*m (93 kgf*cm, 81 in.*lbf)
  2. INSTALL OIL PUMP RELIEF VALVE Coat the oil pump relief valve with engine oil. Insert the relief valve and relief valve spring into the oil pump cover hole. Using a 27 mm socket wrench, install the plug. Torque: 49 N*m (500 kgf*cm, 37 ft.*lbf)

Scheme 39

Scheme 39: INSTALLATION [03/2012 - 07/2012]
Scheme 39: INSTALLATION [03/2012 - 07/2012]

Scheme 40

Scheme 40
Scheme 40

Scheme 41

Scheme 41
Scheme 41

Scheme 42

Scheme 42
Scheme 42

Scheme 43

Scheme 43
Scheme 43

Scheme 44

Scheme 44
Scheme 44
  1. INSTALL TIMING CHAIN COVER OIL SEAL Using SST, tap in a new oil seal until its surface is flush with the timing chain case edge. SST: 09223-22010 SST: 09506-35010 NOTE: Keep the lip free from foreign matter. Do not tap on the oil seal at an angle. Make sure that the oil seal edge does not stick out of the timing chain case. HINT: Tap in the oil seal so that it is positioned within 1.0 mm from the edge of the timing chain case. Apply a light coat of MP grease to the timing chain cover oil seal lip.
  2. INSTALL TIMING CHAIN COVER SUB-ASSEMBLY Apply seal packing in a continuous line to the engine unit as shown in the following illustration. Seal packing Toyota Genuine Seal Packing Black, Three Bond 1207B or equivalent Seal diameter 3.0 mm (0.118 in.) or more NOTE: Be sure to clean and degrease the contact surfaces, especially the surfaces indicated by C in the illustration. If the contact surfaces are wet, wipe them with an oil-free cloth before applying seal packing. Install the chain cover sub-assembly within 3 minutes after applying seal packing. Do not start the engine for at least 2 hours after installing the chain cover sub-assembly. Apply seal packing in a line to the timing chain cover as shown in the following illustration. Seal packing Toyota Genuine Seal Packing Black, Three Bond 1207B or equivalent Toyota Genuine Seal Packing 1282B, Three Bond 1282B or equivalent NOTE: If the contact surfaces are wet, wipe them with an oil-free cloth before applying seal packing. Install the chain cover sub-assembly within 3 minutes and tighten the bolts within 15 minutes after applying seal packing. Do not start the engine for at least 2 hours after installing the chain cover sub-assembly. Seal Packing Application Chart Area Seal Packing Diameter Application Position from Inside Seal Line Continuous Line Area 4.5 mm (0.177 in.) or more 3.0 to 4.0 mm (0.118 to 0.158 in.) Alternate Long and Short Dashed Line Area 3.5 mm (0.138 in.) or more 2.0 to 3.0 mm (0.0787 to 0.118 in.) Dashed Line Area 3.5 mm (0.138 in.) or more 3.0 to 4.0 mm (0.118 to 0.158 in.) Diagonal Line Area 6.0 mm (0.236 in.) or more 5.0 mm (0.197 in.) Install a new gasket. Align the oil pump's drive rotor spline and the crankshaft as shown in the illustration. Install the oil pump and chain cover to the crankshaft. TEXT IN ILLUSTRATION *1 Drive Rotor Spline *2 Crankshaft Temporarily tighten the timing chain cover with the 23 bolts and 2 nuts. BOLT LENGTH Item Length Bolt A 40 mm (1.57 in.) Bolt B 55 mm (2.17 in.) Bolt C 25 mm (0.984 in.) NOTE: Make sure that there is no oil on the threads of bolt B and C. Fully tighten the bolts in area 1 and area 2. Torque: 21 N*m (214 kgf*cm, 15 ft.*lbf) Fully tighten the bolts and nuts in area 3. Torque: 21 N*m (214 kgf*cm, 15 ft.*lbf) HINT: Tighten the bolts and nuts from top to bottom as shown in the illustration. Fully tighten the bolts in area 4. Bolt A Torque: 43 N*m (438 kgf*cm, 32 ft.*lbf) Except bolt A Torque: 21 N*m (214 kgf*cm, 15 ft.*lbf) HINT: Tighten the bolts from bottom to top as shown in the illustration.
  3. INSTALL OIL PAN SUB-ASSEMBLY . Refer to «REASSEMBLY [03/2012 - 07/2012] - Step 37»(ref-602689-S20579706002014030500000)
  4. INSTALL OIL STRAINER SUB-ASSEMBLY . Refer to «REASSEMBLY [03/2012 - 07/2012] - Step 38»(ref-602689-S20579706002014030500000)
  5. INSTALL NO. 2 OIL PAN SUB-ASSEMBLY . Refer to «REASSEMBLY [03/2012 - 07/2012] - Step 39»(ref-602689-S20579706002014030500000)
  6. INSTALL CYLINDER HEAD COVER SUB-ASSEMBLY (for Bank 1) . Refer to «REASSEMBLY [03/2012 - 07/2012] - Step 41»(ref-602689-S20579706002014030500000)
  7. INSTALL CYLINDER HEAD COVER SUB-ASSEMBLY (for Bank 2) . Refer to «REASSEMBLY [03/2012 - 07/2012] - Step 42»(ref-602689-S20579706002014030500000)
  8. INSTALL WATER INLET HOUSING . Refer to «REASSEMBLY [03/2012 - 07/2012] - Step 34»(ref-602689-S20579706002014030500000)
  9. INSTALL OIL COOLER PIPE (w/ oil cooler) Install a new gasket to the oil pan sub-assembly. Install the oil cooler pipe with the bolt and 2 nuts. Torque: 21 N*m (214 kgf*cm, 15 ft.*lbf)
  10. INSTALL CRANKSHAFT PULLEY . Refer to «INSTALLATION [03/2012 - 07/2012] - Step 2»(ref-602689-S35067556862014030500000)
  11. INSTALL NO. 1 OIL PIPE . Refer to «REASSEMBLY [03/2012 - 07/2012] - Step 50»(ref-602689-S20579706002014030500000)
  12. INSTALL OIL PIPE . Refer to «REASSEMBLY [03/2012 - 07/2012] - Step 51»(ref-602689-S20579706002014030500000)
  13. INSTALL ENGINE HANGERS . Refer to «INSTALLATION [03/2012 - ] - Step 21»(ref-602689-S03941313262014030500000)
  14. REMOVE ENGINE STAND
  15. INSTALL ENGINE ASSEMBLY WITH TRANSAXLE HINT: Install engine assembly with transaxle for 2WD. Refer to «INSTALLATION [03/2012 - 07/2012] - Step 13»(ref-602716-S09523939282014030500000) . Install engine assembly with transaxle for AWD. Refer to «INSTALLATION [03/2012 - 07/2012] - Step 19»(ref-602717-S01974199402014030500000) .
  1. INSTALL TIMING CHAIN COVER OIL SEAL Using SST, tap in a new oil seal until its surface is flush with the timing chain case edge. SST: 09223-22010 SST: 09506-35010 NOTE: Keep the lip free from foreign matter. Do not tap on the oil seal at an angle. Make sure that the oil seal edge does not stick out of the timing chain case. HINT: Tap in the oil seal so that it is positioned within 1.0 mm from the edge of the timing chain case. Apply a light coat of MP grease to the timing chain cover oil seal lip.
  2. INSTALL TIMING CHAIN COVER SUB-ASSEMBLY Apply seal packing in a continuous line to the engine unit as shown in the following illustration. Seal packing Toyota Genuine Seal Packing Black, Three Bond 1207B or equivalent Seal diameter 3.0 mm (0.118 in.) or more NOTE: Be sure to clean and degrease the contact surfaces, especially the surfaces indicated by C in the illustration. If the contact surfaces are wet, wipe them with an oil-free cloth before applying seal packing. Install the chain cover sub-assembly within 3 minutes after applying seal packing. Do not start the engine for at least 2 hours after installing the chain cover sub-assembly. Apply seal packing in a line to the timing chain cover as shown in the following illustration. Seal packing Toyota Genuine Seal Packing Black, Three Bond 1207B or equivalent Toyota Genuine Seal Packing 1282B, Three Bond 1282B or equivalent NOTE: If the contact surfaces are wet, wipe them with an oil-free cloth before applying seal packing. Install the chain cover sub-assembly within 3 minutes and tighten the bolts within 15 minutes after applying seal packing. Do not start the engine for at least 2 hours after installing the chain cover sub-assembly. Seal Packing Application Chart Area Seal Packing Diameter Application Position from Inside Seal Line Continuous Line Area 4.5 mm (0.177 in.) or more 3.0 to 4.0 mm (0.118 to 0.158 in.) Alternate Long and Short Dashed Line Area 3.5 mm (0.138 in.) or more 2.0 to 3.0 mm (0.0787 to 0.118 in.) Dashed Line Area 3.5 mm (0.138 in.) or more 3.0 to 4.0 mm (0.118 to 0.158 in.) Diagonal Line Area 6.0 mm (0.236 in.) or more 5.0 mm (0.197 in.) Install a new gasket. Align the oil pump's drive rotor spline and the crankshaft as shown in the illustration. Install the oil pump and chain cover to the crankshaft. TEXT IN ILLUSTRATION *1 Drive Rotor Spline *2 Crankshaft Temporarily tighten the timing chain cover with the 23 bolts and 2 nuts. BOLT LENGTH Item Length Bolt A 40 mm (1.57 in.) Bolt B 55 mm (2.17 in.) Bolt C 25 mm (0.984 in.) NOTE: Make sure that there is no oil on the threads of bolt B and C. Fully tighten the bolts in area 1 and area 2. Torque: 21 N*m (214 kgf*cm, 15 ft.*lbf) Fully tighten the bolts and nuts in area 3. Torque: 21 N*m (214 kgf*cm, 15 ft.*lbf) HINT: Tighten the bolts and nuts from top to bottom as shown in the illustration. Fully tighten the bolts in area 4. Bolt A Torque: 43 N*m (438 kgf*cm, 32 ft.*lbf) Except bolt A Torque: 21 N*m (214 kgf*cm, 15 ft.*lbf) HINT: Tighten the bolts from bottom to top as shown in the illustration.
  3. INSTALL OIL PAN SUB-ASSEMBLY . Refer to «REASSEMBLY [07/2012 - ] - Step 37»(ref-602689-S26119083832014030500000)
  4. INSTALL OIL STRAINER SUB-ASSEMBLY . Refer to «REASSEMBLY [07/2012 - ] - Step 38»(ref-602689-S26119083832014030500000)
  5. INSTALL NO. 2 OIL PAN SUB-ASSEMBLY . Refer to «REASSEMBLY [07/2012 - ] - Step 39»(ref-602689-S26119083832014030500000)
  6. INSTALL CYLINDER HEAD COVER SUB-ASSEMBLY (for Bank 1) . Refer to «REASSEMBLY [07/2012 - ] - Step 41»(ref-602689-S26119083832014030500000)
  7. INSTALL CYLINDER HEAD COVER SUB-ASSEMBLY (for Bank 2) . Refer to «REASSEMBLY [07/2012 - ] - Step 42»(ref-602689-S26119083832014030500000)
  8. INSTALL WATER INLET HOUSING . Refer to «REASSEMBLY [07/2012 - ] - Step 34»(ref-602689-S26119083832014030500000)
  9. INSTALL OIL COOLER PIPE (w/ oil cooler) Install a new gasket to the oil pan sub-assembly. Install the oil cooler pipe with the bolt and 2 nuts. Torque: 21 N*m (214 kgf*cm, 15 ft.*lbf)
  10. INSTALL CRANKSHAFT PULLEY . Refer to «INSTALLATION [07/2012 - ] - Step 2»(ref-602689-S02827794112014030500000)
  11. INSTALL NO. 1 OIL PIPE . Refer to «REASSEMBLY [07/2012 - ] - Step 50»(ref-602689-S26119083832014030500000)
  12. INSTALL OIL PIPE . Refer to «REASSEMBLY [07/2012 - ] - Step 51»(ref-602689-S26119083832014030500000)
  13. INSTALL ENGINE HANGERS . Refer to «INSTALLATION [03/2012 - ] - Step 21»(ref-602689-S03941313262014030500000)
  14. REMOVE ENGINE STAND
  15. INSTALL ENGINE ASSEMBLY WITH TRANSAXLE HINT: for U660E: Refer to «INSTALLATION [07/2012 - ]»(ref-602716-S14070525152014030500000) for U660F: Refer to «INSTALLATION [07/2012 - ]»(ref-602717-S04326225562014030500000) for U880F: Refer to «INSTALLATION [07/2012 - ]»(ref-602718-S28579097392014030500000)

Scheme 45

Scheme 45: ILLUSTRATION
Scheme 45: ILLUSTRATION

Scheme 46

Scheme 46: REMOVAL [03/2012 - ]
Scheme 46: REMOVAL [03/2012 - ]

Scheme 47

Scheme 47
Scheme 47
  1. DRAIN ENGINE COOLANT . Refer to «REPLACEMENT [03/2012 - 07/2012] - Step 6»(ref-602691-S30560292782014030500000)
  2. DRAIN ENGINE OIL See step 1
  3. REMOVE EXHAUST MANIFOLD SUB-ASSEMBLY LH Refer to «REMOVAL [03/2012 - 07/2012]»(ref-602713-S15707392572014030500000)
  4. REMOVE OIL COOLER ASSEMBLY Remove the bolt, 2 clamps, 4 clips, No. 4 water by-pass hose and No. 5 water by-pass hose. TEXT IN ILLUSTRATION *A for TMMC Made *B for TMC Made Remove the oil cooler union bolt, oil cooler assembly and O-ring.

Scheme 48

Scheme 48: INSPECTION [03/2012 - ]
Scheme 48: INSPECTION [03/2012 - ]
  1. INSPECT OIL COOLER ASSEMBLY Visually check the oil cooler assembly for cracks or damage. Blow air into the oil cooler assembly to check for clogging. If necessary, replace the oil cooler assembly.

INSTALLATION [03/2012 - ]

  1. INSTALL OIL COOLER ASSEMBLY Clean the oil cooler assembly contact surface on the mounting area of the engine assembly. Install a new O-ring to the oil cooler assembly. Install the oil cooler assembly with the oil cooler union bolt. Torque: 68 N*m (693 kgf*cm, 50 ft.*lbf) Install the No. 4 water by-pass hose and No. 5 water by-pass hose with the bolt, 2 clamps and 4 clips. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf)
  2. INSTALL EXHAUST MANIFOLD SUB-ASSEMBLY LH Refer to «INSTALLATION [03/2012 - 07/2012]»(ref-602713-S32659287542014030500000)
  3. ADD ENGINE COOLANT . Refer to «REPLACEMENT [03/2012 - 07/2012] - Step 7»(ref-602691-S30560292782014030500000)
  4. ADD ENGINE OIL See step 4
  5. INSPECT FOR COOLANT LEAK . Refer to «ON-VEHICLE INSPECTION [03/2012 - ] - Step 1»(ref-602725-S34080696782014030500000)
  6. INSPECT FOR OIL LEAK Start the engine. Check for engine oil leaks from the oil cooler assembly and the oil cooler union bolt.
  7. CHECK ENGINE OIL LEVEL . Refer to «ON-VEHICLE INSPECTION [03/2012 - ] - Step 1»(ref-602727-S12818145342014030500000)
