Horns (Service Information): Overview Lexus RX III рестайлинг

Scheme 3

Scheme 4

1. REMOVE FRONT BUMPER ASSEMBLY (for Standard) Refer to «REMOVAL [03/2012 - ]»(ref-602726-S35586298562014030500000)
2. REMOVE FRONT BUMPER ASSEMBLY (for Sport Package) Refer to «REMOVAL [03/2012 - ]»(ref-602726-S31616661682014030500000)
3. REMOVE LOW PITCHED HORN ASSEMBLY Disconnect the connector. Remove the bolt and low pitched horn assembly.

Scheme 5

1. INSPECT LOW PITCHED HORN ASSEMBLY Apply battery voltage and check the operation of the horn according to the table below. OK Measurement Condition Specified Condition Battery positive (+) --> Terminal 1 Battery negative (-) --> Body ground Horn sounds If the result is not as specified, replace the low pitched horn assembly.
