Engine Cooling System (Service Information): Removal & Installation Lexus RX III рестайлинг

REPLACEMENT [07/2012 - ]

1. REMOVE ENGINE ROOM SIDE COVER LH . Refer to «REMOVAL [03/2012 - ] - Step 2»(ref-602726-S35458032282014030500000)
2. REMOVE ENGINE ROOM SIDE COVER . Refer to «REMOVAL [03/2012 - ] - Step 1»(ref-602726-S35458032282014030500000)
3. REMOVE COOL AIR INTAKE DUCT SEAL . Refer to «REMOVAL [03/2012 - ] - Step 3»(ref-602726-S35458032282014030500000)
4. REMOVE V-BANK COVER SUB-ASSEMBLY . Refer to «REMOVAL [07/2012 - ] - Step 34»(ref-602689-S23172420682014030500000)
5. REMOVE NO. 1 ENGINE UNDER COVER
6. DRAIN ENGINE COOLANT Loosen the radiator drain cock plug and drain the coolant. NOTE: Do not remove the radiator cap, cylinder block drain cock plugs and radiator drain cock plug while the engine and radiator are still hot. Pressurized, hot engine coolant and steam may be released and cause serious burns. HINT: Collect the coolant in a container and dispose of it according to the regulations in your area. Remove the radiator cap from the radiator assembly. Loosen the 2 cylinder block drain cock plugs. TEXT IN ILLUSTRATION *1 Air Drain Cock Plug *2 Radiator Cap *3 Cylinder Block Drain Cock Plug *4 Radiator Drain Cock Plug
7. ADD ENGINE COOLANT Tighten the radiator drain cock plug by hand. Tighten the 2 cylinder block drain cock plugs. Torque: 13 N*m (130 kgf*cm, 9 ft.*lbf) Remove the radiator cap. Loosen the air drain cock plug on the water inlet housing. Add TOYOTA Super Long Life Coolant (SLLC) to the radiator inlet opening until coolant overflows from the air drain cock hole. Then tighten the air drain cock plug to the water inlet housing. Torque: 13 N*m (130 kgf*cm, 9 ft.*lbf) Slowly fill the radiator with TOYOTA Super Long Life Coolant (SLLC). STANDARD CAPACITY Item Capacity Engine coolant (w/o Towing package) 8.5 liters (9.0 US qts, 7.5 lmp. qts) Engine coolant (w/ Towing package) 9.5 liters (10.0 US qts, 8.3 lmp. qts) HINT: TOYOTA vehicles are filled with TOYOTA SLLC at the factory. In order to avoid damage to the engine cooling system and other technical problems, only use TOYOTA SLLC or similar high quality ethylene glycol based non-silicate, non-amine, non-nitrite, non-borate coolant with long-life hybrid organic acid technology (coolant with long-life hybrid organic acid technology is a combination of low phosphates and organic acids). NOTE: Never use water as a substitute for engine coolant. Tighten the air drain plug. Slowly pour coolant into the radiator reservoir tank until it reaches the FULL line. TEXT IN ILLUSTRATION *1 FULL Line Install the radiator cap. Squeeze the No. 1 and No. 2 radiator hoses several times by hand, and then check the level of the coolant. If the coolant level is low, add coolant. Bleed air from the cooling system. Warm up the engine until the thermostat opens. While the thermostat is open, circulate the coolant for several minutes. HINT: The thermostat open timing can be confirmed by squeezing the No. 2 radiator hose by hand, and checking when the engine coolant starts to flow inside the hose. Maintain the engine speed at 2500 to 3000 RPM. Squeeze the inlet and No. 1 and No. 2 radiator hoses several times by hand to bleed air. WARNING: When squeezing the radiator hoses: Wear protective gloves. Be careful as the radiator hoses are hot. Keep your hands away from the cooling fans. NOTE: Make sure that the radiator reservoir still has some coolant in it. If the coolant temperature gauge indicates an excessive temperature, turn off the engine and let it cool. If there is not enough coolant, the engine may overheat or be seriously damaged. If the radiator reservoir does not have enough coolant, perform the following: 1) stop the engine, 2) wait until the coolant has cooled down, and 3) add coolant until the reservoir is filled to the FULL line. Stop the engine and wait until the engine coolant cools down. Add engine coolant to the FULL line on the radiator reservoir.
8. INSPECT FOR COOLANT LEAK . Refer to «ON-VEHICLE INSPECTION [03/2012 - ] - Step 1»(ref-602725-S34080696782014030500000)
9. INSTALL NO. 1 ENGINE UNDER COVER
10. INSTALL V-BANK COVER SUB-ASSEMBLY . Refer to «INSTALLATION [07/2012 - ] - Step 113»(ref-602689-S30369469832014030500000)
11. INSTALL COOL AIR INTAKE DUCT SEAL . Refer to «INSTALLATION [03/2012 - ] - Step 3»(ref-602726-S31393395272014030500000)
12. INSTALL ENGINE ROOM SIDE COVER . Refer to «INSTALLATION [03/2012 - ] - Step 5»(ref-602726-S31393395272014030500000)
13. INSTALL ENGINE ROOM SIDE COVER LH . Refer to «INSTALLATION [03/2012 - ] - Step 4»(ref-602726-S31393395272014030500000)

Scheme 3

Scheme 4

1. REMOVE V-RIBBED BELT Refer to «REMOVAL [03/2012 - 07/2012]»(ref-602689-S17268304812014030500000) .
2. INSPECT WATER PUMP ASSEMBLY Turn the pulley, and check that the water pump bearing moves smoothly and noiselessly. If the bearing does not move smoothly and noiselessly, replace the water pump.
3. INSTALL V-RIBBED BELT Refer to «INSTALLATION [03/2012 - 07/2012]»(ref-602689-S38725693222014030500000) .

Scheme 5

Scheme 6

1. REMOVE AUTOMATIC TRANSAXLE ASSEMBLY HINT: Remove automatic transaxle assembly for 2WD. Refer to «REMOVAL [03/2012 - 07/2012] - Step 98»(ref-602689-S14087581402014030500000) . Remove automatic transaxle assembly for AWD. Refer to «REMOVAL [03/2012 - 07/2012] - Step 99»(ref-602689-S14087581402014030500000) .
2. INSTALL ENGINE ON ENGINE STAND . Refer to «REMOVAL [03/2012 - ] - Step 1»(ref-602689-S40231256012014030500000)
3. REMOVE ENGINE HANGER . Refer to «REMOVAL [03/2012 - ] - Step 2»(ref-602689-S40231256012014030500000)
4. REMOVE NO. 1 FRONT ENGINE MOUNTING BRACKET LH . Refer to «DISASSEMBLY [03/2012 - 07/2012] - Step 16»(ref-602689-S12257874642014030500000)
5. REMOVE NO. 2 IDLER PULLEY SUB-ASSEMBLY . Refer to «REMOVAL [03/2012 - ] - Step 17»(ref-602689-S40231256012014030500000)
6. REMOVE V-RIBBED BELT TENSIONER ASSEMBLY . Refer to «REMOVAL [03/2012 - ] - Step 14»(ref-602689-S40231256012014030500000)
7. REMOVE WATER INLET HOUSING . Refer to «DISASSEMBLY [03/2012 - 07/2012] - Step 17»(ref-602689-S12257874642014030500000)
8. REMOVE WATER PUMP PULLEY Using SST, hold the water pump pulley. SST: 09960-10010 09962-01000 09963-00700 Remove the 4 bolts and water pump pulley.
9. REMOVE WATER PUMP ASSEMBLY Remove the 16 bolts, water pump assembly and water pump gasket.

REMOVAL [07/2012 - ]

1. REMOVE AUTOMATIC TRANSAXLE ASSEMBLY (for U660E) Refer to «REMOVAL [07/2012 - ]»(ref-602716-S37924994172014030500000)
2. REMOVE AUTOMATIC TRANSAXLE ASSEMBLY (for U660F) Refer to «REMOVAL [07/2012 - ]»(ref-602717-S25966124322014030500000)
3. REMOVE AUTOMATIC TRANSAXLE ASSEMBLY (for U880F) Refer to «REMOVAL [07/2012 - ]»(ref-602718-S00289177742014030500000)
4. INSTALL ENGINE ON ENGINE STAND . Refer to «REMOVAL [03/2012 - ] - Step 1»(ref-602689-S40231256012014030500000)
5. REMOVE ENGINE HANGER . Refer to «REMOVAL [03/2012 - ] - Step 2»(ref-602689-S40231256012014030500000)
6. REMOVE NO. 1 FRONT ENGINE MOUNTING BRACKET LH . Refer to «DISASSEMBLY [07/2012 - ] - Step 16»(ref-602689-S26904166172014030500000)
7. REMOVE NO. 2 IDLER PULLEY SUB-ASSEMBLY . Refer to «REMOVAL [03/2012 - ] - Step 17»(ref-602689-S40231256012014030500000)
8. REMOVE V-RIBBED BELT TENSIONER ASSEMBLY . Refer to «REMOVAL [03/2012 - ] - Step 14»(ref-602689-S40231256012014030500000)
9. REMOVE WATER INLET HOUSING . Refer to «DISASSEMBLY [07/2012 - ] - Step 17»(ref-602689-S26904166172014030500000)
10. REMOVE WATER PUMP PULLEY Using SST, hold the water pump pulley. SST: 09960-10010 09962-01000 09963-00700 Remove the 4 bolts and water pump pulley.
11. REMOVE WATER PUMP ASSEMBLY Remove the 16 bolts, water pump assembly and water pump gasket.

Scheme 7

Scheme 8

1. INSTALL WATER PUMP ASSEMBLY Install a new water pump gasket and the water pump assembly with the 16 bolts. Bolt A Torque: 21 N*m (214 kgf*cm, 15 ft.*lbf) Bolts B and C Torque: 11 N*m (112 kgf*cm, 8 ft.*lbf) NOTE: Make sure that there is no oil on the threads of bolts A. Be sure to replace 2 bolts C with new ones or reuse them after applying adhesive 1344. Adhesive Toyota Genuine Adhesive 1344, Three Bond 1344 or equivalent
2. INSTALL WATER PUMP PULLEY Temporarily install the water pump pulley with the 4 bolts. Using SST, hold the water pump pulley. SST: 09960-10010 09962-01000 09963-00700 Tighten the 4 bolts. Torque: 21 N*m (214 kgf*cm, 15 ft.*lbf)
3. INSTALL WATER INLET HOUSING . Refer to «REASSEMBLY [03/2012 - 07/2012] - Step 34»(ref-602689-S20579706002014030500000)
4. INSTALL V-RIBBED BELT TENSIONER ASSEMBLY . Refer to «INSTALLATION [03/2012 - ] - Step 9»(ref-602689-S03941313262014030500000)
5. INSTALL NO. 2 IDLER PULLEY SUB-ASSEMBLY . Refer to «INSTALLATION [03/2012 - ] - Step 7»(ref-602689-S03941313262014030500000)
6. INSTALL NO. 1 FRONT ENGINE MOUNTING BRACKET LH . Refer to «REASSEMBLY [03/2012 - 07/2012] - Step 35»(ref-602689-S20579706002014030500000)
7. INSTALL ENGINE HANGER . Refer to «INSTALLATION [03/2012 - ] - Step 21»(ref-602689-S03941313262014030500000)
8. REMOVE ENGINE STAND
9. INSTALL AUTOMATIC TRANSAXLE ASSEMBLY HINT: Install automatic transaxle assembly for 2WD. Refer to «INSTALLATION [03/2012 - 07/2012] - Step 5»(ref-602689-S39902766612014030500000) . Install automatic transaxle assembly for AWD. Refer to «INSTALLATION [03/2012 - 07/2012] - Step 6»(ref-602689-S39902766612014030500000) .

INSTALLATION [07/2012 - ]

1. INSTALL WATER PUMP ASSEMBLY Install a new water pump gasket and the water pump assembly with the 16 bolts. Bolt A Torque: 21 N*m (214 kgf*cm, 15 ft.*lbf) Bolts B and C Torque: 11 N*m (112 kgf*cm, 8 ft.*lbf) NOTE: Make sure that there is no oil on the threads of bolts A. Be sure to replace 2 bolts C with new ones or reuse them after applying adhesive 1344. Adhesive Toyota Genuine Adhesive 1344, Three Bond 1344 or equivalent
2. INSTALL WATER PUMP PULLEY Temporarily install the water pump pulley with the 4 bolts. Using SST, hold the water pump pulley. SST: 09960-10010 09962-01000 09963-00700 Tighten the 4 bolts. Torque: 21 N*m (214 kgf*cm, 15 ft.*lbf)
3. INSTALL WATER INLET HOUSING . Refer to «REASSEMBLY [07/2012 - ] - Step 34»(ref-602689-S26119083832014030500000)
4. INSTALL V-RIBBED BELT TENSIONER ASSEMBLY . Refer to «INSTALLATION [03/2012 - ] - Step 9»(ref-602689-S03941313262014030500000)
5. INSTALL NO. 2 IDLER PULLEY SUB-ASSEMBLY . Refer to «INSTALLATION [03/2012 - ] - Step 7»(ref-602689-S03941313262014030500000)
6. INSTALL NO. 1 FRONT ENGINE MOUNTING BRACKET LH . Refer to «REASSEMBLY [07/2012 - ] - Step 35»(ref-602689-S26119083832014030500000)
7. INSTALL ENGINE HANGER . Refer to «INSTALLATION [03/2012 - ] - Step 21»(ref-602689-S03941313262014030500000)
8. REMOVE ENGINE STAND
9. INSTALL AUTOMATIC TRANSAXLE ASSEMBLY (for U660E) Refer to «INSTALLATION [07/2012 - ]»(ref-602716-S14070525152014030500000)
10. INSTALL AUTOMATIC TRANSAXLE ASSEMBLY (for U660F) Refer to «INSTALLATION [07/2012 - ]»(ref-602717-S04326225562014030500000)
11. INSTALL AUTOMATIC TRANSAXLE ASSEMBLY (for U880F) Refer to «INSTALLATION [07/2012 - ]»(ref-602718-S28579097392014030500000)

Scheme 9

Scheme 10

Scheme 11

Scheme 12

1. REMOVE FRONT WHEEL RH
2. REMOVE NO. 1 ENGINE UNDER COVER
3. REMOVE FRONT FENDER LINER RH
4. REMOVE FRONT FENDER APRON SEAL RH . Refer to «REMOVAL [03/2012 - 07/2012] - Step 16»(ref-602689-S14087581402014030500000)
5. REMOVE ENGINE ROOM SIDE COVER LH . Refer to «REMOVAL [03/2012 - ] - Step 2»(ref-602726-S35458032282014030500000)
6. REMOVE ENGINE ROOM SIDE COVER . Refer to «REMOVAL [03/2012 - ] - Step 1»(ref-602726-S35458032282014030500000)
7. REMOVE COOL AIR INTAKE DUCT SEAL . Refer to «REMOVAL [03/2012 - ] - Step 3»(ref-602726-S35458032282014030500000)
8. DRAIN ENGINE COOLANT See step 6
9. REMOVE V-BANK COVER SUB-ASSEMBLY . Refer to «REMOVAL [03/2012 - 07/2012] - Step 33»(ref-602689-S14087581402014030500000)
10. REMOVE V-RIBBED BELT . Refer to «REMOVAL [03/2012 - 07/2012] - Step 4»(ref-602689-S20723867262014030500000)
11. DISCONNECT NO. 2 RADIATOR HOSE Disconnect the No. 2 radiator hose from the water inlet.
12. REMOVE NO. 2 IDLER PULLEY SUB-ASSEMBLY . Refer to «REMOVAL [03/2012 - ] - Step 17»(ref-602689-S40231256012014030500000)
13. REMOVE WATER INLET Remove the 2 nuts and water inlet.
14. REMOVE THERMOSTAT Remove the thermostat from the water inlet housing. Remove the gasket from the thermostat.

1. REMOVE FRONT WHEEL RH
2. REMOVE NO. 1 ENGINE UNDER COVER
3. REMOVE FRONT FENDER LINER RH
4. REMOVE FRONT FENDER APRON SEAL RH . Refer to «REMOVAL [07/2012 - ] - Step 16»(ref-602689-S23172420682014030500000)
5. REMOVE ENGINE ROOM SIDE COVER LH . Refer to «REMOVAL [03/2012 - ] - Step 2»(ref-602726-S35458032282014030500000)
6. REMOVE ENGINE ROOM SIDE COVER . Refer to «REMOVAL [03/2012 - ] - Step 1»(ref-602726-S35458032282014030500000)
7. REMOVE COOL AIR INTAKE DUCT SEAL . Refer to «REMOVAL [03/2012 - ] - Step 3»(ref-602726-S35458032282014030500000)
8. DRAIN ENGINE COOLANT See step 6
9. REMOVE V-BANK COVER SUB-ASSEMBLY . Refer to «REMOVAL [07/2012 - ] - Step 34»(ref-602689-S23172420682014030500000)
10. REMOVE V-RIBBED BELT . Refer to «REMOVAL [07/2012 - ] - Step 4»(ref-602689-S33103005672014030500000)
11. DISCONNECT NO. 2 RADIATOR HOSE Disconnect the No. 2 radiator hose from the water inlet.
12. REMOVE NO. 2 IDLER PULLEY SUB-ASSEMBLY . Refer to «REMOVAL [03/2012 - ] - Step 17»(ref-602689-S40231256012014030500000)
13. REMOVE WATER INLET Remove the 2 nuts and water inlet.
14. REMOVE THERMOSTAT Remove the thermostat from the water inlet housing. Remove the gasket from the thermostat.

Scheme 13

Scheme 14

Scheme 15

1. INSPECT THERMOSTAT Inspect the thermostat. HINT: The valve opening temperature is inscribed on the thermostat. Immerse the thermostat in water and gradually heat the water. Check the valve opening temperature. Standard valve opening temperature 80 to 84°C (176 to 183°F) If the valve opening temperature is not as specified, replace the thermostat. Check the valve lift. Standard valve lift 10 mm (0.394 in.) or more at 95°C (203°F) If the valve lift is not as specified, replace the thermostat. Check that the valve is fully closed when the thermostat is at low temperatures (below 40°C (104°F)). If it is not fully closed, replace the thermostat.

Scheme 16

1. INSTALL THERMOSTAT Install a new gasket to the thermostat. TEXT IN ILLUSTRATION *1 Jiggle Valve Install the thermostat with the jiggle valve facing up. HINT: The jiggle valve may be set within 10° on either side of the prescribed position.
2. INSTALL WATER INLET Install the water inlet with the 2 nuts. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf)
3. INSTALL NO. 2 IDLER PULLEY SUB-ASSEMBLY . Refer to «INSTALLATION [03/2012 - ] - Step 7»(ref-602689-S03941313262014030500000)
4. CONNECT NO. 2 RADIATOR HOSE Connect the No. 2 radiator hose to the water inlet.
5. INSTALL V-RIBBED BELT . Refer to «INSTALLATION [03/2012 - 07/2012] - Step 1»(ref-602689-S30635879092014030500000)
6. ADD ENGINE COOLANT See step 7
7. WARM UP ENGINE . Refer to «REPLACEMENT [03/2012 - ] - Step 3»(ref-602698-S41932265312014030500000)
8. INSPECT FOR COOLANT LEAK . Refer to «ON-VEHICLE INSPECTION [03/2012 - ] - Step 1»(ref-602725-S34080696782014030500000)
9. INSTALL V-BANK COVER SUB-ASSEMBLY . Refer to «INSTALLATION [03/2012 - 07/2012] - Step 108»(ref-602689-S39902766612014030500000)
10. INSTALL COOL AIR INTAKE DUCT SEAL . Refer to «INSTALLATION [03/2012 - ] - Step 3»(ref-602726-S31393395272014030500000)
11. INSTALL ENGINE ROOM SIDE COVER . Refer to «INSTALLATION [03/2012 - ] - Step 5»(ref-602726-S31393395272014030500000)
12. INSTALL ENGINE ROOM SIDE COVER LH . Refer to «INSTALLATION [03/2012 - ] - Step 4»(ref-602726-S31393395272014030500000)
13. INSTALL FRONT FENDER APRON SEAL RH . Refer to «INSTALLATION [03/2012 - 07/2012] - Step 110»(ref-602689-S39902766612014030500000)
14. INSTALL FRONT FENDER LINER RH
15. INSTALL NO. 1 ENGINE UNDER COVER
16. INSTALL FRONT WHEEL RH

1. INSTALL THERMOSTAT Install a new gasket to the thermostat. TEXT IN ILLUSTRATION *1 Jiggle Valve Install the thermostat with the jiggle valve facing up. HINT: The jiggle valve may be set within 10° on either side of the prescribed position.
2. INSTALL WATER INLET Install the water inlet with the 2 nuts. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf)
3. INSTALL NO. 2 IDLER PULLEY SUB-ASSEMBLY . Refer to «INSTALLATION [03/2012 - ] - Step 7»(ref-602689-S03941313262014030500000)
4. CONNECT NO. 2 RADIATOR HOSE Connect the No. 2 radiator hose to the water inlet.
5. INSTALL V-RIBBED BELT . Refer to «INSTALLATION [07/2012 - ] - Step 1»(ref-602689-S02216099562014030500000)
6. ADD ENGINE COOLANT See step 7
7. WARM UP ENGINE . Refer to «REPLACEMENT [03/2012 - ] - Step 3»(ref-602698-S41932265312014030500000)
8. INSPECT FOR COOLANT LEAK . Refer to «ON-VEHICLE INSPECTION [03/2012 - ] - Step 1»(ref-602725-S34080696782014030500000)
9. INSTALL V-BANK COVER SUB-ASSEMBLY . Refer to «INSTALLATION [07/2012 - ] - Step 113»(ref-602689-S30369469832014030500000)
10. INSTALL COOL AIR INTAKE DUCT SEAL . Refer to «INSTALLATION [03/2012 - ] - Step 3»(ref-602726-S31393395272014030500000)
11. INSTALL ENGINE ROOM SIDE COVER . Refer to «INSTALLATION [03/2012 - ] - Step 5»(ref-602726-S31393395272014030500000)
12. INSTALL ENGINE ROOM SIDE COVER LH . Refer to «INSTALLATION [03/2012 - ] - Step 4»(ref-602726-S31393395272014030500000)
13. INSTALL FRONT FENDER APRON SEAL RH . Refer to «INSTALLATION [07/2012 - ] - Step 115»(ref-602689-S30369469832014030500000)
14. INSTALL FRONT FENDER LINER RH
15. INSTALL NO. 1 ENGINE UNDER COVER
16. INSTALL FRONT WHEEL RH

Scheme 17

Scheme 18

Scheme 19

1. INSPECT COOLING FAN MOTOR Check that the motor operates smoothly when the battery is connected to the cooling fan motor connector. TEXT IN ILLUSTRATION *1 Front view of wire harness connector (to Cooling Fan ECU) If the motor does not operate smoothly, replace the cooling fan motor. Connect the pickup of a clamp-on ammeter over one of the two wires for the cooling fan motor. Measure the current while the motor is operating. Item Condition Specified Condition Cooling fan motor (w/o Towing package) 20°C (68°F) 11.8 to 14.8 A at 12 V Cooling fan motor (w/ Towing package) 20°C (68°F) 14.1 to 18.1 A at 12 V If the result is not as specified, replace the cooling fan motor.
2. INSPECT NO. 2 COOLING FAN MOTOR Check that the motor operates smoothly when the battery is connected to the No. 2 cooling fan motor connector. TEXT IN ILLUSTRATION *1 Front view of wire harness connector (to Cooling Fan ECU) If the motor does not operate smoothly, replace the No. 2 cooling fan motor. Connect the pickup of a clamp-on ammeter over one of the two wires for the No. 2 cooling fan motor. Measure the current while the motor is operating. Item Condition Specified Condition Cooling fan motor (w/o Towing package) 20°C (68°F) 8.4 to 10.4 A at 12 V Cooling fan motor (w/ Towing package) 20°C (68°F) 15.1 to 17.1 A at 12 V If the result is not as specified, replace the No. 2 cooling fan motor.

Scheme 20

Scheme 21

Scheme 22

Scheme 23

Scheme 24

Scheme 25

1. REMOVE RADIATOR ASSEMBLY AND FAN ASSEMBLY WITH MOTOR HINT: Refer to «REMOVAL [03/2012 - 07/2012]»(ref-602691-S18313502082014030500000)
2. REMOVE FAN Remove the nut and fan.
3. REMOVE NO. 2 FAN Remove the nut and No. 2 fan.
4. REMOVE COOLING FAN MOTOR Disconnect the cooling fan motor connector and clamp. Remove the 3 screws and cooling fan motor.
5. REMOVE NO. 2 COOLING FAN MOTOR Disconnect the No. 2 cooling fan motor connector and clamp. Remove the 3 screws and No. 2 cooling fan motor.

1. REMOVE RADIATOR ASSEMBLY AND FAN ASSEMBLY WITH MOTOR HINT: Refer to «REMOVAL [07/2012 - ]»(ref-602691-S10594216172014030500000)
2. REMOVE FAN Remove the nut and fan.
3. REMOVE NO. 2 FAN Remove the nut and No. 2 fan.
4. REMOVE COOLING FAN MOTOR Disconnect the cooling fan motor connector and clamp. Remove the 3 screws and cooling fan motor.
5. REMOVE NO. 2 COOLING FAN MOTOR Disconnect the No. 2 cooling fan motor connector and clamp. Remove the 3 screws and No. 2 cooling fan motor.

INSTALLATION [03/2012 - 07/2012]

1. INSTALL NO. 2 COOLING FAN MOTOR Install the No. 2 cooling fan motor with the 3 screws. Torque: 3.9 N*m (40 kgf*cm, 35 in.*lbf) Connect the No. 2 cooling fan motor connector and clamp.
2. INSTALL COOLING FAN MOTOR Install the cooling fan motor with the 3 screws. Torque: 3.9 N*m (40 kgf*cm, 35 in.*lbf) Connect the cooling fan motor connector and clamp.
3. INSTALL NO. 2 FAN Install the No. 2 fan with the nut. Torque: 6.3 N*m (64 kgf*cm, 56 in.*lbf)
4. INSTALL FAN Install the fan with the nut. Torque: 6.3 N*m (64 kgf*cm, 56 in.*lbf)
5. INSTALL RADIATOR ASSEMBLY AND FAN ASSEMBLY WITH MOTOR HINT: Refer to «INSTALLATION [03/2012 - 07/2012]»(ref-602691-S11045437542014030500000)

1. INSTALL NO. 2 COOLING FAN MOTOR Install the No. 2 cooling fan motor with the 3 screws. Torque: 3.9 N*m (40 kgf*cm, 35 in.*lbf) Connect the No. 2 cooling fan motor connector and clamp.
2. INSTALL COOLING FAN MOTOR Install the cooling fan motor with the 3 screws. Torque: 3.9 N*m (40 kgf*cm, 35 in.*lbf) Connect the cooling fan motor connector and clamp.
3. INSTALL NO. 2 FAN Install the No. 2 fan with the nut. Torque: 6.3 N*m (64 kgf*cm, 56 in.*lbf)
4. INSTALL FAN Install the fan with the nut. Torque: 6.3 N*m (64 kgf*cm, 56 in.*lbf)
5. INSTALL RADIATOR ASSEMBLY AND FAN ASSEMBLY WITH MOTOR HINT: Refer to «INSTALLATION [07/2012 - ]»(ref-602691-S38924193342014030500000)

Scheme 26

1. INSPECT COOLING FAN ECU Put the vehicle in the following conditions: Turn the engine switch off. The coolant temperature is less than 95°C (203°F). The battery voltage is between 9 and 14 V. The A/C switch is off. Clamp the 400 A probe of an ammeter over the M+ wire of each cooling fan motor. Turn the engine switch on (IG) and wait for approximately 10 seconds. Check that the fan stops. Start the engine. Check that the fan is stopped with the engine idling. HINT: Make sure that the radiator engine coolant temperature is less than 95°C (203°F). Make sure that the A/C switch is off. Check that the fan operates when the A/C switch is turned on (MAX COOL and the magnetic clutch is operating). Standard Current Item Specified Condition Cooling fan motor 4 to 20 A No. 2 cooling fan motor 4 to 20 A HINT: The coolant temperature is less than 95°C (203°F). Check that the fan operates when the engine coolant temperature sensor connector is disconnected. Standard Current Item Specified Condition Cooling fan motor 4 to 20 A No. 2 cooling fan motor 4 to 20 A After the engine is warmed up, check that the fan operates as shown in the illustration. HINT: The coolant temperature at which the fan starts operating is approximately 97°C (207°F). This system can also be checked using the Techstream. Enter the following menus: Powertrain / Engine / Data List / Coolant Temp.

Scheme 27

Scheme 28

Scheme 29

Scheme 30

Scheme 31

Scheme 32

Scheme 33

1. CHECK RADIATOR CAP SUB-ASSEMBLY Measure the valve opening pressure. If there are water stains or foreign matter on rubber packings 1, 2 or 3, clean the part(s) with water and finger scouring. Check that rubber packings 1, 2 and 3 are not deformed, cracked or swollen. Check that 3 and 4 are not stuck together. Apply engine coolant to rubber packings 2 and 3 before using the radiator cap tester. When using the cap tester, tilt it to 30° or more above the horizontal. Pump the cap tester several times, and check the maximum pressure*. Pump speed 1 pump per second *: Even if the cap cannot maintain the maximum pressure, it is not a defect. Judgment Criterion Item Specified Condition Standard value (for brand-new cap) 94 to 122 kPa (1.0 to 1.2 kgf/cm 2 , 13.5 to 17.8 psi) Minimum standard value (for used cap) 79 kPa (0.8 kgf/cm 2 , 11.4 psi) If the measured maximum pressure is less than the minimum standard value, replace the radiator cap sub-assembly.

Scheme 34

Scheme 35

Scheme 36

Scheme 37

Scheme 38

Scheme 39

Scheme 40

Scheme 41

Scheme 42

Scheme 43

Scheme 44

Scheme 45

Scheme 46

1. PRECAUTION NOTE: After turning the engine switch off, waiting time may be required before disconnecting the cable from the negative (-) battery terminal. Therefore, make sure to read the disconnecting the cable from the negative (-) battery terminal notice before proceeding with work. Refer to «PRECAUTION [03/2012 - ]»(ref-602551-S11461672722014030500000) .
2. REMOVE NO. 1 ENGINE UNDER COVER
3. DRAIN ENGINE COOLANT See step 6
4. REMOVE V-BANK COVER SUB-ASSEMBLY . Refer to «REMOVAL [03/2012 - 07/2012] - Step 33»(ref-602689-S14087581402014030500000)
5. REMOVE NO. 2 AIR CLEANER INLET . Refer to «REMOVAL [03/2012 - 07/2012] - Step 34»(ref-602689-S14087581402014030500000)
6. REMOVE NO. 1 AIR CLEANER INLET . Refer to «REMOVAL [03/2012 - 07/2012] - Step 35»(ref-602689-S14087581402014030500000)
7. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL NOTE: When disconnecting the cable, some systems need to be initialized after the cable is reconnected. Refer to «INITIALIZATION [03/2012 - 07/2012]»(ref-602551-S24591545042014030500000) .
8. REMOVE BATTERY . Refer to «REMOVAL [03/2012 - 07/2012] - Step 36»(ref-602689-S14087581402014030500000)
9. REMOVE FRONT BUMPER ASSEMBLY (for Sport Package) Refer to «REMOVAL [03/2012 - ]»(ref-602726-S31616661682014030500000)
10. REMOVE FRONT BUMPER ASSEMBLY (for Standard) Refer to «REMOVAL [03/2012 - ]»(ref-602726-S35586298562014030500000)
11. REMOVE RADIATOR RESERVE TANK ASSEMBLY Disconnect the radiator reserve tank hose from the radiator. Disconnect the 2 clamps and remove the bolt and radiator reserve tank from the radiator.
12. DISCONNECT NO. 1 RADIATOR HOSE Disconnect the No. 1 radiator hose from the radiator.
13. DISCONNECT NO. 2 RADIATOR HOSE Disconnect the No. 2 radiator hose from the radiator.
14. DISCONNECT NO. 1 INLET OIL COOLER HOSE Disconnect the No. 1 inlet oil cooler hose and clamp from the radiator.
15. DISCONNECT NO. 1 OUTLET OIL COOLER HOSE Remove the No. 1 outlet oil cooler hose.
16. REMOVE MILLIMETER WAVE RADAR SENSOR ASSEMBLY (w/ Dynamic Radar Cruise Control System) . Refer to «REMOVAL [03/2012 - ] - Step 2»(ref-602562-S36233818662014030500000)
17. REMOVE LOW PITCHED HORN ASSEMBLY . Refer to «REMOVAL [03/2012 - ] - Step 3»(ref-602737-S01869269112014030500000)
18. REMOVE SMOG VENTILATION SENSOR . Refer to «REMOVAL [03/2012 - ] - Step 2»(ref-602698-S13460019402014030500000)
19. REMOVE HOOD LOCK CONTROL CABLE COVER . Refer to «REMOVAL [03/2012 - 07/2012] - Step 14»(ref-602738-S19368885742014030500000)
20. REMOVE HOOD LOCK ASSEMBLY . Refer to «REMOVAL [03/2012 - 07/2012] - Step 15»(ref-602738-S19368885742014030500000)
21. REMOVE UPPER RADIATOR SUPPORT Disconnect the 3 clamps of the hood lock control cable and remove the 5 bolts and upper radiator support.
22. REMOVE NO. 2 RADIATOR ASSEMBLY Remove the 2 radiator support cushions from the radiator. TEXT IN ILLUSTRATION *1 Radiator support cushion Remove the 4 bolts, 4 brackets and radiator assembly. TEXT IN ILLUSTRATION *1 Cooler Bracket Disconnect the 3 wire harness clamps and connector. Remove the radiator assembly and fan assembly with motor. NOTE: Do not apply any excessive force to the cooler condenser assembly or pipe when removing the radiator assembly. Remove the 2 lower radiator supports from the radiator. Remove the 2 bolts. Release the claw and pull up the fan assembly with motor from the radiator assembly to remove the fan assembly with motor. TEXT IN ILLUSTRATION *1 Claw *2 Guide

Scheme 47

Scheme 48

1. PRECAUTION NOTE: After turning the engine switch off, waiting time may be required before disconnecting the cable from the negative (-) battery terminal. Therefore, make sure to read the disconnecting the cable from the negative (-) battery terminal notice before proceeding with work. Refer to «PRECAUTION [03/2012 - ]»(ref-602551-S11461672722014030500000) .
2. REMOVE NO. 1 ENGINE UNDER COVER
3. DRAIN ENGINE COOLANT See step 6
4. REMOVE V-BANK COVER SUB-ASSEMBLY . Refer to «REMOVAL [07/2012 - ] - Step 34»(ref-602689-S23172420682014030500000)
5. REMOVE NO. 2 AIR CLEANER INLET . Refer to «REMOVAL [07/2012 - ] - Step 35»(ref-602689-S23172420682014030500000)
6. REMOVE NO. 1 AIR CLEANER INLET . Refer to «REMOVAL [07/2012 - ] - Step 36»(ref-602689-S23172420682014030500000)
7. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL NOTE: When disconnecting the cable from the negative (-) battery terminal, some systems need to be initialized after the cable is reconnected. Refer to «INITIALIZATION [07/2012 - ]»(ref-602551-S38908041872014030500000) .
8. REMOVE BATTERY . Refer to «REMOVAL [07/2012 - ] - Step 37»(ref-602689-S23172420682014030500000)
9. REMOVE FRONT BUMPER ASSEMBLY (for Sport Package) Refer to «REMOVAL [03/2012 - ]»(ref-602726-S31616661682014030500000)
10. REMOVE FRONT BUMPER ASSEMBLY (for Standard) Refer to «REMOVAL [03/2012 - ]»(ref-602726-S35586298562014030500000)
11. REMOVE RADIATOR RESERVE TANK ASSEMBLY Disconnect the radiator reserve tank hose from the No. 2 radiator assembly. Disconnect the 2 clamps and remove the bolt and radiator reserve tank assembly from the No. 2 radiator assembly.
12. DISCONNECT NO. 1 RADIATOR HOSE Disconnect the No. 1 radiator hose from the No. 2 radiator assembly.
13. DISCONNECT NO. 2 RADIATOR HOSE Disconnect the No. 2 radiator hose from the No. 2 radiator assembly.
14. DISCONNECT NO. 1 INLET OIL COOLER HOSE (for U660E, U660F) Disconnect the No. 1 inlet oil cooler hose and clamp from the No. 2 radiator assembly.
15. REMOVE NO. 1 INLET OIL COOLER HOSE (for U880F) . Refer to «REMOVAL [07/2012 - ] - Step 56»(ref-602689-S23172420682014030500000)
16. DISCONNECT NO. 1 OUTLET OIL COOLER HOSE (for U660E, U660F) Remove the No. 1 outlet oil cooler hose from the No. 2 radiator assembly.
17. REMOVE TRANSMISSION OIL COOLER HOSE (for U880F) Remove the transmission oil cooler hose and 2 hose clips. Remove the hose clamp from the transmission oil cooler hose.
18. REMOVE MILLIMETER WAVE RADAR SENSOR ASSEMBLY (w/ Dynamic Radar Cruise Control System) . Refer to «REMOVAL [03/2012 - ] - Step 2»(ref-602562-S36233818662014030500000)
19. REMOVE LOW PITCHED HORN ASSEMBLY . Refer to «REMOVAL [03/2012 - ] - Step 3»(ref-602737-S01869269112014030500000)
20. REMOVE SMOG VENTILATION SENSOR (w/ Smog Ventilation Sensor) . Refer to «REMOVAL [03/2012 - ] - Step 2»(ref-602698-S13460019402014030500000)
21. REMOVE HOOD LOCK CONTROL CABLE COVER . Refer to «REMOVAL [07/2012 - ] - Step 14»(ref-602738-S11511272832014030500000)
22. REMOVE HOOD LOCK ASSEMBLY . Refer to «REMOVAL [07/2012 - ] - Step 15»(ref-602738-S11511272832014030500000)
23. REMOVE UPPER RADIATOR SUPPORT Disconnect the 3 clamps of the hood lock control cable and remove the 5 bolts and upper radiator support.
24. REMOVE NO. 2 RADIATOR ASSEMBLY Remove the 2 radiator support cushions from the No. 2 radiator assembly. TEXT IN ILLUSTRATION *1 Radiator Support Cushion Remove the 4 bolts and 4 cooler brackets from the No. 2 radiator assembly. TEXT IN ILLUSTRATION *1 Cooler Bracket Disconnect the 3 wire harness clamps and connector. Remove the No. 2 radiator assembly and fan assembly with motor. NOTE: Do not apply excessive force to the cooler condenser assembly or pipe when removing the No. 2 radiator assembly. Remove the 2 lower radiator supports from the No. 2 radiator assembly. Remove the 2 bolts. Release the claw and pull up the fan assembly with motor from the No. 2 radiator assembly to remove the fan assembly with motor. TEXT IN ILLUSTRATION *1 Claw

Scheme 49

1. INSTALL NO. 2 RADIATOR ASSEMBLY Install the fan assembly with motor to the radiator with the 3 guides at the bottom and attach the claw. TEXT IN ILLUSTRATION *1 Claw *2 Guide Install the 2 bolts. Torque: 8.0 N*m (82 kgf*cm, 71 in.*lbf) Install the 2 lower radiator supports to the radiator, and radiator assembly and fan assembly with motor. NOTE: Do not apply any excessive force to the cooler condenser assembly or pipe when installing the radiator assembly. Connect the 3 wire harness clamps and connector. Install the radiator assembly with the 4 bolts and 4 brackets. TEXT IN ILLUSTRATION *1 Cooler bracket Torque: 6.0 N*m (61 kgf*cm, 53 in.*lbf) Install the 2 radiator support cushions. TEXT IN ILLUSTRATION *1 Radiator support cushion
2. INSTALL UPPER RADIATOR SUPPORT Install the upper radiator support with the 5 bolts and connect the 3 clamps of the hood lock control cable to the upper radiator support. TEXT IN ILLUSTRATION *1 Bolt Torque: 12 N*m (122 kgf*cm, 9 ft.*lbf)
3. INSTALL HOOD LOCK ASSEMBLY . Refer to «INSTALLATION [03/2012 - 07/2012] - Step 4»(ref-602738-S36692750422014030500000)
4. INSTALL HOOD LOCK CONTROL CABLE COVER . Refer to «INSTALLATION [03/2012 - 07/2012] - Step 5»(ref-602738-S36692750422014030500000)
5. INSTALL SMOG VENTILATION SENSOR . Refer to «INSTALLATION [03/2012 - ] - Step 1»(ref-602698-S20821361082014030500000)
6. INSTALL LOW PITCHED HORN ASSEMBLY . Refer to «INSTALLATION [03/2012 - ] - Step 1»(ref-602737-S07495332102014030500000)
7. INSTALL MILLIMETER WAVE RADAR SENSOR ASSEMBLY (w/ Dynamic Radar Cruise Control System) . Refer to «INSTALLATION [03/2012 - ] - Step 1»(ref-602562-S31722144932014030500000)
8. CONNECT NO. 1 OUTLET OIL COOLER HOSE Connect the No. 1 outlet oil cooler hose to the radiator.
9. CONNECT NO. 1 INLET OIL COOLER HOSE Connect the clamp and No. 1 inlet oil cooler hose to the radiator.
10. CONNECT NO. 2 RADIATOR HOSE Connect the No. 2 radiator hose to the radiator.
11. CONNECT NO. 1 RADIATOR HOSE Connect the No. 1 radiator hose to the radiator.
12. INSTALL RADIATOR RESERVE TANK ASSEMBLY Connect the radiator reserve tank hose to the radiator. Install the radiator reserve tank with the bolt and connect the 2 clamps to the radiator. Torque: 5.3 N*m (54 kgf*cm, 47 in.*lbf)
13. INSTALL FRONT BUMPER ASSEMBLY (for Sport Package) Refer to «INSTALLATION [03/2012 - ]»(ref-602726-S10254119152014030500000)
14. INSTALL FRONT BUMPER ASSEMBLY (for Standard) Refer to «INSTALLATION [03/2012 - ]»(ref-602726-S06902505152014030500000)
15. INSTALL BATTERY . Refer to «INSTALLATION [03/2012 - 07/2012] - Step 68»(ref-602689-S39902766612014030500000)
16. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL NOTE: When disconnecting the cable, some systems need to be initialized after the cable is reconnected. Refer to «INITIALIZATION [03/2012 - 07/2012]»(ref-602551-S24591545042014030500000) .
17. INSTALL NO. 1 AIR CLEANER INLET . Refer to «INSTALLATION [03/2012 - 07/2012] - Step 69»(ref-602689-S39902766612014030500000)
18. INSTALL NO. 2 AIR CLEANER INLET . Refer to «INSTALLATION [03/2012 - 07/2012] - Step 70»(ref-602689-S39902766612014030500000)
19. ADD ENGINE COOLANT See step 7
20. INSPECT FOR COOLANT LEAK . Refer to «ON-VEHICLE INSPECTION [03/2012 - ] - Step 1»(ref-602725-S34080696782014030500000)
21. INSPECT FOR AUTOMATIC TRANSAXLE FLUID LEAK
22. INSTALL NO. 1 ENGINE UNDER COVER
23. INSTALL V-BANK COVER SUB-ASSEMBLY . Refer to «INSTALLATION [03/2012 - 07/2012] - Step 108»(ref-602689-S39902766612014030500000)
24. ADJUST MILLIMETER WAVE RADAR SENSOR ASSEMBLY (w/ Dynamic Radar Cruise Control System) Refer to «ADJUSTMENT [03/2012 - ]»(ref-602562-S10556630812014030500000)

Scheme 50

Scheme 51

1. INSTALL NO. 2 RADIATOR ASSEMBLY Install the fan assembly with motor to the No. 2 radiator assembly with the 3 guides at the bottom and attach the claw. TEXT IN ILLUSTRATION *1 Claw *2 Guide Install the 2 bolts. Torque: 8.0 N*m (82 kgf*cm, 71 in.*lbf) Install the 2 lower radiator supports to the No. 2 radiator assembly, and No. 2 radiator assembly and fan assembly with motor. NOTE: Do not apply excessive force to the cooler condenser assembly or pipe when installing the No. 2 radiator assembly. Connect the 3 wire harness clamps and connector. Install the No. 2 radiator assembly with the 4 bolts and 4 cooler brackets. Torque: 6.0 N*m (61 kgf*cm, 53 in.*lbf) Install the 2 radiator support cushions to the No. 2 radiator assembly.
2. INSTALL UPPER RADIATOR SUPPORT Install the upper radiator support with the 5 bolts and connect the 3 clamps of the hood lock control cable to the upper radiator support. Torque: 12 N*m (122 kgf*cm, 9 ft.*lbf)
3. INSTALL HOOD LOCK ASSEMBLY . Refer to «INSTALLATION [07/2012 - ] - Step 4»(ref-602738-S34905636542014030500000)
4. INSTALL HOOD LOCK CONTROL CABLE COVER . Refer to «INSTALLATION [07/2012 - ] - Step 5»(ref-602738-S34905636542014030500000)
5. INSTALL SMOG VENTILATION SENSOR (w/ Smog Ventilation Sensor) . Refer to «INSTALLATION [03/2012 - ] - Step 1»(ref-602698-S20821361082014030500000)
6. INSTALL LOW PITCHED HORN ASSEMBLY . Refer to «INSTALLATION [03/2012 - ] - Step 1»(ref-602737-S07495332102014030500000)
7. INSTALL MILLIMETER WAVE RADAR SENSOR ASSEMBLY (w/ Dynamic Radar Cruise Control System) . Refer to «INSTALLATION [03/2012 - ] - Step 1»(ref-602562-S31722144932014030500000)
8. CONNECT NO. 1 OUTLET OIL COOLER HOSE (for U660E, U660F) Connect the No. 1 outlet oil cooler hose to the No. 2 radiator assembly.
9. INSTALL TRANSMISSION OIL COOLER HOSE (for U880F) Install the hose clamp to a new transmission oil cooler hose. TEXT IN ILLUSTRATION *1 Hose Clamp No. 2 Radiator Assembly Side Remove any foreign matter on the transmission oil cooler hose installation areas of the No. 2 radiator assembly and oil cooler assembly. Install the transmission oil cooler hose with 2 new hose clips.
10. CONNECT NO. 1 INLET OIL COOLER HOSE (for U660E, U660F) Connect the clamp and No. 1 inlet oil cooler hose to the No. 2 radiator assembly.
11. INSTALL NO. 1 INLET OIL COOLER HOSE (for U880F) . Refer to «INSTALLATION [07/2012 - ] - Step 58»(ref-602689-S30369469832014030500000)
12. CONNECT NO. 2 RADIATOR HOSE Connect the No. 2 radiator hose to the No. 2 radiator assembly.
13. CONNECT NO. 1 RADIATOR HOSE Connect the No. 1 radiator hose to the No. 2 radiator assembly.
14. INSTALL RADIATOR RESERVE TANK ASSEMBLY Install the radiator reserve tank assembly with the bolt and connect the 2 clamps to the No. 2 radiator assembly. Torque: 5.3 N*m (54 kgf*cm, 47 in.*lbf) Connect the radiator reserve tank hose to the No. 2 radiator assembly.
15. INSTALL FRONT BUMPER ASSEMBLY (for Sport Package) Refer to «INSTALLATION [03/2012 - ]»(ref-602726-S10254119152014030500000)
16. INSTALL FRONT BUMPER ASSEMBLY (for Standard) Refer to «INSTALLATION [03/2012 - ]»(ref-602726-S06902505152014030500000)
17. INSTALL BATTERY . Refer to «INSTALLATION [07/2012 - ] - Step 76»(ref-602689-S30369469832014030500000)
18. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL NOTE: When disconnecting the cable from the negative (-) battery terminal, some systems need to be initialized after the cable is reconnected. Refer to «INITIALIZATION [07/2012 - ]»(ref-602551-S38908041872014030500000) .
19. INSTALL NO. 1 AIR CLEANER INLET . Refer to «INSTALLATION [07/2012 - ] - Step 77»(ref-602689-S30369469832014030500000)
20. INSTALL NO. 2 AIR CLEANER INLET . Refer to «INSTALLATION [07/2012 - ] - Step 78»(ref-602689-S30369469832014030500000)
21. ADD ENGINE COOLANT See step 7
22. INSPECT FOR COOLANT LEAK . Refer to «ON-VEHICLE INSPECTION [03/2012 - ] - Step 1»(ref-602725-S34080696782014030500000)
23. INSPECT FOR AUTOMATIC TRANSAXLE FLUID LEAK
24. INSTALL NO. 1 ENGINE UNDER COVER
25. INSTALL V-BANK COVER SUB-ASSEMBLY . Refer to «INSTALLATION [07/2012 - ] - Step 113»(ref-602689-S30369469832014030500000)
26. ADJUST MILLIMETER WAVE RADAR SENSOR ASSEMBLY (w/ Dynamic Radar Cruise Control System) Refer to «ADJUSTMENT [03/2012 - ]»(ref-602562-S10556630812014030500000)

Scheme 52

1. INSPECT COOLING FAN RELAY (RDI FAN NO. 1) Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 3 - 5 Battery voltage is not applied between terminals 1 and 2 10 kohms or higher 3 - 5 Battery voltage is applied between terminals 1 and 2 Below 1 ohms If the result is not as specified, replace the cooling fan relay.
