HOW TO PROCEED WITH TROUBLESHOOTING
HINT
Use the following procedure to troubleshoot the wiper and washer system.
- VEHICLE BROUGHT TO WORKSHOP NEXT: Go to next step
- CUSTOMER PROBLEM ANALYSIS AND SYMPTOM CHECK NEXT: Go to next step
- INSPECT BATTERY VOLTAGE Standard Voltage 11 to 14 V If the voltage is below 11 V, recharge or replace the battery before proceeding to the next step. NEXT: Go to next step
- PROBLEM SYMPTOMS TABLE Result Result Proceed to Fault is not listed in problem symptoms table A Fault is listed in problem symptoms table B B --> Go to 6 step 6 A: Go to next step
- OVERALL ANALYSIS AND TROUBLESHOOTING Terminals of ECU. Refer to «TERMINALS OF ECU»(ref-400840-S14245703292011051800000) Fail-safe chart. Refer to «FAIL-SAFE CHART»(ref-400840-S07871253372011051800000) Inspection On-vehicle inspection NEXT: Go to next step
- ADJUST, REPAIR OR REPLACE NEXT: Go to next step
- CONFIRMATION TEST NEXT --> END
PROBLEM SYMPTOMS TABLE
HINT
Use the table below to help determine the cause of problem symptoms. If multiple suspected areas are listed, the potential causes of the symptoms are listed in order of probability in the "Suspected Area" column of the table. Check each symptom by checking the suspected areas in the order they are listed. Replace parts as necessary.
| Symptom | Suspected Area | See |
|---|---|---|
| Front wipers do not operate at all | Wiper ECU power source circuit | Refer to Wiper ECU Power Source Circuit |
| Front wiper motor circuit | Refer to Front Wiper Motor Circuit | |
| Windshield wiper switch assembly | Refer to REMOVAL (TO 8/2009) | |
| Front wipers do not operate in LO | Front wiper motor circuit | Refer to Front Wiper Motor Circuit |
| Windshield wiper switch assembly | Refer to REMOVAL (TO 8/2009) | |
| Front wipers do not operate in HI | Front wiper motor circuit | Refer to Front Wiper Motor Circuit |
| Windshield wiper switch assembly | Refer to REMOVAL (TO 8/2009) | |
| Front washer motor does not operate | Washer motor circuit | Refer to Washer Motor Circuit |
| Windshield wiper switch assembly | Refer to REMOVAL (TO 8/2009) | |
| Washer fluid does not flow | Washer hose and nozzle | |
| Front wipers do not operate when front washer switch is on | Front wiper motor circuit | Refer to Front Wiper Motor Circuit |
| Windshield wiper switch assembly | Refer to REMOVAL (TO 8/2009) | |
| When the front wiper switch is off, the wiper blades do not park or park in the wrong position | Front wiper arm installation position | Refer to INSTALLATION |
| Windshield wiper motor assembly | Refer to REMOVAL (TO 8/2009) |
FRONT WIPER AND WASHER (W/O AUTO WIPER SYSTEM)
| Symptom | Suspected Area | See |
|---|---|---|
| Front wipers do not operate at all | Wiper ECU power source circuit | Refer to Wiper ECU Power Source Circuit |
| Front wiper motor circuit | Refer to Front Wiper Motor Circuit | |
| Windshield wiper switch assembly | Refer to REMOVAL (TO 8/2009) | |
| Front wipers do not operate in AUTO | Rain sensor tape*1 | |
| Rain sensor circuit | Refer to Rain Sensor Circuit | |
| Speed signal circuit | Refer to Speed Signal Circuit | |
| Front wiper motor circuit | Refer to Front Wiper Motor Circuit | |
| Windshield wiper switch assembly | Refer to REMOVAL (TO 8/2009) | |
| Front wipers do not operate in LO | Front wiper motor circuit | Refer to Front Wiper Motor Circuit |
| Windshield wiper switch assembly | Refer to REMOVAL (TO 8/2009) | |
| Front wipers do not operate in HI | Front wiper motor circuit | Refer to Front Wiper Motor Circuit |
| Windshield wiper switch assembly | Refer to REMOVAL (TO 8/2009) | |
| Front washer motor does not operate | Washer motor circuit | Refer to Washer Motor Circuit |
| Windshield wiper switch assembly | Refer to REMOVAL (TO 8/2009) | |
| Washer fluid does not flow | Washer hose and nozzle | |
| Front wipers do not operate when front washer switch is on | Front wiper motor circuit | Refer to Front Wiper Motor Circuit |
| Windshield wiper switch assembly | Refer to REMOVAL (TO 8/2009) | |
| When the front wiper switch is off, the wiper blades do not park or park in the wrong position | Front wiper arm installation position | Refer to INSTALLATION |
| Windshield wiper motor assembly | Refer to REMOVAL (TO 8/2009) |
FRONT WIPER AND WASHER (W/ AUTO WIPER SYSTEM)
HINT
*1: Before inspecting the rain sensor, first check if the rain sensor tape is correctly installed.
| Symptom | Suspected Area | See |
|---|---|---|
| Rear wiper does not operate at all | RR WIP fuse | |
| Rear wiper motor assembly | Refer to INSPECTION | |
| Windshield wiper switch assembly | Refer to INSPECTION | |
| Harness or connector | ||
| Rear wiper does not operate in LO or HI | Rear wiper motor assembly | Refer to INSPECTION |
| Windshield wiper switch assembly | Refer to INSPECTION | |
| Harness or connector | ||
| Rear washer motor does not operate | RR WASH fuse | |
| Rear washer motor assembly | Refer to INSPECTION | |
| Windshield wiper switch assembly | Refer to INSPECTION | |
| Harness or connector | ||
| Washer fluid does not flow | Washer hose and nozzle | |
| When the rear wiper switch is off, the wiper blade does not park or park in the wrong position | Rear wiper arm installation position | Refer to INSTALLATION |
| Rear wiper motor assembly | Refer to INSPECTION |
REAR WIPER AND WASHER
| Symptom | Suspected Area | See |
|---|---|---|
| Headlight cleaner system does not operate when the headlight cleaner switch is operated. | IG power source circuit | Refer to IG Power Source Circuit |
| Headlight cleaner switch circuit | Refer to Headlight Cleaner Switch Circuit | |
| Headlight cleaner motor and relay circuit | Refer to Headlight Cleaner Motor and Relay Circuit | |
| Headlight cleaner control relay | Refer to REMOVAL | |
| Headlight cleaner system does not operate when the front washer switch is operated*2. | IG power source circuit | Refer to IG Power Source Circuit |
| Headlight signal circuit | Refer to Headlight Signal Circuit | |
| Washer signal circuit | Refer to Washer Signal Circuit | |
| Headlight cleaner motor and relay circuit | Refer to Headlight Cleaner Motor and Relay Circuit | |
| Headlight cleaner control relay | Refer to REMOVAL |
HEADLIGHT CLEANER SYSTEM
| Symptom | Suspected Area | See |
|---|---|---|
| Washer fluid level warning system does not operate | Washer fluid level warning switch circuit | Refer to Washer Fluid Level Warning Switch Circuit |
| Combination meter assembly | Refer to REMOVAL (TO 8/2009) |
WASHER FLUID LEVEL WARNING SYSTEM
HINT
Use the table below to help determine the cause of problem symptoms. If multiple suspected areas are listed, the potential causes of the symptoms are listed in order of probability in the "Suspected Area" column of the table. Check each symptom by checking the suspected areas in the order they are listed. Replace parts as necessary.
| Symptom | Suspected Area | See |
|---|---|---|
| Front wipers do not operate at all | Wiper ECU power source circuit | Refer to Wiper ECU Power Source Circuit |
| Front wiper motor circuit | Refer to Front Wiper Motor Circuit | |
| Windshield wiper switch assembly | Refer to REMOVAL (TO 8/2009) | |
| Front wipers do not operate in LO | Front wiper motor circuit | Refer to Front Wiper Motor Circuit |
| Windshield wiper switch assembly | Refer to REMOVAL (TO 8/2009) | |
| Front wipers do not operate in HI | Front wiper motor circuit | Refer to Front Wiper Motor Circuit |
| Windshield wiper switch assembly | Refer to REMOVAL (TO 8/2009) | |
| Front washer motor does not operate | Washer motor circuit | Refer to Washer Motor Circuit |
| Windshield wiper switch assembly | Refer to REMOVAL (TO 8/2009) | |
| Washer fluid does not flow | Washer hose and nozzle | |
| Front wipers do not operate when front washer switch is on | Front wiper motor circuit | Refer to Front Wiper Motor Circuit |
| Windshield wiper switch assembly | Refer to REMOVAL (TO 8/2009) | |
| When the front wiper switch is off, the wiper blades do not park or park in the wrong position | Front wiper arm installation position | Refer to INSTALLATION |
| Windshield wiper motor assembly | Refer to REMOVAL (TO 8/2009) |
FRONT WIPER AND WASHER (W/O AUTO WIPER SYSTEM)
| Symptom | Suspected Area | See |
|---|---|---|
| Front wipers do not operate at all | Wiper ECU power source circuit | Refer to Wiper ECU Power Source Circuit |
| Front wiper motor circuit | Refer to Front Wiper Motor Circuit | |
| Windshield wiper switch assembly | Refer to REMOVAL (TO 8/2009) | |
| Front wipers do not operate in AUTO | Rain sensor tape*1 | |
| Rain sensor circuit | Refer to Rain Sensor Circuit | |
| Speed signal circuit | Refer to Speed Signal Circuit | |
| Front wiper motor circuit | Refer to Front Wiper Motor Circuit | |
| Windshield wiper switch assembly | Refer to REMOVAL (TO 8/2009) | |
| Front wipers do not operate in LO | Front wiper motor circuit | Refer to Front Wiper Motor Circuit |
| Windshield wiper switch assembly | Refer to REMOVAL (TO 8/2009) | |
| Front wipers do not operate in HI | Front wiper motor circuit | Refer to Front Wiper Motor Circuit |
| Windshield wiper switch assembly | Refer to REMOVAL (TO 8/2009) | |
| Front washer motor does not operate | Washer motor circuit | Refer to Washer Motor Circuit |
| Windshield wiper switch assembly | Refer to REMOVAL (TO 8/2009) | |
| Washer fluid does not flow | Washer hose and nozzle | |
| Front wipers do not operate when front washer switch is on | Front wiper motor circuit | Refer to Front Wiper Motor Circuit |
| Windshield wiper switch assembly | Refer to REMOVAL (TO 8/2009) | |
| When the front wiper switch is off, the wiper blades do not park or park in the wrong position | Front wiper arm installation position | Refer to INSTALLATION |
| Windshield wiper motor assembly | Refer to REMOVAL |
FRONT WIPER AND WASHER (W/ AUTO WIPER SYSTEM)
HINT
*1: Before inspecting the rain sensor, first check if the rain sensor tape is correctly installed.
| Symptom | Suspected Area | See |
|---|---|---|
| Rear wiper does not operate at all | RR WIP fuse | |
| Rear wiper motor assembly | Refer to INSPECTION | |
| Windshield wiper switch assembly | Refer to INSPECTION | |
| Harness or connector | ||
| Rear wiper does not operate in LO or HI | Rear wiper motor assembly | Refer to INSPECTION |
| Windshield wiper switch assembly | Refer to INSPECTION | |
| Harness or connector | ||
| Rear washer motor does not operate | RR WASH fuse | |
| Rear washer motor assembly | Refer to INSPECTION | |
| Windshield wiper switch assembly | Refer to INSPECTION | |
| Harness or connector | ||
| Washer fluid does not flow | Washer hose and nozzle | |
| When the rear wiper switch is off, the wiper blade does not park or park in the wrong position | Rear wiper arm installation position | Refer to INSTALLATION |
| Rear wiper motor assembly | Refer to INSPECTION |
REAR WIPER AND WASHER
| Symptom | Suspected Area | See |
|---|---|---|
| Headlight cleaner system does not operate when the headlight cleaner switch is operated. | IG power source circuit | Refer to IG Power Source Circuit |
| Headlight cleaner switch circuit | Refer to Headlight Cleaner Switch Circuit | |
| Headlight cleaner motor and relay circuit | Refer to Headlight Cleaner Motor and Relay Circuit | |
| Headlight cleaner control relay | Refer to REMOVAL | |
| Headlight cleaner system does not operate when the front washer switch is operated*2. | IG power source circuit | Refer to IG Power Source Circuit |
| Headlight signal circuit | Refer to Headlight Signal Circuit | |
| Washer signal circuit | Refer to Washer Signal Circuit | |
| Headlight cleaner motor and relay circuit | Refer to Headlight Cleaner Motor and Relay Circuit | |
| Headlight cleaner control relay | Refer to REMOVAL |
HEADLIGHT CLEANER SYSTEM
| Symptom | Suspected Area | See |
|---|---|---|
| Washer fluid level warning system does not operate | Washer fluid level warning switch circuit | Refer to Washer Fluid Level Warning Switch Circuit |
| Combination meter assembly | Refer to REMOVAL (TO 8/2009) |
WASHER FLUID LEVEL WARNING SYSTEM
Scheme 155
Scheme 156
Scheme 157
- CHECK WINDSHIELD WIPER SWITCH ASSEMBLY Disconnect the F42 windshield wiper switch assembly connector. Measure the voltage and resistance according to the value(s) in the table below. Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition F42-1 (EW) - Body ground W-B - Body ground Body ground Always Below 1 ohms F42-3 (WIG)*1 - Body ground R - Body ground Power source circuit Engine switch on (IG) 11 to 14 V Engine switch off Below 1 V F42-17 (+B) - Body ground L - Body ground Power source circuit Engine switch on (IG) 11 to 14 V Engine switch off Below 1 V HINT: *1: w/ Auto Wiper System If the result is not as specified, there may be a malfunction in the wire harness. Reconnect the F42 windshield wiper switch assembly connector. Measure the voltage according to the value(s) in the table below. Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition F42-2 (WF) - Body ground B - Body ground Front washer motor circuit Front washer switch on Below 1 V Front washer switch off 11 to 14 V F42-5 (MPX1)*1 - Body ground V - Body ground Rain sensor signal Engine switch on (IG) Pulse generation F42-6 (SPD)*1 - Body ground GR - Body ground Speed signal Driving at approx. 20 km/h (12 mph) Pulse generation F42-7 (TAIL)*1 - Body ground L - Body ground Light control switch tail position signal circuit Light control switch in tail position 11 to 14 V Light control switch off Below 1 V F42-8 (+1) - Body ground SB - Body ground Front wiper motor LO speed signal circuit Front wiper motor in LO operation 11 to 14 V Front wiper motor off Below 1 V F42-9 (+2) - Body ground GR - Body ground Front wiper motor HI speed signal circuit Front wiper motor in HI operation 11 to 14 V Front wiper motor off Below 1 V F42-18 (+S) - Body ground R - Body ground Front wiper motor operation signal Front wiper motor operates 11 to 14 V Front wiper motor off Below 1 V HINT: *1: w/ Auto Wiper System If the result is not as specified, the windshield wiper relay assembly may have a malfunction.
- CHECK MAP LIGHT ASSEMBLY Disconnect the T10 map light assembly connector. Measure the voltage and resistance according to the value(s) in the table below. Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition T10-26 (IG) - Body ground P - Body ground Power source circuit Engine switch on (IG) 11 to 14 V Engine switch off Below 1 V T10-40 (GND) - Body ground W - Body ground Body ground Always Below 1 ohms If the result is not as specified, there may be a malfunction in the wire harness. Reconnect the T10 map light assembly connector. Measure the voltage according to the value(s) in the table below. Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition T10-24 (IG2) - T10-19 (GND2) G - W-B Power source circuit Engine switch on (IG) 11 to 14 V Engine switch off Below 1 V If the result is not as specified, the map light assembly may have a malfunction.
- CHECK HEADLIGHT CLEANER CONTROL RELAY Disconnect the A33 headlight cleaner control relay connector. Measure the voltage and resistance according to the value(s) in the table below. Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition A33-1 (HDLO) - A33-4 (E) L - W-B Low beam headlight signal Light control switch in head position Below 1 V Light control switch off 11 to 14 V A33-2 (H) - A33-4 (E) W - W-B Headlight cleaner switch operation signal Headlight cleaner switch off 11 to 14 V Headlight cleaner switch on Below 1 V A33-3 (IG) - A33-4 (E) BR - W-B Engine switch on (IG) signal (Power source circuit) Engine switch off Below 1 V Engine switch on (IG) 11 to 14 V A33-4 (E) - Body ground W-B - Body ground Body ground Always Below 1 ohms A33-5 (FRWA) - A33-4 (E) P - W-B Front washer switch signal Front washer switch off 11 to 14 V Front washer switch on Below 1 V If the result is not as specified, there may be a malfunction in the wire harness.
INSPECTION PROCEDURE
Note. First check that the low beam headlights operate normally.
Scheme 158
- CHECK HARNESS AND CONNECTOR (LOW BEAM HEADLIGHT RELAY - ECU) Disconnect the A33 headlight cleaner control relay connector. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Switch Condition Specified Condition A33-1 (HDLO) - Body ground Light control switch in head position 11 to 14 V Light control switch off Below 1 V TEXT IN ILLUSTRATION *1 Front view of wire harness connector (to Headlight Cleaner Control Relay) NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 2
- PROCEED TO NEXT SUSPECTED AREA SHOWN IN PROBLEM SYMPTOMS TABLE. Refer to «PROBLEM SYMPTOMS TABLE»(ref-400840-S24523419422011051800000)
Note. First check that the low beam headlights operate normally.
