Firing Order & Cylinder Identification: Other Lexus RX III

Specifications 4 illustrations

4 CYLINDER ENGINE

Engine Configuration Firing Order Cylinder Identification In-Line 4 1-3-4-2

Scheme 1: 4 CYLINDER ENGINE

Engine Configuration Firing Order Cylinder Identification In-Line 6 1-5-3-6-2-4

Scheme 2: IN-LINE 6 ENGINE

Engine Configuration Firing Order Cylinder Identification V6 1-2-3-4-5-6

Scheme 3: V6 ENGINE

Engine Configuration Firing Order Cylinder Identification 4.3L, 4.6L, 5.0L & 5.7L 1-8-7-3-6-5-4-2

Scheme 4: 4.6L, 5.0L & 5.7L

Engine Configuration Firing Order Cylinder Identification All Others 1-8-4-3-6-5-7-2
