Engine Control (Service Information): Removal & Installation

REMOVAL

PRECAUTION (w/ Air Suspension) NOTE: Be sure to read Precaution thoroughly before servicing. Refer to «PRECAUTION»(ref-400808-S39927796452011051800000) .
PRECAUTION (w/ Navigation System for HDD) NOTE: After the engine switch is turned off, the display and navigation module display (HDD navigation system) records various types of memory and settings. As a result, after turning the engine switch off, make sure to wait at least 60 seconds before disconnecting the cable from the negative (-) battery terminal.
REMOVE WINDSHIELD WIPER MOTOR AND LINK ASSEMBLY Remove the windshield wiper motor and link assembly. Refer to «REMOVAL»(ref-400809-S41356394852011051800000) .
REMOVE NO. 1 ENGINE UNDER COVER
DRAIN ENGINE COOLANT . Refer to «REPLACEMENT - Step 7»(ref-400800-S05976021912011051800000)
REMOVE FRONT SHOCK ABSORBER CAP (w/ Air Suspension) . Refer to «REMOVAL - Step 3»(ref-400810-S20661286162011051800000)
REMOVE OUTER COWL TOP PANEL SUB-ASSEMBLY . Refer to «REMOVAL - Step 11»(ref-400778-S19229320722011051800000)
REMOVE V-BANK COVER SUB-ASSEMBLY . Refer to «REMOVAL - Step 34»(ref-400790-S42173954232011051800000)
DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL WARNING: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to disable the SRS system. Refer to «PRECAUTION»(ref-400811-S15765720172011051800000) . NOTE: When disconnecting the cable, some systems need to be initialized after the cable is reconnected. Refer to «INITIALIZATION»(ref-400649-S34584305262011051800000) .
REMOVE BATTERY . Refer to «REMOVAL - Step 37»(ref-400790-S42173954232011051800000)
REMOVE NO. 2 AIR CLEANER INLET . Refer to «REMOVAL - Step 35»(ref-400790-S42173954232011051800000)
REMOVE NO. 1 AIR CLEANER INLET . Refer to «REMOVAL - Step 36»(ref-400790-S42173954232011051800000)
REMOVE AIR CLEANER ASSEMBLY See step 13
REMOVE INTAKE AIR SURGE TANK ASSEMBLY . Refer to «REMOVAL - Step 3»(ref-400802-S36931150902011051800000)
REMOVE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY Remove the bolt and disconnect the wire harness clamp to separate the engine wire. Disconnect the 4 oil control valve connectors. Remove the 4 bolts and 4 oil control valves. Remove the O-ring from each oil control valve. TEXT IN ILLUSTRATION *1 O-ring

Scheme 18

Scheme 18: INSPECTION

Scheme 19

INSPECT CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY Measure the resistance of the oil control valve. Standard Resistance Tester Connection Specified Condition 1 (+B) - 2 (GND) 6.9 to 7.9 ohms at 20°C (68°F) If the result is not as specified, replace the oil control valve assembly. Check the operation. Connect a battery positive (+) lead to terminal 1 and negative (-) lead to terminal 2, and check the movement of the valve. OK Condition Specified Condition Battery positive (+) voltage is applied Valve moves in black arrow direction shown in illustration Battery positive (+) voltage is cut off Valve moves in white arrow direction shown in illustration TEXT IN ILLUSTRATION *1 Spool Valve *2 Battery If the result is not as specified, replace the oil control valve. NOTE: Accumulation of foreign matter can cause minor pressure leaks. Minor pressure leaks in the intake side oil control valve will cause the intake camshaft to advance. Minor pressure leaks in the exhaust side oil control valve will cause the exhaust camshaft to retard. The inappropriate camshaft timing that results from these leaks will cause a DTC to be set.

INSTALLATION

INSTALL CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY Apply a light coat of engine oil to 4 new O-rings and install them to the 4 camshaft timing oil control valve assemblies. TEXT IN ILLUSTRATION *1 O-ring Install the 4 oil control valves with the 4 bolts. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf) NOTE: Make sure that each O-ring is not cracked or does not jump out of position during installation. Connect the 4 oil control valve connectors. Install the bolt and connect the wire harness clamp to install the engine wire. Torque: 14 N*m (138 kgf*cm, 10 ft.*lbf)
INSTALL INTAKE AIR SURGE TANK ASSEMBLY . Refer to «INSTALLATION - Step 5»(ref-400802-S09938504842011051800000)
INSTALL AIR CLEANER ASSEMBLY See step 2
INSTALL NO. 1 AIR CLEANER INLET . Refer to «INSTALLATION - Step 72»(ref-400790-S30060480932011051800000)
INSTALL NO. 2 AIR CLEANER INLET . Refer to «INSTALLATION - Step 73»(ref-400790-S30060480932011051800000)
INSTALL BATTERY . Refer to «INSTALLATION - Step 71»(ref-400790-S30060480932011051800000)
CONNECT CABLE TO NEGATIVE BATTERY TERMINAL NOTE: When disconnecting the cable, some systems need to be initialized after the cable is reconnected. Refer to «INITIALIZATION»(ref-400649-S12881576452011051800000) .
ADD ENGINE COOLANT . Refer to «REPLACEMENT - Step 8»(ref-400800-S21803137222011051800000)
INSPECT FOR ENGINE COOLANT LEAK . Refer to «ON-VEHICLE INSPECTION - Step 1»(ref-400812-S34139223332011051800000)
INSPECT FOR OIL LEAK Start the engine, and check that there are no oil leaks.
INSTALL V-BANK COVER SUB-ASSEMBLY . Refer to «INSTALLATION - Step 113»(ref-400790-S30060480932011051800000)
INSTALL OUTER COWL TOP PANEL SUB-ASSEMBLY . Refer to «INSTALLATION - Step 17»(ref-400778-S06004016952011051800000)
INSTALL FRONT SHOCK ABSORBER CAP (w/ Air Suspension) . Refer to «INSTALLATION - Step 10»(ref-400810-S37673499492011051800000)
INSTALL WINDSHIELD WIPER MOTOR AND LINK ASSEMBLY Install the windshield wiper motor and link assembly. Refer to «INSTALLATION»(ref-400809-S31962938082011051800000) .
INSTALL NO. 1 ENGINE UNDER COVER

INSTALL CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY Apply a light coat of engine oil to 4 new O-rings and install them to the 4 camshaft timing oil control valve assemblies. TEXT IN ILLUSTRATION *1 O-ring Install the 4 oil control valves with the 4 bolts. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf) NOTE: Make sure that each O-ring is not cracked or does not jump out of position during installation. Connect the 4 oil control valve connectors. Install the bolt and connect the wire harness clamp to install the engine wire. Torque: 14 N*m (138 kgf*cm, 10 ft.*lbf)
INSTALL INTAKE AIR SURGE TANK ASSEMBLY . Refer to «INSTALLATION - Step 5»(ref-400802-S09705609702011051800000)
INSTALL AIR CLEANER ASSEMBLY See step 2
INSTALL NO. 1 AIR CLEANER INLET . Refer to «INSTALLATION - Step 72»(ref-400790-S01050581782011051800000)
INSTALL NO. 2 AIR CLEANER INLET . Refer to «INSTALLATION - Step 73»(ref-400790-S01050581782011051800000)
INSTALL BATTERY . Refer to «INSTALLATION - Step 71»(ref-400790-S01050581782011051800000)
CONNECT CABLE TO NEGATIVE BATTERY TERMINAL NOTE: When disconnecting the cable, some systems need to be initialized after the cable is reconnected. Refer to «INITIALIZATION»(ref-400649-S34584305262011051800000) .
ADD ENGINE COOLANT . Refer to «REPLACEMENT - Step 8»(ref-400800-S05976021912011051800000)
INSPECT FOR ENGINE COOLANT LEAK . Refer to «ON-VEHICLE INSPECTION - Step 1»(ref-400812-S34139223332011051800000)
INSPECT FOR OIL LEAK Start the engine, and check that there are no oil leaks.
INSTALL V-BANK COVER SUB-ASSEMBLY . Refer to «INSTALLATION - Step 113»(ref-400790-S01050581782011051800000)
INSTALL OUTER COWL TOP PANEL SUB-ASSEMBLY . Refer to «INSTALLATION - Step 17»(ref-400778-S22039083752011051800000)
INSTALL FRONT SHOCK ABSORBER CAP (w/ Air Suspension) . Refer to «INSTALLATION - Step 10»(ref-400810-S15685281082011051800000)
INSTALL WINDSHIELD WIPER MOTOR AND LINK ASSEMBLY Install the windshield wiper motor and link assembly. Refer to «INSTALLATION»(ref-400809-S31962938082011051800000) .
INSTALL NO. 1 ENGINE UNDER COVER

Scheme 20

Scheme 20: ILLUSTRATION

PRECAUTION (w/ Air Suspension) NOTE: Be sure to read Precaution thoroughly before servicing. Refer to «PRECAUTION»(ref-400808-S39927796452011051800000) .
PRECAUTION (w/ Navigation System for HDD) NOTE: After the engine switch is turned off, the display and navigation module display (HDD navigation system) records various types of memory and settings. As a result, after turning the engine switch off, make sure to wait at least 60 seconds before disconnecting the cable from the negative (-) battery terminal.
REMOVE WINDSHIELD WIPER MOTOR AND LINK ASSEMBLY Remove the windshield wiper motor and link assembly. Refer to «REMOVAL»(ref-400809-S41356394852011051800000) .
REMOVE FRONT SHOCK ABSORBER CAP (w/ Air Suspension) . Refer to «REMOVAL - Step 3»(ref-400810-S20661286162011051800000)
REMOVE OUTER COWL TOP PANEL SUB-ASSEMBLY . Refer to «REMOVAL - Step 11»(ref-400778-S19229320722011051800000)
REMOVE V-BANK COVER SUB-ASSEMBLY . Refer to «REMOVAL - Step 34»(ref-400790-S42173954232011051800000)
DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL WARNING: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to disable the SRS system. Refer to «PRECAUTION»(ref-400811-S15765720172011051800000) . NOTE: When disconnecting the cable, some systems need to be initialized after the cable is reconnected. Refer to «INITIALIZATION»(ref-400649-S34584305262011051800000) .
REMOVE NO. 1 ENGINE UNDER COVER
DRAIN ENGINE COOLANT . Refer to «REPLACEMENT - Step 7»(ref-400800-S05976021912011051800000)
REMOVE NO. 2 AIR CLEANER INLET . Refer to «REMOVAL - Step 35»(ref-400790-S42173954232011051800000)
REMOVE NO. 1 AIR CLEANER INLET . Refer to «REMOVAL - Step 36»(ref-400790-S42173954232011051800000)
REMOVE BATTERY . Refer to «REMOVAL - Step 37»(ref-400790-S42173954232011051800000)
REMOVE AIR CLEANER ASSEMBLY Separate the mass air flow meter connector and wire harness clamp. Separate the vacuum hose from the intake air surge tank assembly. Separate the vacuum hose from the hose clamp. Separate the vacuum switching valve connector and 2 wire harness clamps. Separate the 2 vacuum hoses. Separate the ventilation hose and the fuel vapor feed hose. TEXT IN ILLUSTRATION *1 Ventilation Hose *2 Fuel Vapor Feed Hose Loosen the hose clamp and separate the air cleaner hose from the throttle body. Remove the 2 bolts and remove the air cleaner assembly.
REMOVE THROTTLE BODY Disconnect the 2 water by-pass hoses from the throttle body. Disconnect the throttle body connector and wire harness clamp. Remove the 4 bolts, throttle body and wire harness clamp stay. Remove the gasket from the intake air surge tank assembly.

Scheme 21

Scheme 21: INSPECTION

INSPECT THROTTLE BODY Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 1 (M-) - 2 (M+) 20°C (68°F) 0.3 to 100 ohms TEXT IN ILLUSTRATION *1 Component without harness connected (Throttle Body) If the result is not as specified, replace the throttle body.

Scheme 22

Scheme 22: INSTALLATION

Scheme 23

INSTALL THROTTLE BODY Install a new gasket to the intake air surge tank assembly. TEXT IN ILLUSTRATION *1 Recess Install the throttle body and wire harness clamp stay to the intake air surge tank assembly with the 4 bolts. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf) Connect the throttle body connector and wire harness clamp. Connect the 2 water by-pass hoses to the throttle body.
INSTALL AIR CLEANER ASSEMBLY Insert the tab of the air cleaner assembly to the hole of the vehicle body as shown in the illustration. TEXT IN ILLUSTRATION *1 Tab *2 Hole Install the air cleaner assembly with the 2 bolts. Torque: 5.5 N*m (56 kgf*cm, 49 in.*lbf) Connect the air cleaner hose to the throttle body with the hose clamp. TEXT IN ILLUSTRATION *1 Ventilation Hose *2 Fuel Vapor Feed Hose Connect the ventilation hose and the fuel vapor feed hose. Connect the 2 vacuum hoses. Connect the 2 wire harness clamps and vacuum switching valve connector. Connect the vacuum hose to the intake air surge tank assembly. Install the hose to the hose clamp. Connect the mass air flow meter connector and wire harness clamp.
INSTALL BATTERY . Refer to «INSTALLATION - Step 71»(ref-400790-S30060480932011051800000)
INSTALL NO. 1 AIR CLEANER INLET . Refer to «INSTALLATION - Step 72»(ref-400790-S30060480932011051800000)
INSTALL NO. 2 AIR CLEANER INLET . Refer to «INSTALLATION - Step 73»(ref-400790-S30060480932011051800000)
CONNECT CABLE TO NEGATIVE BATTERY TERMINAL NOTE: When disconnecting the cable, some systems need to be initialized after the cable is reconnected. Refer to «INITIALIZATION»(ref-400649-S12881576452011051800000) .
ADD ENGINE COOLANT . Refer to «REPLACEMENT - Step 8»(ref-400800-S21803137222011051800000)
INSPECT FOR ENGINE COOLANT LEAK . Refer to «ON-VEHICLE INSPECTION - Step 1»(ref-400812-S34139223332011051800000)
INSTALL OUTER COWL TOP PANEL SUB-ASSEMBLY . Refer to «INSTALLATION - Step 17»(ref-400778-S06004016952011051800000)
INSTALL FRONT SHOCK ABSORBER CAP (w/ Air Suspension) . Refer to «INSTALLATION - Step 10»(ref-400810-S37673499492011051800000)
INSTALL WINDSHIELD WIPER MOTOR AND LINK ASSEMBLY Install the windshield wiper motor and link assembly. Refer to «INSTALLATION»(ref-400809-S31962938082011051800000) .
INSTALL V-BANK COVER SUB-ASSEMBLY . Refer to «INSTALLATION - Step 113»(ref-400790-S30060480932011051800000)
INSTALL NO. 1 ENGINE UNDER COVER
PERFORM INITIALIZATION NOTE: Perform the following procedure after replacing the ECM, throttle body assembly or any throttle body components. The following procedure should also be performed if the throttle body is cleaned. Disconnect the cable from the negative (-) battery terminal. Wait at least 60 seconds and reconnect the cable. Turn the engine switch on (IG) without operating the accelerator pedal. NOTE: If the accelerator pedal is operated, perform the above steps again. Connect the Techstream to the DLC3 and clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-400784-S05337578742011051800000) . Start the engine and check that the MIL is not illuminated and that the idle speed is within the specified range when the A/C is switched off after the engine is warmed up. Standard Condition Engine Idle Speed A/C switched off 600 to 700 RPM NOTE: Be sure to perform this step with all accessories off. Make sure that the shift lever is in N. Enter the following menus: Powertrain/ Engine / Data List/ Throttle Sensor Position. Fully depress the accelerator pedal and check that the value is 60% or more. Perform a road test and confirm that there are no abnormalities.

INSTALL THROTTLE BODY Install a new gasket to the intake air surge tank assembly. TEXT IN ILLUSTRATION *1 Recess Install the throttle body and wire harness clamp stay to the intake air surge tank assembly with the 4 bolts. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf) Connect the throttle body connector and wire harness clamp. Connect the 2 water by-pass hoses to the throttle body.
INSTALL AIR CLEANER ASSEMBLY Insert the tab of the air cleaner assembly to the hole of the vehicle body as shown in the illustration. TEXT IN ILLUSTRATION *1 Tab *2 Hole Install the air cleaner assembly with the 2 bolts. Torque: 5.5 N*m (56 kgf*cm, 49 in.*lbf) Connect the air cleaner hose to the throttle body with the hose clamp. TEXT IN ILLUSTRATION *1 Ventilation Hose *2 Fuel Vapor Feed Hose Connect the ventilation hose and the fuel vapor feed hose. Connect the 2 vacuum hoses. Connect the 2 wire harness clamps and vacuum switching valve connector. Connect the vacuum hose to the intake air surge tank assembly. Install the hose to the hose clamp. Connect the mass air flow meter connector and wire harness clamp.
INSTALL BATTERY . Refer to «INSTALLATION - Step 71»(ref-400790-S01050581782011051800000)
INSTALL NO. 1 AIR CLEANER INLET . Refer to «INSTALLATION - Step 72»(ref-400790-S01050581782011051800000)
INSTALL NO. 2 AIR CLEANER INLET . Refer to «INSTALLATION - Step 73»(ref-400790-S01050581782011051800000)
CONNECT CABLE TO NEGATIVE BATTERY TERMINAL NOTE: When disconnecting the cable, some systems need to be initialized after the cable is reconnected. Refer to «INITIALIZATION»(ref-400649-S34584305262011051800000) .
ADD ENGINE COOLANT . Refer to «REPLACEMENT - Step 8»(ref-400800-S05976021912011051800000)
INSPECT FOR ENGINE COOLANT LEAK . Refer to «ON-VEHICLE INSPECTION - Step 1»(ref-400812-S34139223332011051800000)
INSTALL OUTER COWL TOP PANEL SUB-ASSEMBLY . Refer to «INSTALLATION - Step 17»(ref-400778-S22039083752011051800000)
INSTALL FRONT SHOCK ABSORBER CAP (w/ Air Suspension) . Refer to «INSTALLATION - Step 10»(ref-400810-S15685281082011051800000)
INSTALL WINDSHIELD WIPER MOTOR AND LINK ASSEMBLY Install the windshield wiper motor and link assembly. Refer to «INSTALLATION»(ref-400809-S31962938082011051800000) .
INSTALL V-BANK COVER SUB-ASSEMBLY . Refer to «INSTALLATION - Step 113»(ref-400790-S01050581782011051800000)
INSTALL NO. 1 ENGINE UNDER COVER
PERFORM INITIALIZATION NOTE: Perform the following procedure after replacing the ECM, throttle body assembly or any throttle body components. The following procedure should also be performed if the throttle body is cleaned. Disconnect the cable from the negative (-) battery terminal. Wait at least 60 seconds and reconnect the cable. Turn the engine switch on (IG) without operating the accelerator pedal. NOTE: If the accelerator pedal is operated, perform the above steps again. Connect the Techstream to the DLC3 and clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-400784-S02158227972011051800000) . Start the engine and check that the MIL is not illuminated and that the idle speed is within the specified range when the A/C is switched off after the engine is warmed up. Standard Condition Engine Idle Speed A/C switched off 600 to 700 RPM NOTE: Be sure to perform this step with all accessories off. Make sure that the shift lever is in N. Enter the following menus: Powertrain/ Engine / Data List/ Throttle Sensor Position. Fully depress the accelerator pedal and check that the value is 60% or more. Perform a road test and confirm that there are no abnormalities.

Scheme 24

Scheme 24: ILLUSTRATION

Scheme 25

Scheme 25: ILLUSTRATION

Scheme 26

Scheme 26: REMOVAL

Scheme 27

Scheme 28

PRECAUTION (w/ Air Suspension) NOTE: Be sure to read Precaution thoroughly before servicing. Refer to «PRECAUTION»(ref-400808-S18187891512011051800000) .
PRECAUTION (w/ Navigation System for HDD) NOTE: After the engine switch is turned off, the display and navigation module display (HDD navigation system) records various types of memory and settings. As a result, after turning the engine switch off, make sure to wait at least 60 seconds before disconnecting the cable from the negative (-) battery terminal.
REMOVE ENGINE ROOM SIDE COVER . Refer to «REMOVAL - Step 1»(ref-400813-S02084383242011051800000)
REMOVE ENGINE ROOM SIDE COVER LH . Refer to «REMOVAL - Step 2»(ref-400813-S02084383242011051800000)
REMOVE COOL AIR INTAKE DUCT SEAL . Refer to «REMOVAL - Step 3»(ref-400813-S02084383242011051800000)
DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL WARNING: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to disable the SRS system. Refer to «PRECAUTION»(ref-400811-S16232838532011051800000) . NOTE: When disconnecting the cable, some systems need to be initialized after the cable is reconnected. Refer to «INITIALIZATION»(ref-400649-S12881576452011051800000) .
REMOVE V-BANK COVER SUB-ASSEMBLY . Refer to «REMOVAL - Step 34»(ref-400790-S03510589702011051800000)
REMOVE BATTERY . Refer to «REMOVAL - Step 37»(ref-400790-S03510589702011051800000)
REMOVE NO. 2 AIR CLEANER INLET . Refer to «REMOVAL - Step 35»(ref-400790-S03510589702011051800000)
REMOVE NO. 1 AIR CLEANER INLET . Refer to «REMOVAL - Step 36»(ref-400790-S03510589702011051800000)
REMOVE NO. 1 ENGINE UNDER COVER
REMOVE DUTY VACUUM SWITCHING VALVE Disconnect the 3 vacuum hoses and separate the 2 vacuum hoses from the hose clamp. Disconnect the duty vacuum switching valve connector and the clamp. Remove the bolt. Disconnect the hose from the duty vacuum switching valve and remove the duty vacuum switching valve.

PRECAUTION (w/ Air Suspension) NOTE: Be sure to read Precaution thoroughly before servicing. Refer to «PRECAUTION»(ref-400808-S39927796452011051800000) .
PRECAUTION (w/ Navigation System for HDD) NOTE: After the engine switch is turned off, the display and navigation module display (HDD navigation system) records various types of memory and settings. As a result, after turning the engine switch off, make sure to wait at least 60 seconds before disconnecting the cable from the negative (-) battery terminal.
REMOVE ENGINE ROOM SIDE COVER . Refer to «REMOVAL - Step 1»(ref-400813-S02084383242011051800000)
REMOVE ENGINE ROOM SIDE COVER LH . Refer to «REMOVAL - Step 2»(ref-400813-S02084383242011051800000)
REMOVE COOL AIR INTAKE DUCT SEAL . Refer to «REMOVAL - Step 3»(ref-400813-S02084383242011051800000)
DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL WARNING: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to disable the SRS system. Refer to «PRECAUTION»(ref-400811-S15765720172011051800000) . NOTE: When disconnecting the cable, some systems need to be initialized after the cable is reconnected. Refer to «INITIALIZATION»(ref-400649-S34584305262011051800000) .
REMOVE V-BANK COVER SUB-ASSEMBLY . Refer to «REMOVAL - Step 34»(ref-400790-S42173954232011051800000)
REMOVE BATTERY . Refer to «REMOVAL - Step 37»(ref-400790-S42173954232011051800000)
REMOVE NO. 2 AIR CLEANER INLET . Refer to «REMOVAL - Step 35»(ref-400790-S42173954232011051800000)
REMOVE NO. 1 AIR CLEANER INLET . Refer to «REMOVAL - Step 36»(ref-400790-S42173954232011051800000)
REMOVE NO. 1 ENGINE UNDER COVER
REMOVE DUTY VACUUM SWITCHING VALVE Disconnect the 3 vacuum hoses and separate the 2 vacuum hoses from the hose clamp. Disconnect the duty vacuum switching valve connector and the clamp. Remove the bolt. Disconnect the hose from the duty vacuum switching valve and remove the duty vacuum switching valve.

Scheme 29

Scheme 29: INSPECTION

Scheme 30

INSPECT DUTY VACUUM SWITCHING VALVE (OPERATION) Check the operation of the duty vacuum switching valve when positive battery voltage is applied to its terminals. Positive battery voltage is not applied The air from pipe G flows out through pipes E and H. Positive battery voltage is applied The air from pipe F flows out through pipes E and H.
INSPECT DUTY VACUUM SWITCHING VALVE (RESISTANCE) Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Condition Specified Condition 1 - 2 20°C (68°F) 19 to 21 ohms If the resistance is not as specified, replace the duty vacuum switching valve.

INSTALL DUTY VACUUM SWITCHING VALVE Connect the hose to the duty vacuum switching valve and install the duty vacuum switching valve with the bolt. Torque: 4.0 N*m (41 kgf*cm, 35 in.*lbf) Connect the duty vacuum switching valve connector and clamp. Connect the 3 vacuum hoses and install the 3 vacuum hoses to the hose clamp.
INSTALL NO. 1 ENGINE UNDER COVER
INSTALL NO. 1 AIR CLEANER INLET . Refer to «INSTALLATION - Step 72»(ref-400790-S30060480932011051800000)
INSTALL NO. 2 AIR CLEANER INLET . Refer to «INSTALLATION - Step 73»(ref-400790-S30060480932011051800000)
INSTALL BATTERY . Refer to «INSTALLATION - Step 71»(ref-400790-S30060480932011051800000)
CONNECT CABLE TO NEGATIVE BATTERY TERMINAL NOTE: When disconnecting the cable, some systems need to be initialized after the cable is reconnected. Refer to «INITIALIZATION»(ref-400649-S12881576452011051800000) .
INSTALL V-BANK COVER SUB-ASSEMBLY . Refer to «INSTALLATION - Step 113»(ref-400790-S30060480932011051800000)
INSTALL COOL AIR INTAKE DUCT SEAL . Refer to «INSTALLATION - Step 3»(ref-400813-S41344728382011051800000)
INSTALL ENGINE ROOM SIDE COVER LH . Refer to «INSTALLATION - Step 5»(ref-400813-S41344728382011051800000)
INSTALL ENGINE ROOM SIDE COVER . Refer to «INSTALLATION - Step 4»(ref-400813-S41344728382011051800000)

INSTALL DUTY VACUUM SWITCHING VALVE Connect the hose to the duty vacuum switching valve and install the duty vacuum switching valve with the bolt. Torque: 4.0 N*m (41 kgf*cm, 35 in.*lbf) Connect the duty vacuum switching valve connector and clamp. Connect the 3 vacuum hoses and install the 3 vacuum hoses to the hose clamp.
INSTALL NO. 1 ENGINE UNDER COVER
INSTALL NO. 1 AIR CLEANER INLET . Refer to «INSTALLATION - Step 72»(ref-400790-S01050581782011051800000)
INSTALL NO. 2 AIR CLEANER INLET . Refer to «INSTALLATION - Step 73»(ref-400790-S01050581782011051800000)
INSTALL BATTERY . Refer to «INSTALLATION - Step 71»(ref-400790-S01050581782011051800000)
CONNECT CABLE TO NEGATIVE BATTERY TERMINAL NOTE: When disconnecting the cable, some systems need to be initialized after the cable is reconnected. Refer to «INITIALIZATION»(ref-400649-S34584305262011051800000) .
INSTALL V-BANK COVER SUB-ASSEMBLY . Refer to «INSTALLATION - Step 113»(ref-400790-S01050581782011051800000)
INSTALL COOL AIR INTAKE DUCT SEAL . Refer to «INSTALLATION - Step 3»(ref-400813-S41344728382011051800000)
INSTALL ENGINE ROOM SIDE COVER LH . Refer to «INSTALLATION - Step 5»(ref-400813-S41344728382011051800000)
INSTALL ENGINE ROOM SIDE COVER . Refer to «INSTALLATION - Step 4»(ref-400813-S41344728382011051800000)

Scheme 31

Scheme 31: ILLUSTRATION

Scheme 32

Scheme 32: ILLUSTRATION

Scheme 33

Scheme 33: ON-VEHICLE INSPECTION

INSPECT FRONT ENGINE MOUNTING INSULATOR ASSEMBLY Check the operation. Connect the Techstream to DLC3. Start the engine and turn the Techstream on. Enter the following menus: Powertrain / Engine / Active Test / Control the ACM Inhibit. Tester Display Test Part Control Range Diagnostic Note Control the ACM Inhibit ACM ON / OFF Test is possible while engine is idling Check if the front engine mounting insulator assembly operates in accordance with tester operation. Result Condition Specified Condition "Control the ACM Inhibit" is OFF The engine does not move (insulator operation is normal). "Control the ACM Inhibit" is ON The engine moves in accordance with insulator operation. Inspect for vacuum leak. Disconnect the vacuum hose from the front engine mounting insulator assembly. Using a vacuum pump, apply a vacuum of 80 kPa (600 mmHg, 0.394 in.Hg) and wait for 1 minute. Check that there is no change in the needle movement of the vacuum pump gauge. OK Vacuum pressure holds. Check that there is no fluid leakage caused by a break in the diaphragm. Reconnect the vacuum hose.

Scheme 34

Scheme 34: REMOVAL

Scheme 35

PRECAUTION NOTE: Be sure to read Precaution thoroughly before servicing. Refer to «PRECAUTION»(ref-400808-S18187891512011051800000) .
REMOVE RADIATOR ASSEMBLY AND FAN ASSEMBLY WITH MOTOR Remove the radiator assembly and fan assembly with motor. Refer to «REMOVAL»(ref-400800-S29930055992011051800000) .
REMOVE TRANSVERSE ENGINE MOUNTING BRACKET HINT: Securely support the automatic transaxle using a jack. Remove the nut, 3 bolts and the transverse engine mounting bracket.
REMOVE FRONT ENGINE MOUNTING INSULATOR ASSEMBLY Disconnect the 2 vacuum hoses. Disconnect the duty vacuum switching valve connector and clamp. Remove the cap, 3 nuts and front engine mounting insulator assembly. TEXT IN ILLUSTRATION *1 Hole Plug

PRECAUTION NOTE: Be sure to read Precaution thoroughly before servicing. Refer to «PRECAUTION»(ref-400808-S39927796452011051800000) .
REMOVE RADIATOR ASSEMBLY AND FAN ASSEMBLY WITH MOTOR Remove the radiator assembly and fan assembly with motor. Refer to «REMOVAL»(ref-400800-S34662827102011051800000) .
REMOVE TRANSVERSE ENGINE MOUNTING BRACKET HINT: Securely support the automatic transaxle using a jack. Remove the nut, 3 bolts and the transverse engine mounting bracket.
REMOVE FRONT ENGINE MOUNTING INSULATOR ASSEMBLY Disconnect the 2 vacuum hoses. Disconnect the duty vacuum switching valve connector and clamp. Remove the cap, 3 nuts and front engine mounting insulator assembly. TEXT IN ILLUSTRATION *1 Hole Plug

Scheme 36

Scheme 36: INSTALLATION

Scheme 37

INSTALL FRONT ENGINE MOUNTING INSULATOR ASSEMBLY Install the front engine mounting insulator assembly with the 3 nuts and cap. Torque: 52 N*m (530 kgf*cm, 38 ft.*lbf) TEXT IN ILLUSTRATION *1 Hole Plug Connect the duty vacuum switching valve connector and clamp. Connect the 2 vacuum hoses.
INSTALL TRANSVERSE ENGINE MOUNTING BRACKET Install the transverse engine mounting bracket with the 3 bolts and nut. Torque: 64 N*m (653 kgf*cm, 47 ft.*lbf) for the nut Torque: 87 N*m (887 kgf*cm, 64 ft.*lbf) for the bolt A Torque: 64 N*m (653 kgf*cm, 47 ft.*lbf) for the bolt B
INSTALL RADIATOR ASSEMBLY AND FAN ASSEMBLY WITH MOTOR Install the radiator assembly and fan assembly with motor. Refer to «INSTALLATION»(ref-400800-S15792145172011051800000) .

INSTALL FRONT ENGINE MOUNTING INSULATOR ASSEMBLY Install the front engine mounting insulator assembly with the 3 nuts and cap. Torque: 52 N*m (530 kgf*cm, 38 ft.*lbf) TEXT IN ILLUSTRATION *1 Hole Plug Connect the duty vacuum switching valve connector and clamp. Connect the 2 vacuum hoses.
INSTALL TRANSVERSE ENGINE MOUNTING BRACKET Install the transverse engine mounting bracket with the 3 bolts and nut. Torque: 64 N*m (653 kgf*cm, 47 ft.*lbf) for the nut Torque: 87 N*m (887 kgf*cm, 64 ft.*lbf) for the bolt A Torque: 64 N*m (653 kgf*cm, 47 ft.*lbf) for the bolt B
INSTALL RADIATOR ASSEMBLY AND FAN ASSEMBLY WITH MOTOR Install the radiator assembly and fan assembly with motor. Refer to «INSTALLATION»(ref-400800-S30883477082011051800000) .

Scheme 38

Scheme 38: ILLUSTRATION

Scheme 39

Scheme 39: ILLUSTRATION

Note. The Vehicle Identification Number (VIN) must be input into a replacement ECM. Refer to REGISTRATION .

Scheme 40

Scheme 40: REMOVAL

Scheme 41

Scheme 42

Scheme 43

PRECAUTION (w/ Navigation System for HDD) NOTE: After the engine switch is turned off, the display and navigation module display (HDD navigation system) records various types of memory and settings. As a result, after turning the engine switch off, make sure to wait at least 60 seconds before disconnecting the cable from the negative (-) battery terminal.
REMOVE WINDSHIELD WIPER MOTOR AND LINK ASSEMBLY Remove the windshield wiper motor and link assembly. Refer to «REMOVAL»(ref-400809-S41356394852011051800000) .
REMOVE FRONT SHOCK ABSORBER CAP (w/ Air Suspension) . Refer to «REMOVAL - Step 3»(ref-400810-S01269755922011051800000)
REMOVE OUTER COWL TOP PANEL SUB-ASSEMBLY . Refer to «REMOVAL - Step 11»(ref-400778-S07130150422011051800000)
REMOVE V-BANK COVER SUB-ASSEMBLY . Refer to «REMOVAL - Step 34»(ref-400790-S03510589702011051800000)
DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL WARNING: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to disable the SRS system. Refer to «PRECAUTION»(ref-400811-S16232838532011051800000) . NOTE: When disconnecting the cable, some systems need to be initialized after the cable is reconnected. Refer to «INITIALIZATION»(ref-400649-S12881576452011051800000) .
REMOVE NO. 2 AIR CLEANER INLET . Refer to «REMOVAL - Step 35»(ref-400790-S03510589702011051800000)
REMOVE NO. 1 AIR CLEANER INLET . Refer to «REMOVAL - Step 36»(ref-400790-S03510589702011051800000)
REMOVE BATTERY . Refer to «REMOVAL - Step 37»(ref-400790-S03510589702011051800000)
REMOVE AIR CLEANER ASSEMBLY See step 13
REMOVE ECM Separate the wire harness clamp. Separate the wire harness clamp. Disconnect the 2 ECM connectors and remove the ECM with brackets. Push in the locks on the 2 levers, raise the levers, and disconnect the 2 ECM connectors. NOTE: After disconnecting the connectors, make sure that dirt, water or other foreign matter does not contact the connecting part of the connectors. Remove the 3 bolts and the ECM with bracket. Remove the 5 screws and 2 ECM brackets. TEXT IN ILLUSTRATION *1 ECM Bracket

Note. The Vehicle Identification Number (VIN) must be input into a replacement ECM. Refer to REGISTRATION .

PRECAUTION (w/ Navigation System for HDD) NOTE: After the engine switch is turned off, the display and navigation module display (HDD navigation system) records various types of memory and settings. As a result, after turning the engine switch off, make sure to wait at least 60 seconds before disconnecting the cable from the negative (-) battery terminal.
REMOVE WINDSHIELD WIPER MOTOR AND LINK ASSEMBLY Remove the windshield wiper motor and link assembly. Refer to «REMOVAL»(ref-400809-S41356394852011051800000) .
REMOVE FRONT SHOCK ABSORBER CAP (w/ Air Suspension) . Refer to «REMOVAL - Step 3»(ref-400810-S20661286162011051800000)
REMOVE OUTER COWL TOP PANEL SUB-ASSEMBLY . Refer to «REMOVAL - Step 11»(ref-400778-S19229320722011051800000)
REMOVE V-BANK COVER SUB-ASSEMBLY . Refer to «REMOVAL - Step 34»(ref-400790-S42173954232011051800000)
DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL WARNING: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to disable the SRS system. Refer to «PRECAUTION»(ref-400811-S15765720172011051800000) . NOTE: When disconnecting the cable, some systems need to be initialized after the cable is reconnected. Refer to «INITIALIZATION»(ref-400649-S34584305262011051800000) .
REMOVE NO. 2 AIR CLEANER INLET . Refer to «REMOVAL - Step 35»(ref-400790-S42173954232011051800000)
REMOVE NO. 1 AIR CLEANER INLET . Refer to «REMOVAL - Step 36»(ref-400790-S42173954232011051800000)
REMOVE BATTERY . Refer to «REMOVAL - Step 37»(ref-400790-S42173954232011051800000)
REMOVE AIR CLEANER ASSEMBLY See step 13
REMOVE ECM Separate the wire harness clamp. Separate the wire harness clamp. Disconnect the 2 ECM connectors and remove the ECM with brackets. Push in the locks on the 2 levers, raise the levers, and disconnect the 2 ECM connectors. NOTE: After disconnecting the connectors, make sure that dirt, water or other foreign matter does not contact the connecting part of the connectors. Remove the 3 bolts and the ECM with bracket. Remove the 5 screws and 2 ECM brackets. TEXT IN ILLUSTRATION *1 ECM Bracket

Scheme 44

INSTALL ECM Install the 2 brackets to the ECM with the 5 screws. TEXT IN ILLUSTRATION *1 ECM Bracket Install the ECM with bracket with the 3 bolts. Torque: 8.0 N*m (82 kgf*cm, 70 in.*lbf) Connect the 2 ECM connectors and lower the 2 levers. NOTE: When connecting the connectors, make sure that dirt, water or other foreign matter does not become stuck between the connectors and other part. Make sure that the 2 levers are securely locked. Install the wire harness clamp. Install the wire harness clamp.
INSTALL AIR CLEANER ASSEMBLY See step 2
INSTALL BATTERY . Refer to «INSTALLATION - Step 71»(ref-400790-S30060480932011051800000)
INSTALL NO. 1 AIR CLEANER INLET . Refer to «INSTALLATION - Step 72»(ref-400790-S30060480932011051800000)
INSTALL NO. 2 AIR CLEANER INLET . Refer to «INSTALLATION - Step 73»(ref-400790-S30060480932011051800000)
CONNECT CABLE TO NEGATIVE BATTERY TERMINAL NOTE: When disconnecting the cable, some systems need to be initialized after the cable is reconnected. Refer to «INITIALIZATION»(ref-400649-S12881576452011051800000) .
INSTALL V-BANK COVER SUB-ASSEMBLY . Refer to «INSTALLATION - Step 113»(ref-400790-S30060480932011051800000)
INSTALL OUTER COWL TOP PANEL SUB-ASSEMBLY . Refer to «INSTALLATION - Step 17»(ref-400778-S06004016952011051800000)
INSTALL FRONT SHOCK ABSORBER CAP (w/ Air Suspension) . Refer to «INSTALLATION - Step 10»(ref-400810-S37673499492011051800000)
INSTALL WINDSHIELD WIPER MOTOR AND LINK ASSEMBLY Install the windshield wiper motor and link assembly. Refer to «INSTALLATION»(ref-400809-S31962938082011051800000) .
PERFORM INITIALIZATION HINT: Initialization cannot be completed by only disconnecting and reconnecting the cable of the negative (-) battery terminal. The Vehicle Identification Number (VIN) must be input into a replacement ECM. Refer to «INITIALIZATION»(ref-400649-S12881576452011051800000) . If the ECM has been replaced, register the ECM communication ID for the immobilizer system. Refer to «INITIALIZATION»(ref-400649-S12881576452011051800000) . Perform Initialization when replacing the ECM See step 14 .

INSTALL ECM Install the 2 brackets to the ECM with the 5 screws. TEXT IN ILLUSTRATION *1 ECM Bracket Install the ECM with bracket with the 3 bolts. Torque: 8.0 N*m (82 kgf*cm, 70 in.*lbf) Connect the 2 ECM connectors and lower the 2 levers. NOTE: When connecting the connectors, make sure that dirt, water or other foreign matter does not become stuck between the connectors and other part. Make sure that the 2 levers are securely locked. Install the wire harness clamp. Install the wire harness clamp.
INSTALL AIR CLEANER ASSEMBLY See step 2
INSTALL BATTERY . Refer to «INSTALLATION - Step 71»(ref-400790-S01050581782011051800000)
INSTALL NO. 1 AIR CLEANER INLET . Refer to «INSTALLATION - Step 72»(ref-400790-S01050581782011051800000)
INSTALL NO. 2 AIR CLEANER INLET . Refer to «INSTALLATION - Step 73»(ref-400790-S01050581782011051800000)
CONNECT CABLE TO NEGATIVE BATTERY TERMINAL NOTE: When disconnecting the cable, some systems need to be initialized after the cable is reconnected. Refer to «INITIALIZATION»(ref-400649-S34584305262011051800000) .
INSTALL V-BANK COVER SUB-ASSEMBLY . Refer to «INSTALLATION - Step 113»(ref-400790-S01050581782011051800000)
INSTALL OUTER COWL TOP PANEL SUB-ASSEMBLY . Refer to «INSTALLATION - Step 17»(ref-400778-S22039083752011051800000)
INSTALL FRONT SHOCK ABSORBER CAP (w/ Air Suspension) . Refer to «INSTALLATION - Step 10»(ref-400810-S15685281082011051800000)
INSTALL WINDSHIELD WIPER MOTOR AND LINK ASSEMBLY Install the windshield wiper motor and link assembly. Refer to «INSTALLATION»(ref-400809-S31962938082011051800000) .
PERFORM INITIALIZATION HINT: Initialization cannot be completed by only disconnecting and reconnecting the cable of the negative (-) battery terminal. The Vehicle Identification Number (VIN) must be input into a replacement ECM. Refer to «INITIALIZATION»(ref-400649-S34584305262011051800000) . If the ECM has been replaced, register the ECM communication ID for the immobilizer system. Refer to «INITIALIZATION»(ref-400649-S34584305262011051800000) . Perform Initialization when replacing the ECM See step 14 .

Scheme 45

Scheme 45: ILLUSTRATION

INSTALL ACCELERATOR PEDAL ASSEMBLY Install the accelerator pedal assembly with the 2 nuts. Torque: 5.4 N*m (55 kgf*cm, 48 in.*lbf) NOTE: Avoid physical shocks to the accelerator pedal assembly. Connect the accelerator pedal assembly connector.
INSTALL NO. 1 INSTRUMENT PANEL UNDER COVER SUB-ASSEMBLY

Scheme 46

Scheme 46: ILLUSTRATION

REMOVE WINDSHIELD WIPER MOTOR AND LINK ASSEMBLY Remove the windshield wiper motor and link assembly. Refer to «REMOVAL»(ref-400809-S41356394852011051800000) .
REMOVE FRONT SHOCK ABSORBER CAP (w/ Air Suspension) . Refer to «REMOVAL - Step 3»(ref-400810-S20661286162011051800000)
REMOVE OUTER COWL TOP PANEL SUB-ASSEMBLY . Refer to «REMOVAL - Step 11»(ref-400778-S19229320722011051800000)
REMOVE MASS AIR FLOW METER Separate the mass air flow meter connector. Remove the 2 screws and mass air flow meter.

Scheme 47

Scheme 47: INSPECTION

Scheme 48

INSPECT MASS AIR FLOW METER Perform a visual check for any foreign matter on the platinum hot wire (heater) of the mass air flow meter shown in the illustration. OK There is no foreign matter. TEXT IN ILLUSTRATION *1 Platinum Hot Wire (Heater) If the result is not as specified, replace the mass air flow meter. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 1 (THA) - 2 (E2) -20°C (-4°F) 13.6 to 18.4 kohms 1 (THA) - 2 (E2) 20°C (68°F) 2.21 to 2.69 kohms 1 (THA) - 2 (E2) 60°C (140°F) 0.49 to 0.67 kohms TEXT IN ILLUSTRATION *1 Mass Air Flow Meter If the result is not as specified, replace the mass air flow meter.

INSTALL MASS AIR FLOW METER Install the mass air flow meter with the 2 screws. NOTE: Make sure that the O-ring is not cracked or does not jump out of position during installation. Connect the mass air flow meter connector.
INSTALL OUTER COWL TOP PANEL SUB-ASSEMBLY . Refer to «INSTALLATION - Step 17»(ref-400778-S06004016952011051800000)
INSTALL FRONT SHOCK ABSORBER CAP (w/ Air Suspension) . Refer to «INSTALLATION - Step 10»(ref-400810-S37673499492011051800000)
INSTALL WINDSHIELD WIPER MOTOR AND LINK ASSEMBLY Install the windshield wiper motor and link assembly. Refer to «INSTALLATION»(ref-400809-S31962938082011051800000) .

INSTALL MASS AIR FLOW METER Install the mass air flow meter with the 2 screws. NOTE: Make sure that the O-ring is not cracked or does not jump out of position during installation. Connect the mass air flow meter connector.
INSTALL OUTER COWL TOP PANEL SUB-ASSEMBLY . Refer to «INSTALLATION - Step 17»(ref-400778-S22039083752011051800000)
INSTALL FRONT SHOCK ABSORBER CAP (w/ Air Suspension) . Refer to «INSTALLATION - Step 10»(ref-400810-S15685281082011051800000)
INSTALL WINDSHIELD WIPER MOTOR AND LINK ASSEMBLY Install the windshield wiper motor and link assembly. Refer to «INSTALLATION»(ref-400809-S31962938082011051800000) .

Scheme 49

Scheme 49: ILLUSTRATION

Scheme 50

Scheme 50: REMOVAL

PRECAUTION (w/ Air Suspension) NOTE: Be sure to read Precaution thoroughly before servicing. Refer to «PRECAUTION»(ref-400808-S18187891512011051800000) .
PRECAUTION (w/ Navigation System for HDD) NOTE: After the engine switch is turned off, the display and navigation module display (HDD navigation system) records various types of memory and settings. As a result, after turning the engine switch off, make sure to wait at least 60 seconds before disconnecting the cable from the negative (-) battery terminal.
REMOVE WINDSHIELD WIPER MOTOR AND LINK ASSEMBLY Remove the windshield wiper motor and link assembly. Refer to «REMOVAL»(ref-400809-S41356394852011051800000) .
REMOVE FRONT SHOCK ABSORBER CAP (w/ Air Suspension) . Refer to «REMOVAL - Step 3»(ref-400810-S01269755922011051800000)
REMOVE OUTER COWL TOP PANEL SUB-ASSEMBLY . Refer to «REMOVAL - Step 11»(ref-400778-S07130150422011051800000)
REMOVE V-BANK COVER SUB-ASSEMBLY . Refer to «REMOVAL - Step 34»(ref-400790-S03510589702011051800000)
DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL WARNING: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to disable the SRS system. Refer to «PRECAUTION»(ref-400811-S16232838532011051800000) . NOTE: When disconnecting the cable, some systems need to be initialized after the cable is reconnected. Refer to «INITIALIZATION»(ref-400649-S12881576452011051800000) .
REMOVE NO. 2 AIR CLEANER INLET . Refer to «REMOVAL - Step 35»(ref-400790-S03510589702011051800000)
REMOVE NO. 1 AIR CLEANER INLET . Refer to «REMOVAL - Step 36»(ref-400790-S03510589702011051800000)
REMOVE BATTERY . Refer to «REMOVAL - Step 37»(ref-400790-S03510589702011051800000)
REMOVE NO. 1 ENGINE UNDER COVER
DRAIN ENGINE COOLANT . Refer to «REPLACEMENT - Step 7»(ref-400800-S21803137222011051800000)
REMOVE AIR CLEANER ASSEMBLY See step 13
REMOVE INTAKE AIR SURGE TANK ASSEMBLY . Refer to «REMOVAL - Step 3»(ref-400802-S06641726382011051800000)
REMOVE VVT SENSOR Disconnect the 4 sensor connectors. Remove the 4 bolts and 4 sensors.

PRECAUTION (w/ Air Suspension) NOTE: Be sure to read Precaution thoroughly before servicing. Refer to «PRECAUTION»(ref-400808-S39927796452011051800000) .
PRECAUTION (w/ Navigation System for HDD) NOTE: After the engine switch is turned off, the display and navigation module display (HDD navigation system) records various types of memory and settings. As a result, after turning the engine switch off, make sure to wait at least 60 seconds before disconnecting the cable from the negative (-) battery terminal.
REMOVE WINDSHIELD WIPER MOTOR AND LINK ASSEMBLY Remove the windshield wiper motor and link assembly. Refer to «REMOVAL»(ref-400809-S41356394852011051800000) .
REMOVE FRONT SHOCK ABSORBER CAP (w/ Air Suspension) . Refer to «REMOVAL - Step 3»(ref-400810-S20661286162011051800000)
REMOVE OUTER COWL TOP PANEL SUB-ASSEMBLY . Refer to «REMOVAL - Step 11»(ref-400778-S19229320722011051800000)
REMOVE V-BANK COVER SUB-ASSEMBLY . Refer to «REMOVAL - Step 34»(ref-400790-S42173954232011051800000)
DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL WARNING: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to disable the SRS system. Refer to «PRECAUTION»(ref-400811-S15765720172011051800000) . NOTE: When disconnecting the cable, some systems need to be initialized after the cable is reconnected. Refer to «INITIALIZATION»(ref-400649-S34584305262011051800000) .
REMOVE NO. 2 AIR CLEANER INLET . Refer to «REMOVAL - Step 35»(ref-400790-S42173954232011051800000)
REMOVE NO. 1 AIR CLEANER INLET . Refer to «REMOVAL - Step 36»(ref-400790-S42173954232011051800000)
REMOVE BATTERY . Refer to «REMOVAL - Step 37»(ref-400790-S42173954232011051800000)
REMOVE NO. 1 ENGINE UNDER COVER
DRAIN ENGINE COOLANT . Refer to «REPLACEMENT - Step 7»(ref-400800-S05976021912011051800000)
REMOVE AIR CLEANER ASSEMBLY See step 13
REMOVE INTAKE AIR SURGE TANK ASSEMBLY . Refer to «REMOVAL - Step 3»(ref-400802-S36931150902011051800000)
REMOVE VVT SENSOR Disconnect the 4 sensor connectors. Remove the 4 bolts and 4 sensors.

INSTALL VVT SENSOR Install the 4 sensors with the 4 bolts. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf) Connect the 4 sensor connectors.
INSTALL INTAKE AIR SURGE TANK ASSEMBLY . Refer to «INSTALLATION - Step 5»(ref-400802-S09938504842011051800000)
INSTALL AIR CLEANER ASSEMBLY See step 2
INSTALL BATTERY . Refer to «INSTALLATION - Step 71»(ref-400790-S30060480932011051800000)
INSTALL NO. 1 AIR CLEANER INLET . Refer to «INSTALLATION - Step 72»(ref-400790-S30060480932011051800000)
INSTALL NO. 2 AIR CLEANER INLET . Refer to «INSTALLATION - Step 73»(ref-400790-S30060480932011051800000)
CONNECT CABLE TO NEGATIVE BATTERY TERMINAL NOTE: When disconnecting the cable, some systems need to be initialized after the cable is reconnected. Refer to «INITIALIZATION»(ref-400649-S12881576452011051800000) .
ADD ENGINE COOLANT . Refer to «REPLACEMENT - Step 8»(ref-400800-S21803137222011051800000)
INSPECT FOR COOLANT LEAK . Refer to «ON-VEHICLE INSPECTION - Step 1»(ref-400812-S34139223332011051800000)
INSPECT FOR OIL LEAK Start the engine, and check that there are no oil leaks.
INSTALL V-BANK COVER SUB-ASSEMBLY . Refer to «INSTALLATION - Step 113»(ref-400790-S30060480932011051800000)
INSTALL OUTER COWL TOP PANEL SUB-ASSEMBLY . Refer to «INSTALLATION - Step 17»(ref-400778-S06004016952011051800000)
INSTALL FRONT SHOCK ABSORBER CAP (w/ Air Suspension) . Refer to «INSTALLATION - Step 10»(ref-400810-S37673499492011051800000)
INSTALL WINDSHIELD WIPER MOTOR AND LINK ASSEMBLY Install the windshield wiper motor and link assembly. Refer to «INSTALLATION»(ref-400809-S31962938082011051800000) .
INSTALL NO. 1 ENGINE UNDER COVER

INSTALL VVT SENSOR Install the 4 sensors with the 4 bolts. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf) Connect the 4 sensor connectors.
INSTALL INTAKE AIR SURGE TANK ASSEMBLY . Refer to «INSTALLATION - Step 5»(ref-400802-S09705609702011051800000)
INSTALL AIR CLEANER ASSEMBLY See step 2
INSTALL BATTERY . Refer to «INSTALLATION - Step 71»(ref-400790-S01050581782011051800000)
INSTALL NO. 1 AIR CLEANER INLET . Refer to «INSTALLATION - Step 72»(ref-400790-S01050581782011051800000)
INSTALL NO. 2 AIR CLEANER INLET . Refer to «INSTALLATION - Step 73»(ref-400790-S01050581782011051800000)
CONNECT CABLE TO NEGATIVE BATTERY TERMINAL NOTE: When disconnecting the cable, some systems need to be initialized after the cable is reconnected. Refer to «INITIALIZATION»(ref-400649-S34584305262011051800000) .
ADD ENGINE COOLANT . Refer to «REPLACEMENT - Step 8»(ref-400800-S05976021912011051800000)
INSPECT FOR COOLANT LEAK . Refer to «ON-VEHICLE INSPECTION - Step 1»(ref-400812-S34139223332011051800000)
INSPECT FOR OIL LEAK Start the engine, and check that there are no oil leaks.
INSTALL V-BANK COVER SUB-ASSEMBLY . Refer to «INSTALLATION - Step 113»(ref-400790-S01050581782011051800000)
INSTALL OUTER COWL TOP PANEL SUB-ASSEMBLY . Refer to «INSTALLATION - Step 17»(ref-400778-S22039083752011051800000)
INSTALL FRONT SHOCK ABSORBER CAP (w/ Air Suspension) . Refer to «INSTALLATION - Step 10»(ref-400810-S15685281082011051800000)
INSTALL WINDSHIELD WIPER MOTOR AND LINK ASSEMBLY Install the windshield wiper motor and link assembly. Refer to «INSTALLATION»(ref-400809-S31962938082011051800000) .
INSTALL NO. 1 ENGINE UNDER COVER

Scheme 51

Scheme 51: ILLUSTRATION

Scheme 52

Scheme 52: REMOVAL

PRECAUTION (w/ Air Suspension) NOTE: Be sure to read Precaution thoroughly before servicing. Refer to «PRECAUTION»(ref-400808-S18187891512011051800000) .
REMOVE COMPRESSOR AND MAGNETIC CLUTCH Remove the compressor and magnetic clutch. Refer to «REMOVAL»(ref-400783-S29353979272011051800000) .
REMOVE CRANK POSITION SENSOR Disconnect the crank position sensor connector. Remove the bolt and crank position sensor.

PRECAUTION (w/ Air Suspension) NOTE: Be sure to read Precaution thoroughly before servicing. Refer to «PRECAUTION»(ref-400808-S39927796452011051800000) .
REMOVE COMPRESSOR AND MAGNETIC CLUTCH Remove the compressor and magnetic clutch. Refer to «REMOVAL»(ref-400783-S04470433622011051800000) .
REMOVE CRANK POSITION SENSOR Disconnect the crank position sensor connector. Remove the bolt and crank position sensor.

Scheme 53

Scheme 53: INSPECTION

INSPECT CRANK POSITION SENSOR Measure the resistance according to the value(s) in the table below. Standard Resistance Temperature Specified Condition Cold 1630 to 2740 ohms Hot 2065 to 3225 ohms TEXT IN ILLUSTRATION *1 Component without harness connected (Crankshaft Position Sensor) HINT: "Cold" and "Hot" mean the temperature of the coils themselves. "Cold" is from -10 to 50°C (14 to 122 °F) and "Hot" is from 50 to 100°C (122 to 212°F). If the resistance is not as specified, replace the crank position sensor.

Scheme 54

Scheme 54: INSTALLATION

INSTALL CRANK POSITION SENSOR Apply a light coat of engine oil to the O-ring on the crank position sensor. TEXT IN ILLUSTRATION *1 O-ring Install the crank position sensor with the bolt. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf) Connect the crank position sensor connector.
INSTALL COMPRESSOR AND MAGNETIC CLUTCH Install the compressor and magnetic clutch. Refer to «INSTALLATION»(ref-400783-S25769912262011051800000) .

INSTALL CRANK POSITION SENSOR Apply a light coat of engine oil to the O-ring on the crank position sensor. TEXT IN ILLUSTRATION *1 O-ring Install the crank position sensor with the bolt. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf) Connect the crank position sensor connector.
INSTALL COMPRESSOR AND MAGNETIC CLUTCH Install the compressor and magnetic clutch. Refer to «INSTALLATION»(ref-400783-S11571281032011051800000) .

Scheme 55

Scheme 55: ILLUSTRATION

Scheme 56

Scheme 56: REMOVAL

Scheme 57

Scheme 58

Scheme 59

PRECAUTION (w/ Air Suspension) NOTE: Be sure to read Precaution thoroughly before servicing. Refer to «PRECAUTION»(ref-400808-S18187891512011051800000) .
PRECAUTION (w/ Navigation System for HDD) NOTE: After the engine switch is turned off, the display and navigation module display (HDD navigation system) records various types of memory and settings. As a result, after turning the engine switch off, make sure to wait at least 60 seconds before disconnecting the cable from the negative (-) battery terminal.
REMOVE WINDSHIELD WIPER MOTOR AND LINK ASSEMBLY Remove the windshield wiper motor and link assembly. Refer to «REMOVAL»(ref-400809-S41356394852011051800000) .
REMOVE FRONT SHOCK ABSORBER CAP (w/ Air Suspension) . Refer to «REMOVAL - Step 3»(ref-400810-S01269755922011051800000)
REMOVE OUTER COWL TOP PANEL SUB-ASSEMBLY . Refer to «REMOVAL - Step 11»(ref-400778-S07130150422011051800000)
REMOVE V-BANK COVER SUB-ASSEMBLY . Refer to «REMOVAL - Step 34»(ref-400790-S03510589702011051800000)
DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL WARNING: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to disable the SRS system. Refer to «PRECAUTION»(ref-400811-S16232838532011051800000) . NOTE: When disconnecting the cable, some systems need to be initialized after the cable is reconnected. Refer to «INITIALIZATION»(ref-400649-S12881576452011051800000) .
REMOVE NO. 2 AIR CLEANER INLET . Refer to «REMOVAL - Step 35»(ref-400790-S03510589702011051800000)
REMOVE NO. 1 AIR CLEANER INLET . Refer to «REMOVAL - Step 36»(ref-400790-S03510589702011051800000)
REMOVE BATTERY . Refer to «REMOVAL - Step 37»(ref-400790-S03510589702011051800000)
REMOVE NO. 1 ENGINE UNDER COVER
DRAIN ENGINE COOLANT . Refer to «REPLACEMENT - Step 7»(ref-400800-S21803137222011051800000)
REMOVE AIR CLEANER ASSEMBLY See step 13
REMOVE INTAKE AIR SURGE TANK ASSEMBLY . Refer to «REMOVAL - Step 3»(ref-400802-S06641726382011051800000)
REMOVE NO. 1 SURGE TANK STAY . Refer to «REMOVAL - Step 4»(ref-400790-S23937829252011051800000)
REMOVE IGNITION COIL ASSEMBLY Disconnect the 3 wire harness clamps. Disconnect the 6 ignition coil connectors. Remove the 6 bolts and 6 ignition coils.
REMOVE SPARK PLUG Remove the 6 spark plugs.

PRECAUTION (w/ Air Suspension) NOTE: Be sure to read Precaution thoroughly before servicing. Refer to «PRECAUTION»(ref-400808-S39927796452011051800000) .
PRECAUTION (w/ Navigation System for HDD) NOTE: After the engine switch is turned off, the display and navigation module display (HDD navigation system) records various types of memory and settings. As a result, after turning the engine switch off, make sure to wait at least 60 seconds before disconnecting the cable from the negative (-) battery terminal.
REMOVE WINDSHIELD WIPER MOTOR AND LINK ASSEMBLY Remove the windshield wiper motor and link assembly. Refer to «REMOVAL»(ref-400809-S41356394852011051800000) .
REMOVE FRONT SHOCK ABSORBER CAP (w/ Air Suspension) . Refer to «REMOVAL - Step 3»(ref-400810-S20661286162011051800000)
REMOVE OUTER COWL TOP PANEL SUB-ASSEMBLY . Refer to «REMOVAL - Step 11»(ref-400778-S19229320722011051800000)
REMOVE V-BANK COVER SUB-ASSEMBLY . Refer to «REMOVAL - Step 34»(ref-400790-S42173954232011051800000)
DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL WARNING: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to disable the SRS system. Refer to «PRECAUTION»(ref-400811-S15765720172011051800000) . NOTE: When disconnecting the cable, some systems need to be initialized after the cable is reconnected. Refer to «INITIALIZATION»(ref-400649-S34584305262011051800000) .
REMOVE NO. 2 AIR CLEANER INLET . Refer to «REMOVAL - Step 35»(ref-400790-S42173954232011051800000)
REMOVE NO. 1 AIR CLEANER INLET . Refer to «REMOVAL - Step 36»(ref-400790-S42173954232011051800000)
REMOVE BATTERY . Refer to «REMOVAL - Step 37»(ref-400790-S42173954232011051800000)
REMOVE NO. 1 ENGINE UNDER COVER
DRAIN ENGINE COOLANT . Refer to «REPLACEMENT - Step 7»(ref-400800-S05976021912011051800000)
REMOVE AIR CLEANER ASSEMBLY See step 13
REMOVE INTAKE AIR SURGE TANK ASSEMBLY . Refer to «REMOVAL - Step 3»(ref-400802-S36931150902011051800000)
REMOVE NO. 1 SURGE TANK STAY . Refer to «REMOVAL - Step 4»(ref-400790-S22188355832011051800000)
REMOVE IGNITION COIL ASSEMBLY Disconnect the 3 wire harness clamps. Disconnect the 6 ignition coil connectors. Remove the 6 bolts and 6 ignition coils.
REMOVE SPARK PLUG Remove the 6 spark plugs.

Scheme 60

Scheme 60: INSTALLATION

INSTALL SPARK PLUG Install the 6 spark plugs. Torque: 18 N*m (184 kgf*cm, 13 ft.*lbf)
INSTALL IGNITION COIL ASSEMBLY Install the 6 ignition coils with the 6 bolts. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf) Connect the 6 ignition coil connectors. Connect the 3 wire harness clamps.
INSTALL NO. 1 SURGE TANK STAY . Refer to «INSTALLATION - Step 18»(ref-400790-S34028239022011051800000)
INSTALL INTAKE AIR SURGE TANK ASSEMBLY . Refer to «INSTALLATION - Step 5»(ref-400802-S09938504842011051800000)
INSTALL AIR CLEANER ASSEMBLY See step 2
INSTALL BATTERY . Refer to «INSTALLATION - Step 71»(ref-400790-S30060480932011051800000)
INSTALL NO. 1 AIR CLEANER INLET . Refer to «INSTALLATION - Step 72»(ref-400790-S30060480932011051800000)
INSTALL NO. 2 AIR CLEANER INLET . Refer to «INSTALLATION - Step 73»(ref-400790-S30060480932011051800000)
CONNECT CABLE TO NEGATIVE BATTERY TERMINAL NOTE: When disconnecting the cable, some systems need to be initialized after the cable is reconnected. Refer to «INITIALIZATION»(ref-400649-S12881576452011051800000) .
ADD ENGINE COOLANT . Refer to «REPLACEMENT - Step 8»(ref-400800-S21803137222011051800000)
INSPECT FOR ENGINE COOLANT LEAK . Refer to «ON-VEHICLE INSPECTION - Step 1»(ref-400812-S34139223332011051800000)
INSTALL V-BANK COVER SUB-ASSEMBLY . Refer to «INSTALLATION - Step 113»(ref-400790-S30060480932011051800000)
INSTALL OUTER COWL TOP PANEL SUB-ASSEMBLY . Refer to «INSTALLATION - Step 17»(ref-400778-S06004016952011051800000)
INSTALL FRONT SHOCK ABSORBER CAP (w/ Air Suspension) . Refer to «INSTALLATION - Step 10»(ref-400810-S37673499492011051800000)
INSTALL WINDSHIELD WIPER MOTOR AND LINK ASSEMBLY Install the windshield wiper motor and link assembly. Refer to «INSTALLATION»(ref-400809-S31962938082011051800000) .
INSTALL NO. 1 ENGINE UNDER COVER

INSTALL SPARK PLUG Install the 6 spark plugs. Torque: 18 N*m (184 kgf*cm, 13 ft.*lbf)
INSTALL IGNITION COIL ASSEMBLY Install the 6 ignition coils with the 6 bolts. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf) Connect the 6 ignition coil connectors. Connect the 3 wire harness clamps.
INSTALL NO. 1 SURGE TANK STAY . Refer to «INSTALLATION - Step 18»(ref-400790-S04230915992011051800000)
INSTALL INTAKE AIR SURGE TANK ASSEMBLY . Refer to «INSTALLATION - Step 5»(ref-400802-S09705609702011051800000)
INSTALL AIR CLEANER ASSEMBLY See step 2
INSTALL BATTERY . Refer to «INSTALLATION - Step 71»(ref-400790-S01050581782011051800000)
INSTALL NO. 1 AIR CLEANER INLET . Refer to «INSTALLATION - Step 72»(ref-400790-S01050581782011051800000)
INSTALL NO. 2 AIR CLEANER INLET . Refer to «INSTALLATION - Step 73»(ref-400790-S01050581782011051800000)
CONNECT CABLE TO NEGATIVE BATTERY TERMINAL NOTE: When disconnecting the cable, some systems need to be initialized after the cable is reconnected. Refer to «INITIALIZATION»(ref-400649-S34584305262011051800000) .
ADD ENGINE COOLANT . Refer to «REPLACEMENT - Step 8»(ref-400800-S05976021912011051800000)
INSPECT FOR ENGINE COOLANT LEAK . Refer to «ON-VEHICLE INSPECTION - Step 1»(ref-400812-S34139223332011051800000)
INSTALL V-BANK COVER SUB-ASSEMBLY . Refer to «INSTALLATION - Step 113»(ref-400790-S01050581782011051800000)
INSTALL OUTER COWL TOP PANEL SUB-ASSEMBLY . Refer to «INSTALLATION - Step 17»(ref-400778-S22039083752011051800000)
INSTALL FRONT SHOCK ABSORBER CAP (w/ Air Suspension) . Refer to «INSTALLATION - Step 10»(ref-400810-S15685281082011051800000)
INSTALL WINDSHIELD WIPER MOTOR AND LINK ASSEMBLY Install the windshield wiper motor and link assembly. Refer to «INSTALLATION»(ref-400809-S31962938082011051800000) .
INSTALL NO. 1 ENGINE UNDER COVER

Scheme 61

Scheme 61: ILLUSTRATION

Scheme 62

Scheme 62: REMOVAL

PRECAUTION (w/ Air Suspension) NOTE: Be sure to read Precaution thoroughly before servicing. Refer to «PRECAUTION»(ref-400808-S18187891512011051800000) .
PRECAUTION (w/ Navigation System for HDD) NOTE: After the engine switch is turned off, the display and navigation module display (HDD navigation system) records various types of memory and settings. As a result, after turning the engine switch off, make sure to wait at least 60 seconds before disconnecting the cable from the negative (-) battery terminal.
REMOVE WINDSHIELD WIPER MOTOR AND LINK ASSEMBLY Remove the windshield wiper motor and link assembly. Refer to «REMOVAL»(ref-400809-S41356394852011051800000) .
REMOVE FRONT SHOCK ABSORBER CAP (w/ Air Suspension) . Refer to «REMOVAL - Step 3»(ref-400810-S01269755922011051800000)
REMOVE OUTER COWL TOP PANEL SUB-ASSEMBLY . Refer to «REMOVAL - Step 11»(ref-400778-S07130150422011051800000)
REMOVE V-BANK COVER SUB-ASSEMBLY . Refer to «REMOVAL - Step 34»(ref-400790-S03510589702011051800000)
DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL WARNING: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to disable the SRS system. Refer to «PRECAUTION»(ref-400811-S16232838532011051800000) . NOTE: When disconnecting the cable, some systems need to be initialized after the cable is reconnected. Refer to «INITIALIZATION»(ref-400649-S12881576452011051800000) .
REMOVE NO. 1 ENGINE UNDER COVER
DRAIN ENGINE COOLANT . Refer to «REPLACEMENT - Step 7»(ref-400800-S21803137222011051800000)
REMOVE BATTERY . Refer to «REMOVAL - Step 37»(ref-400790-S03510589702011051800000)
REMOVE NO. 2 AIR CLEANER INLET . Refer to «REMOVAL - Step 35»(ref-400790-S03510589702011051800000)
REMOVE NO. 1 AIR CLEANER INLET . Refer to «REMOVAL - Step 36»(ref-400790-S03510589702011051800000)
REMOVE AIR CLEANER ASSEMBLY See step 13
REMOVE ENGINE COOLANT TEMPERATURE SENSOR Disconnect the engine coolant temperature sensor connector. Remove the engine coolant temperature sensor and gasket.

PRECAUTION (w/ Air Suspension) NOTE: Be sure to read Precaution thoroughly before servicing. Refer to «PRECAUTION»(ref-400808-S39927796452011051800000) .
PRECAUTION (w/ Navigation System for HDD) NOTE: After the engine switch is turned off, the display and navigation module display (HDD navigation system) records various types of memory and settings. As a result, after turning the engine switch off, make sure to wait at least 60 seconds before disconnecting the cable from the negative (-) battery terminal.
REMOVE WINDSHIELD WIPER MOTOR AND LINK ASSEMBLY Remove the windshield wiper motor and link assembly. Refer to «REMOVAL»(ref-400809-S41356394852011051800000) .
REMOVE FRONT SHOCK ABSORBER CAP (w/ Air Suspension) . Refer to «REMOVAL - Step 3»(ref-400810-S20661286162011051800000)
REMOVE OUTER COWL TOP PANEL SUB-ASSEMBLY . Refer to «REMOVAL - Step 11»(ref-400778-S19229320722011051800000)
REMOVE V-BANK COVER SUB-ASSEMBLY . Refer to «REMOVAL - Step 34»(ref-400790-S42173954232011051800000)
DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL WARNING: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to disable the SRS system. Refer to «PRECAUTION»(ref-400811-S15765720172011051800000) . NOTE: When disconnecting the cable, some systems need to be initialized after the cable is reconnected. Refer to «INITIALIZATION»(ref-400649-S34584305262011051800000) .
REMOVE NO. 1 ENGINE UNDER COVER
DRAIN ENGINE COOLANT . Refer to «REPLACEMENT - Step 7»(ref-400800-S05976021912011051800000)
REMOVE BATTERY . Refer to «REMOVAL - Step 37»(ref-400790-S42173954232011051800000)
REMOVE NO. 2 AIR CLEANER INLET . Refer to «REMOVAL - Step 35»(ref-400790-S42173954232011051800000)
REMOVE NO. 1 AIR CLEANER INLET . Refer to «REMOVAL - Step 36»(ref-400790-S42173954232011051800000)
REMOVE AIR CLEANER ASSEMBLY See step 13
REMOVE ENGINE COOLANT TEMPERATURE SENSOR Disconnect the engine coolant temperature sensor connector. Remove the engine coolant temperature sensor and gasket.

Scheme 63

Scheme 63: INSPECTION

INSPECT ENGINE COOLANT TEMPERATURE SENSOR Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 1 (E2) - 2 (THW) 20°C (68°F) 2.32 to 2.59 kohms 1 (E2) - 2 (THW) 80°C (176°F) 0.310 to 0.326 kohms NOTE: If checking the sensor in water, be careful not to allow water to contact the terminals. After checking, wipe the water off the sensor. If the result is not as specified, replace the engine coolant temperature sensor.

INSTALL ENGINE COOLANT TEMPERATURE SENSOR Install a new gasket onto the engine coolant temperature sensor. Install the engine coolant temperature sensor and gasket. Torque: 20 N*m (204 kgf*cm, 15 ft.*lbf) Connect the engine coolant temperature sensor connector.
INSTALL AIR CLEANER ASSEMBLY See step 2
INSTALL NO. 1 AIR CLEANER INLET . Refer to «INSTALLATION - Step 72»(ref-400790-S30060480932011051800000)
INSTALL NO. 2 AIR CLEANER INLET . Refer to «INSTALLATION - Step 73»(ref-400790-S30060480932011051800000)
INSTALL BATTERY . Refer to «INSTALLATION - Step 71»(ref-400790-S30060480932011051800000)
CONNECT CABLE TO NEGATIVE BATTERY TERMINAL NOTE: When disconnecting the cable, some systems need to be initialized after the cable is reconnected. Refer to «INITIALIZATION»(ref-400649-S12881576452011051800000) .
ADD ENGINE COOLANT . Refer to «REPLACEMENT - Step 8»(ref-400800-S21803137222011051800000)
INSPECT FOR COOLANT LEAK . Refer to «ON-VEHICLE INSPECTION - Step 1»(ref-400812-S34139223332011051800000)
INSTALL V-BANK COVER SUB-ASSEMBLY . Refer to «INSTALLATION - Step 113»(ref-400790-S30060480932011051800000)
INSTALL OUTER COWL TOP PANEL SUB-ASSEMBLY . Refer to «INSTALLATION - Step 17»(ref-400778-S06004016952011051800000)
INSTALL FRONT SHOCK ABSORBER CAP (w/ Air Suspension) . Refer to «INSTALLATION - Step 10»(ref-400810-S37673499492011051800000)
INSTALL WINDSHIELD WIPER MOTOR AND LINK ASSEMBLY Install the windshield wiper motor and link assembly. Refer to «INSTALLATION»(ref-400809-S31962938082011051800000) .
INSTALL NO. 1 ENGINE UNDER COVER

INSTALL ENGINE COOLANT TEMPERATURE SENSOR Install a new gasket onto the engine coolant temperature sensor. Install the engine coolant temperature sensor and gasket. Torque: 20 N*m (204 kgf*cm, 15 ft.*lbf) Connect the engine coolant temperature sensor connector.
INSTALL AIR CLEANER ASSEMBLY See step 2
INSTALL NO. 1 AIR CLEANER INLET . Refer to «INSTALLATION - Step 72»(ref-400790-S01050581782011051800000)
INSTALL NO. 2 AIR CLEANER INLET . Refer to «INSTALLATION - Step 73»(ref-400790-S01050581782011051800000)
INSTALL BATTERY . Refer to «INSTALLATION - Step 71»(ref-400790-S01050581782011051800000)
CONNECT CABLE TO NEGATIVE BATTERY TERMINAL NOTE: When disconnecting the cable, some systems need to be initialized after the cable is reconnected. Refer to «INITIALIZATION»(ref-400649-S34584305262011051800000) .
ADD ENGINE COOLANT . Refer to «REPLACEMENT - Step 8»(ref-400800-S05976021912011051800000)
INSPECT FOR COOLANT LEAK . Refer to «ON-VEHICLE INSPECTION - Step 1»(ref-400812-S34139223332011051800000)
INSTALL V-BANK COVER SUB-ASSEMBLY . Refer to «INSTALLATION - Step 113»(ref-400790-S01050581782011051800000)
INSTALL OUTER COWL TOP PANEL SUB-ASSEMBLY . Refer to «INSTALLATION - Step 17»(ref-400778-S22039083752011051800000)
INSTALL FRONT SHOCK ABSORBER CAP (w/ Air Suspension) . Refer to «INSTALLATION - Step 10»(ref-400810-S15685281082011051800000)
INSTALL WINDSHIELD WIPER MOTOR AND LINK ASSEMBLY Install the windshield wiper motor and link assembly. Refer to «INSTALLATION»(ref-400809-S31962938082011051800000) .
INSTALL NO. 1 ENGINE UNDER COVER

Scheme 64

Scheme 64: ILLUSTRATION

Scheme 65

Scheme 65: ILLUSTRATION

Scheme 66

Scheme 66: REMOVAL

PRECAUTION (w/ Air Suspension) NOTE: Be sure to read Precaution thoroughly before servicing. Refer to «PRECAUTION»(ref-400808-S18187891512011051800000) .
REMOVE INTAKE MANIFOLD Remove the intake manifold. Refer to «REMOVAL»(ref-400802-S19437195772011051800000) .
REMOVE KNOCK CONTROL SENSOR Disconnect the 2 knock control sensor connectors. Remove the 2 bolts and 2 knock control sensors.

PRECAUTION (w/ Air Suspension) NOTE: Be sure to read Precaution thoroughly before servicing. Refer to «PRECAUTION»(ref-400808-S39927796452011051800000) .
REMOVE INTAKE MANIFOLD Remove the intake manifold. Refer to «REMOVAL»(ref-400802-S05084489782011051800000) .
REMOVE KNOCK CONTROL SENSOR Disconnect the 2 knock control sensor connectors. Remove the 2 bolts and 2 knock control sensors.

Scheme 67

Scheme 67: INSPECTION

INSPECT KNOCK CONTROL SENSOR Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 1 (Ground) - 2 (Output) 20°C (68°F) 120 to 280 kohms TEXT IN ILLUSTRATION *1 Ground *2 Output If the result is not as specified, replace the knock control sensor.

Scheme 68

Scheme 68: INSTALLATION

INSTALL KNOCK CONTROL SENSOR Install the 2 knock control sensors with the 2 bolts as shown in the illustration. Torque: 20 N*m (204 kgf*cm, 15 ft.*lbf) NOTE: Make sure that each knock control sensor is in the correct position. Connect the 2 knock control sensor connectors.
INSTALL INTAKE MANIFOLD Install the intake manifold. Refer to «INSTALLATION»(ref-400802-S09606954432011051800000) .

INSTALL KNOCK CONTROL SENSOR Install the 2 knock control sensors with the 2 bolts as shown in the illustration. Torque: 20 N*m (204 kgf*cm, 15 ft.*lbf) NOTE: Make sure that each knock control sensor is in the correct position. Connect the 2 knock control sensor connectors.
INSTALL INTAKE MANIFOLD Install the intake manifold. Refer to «INSTALLATION»(ref-400802-S25657862122011051800000) .

Scheme 69

Scheme 69: ILLUSTRATION

Scheme 70

Scheme 70: REMOVAL

PRECAUTION (w/ Air Suspension) NOTE: Be sure to read Precaution thoroughly before servicing. Refer to «PRECAUTION»(ref-400808-S18187891512011051800000) .
REMOVE EXHAUST MANIFOLD Remove the exhaust manifold. Refer to «REMOVAL»(ref-400802-S41875932222011051800000) .
REMOVE AIR FUEL RATIO SENSOR (for Bank 1 Sensor 1) Using SST, remove the air fuel ratio sensor from the exhaust manifold RH. SST: 09224-00010
REMOVE AIR FUEL RATIO SENSOR (for Bank 2 Sensor 1) Use the same procedure for bank 1 and bank 2. SST: 09224-00010

PRECAUTION (w/ Air Suspension) NOTE: Be sure to read Precaution thoroughly before servicing. Refer to «PRECAUTION»(ref-400808-S39927796452011051800000) .
REMOVE EXHAUST MANIFOLD Remove the exhaust manifold. Refer to «REMOVAL»(ref-400802-S34335653722011051800000) .
REMOVE AIR FUEL RATIO SENSOR (for Bank 1 Sensor 1) Using SST, remove the air fuel ratio sensor from the exhaust manifold RH. SST: 09224-00010
REMOVE AIR FUEL RATIO SENSOR (for Bank 2 Sensor 1) Use the same procedure for bank 1 and bank 2. SST: 09224-00010

Scheme 71

Scheme 71: INSPECTION

Scheme 72

INSPECT AIR FUEL RATIO SENSOR (for Bank 1) Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 1 (HA1A) - 2 (+B) 20°C (68°F) 1.8 to 3.4 ohms 1 (HA1A) - 4 (A1A-) - 10 kohms or higher TEXT IN ILLUSTRATION *a Component without harness connected (Air Fuel Ratio Sensor) If the result is not as specified, replace the air fuel ratio sensor.
INSPECT AIR FUEL RATIO SENSOR (for Bank 2) Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 1 (HA2A) - 2 (+B) 20°C (68°F) 1.8 to 3.4 ohms 1 (HA2A) - 4 (A2A-) - 10 kohms or higher TEXT IN ILLUSTRATION *a Component without harness connected (Air Fuel Ratio Sensor) If the result is not as specified, replace the air fuel ratio sensor.

Scheme 73

Scheme 73: INSTALLATION

INSTALL AIR FUEL RATIO SENSOR (for Bank 1 Sensor 1) Using SST, install the air fuel ratio sensor to the exhaust manifold RH. TEXT IN ILLUSTRATION *1 Fulcrum Length 30 mm *2 Fulcrum Length 300 mm SST: 09224-00010 without SST Torque: 44 N*m (449 kgf*cm, 33 ft.*lbf) with SST Torque: 40 N*m (408 kgf*cm, 30 ft.*lbf) NOTE: The "with SST" torque value is effective when using SST with a fulcrum length of 30 mm (1.18 in.). The "with SST" torque value is effective when using a torque wrench with a fulcrum length of 300 mm (11.81 in.). Refer to «PRECAUTION»(ref-400649-S21890762562011051800000) . The "with SST" torque value is effective when SST is parallel to the torque wrench. Connect the air fuel ratio sensor connector.
INSTALL AIR FUEL RATIO SENSOR (for Bank 2 Sensor 1) Use the same procedure for bank 1 and bank 2. SST: 09224-00010 without SST Torque: 44 N*m (449 kgf*cm, 33 ft.*lbf) with SST Torque: 40 N*m (408 kgf*cm, 30 ft.*lbf) NOTE: The "with SST" torque value is effective when using SST with a fulcrum length of 30 mm (1.18 in.). The "with SST" torque value is effective when using a torque wrench with a fulcrum length of 300 mm (11.81 in.). Refer to «PRECAUTION»(ref-400649-S21890762562011051800000) . The "with SST" torque value is effective when SST is parallel to the torque wrench.
INSTALL EXHAUST MANIFOLD Install the exhaust manifold. Refer to «INSTALLATION»(ref-400802-S32880132372011051800000) .

INSTALL AIR FUEL RATIO SENSOR (for Bank 1 Sensor 1) Using SST, install the air fuel ratio sensor to the exhaust manifold RH. TEXT IN ILLUSTRATION *1 Fulcrum Length 30 mm *2 Fulcrum Length 300 mm SST: 09224-00010 without SST Torque: 44 N*m (449 kgf*cm, 33 ft.*lbf) with SST Torque: 40 N*m (408 kgf*cm, 30 ft.*lbf) NOTE: The "with SST" torque value is effective when using SST with a fulcrum length of 30 mm (1.18 in.). The "with SST" torque value is effective when using a torque wrench with a fulcrum length of 300 mm (11.81 in.). Refer to «PRECAUTION»(ref-400649-S04310564762011051800000) . The "with SST" torque value is effective when SST is parallel to the torque wrench. Connect the air fuel ratio sensor connector.
INSTALL AIR FUEL RATIO SENSOR (for Bank 2 Sensor 1) Use the same procedure for bank 1 and bank 2. SST: 09224-00010 without SST Torque: 44 N*m (449 kgf*cm, 33 ft.*lbf) with SST Torque: 40 N*m (408 kgf*cm, 30 ft.*lbf) NOTE: The "with SST" torque value is effective when using SST with a fulcrum length of 30 mm (1.18 in.). The "with SST" torque value is effective when using a torque wrench with a fulcrum length of 300 mm (11.81 in.). Refer to «PRECAUTION»(ref-400649-S04310564762011051800000) . The "with SST" torque value is effective when SST is parallel to the torque wrench.
INSTALL EXHAUST MANIFOLD Install the exhaust manifold. Refer to «INSTALLATION»(ref-400802-S02165218642011051800000) .

Scheme 74

Scheme 74: ILLUSTRATION

Scheme 75

Scheme 75: REMOVAL

Scheme 76

Scheme 77

Scheme 78

Scheme 79

PRECAUTION (w/ Air Suspension) NOTE: Be sure to read Precaution thoroughly before servicing. Refer to «PRECAUTION»(ref-400808-S18187891512011051800000) .
REMOVE FRONT FLOOR COVER LH . Refer to «REMOVAL - Step 2»(ref-400802-S33534498812011051800000)
REMOVE OXYGEN SENSOR (for Bank 1 Sensor 2) Disconnect the 3 clamps and oxygen sensor connector (for Bank 1 Sensor 2). Remove the wire harness clamp bracket. Using SST, remove the oxygen sensor from the No. 3 front exhaust pipe sub-assembly. SST: 09224-00010
REMOVE NO. 3 FRONT EXHAUST PIPE SUB-ASSEMBLY Remove the 4 bolts, 2 nuts, 2 compression springs and No. 3 front exhaust pipe sub-assembly. Remove the 3 gaskets from the No. 3 front exhaust pipe sub-assembly.
REMOVE FRONT EXHAUST PIPE ASSEMBLY . Refer to «REMOVAL - Step 8»(ref-400802-S39560348452011051800000)
REMOVE NO. 2 OXYGEN SENSOR (for Bank 2 Sensor 2) Using SST, remove the No. 2 oxygen sensor from the front exhaust pipe assembly. SST: 09224-00010

PRECAUTION (w/ Air Suspension) NOTE: Be sure to read Precaution thoroughly before servicing. Refer to «PRECAUTION»(ref-400808-S39927796452011051800000) .
REMOVE FRONT FLOOR COVER LH . Refer to «REMOVAL - Step 2»(ref-400802-S25680554822011051800000)
REMOVE OXYGEN SENSOR (for Bank 1 Sensor 2) Disconnect the 3 clamps and oxygen sensor connector (for Bank 1 Sensor 2). Remove the wire harness clamp bracket. Using SST, remove the oxygen sensor from the No. 3 front exhaust pipe sub-assembly. SST: 09224-00010
REMOVE NO. 3 FRONT EXHAUST PIPE SUB-ASSEMBLY Remove the 4 bolts, 2 nuts, 2 compression springs and No. 3 front exhaust pipe sub-assembly. Remove the 3 gaskets from the No. 3 front exhaust pipe sub-assembly.
REMOVE FRONT EXHAUST PIPE ASSEMBLY . Refer to «REMOVAL - Step 8»(ref-400802-S07854733242011051800000)
REMOVE NO. 2 OXYGEN SENSOR (for Bank 2 Sensor 2) Using SST, remove the No. 2 oxygen sensor from the front exhaust pipe assembly. SST: 09224-00010

Scheme 80

Scheme 80: INSPECTION

Scheme 81

INSPECT OXYGEN SENSOR (for Bank 1 Sensor 2) Measure the resistance according to the value(s) in the table below. TEXT IN ILLUSTRATION *1 Component without harness connected (Heated Oxygen Sensor) Standard Resistance Tester Connection Condition Specified Condition 2 (HT) - 1 (+B) 20°C (68°F) 11 to 16 ohms 2 (HT) - 3 (E) - 10 kohms or higher If the resistance is not as specified, replace the oxygen sensor.
INSPECT NO. 2 OXYGEN SENSOR (for Bank 2 Sensor 2) Measure the resistance according to the value(s) in the table below. TEXT IN ILLUSTRATION *1 Component without harness connected (Heated Oxygen Sensor) Standard Resistance Tester Connection Condition Specified Condition 1 (HT) - 2 (+B) 20°C (68°F) 11 to 16 ohms 1 (HT) - 4 (E) - 10 kohms or higher If the resistance is not as specified, replace the No. 2 oxygen sensor.

Scheme 82

Scheme 82: INSTALLATION

Scheme 83

Scheme 84

Scheme 85

INSTALL NO. 2 OXYGEN SENSOR (for Bank 2 Sensor 2) Using SST, install the No. 2 oxygen sensor to the front exhaust pipe assembly. TEXT IN ILLUSTRATION *1 Fulcrum Length 30 mm *2 Fulcrum Length 300 mm SST: 09224-00010 without SST Torque: 44 N*m (449 kgf*cm, 33 ft.*lbf) with SST Torque: 40 N*m (408 kgf*cm, 30 ft.*lbf) NOTE: The "with SST" torque value is effective when using SST with a fulcrum length of 30 mm (1.18 in.). The "with SST" torque value is effective when using a torque wrench with a fulcrum length of 300 mm (11.81 in.). Refer to «PRECAUTION»(ref-400649-S21890762562011051800000) . The "with SST" torque value is effective when SST is parallel to the torque wrench.
INSTALL FRONT EXHAUST PIPE ASSEMBLY . Refer to «INSTALLATION - Step 2»(ref-400802-S39933712072011051800000)
INSTALL NO. 3 FRONT EXHAUST PIPE SUB-ASSEMBLY Using a vernier caliper, measure the free length of the compression springs. Minimum length 41.5 mm (1.64 in.) If the free length is less than the minimum, replace the compression spring. Fully insert a new gasket to the No. 3 front exhaust pipe sub-assembly. Using a plastic hammer and wooden block, tap in the new gasket until its surface is flush with the No. 3 front exhaust pipe sub-assembly. TEXT IN ILLUSTRATION *1 No. 3 Front Exhaust Pipe Sub-assembly *2 Gasket *3 Wooden Block NOTE: Be sure to install the gasket in the correct direction. Do not reuse the gasket. Do not damage the gasket. Do not push in the gasket by using the exhaust pipe when connecting it. Install 2 new gaskets to the No. 3 front exhaust pipe sub-assembly. Install the No. 3 front exhaust pipe sub-assembly with the 4 bolts, 2 compression springs and 2 nuts. Torque: 55 N*m (561 kgf*cm, 40 ft.*lbf) for the bolt Torque: 55 N*m (561 kgf*cm, 40 ft.*lbf) for the nut
INSTALL OXYGEN SENSOR (for Bank 1 Sensor 2) Using SST, install the oxygen sensor to the center exhaust pipe assembly. TEXT IN ILLUSTRATION *1 Fulcrum Length 30 mm *2 Fulcrum Length 300 mm SST: 09224-00010 without SST Torque: 44 N*m (449 kgf*cm, 33 ft.*lbf) with SST Torque: 40 N*m (408 kgf*cm, 30 ft.*lbf) NOTE: The "with SST" torque value is effective when using SST with a fulcrum length of 30 mm (1.18 in.). The "with SST" torque value is effective when using a torque wrench with a fulcrum length of 300 mm (11.81 in.). Refer to «PRECAUTION»(ref-400649-S21890762562011051800000) . The "with SST" torque value is effective when SST is parallel to the torque wrench. Install the wire harness clamp bracket. Connect the 3 clamps and oxygen sensor connector (for Bank 1 Sensor 2).
INSPECT FOR EXHAUST GAS LEAK
INSTALL FRONT FLOOR COVER LH . Refer to «INSTALLATION - Step 13»(ref-400802-S21729616722011051800000)

INSTALL NO. 2 OXYGEN SENSOR (for Bank 2 Sensor 2) Using SST, install the No. 2 oxygen sensor to the front exhaust pipe assembly. TEXT IN ILLUSTRATION *1 Fulcrum Length 30 mm *2 Fulcrum Length 300 mm SST: 09224-00010 without SST Torque: 44 N*m (449 kgf*cm, 33 ft.*lbf) with SST Torque: 40 N*m (408 kgf*cm, 30 ft.*lbf) NOTE: The "with SST" torque value is effective when using SST with a fulcrum length of 30 mm (1.18 in.). The "with SST" torque value is effective when using a torque wrench with a fulcrum length of 300 mm (11.81 in.). Refer to «PRECAUTION»(ref-400649-S04310564762011051800000) . The "with SST" torque value is effective when SST is parallel to the torque wrench.
INSTALL FRONT EXHAUST PIPE ASSEMBLY . Refer to «INSTALLATION - Step 2»(ref-400802-S07946296732011051800000)
INSTALL NO. 3 FRONT EXHAUST PIPE SUB-ASSEMBLY Using a vernier caliper, measure the free length of the compression springs. Minimum length 41.5 mm (1.64 in.) If the free length is less than the minimum, replace the compression spring. Fully insert a new gasket to the No. 3 front exhaust pipe sub-assembly. Using a plastic hammer and wooden block, tap in the new gasket until its surface is flush with the No. 3 front exhaust pipe sub-assembly. TEXT IN ILLUSTRATION *1 No. 3 Front Exhaust Pipe Sub-assembly *2 Gasket *3 Wooden Block NOTE: Be sure to install the gasket in the correct direction. Do not reuse the gasket. Do not damage the gasket. Do not push in the gasket by using the exhaust pipe when connecting it. Install 2 new gaskets to the No. 3 front exhaust pipe sub-assembly. Install the No. 3 front exhaust pipe sub-assembly with the 4 bolts, 2 compression springs and 2 nuts. Torque: 55 N*m (561 kgf*cm, 40 ft.*lbf) for the bolt Torque: 55 N*m (561 kgf*cm, 40 ft.*lbf) for the nut
INSTALL OXYGEN SENSOR (for Bank 1 Sensor 2) Using SST, install the oxygen sensor to the center exhaust pipe assembly. TEXT IN ILLUSTRATION *1 Fulcrum Length 30 mm *2 Fulcrum Length 300 mm SST: 09224-00010 without SST Torque: 44 N*m (449 kgf*cm, 33 ft.*lbf) with SST Torque: 40 N*m (408 kgf*cm, 30 ft.*lbf) NOTE: The "with SST" torque value is effective when using SST with a fulcrum length of 30 mm (1.18 in.). The "with SST" torque value is effective when using a torque wrench with a fulcrum length of 300 mm (11.81 in.). Refer to «PRECAUTION»(ref-400649-S04310564762011051800000) . The "with SST" torque value is effective when SST is parallel to the torque wrench. Install the wire harness clamp bracket. Connect the 3 clamps and oxygen sensor connector (for Bank 1 Sensor 2).
INSPECT FOR EXHAUST GAS LEAK
INSTALL FRONT FLOOR COVER LH . Refer to «INSTALLATION - Step 13»(ref-400802-S40288001152011051800000)

Scheme 86

Scheme 86: ON-VEHICLE INSPECTION

Scheme 87

INSPECT EFI MAIN RELAY Remove the EFI MAIN relay from the relay block. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 3 - 5 No battery voltage is applied across terminals 1 and 2 10 kohms or higher 3 - 5 Battery voltage is applied across terminals 1 and 2 Below 1 ohms If the result is not as specified, replace the relay.
INSPECT C/OPN RELAY Remove the C/OPN relay from the relay block. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 3 - 5 No battery voltage is applied across terminals 1 and 2 10 kohms or higher 3 - 5 Battery voltage is applied across terminals 1 and 2 Below 1 ohms If the result is not as specified, replace the relay.
INSPECT F/PMP RELAY Remove the F/PMP relay from the relay block. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 3 - 4 No battery voltage is applied across terminals 1 and 2 Below 1 ohms 3 - 5 No battery voltage is applied across terminals 1 and 2 10 kohms or higher 3 - 4 Battery voltage is applied across terminals 1 and 2 10 kohms or higher 3 - 5 Battery voltage is applied across terminals 1 and 2 Below 1 ohms If the result is not as specified, replace the relay.
INSPECT IG2 RELAY Remove the IG2 relay from the relay block. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 3 - 5 No battery voltage is applied across terminals 1 and 2 10 kohms or higher 3 - 5 Battery voltage is applied across terminals 1 and 2 Below 1 ohms If the result is not as specified, replace the relay.

Engine Control (Service Information): Removal & Installation Lexus RX III
