DESCRIPTION
The certification ECU (smart key ECU assembly) generates a request signal and sends it to the electrical key oscillator built into the front door outside handle assembly (for driver side) at 0.25-second intervals. To detect a key near the driver door, the front door outside handle assembly (for driver side) creates a detection area with a radius of approximately 1.0 m (3.28 ft.) from the driver door at 0.25-second intervals.
DTC B27A1 is detected by the certification ECU (smart key ECU assembly) if an open circuit is detected between the certification ECU (smart key ECU assembly) and front door outside handle assembly (for driver side) terminals (between CLG1 and ANT1, or CG1B and ANT2).
| DTC No. | DTC Detection Condition | Trouble Area |
|---|---|---|
| B27A1 | Open circuit detected between the certification ECU (smart key ECU assembly) and front door outside handle assembly (for driver side) terminals (between CLG1 and ANT1, or CG1B and ANT2). | Front door outside handle assembly (for driver side) Certification ECU (smart key ECU assembly) Wire harness or connector |
Scheme 191
The certification ECU (smart key ECU assembly) generates a request signal and sends it to the electrical key oscillator built into the front door outside handle assembly (for driver side) at 0.25-second intervals. To detect a key near the driver door, the front door outside handle assembly (for driver side) creates a detection area with a radius of approximately 1.0 m (3.28 ft.) from the driver door at 0.25-second intervals.
DTC B27A1 is detected by the certification ECU (smart key ECU assembly) if an open circuit is detected between the certification ECU (smart key ECU assembly) and front door outside handle assembly (for driver side) terminals (between CLG1 and ANT1, or CG1B and ANT2).
| DTC No. | DTC Detection Condition | Trouble Area |
|---|---|---|
| B27A1 | Open circuit detected between the certification ECU (smart key ECU assembly) and front door outside handle assembly (for driver side) terminals (between CLG1 and ANT1, or CG1B and ANT2). | Front door outside handle assembly (for driver side) Certification ECU (smart key ECU assembly) Wire harness or connector |
The certification ECU (smart key ECU assembly) generates a request signal and sends it to the door electrical key oscillator built into the front door outside handle assembly (for front passenger side) at 0.25-second intervals. To detect a key near the front passenger door, the front door outside handle assembly (for front passenger side) creates a detection area with a radius of approximately 1.0 m (3.28 ft.) from the front passenger door at 0.25-second intervals.
DTC B27A2 is detected by the certification ECU (smart key ECU assembly) if an open circuit is detected between the certification ECU (smart key ECU assembly) and front door outside handle assembly (for front passenger side) terminals (between CLG2 and ANT1, or CG2B and ANT2).
| DTC No. | DTC Detection Condition | Trouble Area |
|---|---|---|
| B27A2 | Open circuit detected between the certification ECU (smart key ECU assembly) and front door outside handle assembly (for front passenger side) terminals (between CLG2 and ANT1, or CG2B and ANT2). | Front door outside handle assembly (for front passenger side) Certification ECU (smart key ECU assembly) Wire harness or connector |
Scheme 192
The certification ECU (smart key ECU assembly) generates a request signal and sends it to the door electrical key oscillator built into the front door outside handle assembly (for front passenger side) at 0.25-second intervals. To detect a key near the front passenger door, the front door outside handle assembly (for front passenger side) creates a detection area with a radius of approximately 1.0 m (3.28 ft.) from the front passenger door at 0.25-second intervals.
DTC B27A2 is detected by the certification ECU (smart key ECU assembly) if an open circuit is detected between the certification ECU (smart key ECU assembly) and front door outside handle assembly (for front passenger side) terminals (between CLG2 and ANT1, or CG2B and ANT2).
| DTC No. | DTC Detection Condition | Trouble Area |
|---|---|---|
| B27A2 | Open circuit detected between the certification ECU (smart key ECU assembly) and front door outside handle assembly (for front passenger side) terminals (between CLG2 and ANT1, or CG2B and ANT2). | Front door outside handle assembly (for front passenger side) Certification ECU (smart key ECU assembly) Wire harness or connector |
The certification ECU (smart key ECU assembly) generates a request signal and sends it to the indoor electrical key oscillator (for front floor). To detect the key inside the cabin, the indoor electrical key oscillator (for front floor) creates a detection area in the cabin.
DTC B27A5 is detected by the certification ECU (smart key ECU assembly) when an open circuit occurs between the certification ECU (smart key ECU assembly) and indoor electrical key oscillator (for front floor) terminals (between CLG5 and CLG3, or CG5B and CLGB).
| DTC No. | DTC Detection Condition | Trouble Area |
|---|---|---|
| B27A5 | Open circuit detected between the certification ECU (smart key ECU assembly) and indoor electrical key oscillator (for front floor) terminals (between CLG5 and CLG3, or CG5B and CLGB). | Indoor electrical key oscillator (for front floor) Certification ECU (smart key ECU assembly) Wire harness or connector |
Scheme 193
The certification ECU (smart key ECU assembly) generates a request signal and sends it to the indoor electrical key oscillator (for front floor). To detect the key inside the cabin, the indoor electrical key oscillator (for front floor) creates a detection area in the cabin.
DTC B27A5 is detected by the certification ECU (smart key ECU assembly) when an open circuit occurs between the certification ECU (smart key ECU assembly) and indoor electrical key oscillator (for front floor) terminals (between CLG5 and CLG3, or CG5B and CLGB).
| DTC No. | DTC Detection Condition | Trouble Area |
|---|---|---|
| B27A5 | Open circuit detected between the certification ECU (smart key ECU assembly) and indoor electrical key oscillator (for front floor) terminals (between CLG5 and CLG3, or CG5B and CLGB). | Indoor electrical key oscillator (for front floor) Certification ECU (smart key ECU assembly) Wire harness or connector |
The certification ECU (smart key ECU assembly) generates a request signal and sends it to the indoor electrical key oscillator (for center floor). To detect the key inside the cabin, the indoor electrical key oscillator (for center floor) creates a detection area in the cabin.
DTC B27A6 is detected by the certification ECU (smart key ECU assembly) when an open circuit occurs between the certification ECU (smart key ECU assembly) and indoor electrical key oscillator (for center floor) terminals (between CLG6 and CLG4, or CG6B and CLGB).
| DTC No. | DTC Detection Condition | Trouble Area |
|---|---|---|
| B27A6 | Open circuit detected between the certification ECU (smart key ECU assembly) and indoor electrical key oscillator (for center floor) terminals (between CLG6 and CLG4, or CG6B and CLGB). | Indoor electrical key oscillator (for center floor) Certification ECU (smart key ECU assembly) Wire harness or connector |
Scheme 194
The certification ECU (smart key ECU assembly) generates a request signal and sends it to the indoor electrical key oscillator (for center floor). To detect the key inside the cabin, the indoor electrical key oscillator (for center floor) creates a detection area in the cabin.
DTC B27A6 is detected by the certification ECU (smart key ECU assembly) when an open circuit occurs between the certification ECU (smart key ECU assembly) and indoor electrical key oscillator (for center floor) terminals (between CLG6 and CLG4, or CG6B and CLGB).
| DTC No. | DTC Detection Condition | Trouble Area |
|---|---|---|
| B27A6 | Open circuit detected between the certification ECU (smart key ECU assembly) and indoor electrical key oscillator (for center floor) terminals (between CLG6 and CLG4, or CG6B and CLGB). | Indoor electrical key oscillator (for center floor) Certification ECU (smart key ECU assembly) Wire harness or connector |
The certification ECU (smart key ECU assembly) generates a request signal and sends it to the indoor electrical key oscillator (for rear floor). To detect the key inside the cabin, the indoor electrical key oscillator (for rear floor) creates a detection area in the cabin.
DTC B27A7 is detected by the certification ECU (smart key ECU assembly) when an open circuit occurs between the certification ECU (smart key ECU assembly) and indoor electrical key oscillator (for rear floor) terminals (between CLG7 and CLG6, or CG7B and CLGB).
| DTC No. | DTC Detection Condition | Trouble Area |
|---|---|---|
| B27A7 | Open circuit detected between the certification ECU (smart key ECU assembly) and indoor electrical key oscillator (for rear floor) terminals (between CLG7 and CLG6, or CG7B and CLGB). | Indoor electrical key oscillator (for rear floor) Certification ECU (smart key ECU assembly) Wire harness or connector |
Scheme 195
The certification ECU (smart key ECU assembly) generates a request signal and sends it to the indoor electrical key oscillator (for rear floor). To detect the key inside the cabin, the indoor electrical key oscillator (for rear floor) creates a detection area in the cabin.
DTC B27A7 is detected by the certification ECU (smart key ECU assembly) when an open circuit occurs between the certification ECU (smart key ECU assembly) and indoor electrical key oscillator (for rear floor) terminals (between CLG7 and CLG6, or CG7B and CLGB).
| DTC No. | DTC Detection Condition | Trouble Area |
|---|---|---|
| B27A7 | Open circuit detected between the certification ECU (smart key ECU assembly) and indoor electrical key oscillator (for rear floor) terminals (between CLG7 and CLG6, or CG7B and CLGB). | Indoor electrical key oscillator (for rear floor) Certification ECU (smart key ECU assembly) Wire harness or connector |
The certification ECU (smart key ECU assembly) generates a request signal and sends it to the outside electrical key oscillator (for rear side). To detect the key near the driver door, the outside electrical key oscillator (for rear side) creates a detection area towards the area approximately 1.0 m (3.28 ft.) from the back door.
DTC B27A8 is detected by the certification ECU (smart key ECU assembly) when an open circuit occurs between the certification ECU (smart key ECU assembly) and outside electrical key oscillator (for rear side) terminals (between CLG8 and CLG5, or CG8B and CLGB).
| DTC No. | DTC Detection Condition | Trouble Area |
|---|---|---|
| B27A8 | Open circuit detected between the certification ECU (smart key ECU assembly and outside electrical key oscillator (for rear side) terminals (between CLG8 and CLG5, or CG8B and CLGB). | Outside electrical key oscillator (for rear side) Certification ECU (smart key ECU assembly) Wire harness or connector |
Scheme 196
The certification ECU (smart key ECU assembly) generates a request signal and sends it to the outside electrical key oscillator (for rear side). To detect the key near the driver door, the outside electrical key oscillator (for rear side) creates a detection area towards the area approximately 1.0 m (3.28 ft.) from the back door.
DTC B27A8 is detected by the certification ECU (smart key ECU assembly) when an open circuit occurs between the certification ECU (smart key ECU assembly) and outside electrical key oscillator (for rear side) terminals (between CLG8 and CLG5, or CG8B and CLGB).
| DTC No. | DTC Detection Condition | Trouble Area |
|---|---|---|
| B27A8 | Open circuit detected between the certification ECU (smart key ECU assembly and outside electrical key oscillator (for rear side) terminals (between CLG8 and CLG5, or CG8B and CLGB). | Outside electrical key oscillator (for rear side) Certification ECU (smart key ECU assembly) Wire harness or connector |
The smart access system with push-button start uses the wireless door lock buzzer assembly to perform various vehicle exterior warnings. When the conditions for each warning are met, the certification ECU (smart key ECU assembly) sends a buzzer request signal to the main body ECU (multiplex network body ECU) via CAN communication. The wireless door lock assembly sounds the buzzer according to the signal from the main body ECU (multiplex network body ECU).
The smart access system with push-button start uses the wireless door lock buzzer assembly to perform various vehicle exterior warnings. When the conditions for each warning are met, the certification ECU (smart key ECU assembly) sends a buzzer request signal to the main body ECU (multiplex network body ECU) via CAN communication. The wireless door lock assembly sounds the buzzer according to the signal from the main body ECU (multiplex network body ECU).
When the entry door lock and unlock functions and wireless door lock and unlock functions do not operate, radio wave interference, or a malfunction in the key or signal circuit between the door control receiver assembly and certification ECU (smart key ECU assembly) is suspected. The signal circuit is shared by the entry function and wireless door lock function.
Scheme 197
When the entry door lock and unlock functions and wireless door lock and unlock functions do not operate, radio wave interference, or a malfunction in the key or signal circuit between the door control receiver assembly and certification ECU (smart key ECU assembly) is suspected. The signal circuit is shared by the entry function and wireless door lock function.
When the wireless door lock and unlock functions operate, the communication circuit between the door lock receiver assembly and certification ECU (smart key ECU assembly) is normal. When the entry lock and unlock functions do not operate, radio wave interference, a customized entry cancel function, or a communication error between the key and vehicle in the smart communication circuit, is suspected.
When the wireless door lock and unlock functions operate, the communication circuit between the door lock receiver assembly and certification ECU (smart key ECU assembly) is normal. When the entry lock and unlock functions do not operate, radio wave interference, a customized entry cancel function, or a communication error between the key and vehicle in the smart communication circuit, is suspected.
If the driver door entry lock function operates normally, but its entry unlock function does not, this means that the request code from the driver door is being output normally. In this case, a malfunction in the touch sensor circuit (from the certification ECU (smart key ECU assembly) to the front door outside handle assembly (touch sensor)) is suspected.
Scheme 198
If the driver door entry lock function operates normally, but its entry unlock function does not, this means that the request code from the driver door is being output normally. In this case, a malfunction in the touch sensor circuit (from the certification ECU (smart key ECU assembly) to the front door outside handle assembly (touch sensor)) is suspected.
If the front passenger door entry lock function operates normally, but its entry unlock function does not, this means that the request code from the front passenger door is being output normally. In this case, a malfunction in the touch sensor circuit (from the certification ECU (smart key ECU assembly) to the front door outside handle assembly (touch sensor)) is suspected.
Scheme 199
If the front passenger door entry lock function operates normally, but its entry unlock function does not, this means that the request code from the front passenger door is being output normally. In this case, a malfunction in the touch sensor circuit (from the certification ECU (smart key ECU assembly) to the front door outside handle assembly (touch sensor)) is suspected.
When the entry lock and unlock functions do not operate only for the driver door, an error in output request codes from the driver door or malfunction in the front door outside handle assembly is suspected. If the entry functions for the other doors operate normally, then the communication circuit between the key and door control receiver assembly is functioning normally. In this case, radio wave interference or a malfunction in the request code sending circuit (from the certification ECU (smart key ECU assembly) to the front door outside handle assembly (for driver side)) is suspected.
Scheme 200
When the entry lock and unlock functions do not operate only for the driver door, an error in output request codes from the driver door or malfunction in the front door outside handle assembly is suspected. If the entry functions for the other doors operate normally, then the communication circuit between the key and door control receiver assembly is functioning normally. In this case, radio wave interference or a malfunction in the request code sending circuit (from the certification ECU (smart key ECU assembly) to the front door outside handle assembly (for driver side)) is suspected.
When the entry lock and unlock functions do not operate only for the front passenger door, an error in output request codes from the front passenger door or malfunction in the front door outside handle assembly is suspected. If the entry functions for the other doors operate normally, then the communication circuit between the key and door control receiver assembly is functioning normally. In this case, radio wave interference or a malfunction in the request code sending circuit (from the certification ECU (smart key ECU assembly) to the front door outside handle assembly (for driver side)) is suspected.
Scheme 201
When the entry lock and unlock functions do not operate only for the front passenger door, an error in output request codes from the front passenger door or malfunction in the front door outside handle assembly is suspected. If the entry functions for the other doors operate normally, then the communication circuit between the key and door control receiver assembly is functioning normally. In this case, radio wave interference or a malfunction in the request code sending circuit (from the certification ECU (smart key ECU assembly) to the front door outside handle assembly (for driver side)) is suspected.
If the driver door entry unlock function operates normally, but its entry lock function does not, this means that the request code from the driver door is being output normally. In this case, a malfunction in the lock sensor circuit (from the certification ECU (smart key ECU assembly) to the front door outside handle assembly (lock sensor)) is suspected.
Scheme 202
If the driver door entry unlock function operates normally, but its entry lock function does not, this means that the request code from the driver door is being output normally. In this case, a malfunction in the lock sensor circuit (from the certification ECU (smart key ECU assembly) to the front door outside handle assembly (lock sensor)) is suspected.
If the front passenger door entry unlock function operates normally, but its entry lock function does not, this means that the request code from the front passenger door is being output normally. In this case, a malfunction in the lock sensor circuit (from the certification ECU (smart key ECU assembly) to the front door outside handle assembly (lock sensor)) is suspected.
Scheme 203
If the front passenger door entry unlock function operates normally, but its entry lock function does not, this means that the request code from the front passenger door is being output normally. In this case, a malfunction in the lock sensor circuit (from the certification ECU (smart key ECU assembly) to the front door outside handle assembly (lock sensor)) is suspected.
If the room oscillator does not recognize a key, one of the following may be the cause: 1) communication between the indoor electrical key oscillator (for front floor) and key cannot be performed; 2) communication between the indoor electrical key oscillator (for center floor) and key cannot be performed; or 3) communication between the indoor electrical key oscillator (for rear floor) and key cannot be performed.
Scheme 204
If the room oscillator does not recognize a key, one of the following may be the cause: 1) communication between the indoor electrical key oscillator (for front floor) and key cannot be performed; 2) communication between the indoor electrical key oscillator (for center floor) and key cannot be performed; or 3) communication between the indoor electrical key oscillator (for rear floor) and key cannot be performed.
The smart access system with push-button start uses the combination meter buzzer to perform various vehicle interior warnings. When the conditions for each warning are met, the certification ECU (smart key ECU assembly) sends a buzzer signal to the combination meter assembly, and the combination meter buzzer sounds.
The smart access system with push-button start uses the combination meter buzzer to perform various vehicle interior warnings. When the conditions for each warning are met, the certification ECU (smart key ECU assembly) sends a buzzer signal to the combination meter assembly, and the combination meter buzzer sounds.
If the entry back door open function does not operate but the back door entry lock function operates, the communication between the vehicle and key is normal. As a faulty part, the back door open switch circuit (from the back door opener switch assembly (opener switch) to the certification ECU (smart key ECU assembly)) is suspected.
Scheme 205
If the entry back door open function does not operate but the back door entry lock function operates, the communication between the vehicle and key is normal. As a faulty part, the back door open switch circuit (from the back door opener switch assembly (opener switch) to the certification ECU (smart key ECU assembly)) is suspected.
When the back door entry lock and unlock functions do not operate, one of the following may be malfunctioning: 1) power door lock control system; 2) outside electrical key oscillator (for rear side); 3) certification ECU (smart key ECU assembly), or 4) back door opener switch assembly.
Scheme 206
When the back door entry lock and unlock functions do not operate, one of the following may be malfunctioning: 1) power door lock control system; 2) outside electrical key oscillator (for rear side); 3) certification ECU (smart key ECU assembly), or 4) back door opener switch assembly.
If the back door entry lock function does not operate but the back door open function operates, the communication between the vehicle and key is normal. As a faulty part, the entry lock switch circuit (from the back door opener switch assembly (lock switch) to the certification ECU (smart key ECU assembly)) is suspected.
Scheme 207
If the back door entry lock function does not operate but the back door open function operates, the communication between the vehicle and key is normal. As a faulty part, the entry lock switch circuit (from the back door opener switch assembly (lock switch) to the certification ECU (smart key ECU assembly)) is suspected.
