Suspension: Removal & Installation Lexus RX II рестайлинг

INSTALLATION

1. INSTALL FRONT LOWER BALL JOINT Install the front lower ball joint to the steering knuckle with the nut. Torque: 123 N*m (1, 250 kgf*cm, 91 ft.*lbf) NOTE: Prevent oil from adhering to the screw and tapered parts. Install a new cotter pin. NOTE: If the holes for the cotter pin are not aligned, tighten the nut further up to 60°.
2. INSTALL FRONT AXLE HUB BEARING (See «INSTALLATION»(ref-282975-S40184110932008041400000) )
3. INSTALL FRONT DISC BRAKE DUST COVER (See «INSTALLATION»(ref-282975-S40184110932008041400000) )
4. INSTALL FRONT AXLE HUB (See «INSTALLATION»(ref-282975-S40184110932008041400000) )
5. INSTALL FRONT AXLE HUB HOLE SNAP RING (See «INSTALLATION»(ref-282975-S40184110932008041400000) )
6. INSTALL FRONT WHEEL NO.1 BEARING DUST DEFLECTOR (See «INSTALLATION»(ref-282975-S40184110932008041400000) )
7. INSTALL FRONT AXLE ASSEMBLY (See «INSTALLATION»(ref-282975-S40184110932008041400000) )
8. CONNECT FRONT SUSPENSION LOWER NO. 1 ARM (See «INSTALLATION»(ref-283003-S23401246402008041400000) )
9. CONNECT TIE ROD ASSEMBLY (See «INSTALLATION»(ref-282975-S40184110932008041400000) )
10. INSTALL FRONT DISC
11. INSTALL FRONT DISC BRAKE CALIPER ASSEMBLY (See «INSTALLATION»(ref-282975-S40184110932008041400000) )
12. INSTALL FRONT SPEED SENSOR (See «INSTALLATION»(ref-283003-S23401246402008041400000) )
13. INSTALL FRONT AXLE HUB NUT (See «INSTALLATION»(ref-282975-S40184110932008041400000) )
14. SEPARATE FRONT DISC BRAKE CALIPER ASSEMBLY (See «INSTALLATION»(ref-282975-S40184110932008041400000) )
15. REMOVE FRONT DISC
16. INSPECT FRONT AXLE HUB BEARING LOOSENESS (See «ON-VEHICLE INSPECTION»(ref-282975-S40506666102008041400000) )
17. INSPECT FRONT AXLE HUB RUNOUT (See «ON-VEHICLE INSPECTION»(ref-282975-S40506666102008041400000) )
18. INSTALL FRONT DISC
19. INSTALL FRONT DISC BRAKE CALIPER ASSEMBLY (See «INSTALLATION»(ref-282975-S40184110932008041400000) )
20. INSTALL FRONT AXLE HUB NUT (See «INSTALLATION»(ref-282975-S40184110932008041400000) )
21. CHECK ABS SPEED SENSOR SIGNAL (See «DTC CHECK / CLEAR»(ref-282978-S31892089082008041400000) )
22. INSTALL FRONT WHEEL Torque: 103 N*m (1, 050 kgf*cm, 76 ft.*lbf)
23. INSPECT AND ADJUST FRONT WHEEL ALIGNMENT (See «FRONT WHEEL ALIGNMENT»(ref-283002-S07883908282008041400000) )

Scheme 45

Scheme 46

Scheme 47

1. REMOVE FRONT WHEELS
2. REMOVE FRONT STABILIZER LINK ASSEMBLY LH Remove the 2 nuts and the front stabilizer link assembly LH. HINT: If the ball joint turns together with the nut, use a hexagon wrench (6 mm) to hold the stud.
3. REMOVE FRONT STABILIZER LINK ASSEMBLY RH Remove the 2 nuts and the front stabilizer link assembly RH. HINT: If the ball joint turns together with the nut, use a hexagon wrench (6 mm) to hold the stud.
4. REMOVE ENGINE ASSEMBLY WITH TRANSAXLE HINT: Refer to the instructions for removal of the engine assembly (See «REMOVAL»(ref-282992-S02024628612008041400000) ).
5. REMOVE FRONT NO.1 STABILIZER BRACKET LH Remove the 2 bolts and front stabilizer bracket No. 1 LH.
6. REMOVE FRONT NO.1 STABILIZER BRACKET RH Remove the 2 bolts and front stabilizer bracket No. 1 RH.
7. REMOVE FRONT STABILIZER BAR Remove the front stabilizer bar from the front frame assembly.
8. REMOVE FRONT NO.2 STABILIZER BRACKET LH Remove the front stabilizer bracket No.2 LH from the front stabilizer bar bushing No.1.
9. REMOVE FRONT NO.2 STABILIZER BRACKET RH Remove the front stabilizer bracket No.2 RH from the front stabilizer bar bushing No.1.
10. REMOVE FRONT NO.1 STABILIZER BAR BUSHING Remove the 2 front stabilizer bar bushings No.1 from the front stabilizer bar.

Scheme 48

1. INSPECT FRONT STABILIZER LINK ASSEMBLY Inspect the turning of the ball joint. Secure the front stabilizer link assembly in a vise using aluminum plates. Install the nut to the front stabilizer link assembly stud. Using a torque wrench, turn the nut continuously at a rate of 3 to 5 seconds per turn and take the torque reading on the 5th turn. Turning torque: 2.0 N*m (20 kgf*cm, 18 in.*lbf) or less HINT: If the turning torque is greater than the specified range, replace the front stabilizer link assembly with a new one. Inspect the dust cover. Check that there are no cracks and grease on the dust cover.

Scheme 49

Scheme 50

1. INSTALL FRONT NO.1 STABILIZER BAR BUSHING Install the 2 front stabilizer bar bushings No.1 to the outer side of the bushing stopper on the front stabilizer bar. NOTE: Place the cutout of the front stabilizer bar bushing No.1 as facing the rear side as shown in the illustration.
2. INSTALL FRONT NO.2 STABILIZER BRACKET LH Install the front stabilizer bracket No.2 LH to the front frame assembly.
3. INSTALL FRONT NO.2 STABILIZER BRACKET RH Install the front stabilizer bracket No.2 RH to the front frame assembly.
4. INSTALL FRONT STABILIZER BAR Install the front stabilizer bar to the front flame.
5. INSTALL FRONT NO.1 STABILIZER BRACKET LH Install the front stabilizer bracket No. 1 LH with the 2 bolts. Torque: 16 N*m (163 kgf*cm, 12 ft.*lbf)
6. INSTALL FRONT NO.1 STABILIZER BRACKET RH Install the front stabilizer bracket No.1 RH with the 2 bolts. Torque: 16 N*m (163 kgf*cm, 12 ft.*lbf)
7. INSTALL ENGINE ASSEMBLY WITH TRANSAXLE HINT: Refer to the instructions for installation of the engine assembly (See «INSTALLATION»(ref-282992-S11458015172008041400000) ).
8. INSTALL FRONT STABILIZER LINK ASSEMBLY LH Install the front stabilizer link assembly LH with the 2 nuts. Torque: 74 N*m (755 kgf*cm, 55 ft.*lbf) HINT: If the ball joint turns together with the nut, use a hexagon (6 mm) wrench to hold the stud.
9. INSTALL FRONT STABILIZER LINK ASSEMBLY RH Install the front stabilizer link assembly RH with the 2 nuts. Torque: 74 N*m (755 kgf*cm, 55 ft.*lbf) HINT: If the ball joint turns together with the nut, use a hexagon (6 mm) wrench to hold the stud.
10. INSTALL FRONT WHEELS Torque: 103 N*m (1, 050 kgf*cm, 76 ft *lbf)

Scheme 51

Scheme 52

Scheme 53

Scheme 54

Scheme 55

Scheme 56

Scheme 57

Scheme 58

Scheme 59

Scheme 60

1. REMOVE DECK BOARD SUB-ASSEMBLY (See «REMOVAL»(ref-282982-S27013933812008041400000) )
2. REMOVE FRONT DECK FLOOR BOX (See «REMOVAL»(ref-282982-S27013933812008041400000) )
3. REMOVE REAR DECK FLOOR BOX (See «REMOVAL»(ref-282982-S27013933812008041400000) )
4. REMOVE DECK NO.2 BOARD SUB-ASSEMBLY (See «REMOVAL»(ref-282982-S27013933812008041400000) )
5. REMOVE DECK NO.3 BOARD SUB-ASSEMBLY (See «REMOVAL»(ref-282982-S27013933812008041400000) )
6. REMOVE REAR FLOOR FINISH PLATE (See «REMOVAL»(ref-282982-S27013933812008041400000) )
7. REMOVE JACK CARRIER SUPPORT
8. REMOVE JACK ASSY
9. REMOVE JACK CARRIER ASSY
10. REMOVE DECK SIDE TRIM BOX RH
11. REMOVE DECK SIDE TRIM BOX LH (See «REMOVAL»(ref-282982-S27013933812008041400000) )
12. REMOVE REAR DOOR SCUFF PLATE (See «REMOVAL»(ref-282982-S27013933812008041400000) )
13. REMOVE DECK SIDE TRIM COVER (See «REMOVAL»(ref-282982-S27013933812008041400000) )
14. REMOVE REAR SEAT SIDE COVER (See «REMOVAL»(ref-282982-S27013933812008041400000) )
15. REMOVE REAR FLOOR FINISH SIDE PLATE (See «REMOVAL»(ref-282982-S27013933812008041400000) )
16. REMOVE DECK TRIM SIDE PANEL ASSEMBLY (See «REMOVAL»(ref-282982-S27013933812008041400000) )
17. REMOVE REAR WHEEL
18. SEPARATE REAR STABILIZER LINK ASSEMBLY Support the rear axle carrier with a jack using a wooden block to avoid damage. Remove the nut and separate the rear stabilizer link assembly from the rear shock absorber. HINT: If the ball joint turns together with the nut, use a hexagon wrench (5 mm) to hold the stud.
19. SEPARATE REAR SPEED SENSOR 2WD: Remove the 2 bolts, and disconnect the rear brake flexible hose and rear speed sensor from the rear shock absorber with coil spring and rear axle carrier. NOTE: Be sure to remove the rear speed sensor from the rear shock absorber with coil spring. 4WD: Remove the 3 bolts, and disconnect the rear brake flexible hose and rear speed sensor from the rear shock absorber with coil spring and rear axle carrier. NOTE: Be sure to remove the rear speed sensor from the rear shock absorber with coil spring.
20. REMOVE REAR SHOCK ABSORBER WITH COIL SPRING Loosen the lock nut of the rear shock absorber with coil spring. NOTE: Do not remove the lock nut. Only loosen the nut when disassembling the rear shock absorber with coil spring. Remove the 2 nuts and bolt on the lower side of the rear shock absorber with coil spring. NOTE: When removing the nuts, keep the bolts from rotating. Keep one bolt inserted to secure the hub and disc rotor. Remove the 3 nuts on the upper side of the rear shock absorber with coil spring. Lower the rear axle carrier, and remove the 2 bolts on the lower side of the rear shock absorber with coil spring. NOTE: Make sure that the rear speed sensor is disconnected from the rear shock absorber with coil spring.

Scheme 61

Scheme 62

1. FIX REAR SHOCK ABSORBER WITH COIL SPRING As shown in the illustration, secure the rear shock absorber with coil spring in a vise using aluminum plates by closing the vise onto the double nutted bolt affixed to the bracket at the bottom of the absorber.
2. REMOVE REAR SHOCK ABSORBER Using SST, compress the rear coil spring. SST 09727-30021 (09727-00010, 09727-00021, 09727-00031) NOTE: Do not use an impact wrench. Remove the nut, rear shock absorber collar and rear suspension support assembly. Remove the rear coil spring, rear spring bumper No.1, and rear coil spring insulator lower.

Scheme 63

1. INSPECT REAR SHOCK ABSORBER Compress and extend the shock absorber rod 4 or more times. Standard: There is no abnormal resistance or sound and operation resistance is normal. HINT: If there is any abnormality, replace the rear shock absorber with a new one.

Scheme 64

Scheme 65

Scheme 66

Scheme 67

1. INSTALL REAR SHOCK ABSORBER Install the rear spring bumper No.1 to the piston rod. Install the rear coil spring insulator lower onto the rear shock absorber. Using SST, compress the rear coil spring. SST 09727-30021 (09727-00010, 09727-00021, 09727-00031) NOTE: Do not use an impact wrench. Install the rear coil spring to the rear shock absorber. NOTE: The smaller diameter end must face upward. HINT: Fit the lower end of the rear coil spring into the gap of the lower seat. Install the rear suspension support assembly with the identification mark facing the outer side of the vehicle. NOTE: Check that the width across flat on the piston rod and the width across flat on the rear suspension support assembly are aligned. Install the rear shock absorber collar. Loosely tighten a new lock nut to the rear suspension piston rod. Release the spring while adjusting the rear suspension support assembly to the position shown in the illustration, and remove the SST from the rear coil spring. NOTE: Do not use an impact wrench. HINT: Ensure that the stud bolt is positioned 3.5° to the front of the vehicle as shown in the illustration. The deviation should be within +- 5°.

Scheme 68

Scheme 69

Scheme 70

1. INSTALL REAR SHOCK ABSORBER WITH COIL SPRING Install the rear shock absorber with coil spring to the rear axle carrier assembly and insert the 2 bolts from the rear side of the vehicle. Slowly jack up the vehicle using a wooden block and install the rear shock absorber with coil spring (upper side) to the vehicle. Install the 3 nuts to the upper side of rear shock absorber with coil spring. Torque: 58 N*m (591 kgf*cm, 43 ft.*lbf) Install the 2 nuts to the lower side of rear shock absorber with coil spring. Torque: 180 N*m (1, 840 kgf*cm, 133 ft.*lbf) NOTE: When installing the nuts, keep the bolts from rotating. Fully tighten the lock nut. Torque: 49 N*m (500 kgf*cm, 36 ft.*lbf)
2. CONNECT REAR SPEED SENSOR 2WD: Install the rear brake flexible hose and rear speed sensor wire harness with the 2 bolts. Connect the rear speed sensor connector. Torque: 5.0 N*m (51 kgf*cm, 44 in.*lbf) (bolt A) 19 N*m (194 kgf*cm, 14 ft.*lbf) (bolt B) 4WD: Install the rear brake flexible hose and rear speed sensor with the 3 bolts. Torque: 5.0 N*m (51 kgf*cm, 44 in.*lbf) (bolt A) 19 N*m (194 kgf*cm, 14 ft.*lbf) (bolt B) 8.0 N*m (82 kgf*cm, 71 in.*lbf) (bolt C)
3. INSTALL REAR STABILIZER LINK ASSEMBLY Install the rear stabilizer link assembly to the rear shock absorber with the nut. Torque: 39 N*m (398 kgf*cm, 29 ft.*lbf) HINT: If the ball joint turns together with the nut, use a hexagon wrench (5 mm) to hold the stud.
4. INSTALL DECK TRIM SIDE PANEL ASSEMBLY (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
5. INSTALL REAR FLOOR FINISH SIDE PLATE (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
6. INSTALL REAR SEAT SIDE COVER (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
7. INSTALL DECK SIDE TRIM COVER (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
8. INSTALL REAR DOOR SCUFF PLATE (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
9. INSTALL DECK SIDE TRIM BOX LH
10. INSTALL DECK SIDE TRIM BOX RH
11. INSTALL JACK CARRIER ASSY
12. INSTALL JACK ASSY
13. INSTALL JACK CARRIER SUPPORT
14. INSTALL REAR FLOOR FINISH PLATE (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
15. INSTALL DECK NO.3 BOARD SUB-ASSEMBLY (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
16. INSTALL DECK NO.2 BOARD SUB-ASSEMBLY (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
17. INSTALL REAR DECK FLOOR BOX (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
18. INSTALL FRONT DECK FLOOR BOX (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
19. INSTALL DECK BOARD SUB-ASSEMBLY (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
20. CHECK ABS SPEED SENSOR SIGNAL (See «DTC CHECK / CLEAR»(ref-282978-S31892089082008041400000) )
21. INSTALL REAR WHEEL Torque: 103 N*m (1, 050 kgf*cm, 76 ft.*lbf)
22. INSPECT AND ADJUST REAR WHEEL ALIGNMENT (See «REAR WHEEL ALIGNMENT»(ref-283002-S00223415752008041400000) )

Scheme 71

1. DISPOSE OF REAR SHOCK ABSORBER Fully extend the shock absorber piston rod. Using a drill, make a hole in area B shown in the illustration to discharge the gas inside. CAUTION: Be careful when drilling because shards of metal may fly about. Always use the proper safety equipment. The gas is colorless, odorless and non-poisonous.

Scheme 72

Scheme 73

Scheme 74

Scheme 75

1. REMOVE REAR WHEEL
2. SEPARATE PARKING BRAKE NO.3 CABLE ASSEMBLY Remove the nut, and separate the parking brake cable assembly No.3.
3. REMOVE REAR STRUT ROD Support the rear axle carrier with a jack. Remove the bolt and nut, and disconnect the strut rod (front side). NOTE: When removing the bolt, keep the nut from rotating. Remove the bolt, nut and strut rod from the rear axle carrier. NOTE: When removing the bolt, keep the nut from rotating.

Scheme 76

Scheme 77

Scheme 78

Scheme 79

1. TEMPORARILY TIGHTEN REAR STRUT ROD Install the strut rod (rear side), bolt and nut, and temporarily tighten the bolt. NOTE: When temporarily tightening the bolt, keep the nut from rotating. Support the rear axle carrier. Connect the strut rod (inner side) with the bolt and nut. NOTE: When temporarily tightening the bolt, keep the nut from rotating.
2. STABILIZE SUSPENSION 2WD: Jack up the rear axle carrier, placing a wooden block to avoid damage. Apply load to the suspension so that the installed bolt of the rear suspension arm No.1 (inner side of vehicle) is horizontally aligned with the center of the rear axle hub. 4WD: Jack up the rear axle carrier, placing a wooden block to avoid damage. Apply load to the suspension so that the rear drive shaft assembly is horizontally positioned.
3. FULLY TIGHTEN REAR STRUT ROD Fully tighten the bolt. Torque: 80 N*m (816 kgf*cm, 59 ft.*lbf) Fully tighten the bolt. Torque: 80 N*m (816 kgf*cm, 59 ft.*lbf)
4. CONNECT PARKING BRAKE NO.3 CABLE ASSEMBLY Install the parking brake cable assembly No.3 with the nut. Torque: 6.0 N*m (61 kgf*cm, 53 in.*lbf)
5. INSTALL REAR WHEEL Torque: 103 N*m (1, 050 kgf*cm, 76 ft.*lbf)

Scheme 80

Scheme 81

Scheme 82

Scheme 83

1. REMOVE REAR WHEEL
2. REMOVE REAR STABILIZER LINK ASSEMBLY LH (See «REMOVAL»(ref-283002-S41527540232008041400000) )
3. REMOVE REAR STABILIZER LINK ASSEMBLY RH (See «REMOVAL»(ref-283002-S41527540232008041400000) )
4. REMOVE REAR STABILIZER BAR (See «REMOVAL»(ref-283002-S41527540232008041400000) )
5. REMOVE REAR STABILIZER BAR BRACKET (See «REMOVAL»(ref-283002-S41527540232008041400000) )
6. REMOVE REAR STABILIZER BUSHING (See «REMOVAL»(ref-283002-S41527540232008041400000) )
7. REMOVE REAR SUSPENSION N0.1 ARM Remove the bolt and disconnect the rear suspension arm No.1 (inner side). Remove the bolt, nut and the rear suspension arm No.1 (outer side) from the rear axle carrier. NOTE: When removing the bolt, keep the nut from rotating.

Scheme 84

Scheme 85

1. TEMPORARILY TIGHTEN REAR SUSPENSION NO.1 ARM Install the rear suspension arm No.1 (inner side) with the bolt, and temporarily tighten the bolt. HINT: Ensure that the paint mark faces to the rear of the vehicle. Connect the rear suspension arm No.1 (outer side) to the rear axle carrier with the bolt and nut, and temporarily tighten the bolt and nut. NOTE: When temporarily tightening the bolt, keep the nut from rotating.
2. STABILIZE SUSPENSION (See «INSTALLATION»(ref-283002-S00681830062008041400000) )
3. FULLY TIGHTEN REAR SUSPENSION NO.1 ARM Fully tighten the bolt. Torque: 120 N*m (1, 220 kgf*cm, 89 ft.*lbf) Fully tighten the bolt. Torque: 112 N*m (1, 140 kgf*cm, 83 ft.*lbf)
4. INSTALL REAR STABILIZER BUSHING (See «INSTALLATION»(ref-283002-S11166133222008041400000) )
5. INSTALL REAR STABILIZER BAR BRACKET (See «INSTALLATION»(ref-283002-S11166133222008041400000) )
6. INSTALL REAR STABILIZER BAR (See «INSTALLATION»(ref-283002-S11166133222008041400000) )
7. INSTALL REAR STABILIZER LINK ASSEMBLY LH (See «INSTALLATION»(ref-283002-S11166133222008041400000) )
8. INSTALL REAR STABILIZER LINK ASSEMBLY RH (See «INSTALLATION»(ref-283002-S11166133222008041400000) )
9. INSTALL REAR WHEEL Torque: 103 N*m (1, 050 kgf*cm, 76 ft.*lbf)
10. INSPECT AND ADJUST REAR WHEEL ALIGNMENT (See «REAR WHEEL ALIGNMENT»(ref-283002-S00223415752008041400000) )

Scheme 86

Scheme 87

1. REMOVE REAR WHEEL
2. SEPARATE PARKING BRAKE NO.3 CABLE ASSEMBLY (See «REAR STRUT ROD»(ref-283002-S15824782812008041400000) )
3. REMOVE REAR STRUT ROD (See «REMOVAL»(ref-283002-S41527540232008041400000) )
4. REMOVE REAR SUSPENSION NO.1 ARM Remove the 2 bolts, 2 nuts, and rear suspension arm No.1. NOTE: Secure the nuts and turn the bolts to remove them. Do not turn the nuts because they have a rotational stopper.

Scheme 88

Scheme 89

Scheme 90

1. TEMPORARILY TIGHTEN REAR SUSPENSION NO.1 ARM Install the rear suspension arm No.1 (inner side) with the bolt, and temporarily tighten the bolt. HINT: Ensure that the paint mark faces to the rear side of the vehicle. Set the rear suspension arm No.1 in the position shown in the illustration, and fully tighten the bolt. Torque: 80 N*m (816 kgf*cm, 59 ft.*lbf) NOTE: When temporarily tightening the bolt, keep the nut from rotating. Install the rear suspension arm No.1 (outer side) to the rear axle carrier, and temporarily tighten the bolt. NOTE: When temporarily tightening the bolt, keep the nut from rotating.
2. TEMPORARILY TIGHTEN REAR STRUT ROD (See «INSTALLATION»(ref-283002-S00681830062008041400000) )
3. STABILIZE SUSPENSION (See «INSTALLATION»(ref-283002-S00681830062008041400000) )
4. FULLY TIGHTEN REAR SUSPENSION NO.1 ARM Fully tighten the bolt. Torque: 112 N*m (1, 140 kgf*cm, 83 ft.*lbf)
5. FULLY TIGHTEN REAR STRUT ROD (See «INSTALLATION»(ref-283002-S00681830062008041400000) )
6. CONNECT PARKING BRAKE NO.3 CABLE ASSEMBLY (See «INSTALLATION»(ref-283002-S00681830062008041400000) )
7. INSTALL REAR WHEEL Torque: 103 N*m (1, 050 kgf*cm, 76 ft.*lbf)
8. INSPECT AND ADJUST REAR WHEEL ALIGNMENT (See «REAR WHEEL ALIGNMENT»(ref-283002-S00223415752008041400000) )

Scheme 91

Scheme 92

Scheme 93

1. REMOVE REAR WHEEL
2. REMOVE REAR SUSPENSION NO.2 ARM Remove the bolt, and disconnect the rear suspension arm No.2 (inner side). Remove the bolt, nut and the rear suspension arm No.2 (outer side) from the rear axle carrier. NOTE: When removing the bolt, keep the nut from rotating.

Scheme 94

1. TEMPORARILY TIGHTEN REAR NO. 2 SUSPENSION ARM Install the rear suspension arm No.2 (inner side) with the bolt, and temporarily tighten the bolt. HINT: Ensure that the paint mark faces to the rear side of the vehicle. Connect the rear suspension arm No.2 (outer side) to the rear axle carrier with the bolt and nut, and temporarily tighten the bolt. NOTE: When temporarily tightening the bolt, keep the nut from rotating.
2. STABILIZE SUSPENSION (See «INSTALLATION»(ref-283002-S00681830062008041400000) )
3. FULLY TIGHTEN REAR SUSPENSION NO.2 ARM Fully tighten the bolt. Torque: 120 N*m (1, 220 kgf*cm, 89 ft.*lbf) Fully tighten the bolt. Torque: 112 N*m (1, 140 kgf*cm, 83 ft.*lbf)
4. INSTALL REAR WHEEL Torque: 103 N*m (1, 050 kgf*cm, 76 ft.*lbf)
5. INSPECT AND ADJUST REAR WHEEL ALIGNMENT (See «REAR WHEEL ALIGNMENT»(ref-283002-S00223415752008041400000) )

Scheme 95

Scheme 96

Scheme 97

1. REMOVE REAR WHEEL
2. REMOVE REAR SUSPENSION NO.2 ARM Put matchmarks on the adjust cams and rear suspension member sub-assembly. Remove the nut, camber adjust cam and toe adjust cam, and disconnect the rear suspension arm No.2 (inner side). NOTE: When removing the nut, keep the bolt from rotating. Remove the bolt, nut and the rear suspension arm No.2 (outer side) from the rear axle carrier. NOTE: When removing the bolt, keep the nut from rotating.

Scheme 98

Scheme 99

1. TEMPORARILY TIGHTEN REAR SUSPENSION NO.2 ARM Install the rear suspension arm No.2 (inner side) to the rear suspension member sub-assembly with the camber adjust cam and toe adjust cam, and temporarily tighten the nut. HINT: Ensure that the paint mark faces to the rear side of the vehicle. Connect the rear suspension arm No.2 (outer side) to the rear axle carrier with the bolt and nut. NOTE: When temporarily tightening the bolt, keep the nut from rotating.
2. STABILIZE SUSPENSION (See «INSTALLATION»(ref-283002-S00681830062008041400000) )
3. FULLY TIGHTEN REAR SUSPENSION NO.2 ARM Put matchmarks on the adjust cams and rear suspension member sub-assembly. Fully tighten the nut. Torque: 100 N*m (1, 020 kgf*cm, 74 ft.*lbf) Fully tighten the nut. Torque: 112 N*m (1, 140 kgf*cm, 83 ft.*lbf)
4. INSTALL REAR WHEEL Torque: 103 N*m (1, 050 kgf*cm, 76 ft.*lbf)
5. INSPECT AND ADJUST REAR WHEEL ALIGNMENT (See «REAR WHEEL ALIGNMENT»(ref-283002-S00223415752008041400000) )

Scheme 100

Scheme 101

1. REMOVE REAR WHEELS
2. REMOVE REAR STABILIZER LINK ASSEMBLY LH Remove the 2 nuts and rear stabilizer link assembly LH. HINT: If the ball joint turns together with the nut, use a hexagon wrench (5 mm) to hold the stud.
3. REMOVE REAR STABILIZER LINK ASSEMBLY RH Remove the 2 nuts and rear stabilizer link assembly RH. HINT: If the ball joint turns together with the nut, use a hexagon wrench (5 mm) to hold the stud.
4. REMOVE REAR STABILIZER BAR Remove the 4 bolts and rear stabilizer bar.
5. REMOVE REAR STABILIZER BAR BRACKET Remove the 2 rear stabilizer bar brackets.
6. REMOVE REAR STABILIZER BUSHING Remove the 2 rear stabilizer bushings from the rear stabilizer bar.

Scheme 102

1. INSPECT REAR STABILIZER LINK ASSEMBLY Inspect the turning of the ball joint. Secure the rear stabilizer link assembly in a vise using aluminum plates. Install the nut to the rear stabilizer link assembly stud. Using a torque wrench, turn the nut continuously at a rate of 3 to 5 seconds per turn and take the torque reading on the 5th turn. Turning torque: 1.0 N*m (10 kgf*cm, 8.9 in.*lbf) or less HINT: If the turning torque is not within the specified range, replace the rear stabilizer link assembly with a new one. Inspect the dust cover. Check that the dust cover is not cracked and that there is no grease on it.

Scheme 103

1. INSTALL REAR STABILIZER BUSHING Install 2 rear stabilizer bushings to the outer side of the stopper ring on the stabilizer bar.
2. INSTALL REAR STABILIZER BAR BRACKET Install the 2 rear stabilizer bar brackets.
3. INSTALL REAR STABILIZER BAR Install the rear stabilizer bar with the 4 bolts. Torque: 19 N*m (194 kgf*cm, 14 ft.*lbf)
4. INSTALL REAR STABILIZER LINK ASSEMBLY LH Install the rear stabilizer link assembly LH with the 2 nuts. Torque: 39 N*m (398 kgf*cm, 29 ft.*lbf) HINT: If the ball joint turns together with the nut, use a hexagon wrench (5 mm) to hold the stud.
5. INSTALL REAR STABILIZER LINK ASSEMBLY RH Install the rear stabilizer link assembly RH with the 2 nuts. Torque: 39 N*m (398 kgf*cm, 29 ft.*lbf) HINT: If the ball joint turns together with the nut, use a hexagon wrench (5 mm) to hold the stud.
6. INSTALL REAR WHEELS Torque: 103 N*m (1, 050 kgf*cm, 76 ft.*lbf)

Scheme 104

Scheme 105

Scheme 106

Scheme 107

1. REMOVE REAR WHEELS
2. REMOVE REAR STABILIZER LINK ASSEMBLY LH Remove the 2 nuts and rear stabilizer link assembly LH. HINT: If the ball joint turns together with the nut, use a hexagon wrench (5 mm) to hold the stud.
3. REMOVE REAR STABILIZER LINK ASSEMBLY RH Remove the 2 nuts and rear stabilizer link assembly RH. HINT: If the ball joint turns together with the nut, use a hexagon wrench (5 mm) to hold the stud.
4. REMOVE REAR STABILIZER BAR Left side: Remove the bolt. Right side: Remove the 2 bolts and rear stabilizer bar.
