Mirrors: Diagnosis Lexus RX II

Mirrors 7 illustrations ~749 words

PROBLEM SYMPTOMS TABLE

SymptomSuspected AreaAction
Mirror does not operateOuter mirror switch assy Outer rear view mirror assy Seat memory switch (w/ Memory seat) Wire harnessINSPECTION INSPECTION INSPECTION
Mirror operates abnormallyOuter mirror switch assy Outer rear view mirror assy Seat memory switch (w/ Memory seat) Wire harnessINSPECTION INSPECTION INSPECTION

PROBLEM SYMPTOMS

Scheme 18

Scheme 18: INSPECTION

Scheme 19

Scheme 19

Scheme 20

Scheme 20

Scheme 21

Scheme 21

Scheme 22

Scheme 22

Scheme 23

Scheme 23

Scheme 24

Scheme 24
  1. INSPECT OUTER MIRROR SWITCH ASSY W/O MEMORY SEAT: Select "L" on the left/right adjustment switch: Check the switch resistance. Standard: TESTER CONNECTION SPECIFICATION Tester Connection Switch Position Specified Condition 4 - 8 UP Below 1 ohm 6 - 7 4 - 7 DOWN 6 - 8 5 - 8 LEFT 6 - 7 5 - 7 RIGHT 6 - 8 If the result is not as specified, replace the switch assy. Select "L" on the left/right adjustment switch: Check the switch resistance. Standard: TESTER CONNECTION SPECIFICATION Tester Connection Switch Position Specified Condition 3 - 8 UP Below 1 ohm 6 - 7 3 - 7 DOWN 6 - 8 2 - 8 LEFT 6 - 7 2 - 7 RIGHT 6 - 8 If the result is not as specified, replace the switch assy.
  2. INSPECT OUTER MIRROR SWITCH ASSY W/ MEMORY SEAT: Check the switch resistance. Standard: TESTER CONNECTION SPECIFICATION Tester Connection Switch Position Specified Condition 2 - 3 OFF 10 kohm or higher UP 225 - 275 ohm DOWN 437 - 503 ohm LEFT 744 - 856 ohm RIGHT 437 - 503 ohm If the result is not as specified, replace the switch assy. Check the left/right adjustment switch resistance. Standard: TESTER CONNECTION SPECIFICATION Tester Connection Switch Position Specified Condition 1 - 2 L 90 - 110 ohm R 10 ohm or less If the result is not as specified, replace the switch assy.
  3. INSPECT SEAT MEMORY SWITCH W/ MEMORY SEAT: Check the switch resistance. Standard: TESTER CONNECTION SPECIFICATION Tester Connection Switch Position Specified Condition 3 - 4 SET Switch ON Below 1 ohm 1 - 4 M1 Switch ON 2 - 4 M2 Switch ON If the result is not as specified, replace the switch assy.
  4. INSPECT OUTER REAR VIEW MIRROR ASSY LH W/ MEMORY SEAT: Disconnect the mirror connector. Apply battery voltage and check operation of the mirror. Standard: MEASUREMENT CONDITION OPERATION Measurement Condition Mirror Operation Battery positive (+) --> Terminal 1 (LMVR) Battery negative (-) --> Terminal 10 (LM+R) Turns upward (A) Battery positive (+) --> Terminal 10 (LM+R) Battery negative (-) --> Terminal 1 (LMVR) Turns downward (B) Battery positive (+) --> Terminal 10 (LM+R) Battery negative (-) --> Terminal 9 (LMHR) Turns left (C) Battery positive (+) --> Terminal 9 (LMHR) Battery negative (-) --> Terminal 10 (LM+R) Turns right (D) If the result is not as specified, replace the mirror assy.
  5. INSPECT OUTER REAR VIEW MIRROR ASSY LH W/O MEMORY SEAT: Disconnect the mirror connector. Apply battery voltage and check operation of the mirror. Standard: MEASUREMENT CONDITION OPERATION Measurement Condition Mirror Operation Battery positive (+) --> Terminal 2 (MV) Battery negative (-) --> Terminal 6 (M+) Turns upward (A) Battery positive (+) --> Terminal 6 (M+) Battery negative (-) --> Terminal 2 (MV) Turns downward (B) Battery positive (+) --> Terminal 6 (M+) Battery negative (-) --> Terminal 1 (MH) Turns left (C) Battery positive (+) --> Terminal 1 (MH Battery negative (-) --> Terminal 6 (M+) Turns right (D) If the result is not as specified, replace the mirror assy.
  6. INSPECT OUTER REAR VIEW MIRROR ASSY RH W/ MEMORY SEAT: Disconnect the mirror connector. Apply battery voltage and check operation of the mirror. Standard: MEASUREMENT CONDITION OPERATION Measurement Condition Mirror Operation Battery positive (+) --> Terminal 1 (RMVR) Battery negative (-) --> Terminal 10 (RM+R) Turns upward (A) Battery positive (+) --> Terminal 10 (RM+R) Battery negative (-) --> Terminal 1 (RMVR) Turns downward (B) Battery positive (+) --> Terminal 10 (RM+R) Battery negative (-) --> Terminal 9 (RMHR) Turns right (D) Battery positive (+) --> Terminal 9 (RMHR) Battery negative (-) --> Terminal 10 (RM+R) Turns left (C) If the result is not as specified, replace the mirror assy.
  7. INSPECT OUTER REAR VIEW MIRROR ASSY RH W/O MEMORY SEAT: Disconnect the mirror connector. Apply battery voltage and check operation of the mirror. Standard: MEASUREMENT CONDITION OPERATION Measurement Condition Mirror Operation Battery positive (+) --> Terminal 2 (MV) Battery negative (-) --> Terminal 6 (M+) Turns upward (A) Battery positive (+) --> Terminal 6 (M+) Battery negative (-) --> Terminal 2 (MV) Turns downward (B) Battery positive (+) --> Terminal 6 (M+) Battery negative (-) --> Terminal 1 (MH) Turns right (D) Battery positive (+) --> Terminal 1 (MH) Battery negative (-) --> Terminal 6 (M+) Turns left (C) If the result is not as specified, replace the mirror assy.
