Lighting System: Removal & Installation Lexus RX II

REPLACEMENT

HINT

COMPONENTS: See «COMPONENTS»

Scheme 176

1. REMOVE BACK DOOR TRIM BOARD LH (W/ POWER BACK DOOR) (See «OVERHAUL» )
2. REMOVE BACK WINDOW PANEL TRIM UPPER (See «OVERHAUL» )
3. REMOVE BACK DOOR TRIM COVER LH (W/ POWER BACK DOOR) (See «OVERHAUL» )
4. REMOVE BACK DOOR TRIM COVER RH (W/ POWER BACK DOOR) (See «OVERHAUL» )
5. REMOVE REAR SPOILER (W/ AIR SUSPENSION) (See «REPLACEMENT» )
6. REMOVE REAR SPOILER (W/O AIR SUSPENSION) (See «REPLACEMENT» )
7. REMOVE CENTER STOP LAMP ASSY Install the strap to the connector of the center stop lamp assy. Remove the 2 screws. Pass the connector through the inside of the rear spoiler and remove the center stop lamp assy. HINT: Leave the strap inside the rear spoiler.
