REPLACEMENT
HINT
Replace the RH side by using the same procedures as those for the LH side.
Scheme 197
Scheme 198
Scheme 199
Scheme 200
- REMOVE FRONT WHEEL
- REMOVE FRONT FENDER SPLASH SHIELD SUB-ASSY LH
- REMOVE SPEED SENSOR FRONT LH Disconnect the speed sensor connector. Remove the 2 bolts and the clamp from the body and the shock absorber assy. Remove the bolt and the speed sensor front. NOTE: Prevent foreign matter from attaching to the sensor tip.
- INSTALL SPEED SENSOR FRONT LH Install the speed sensor front with the bolt. Torque: 8.0 N.m (82 kgf.cm, 71 in.lbf) NOTE: Prevent foreign matter from attaching to the sensor tip. Install the speed sensor front with the 2 bolts and the clamp. Torque: Bolt A: 5.0 N.m (51 kgf.cm, 44 in.lbf) Bolt B: 29 N.m (296 kgf.cm, 21 ft.lbf) NOTE: Do not twist the sensor wire when installing the sensor. Connect the speed sensor connector.
- INSTALL FRONT FENDER SPLASH SHIELD SUB-ASSY LH
- INSTALL FRONT WHEEL Torque: 103 N.m (1,050 kgf.cm, 76 ft.lbf)
- CHECK ABS SPEED SENSOR SIGNAL (See «PRE-CHECK»(ref-209545-S24601868202005121000000) )
