SPECIFICATIONS
| Application | Specification |
|---|
| Compressor Type | Nippondenso 10-Cyl. |
| Compressor Belt Tension |
| New Belt | 139-191 lbs. (63.1-86.6 kg) |
| Used Belt | 66-110 lbs. (29.9-49.9 kg) |
| Compressor Oil Capacity | (1) |
| Refrigerant (R-134a) Capacity | 21.2-24.7 ozs. |
| System Operating Pressures (2) |
| High Side | 199-228 psi (14-16 kg/cm 2 ) |
| Low Side | 21-36 psi (1.5-2.5 kg/cm 2 ) |
| (1) Use ND-OIL 8. See underhood A/C specification label for system refrigerant oil capacity. (2) Specification is with ambient temperature at 86-95°F (30-35°C) and engine speed at 1500 RPM. |
| (1) | Use ND-OIL 8. See underhood A/C specification label for system refrigerant oil capacity. |
| (2) | Specification is with ambient temperature at 86-95°F (30-35°C) and engine speed at 1500 RPM. |
TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) |
|---|
| A/C Compressor Bolts | 18 (25) |
| Drive Belt Adjusting Bar Bracket-To-Adjusting Bar | 13 (18) |
| Drive Belt Adjusting Bar Bracket-To-Compressor | 18 (25) |
| Generator Adjusting Lock Bolt | 13 (18) |
| Generator Pivot Bolt/Nut | 18 (25) |
| Passenger Side Air Bag Bolts | 15 (20) |
| Steering Column Assembly Support Nuts | 19 (26) |
| Steering Column U-Joint Pinch Bolts | 27 (36) |
| Steering Wheel Nut | 37 (50) |
| Suction Line (Pipe Joint) | 24 (32) |
| Wiper Arm Nuts | 15 (20) |
| INCH Lbs. (N.m) |
| Compressor Pressure Plate Bolt | 116 (13.0) |
| Expansion Valve Tubing Bolts | 36 (4.1) |
| Passenger Side Air Bag Nuts | 50 (5.6) |
| Refrigerant Lines | 84 (10.0) |
| Wiper Motor Assembly Bolts | 62 (7.0) |
Automatic A/C-Heater System Wiring Diagram (2000 RX 300 - 1 Of 2). Scheme 15
Scheme 15: Automatic A/C-Heater System Wiring Diagram (2000 RX 300 - 1 Of 2)
Automatic A/C-Heater System Wiring Diagram (2000 RX 300 - 2 Of 2). Scheme 16
Scheme 16: Automatic A/C-Heater System Wiring Diagram (2000 RX 300 - 2 Of 2)
Automatic A/C-Heater System Wiring Diagram (2001 RX 300 - 1 Of 2). Scheme 17
Scheme 17: Automatic A/C-Heater System Wiring Diagram (2001 RX 300 - 1 Of 2)
Automatic A/C-Heater System Wiring Diagram (2001 RX 300 - 2 Of 2). Scheme 18
Scheme 18: Automatic A/C-Heater System Wiring Diagram (2001 RX 300 - 2 Of 2)
