Wiring diagram: Shift interlock — Shift interlock circuit Lexus NX Z10
All systems
- Active bodyworks
- Air conditioning
- Anti-lock brakes
- Anti-theft 2
- Body control modules 3
- Computer data lines
- Cooling fan
- Cruise control
- Defoggers 2
- Electronic power steering 2
- Electronic suspension
- Engine performance 2.4l turbo
- Engine performance 2.5l
- Exterior lights 2
- Ground distribution
- Headlights
- Horn
- Instrument cluster
- Interior lights 2
- Memory systems 3
- Navigation 6
- Passive restraints
- Power distribution
- Power door locks
- Power mirrors 2
- Power seats 7
- Power top/sunroof
- Power windows
- Radio 2
- Shift interlock 3
- Starting/charging 3
- Supplemental restraints
- Transmission 2
- Trunk, tailgate, fuel door 3
- Warning systems 2
- Wiper/washer 2
Shift interlock circuit (1 of 2) Lexus NX Z10
Components on the diagram
Shift interlock circuit (2 of 2) Lexus NX Z10
