Engine Controls - Specifications: Other — Lexus LX J80 (1995-1997)

ENGINE COMPRESSION

Check engine compression with engine at normal operating temperature at specified cranking speed, all spark plugs removed and throttle wide open.

Application	Specification
Compression Ratio	9.0:1
Compression Pressure	171 psi (12.0 kg/cm 2 )
Minimum Compression Pressure	128 psi (9.0 kg/cm 2 )
Maximum Variation Between Cylinders	14 psi (1.0 kg/cm 2 )

COMPRESSION SPECIFICATIONS

VALVE CLEARANCE

Application	(1) In. (mm)
Intake	.006-.010 (.15-.25)
Exhaust	.010-.014 (.25-.35)
(1) Adjust valve clearance with engine cold.

(1)	Adjust valve clearance with engine cold.

VALVE CLEARANCE SPECIFICATIONS

IGNITION COIL

Application	Primary	Secondary
Cold (1)	.36-.55	9000-15,400
Hot (2)	.45-.65	11,400-18,100
(1) Cold is with temperature of 14-122°F (-10-50°C). (2) Hot is with temperature of 122-212°F (50-100°C).

(1)	Cold is with temperature of 14-122°F (-10-50°C).

(2)	Hot is with temperature of 122-212°F (50-100°C).

IGNITION COIL RESISTANCE - Ohms

DISTRIBUTOR SENSORS

Application	In. (mm)
Land Cruiser, LX450	.008-.016 (.20-.40)
(1) Distributor Less Ignition System (DIS) is used.

(1)	Distributor Less Ignition System (DIS) is used.

DISTRIBUTOR PICK-UP COIL AIR GAP (1)

Pick-Up Coil Terminals (1)		Ohms
Cold (14-122°F (-10-50°C))
G1 & G		185-275
G2 & G		185-275
NE & G		185-275
Hot (122-212°F (50-100°C))
G1 & G		240-325
G2 & G		240-325
NE & G		240-325
(1) For proper testing and terminal identification, see BASIC TESTING article.

(1)	For proper testing and terminal identification, see BASIC TESTING article.

DISTRIBUTOR PICK-UP COIL RESISTANCE

Application	Ohms
Cold (14-122°F (-10-50°C))	1630-2740
Hot (122-212°F (50-100°C))	2065-3225

CRANKSHAFT POSITION SENSOR RESISTANCE

HIGH TENSION WIRE RESISTANCE

Application	Maximum Ohms
Land Cruiser, LX450	25,000 Per Wire
(1) Distributorless Ignition System (DIS) is used. No high tension wires are used.

(1)	Distributorless Ignition System (DIS) is used. No high tension wires are used.

HIGH TENSION WIRE RESISTANCE (1)

SPARK PLUGS

Application	NGK No.	Nippondenso No.
Land Cruiser, LX450	BKR5EYA	K16R-U

SPARK PLUG TYPE

Application	Gap: In. (mm)	Torque: Ft. Lbs. (N.m)
Land Cruiser, LX450	.031 (.80)	15 (20)

SPARK PLUG SPECIFICATIONS

Scheme 1

Scheme 1: FIRING ORDER

Application	Firing Order
6-Cylinder (1)	1-5-3-6-2-4
(1) Cylinder No. 1 is located at timing belt or timing chain end of engine. Cylinder No. 6 is located at flywheel end of engine.

(1)	Cylinder No. 1 is located at timing belt or timing chain end of engine. Cylinder No. 6 is located at flywheel end of engine.

FIRING ORDER

IGNITION TIMING

Application	(2) Base Timing	(3) ECM Controlled Timing
Land Cruiser, LX450	3	2-13
(1) Check with engine at normal operating temperature, transmission in Neutral, parking brake applied, A/C and all accessories off. (2) With Jumper Wire (SST 09843-18020) installed between terminals TE1 and E1 on data link connector No. 1. (3) With jumper wire removed from data link connector No. 1.

(1)	Check with engine at normal operating temperature, transmission in Neutral, parking brake applied, A/C and all accessories off.

(2)	With Jumper Wire (SST 09843-18020) installed between terminals TE1 and E1 on data link connector No. 1.

(3)	With jumper wire removed from data link connector No. 1.

IGNITION TIMING (Degrees BTDC @ Idle) (1)

FUEL PUMP

Note. Fuel pump performance measures fuel pressure, not regulated fuel pressure.

Application	Pressure: psi (kg/cm 2 )
Land Cruiser, LX450	(1) 38-44 (2.7-3.1)
(1) Check fuel pressure with engine off and using scan tester connected to data link connector No. 3 with ignition on to activate fuel pump or by connecting battery voltage to terminals on electric fuel pump.

(1)	Check fuel pressure with engine off and using scan tester connected to data link connector No. 3 with ignition on to activate fuel pump or by connecting battery voltage to terminals on electric fuel pump.

FUEL PUMP PERFORMANCE

Model/ Application	At Idle W/Vacuum psi (kg/cm 2 )	At Idle W/O Vacuum psi (kg/cm 2 )
Land Cruiser, LX450	31-37 (2.2-2.6)	38-44 (2.7-3.1)

REGULATED FUEL PRESSURE

Application	Ohms
Land Cruiser, LX450	.2-3.0

FUEL PUMP RESISTANCE - Ohms @ 68°F (20°C)

FUEL INJECTOR RESISTANCE

Application	Ohms
Land Cruiser, LX450	13.4-14.2

FUEL INJECTOR RESISTANCE - Ohms @ 68°F (20°C)

IDLE SPEED

Application	RPM
Land Cruiser, LX450	600-700
(1) Check with engine at normal operating temperature, transmission in Neutral, parking brake applied, ignition timing properly set and with A/C and all accessories off.

(1)	Check with engine at normal operating temperature, transmission in Neutral, parking brake applied, ignition timing properly set and with A/C and all accessories off.

IDLE SPEED SPECIFICATIONS (1)

THROTTLE OPENER

Application	RPM
Land Cruiser, LX450	700-1000
(1) Check with engine at normal operating temperature and with electric cooling fan turned off (if equipped).

(1)	Check with engine at normal operating temperature and with electric cooling fan turned off (if equipped).

THROTTLE OPENER SPECIFICATIONS (1)

FUEL CUT

Application	Fuel Return RPM
Land Cruiser, LX450	1200
(1) Check with engine at normal operating temperature and A/C off.

(1)	Check with engine at normal operating temperature and A/C off.

FUEL CUT SPECIFICATIONS (1)

THROTTLE POSITION (TP) SENSOR

Application	Clearance In. (mm)	Terminal	Ohms
4.5L (1)	0 (0)	VTA & E2	200-5700
"	.020 (.50)	IDL & E2	2300 Or Less
"	.030 (.75)	IDL & E2	No Continuity
"	Fully Open	VTA & E2	2000-10,200
"	"	VC & E2	2500-5900
(1) Apply vacuum to throttle opener before checking TP sensor.

(1)	Apply vacuum to throttle opener before checking TP sensor.

TPS RESISTANCE SPECIFICATIONS
