Maintenance Information: Component Locations Lexus LX J80

Procedures 3 illustrations ~656 words

VIN LOCATION

The Vehicle Identification Number (VIN) is located on the left side of the dash panel at the base of the windshield. The VIN chart explains the code characters.

FUSE PANEL LOCATION

Fuse box is located below instrument panel to left of steering column on all vehicles. On 1991-93 models, there is an additional fuse and relay box located on the left side of the engine compartment.

Scheme 4

Scheme 4: FUSE BOX IDENTIFICATION (1983-84 2-DOOR)
Scheme 4: FUSE BOX IDENTIFICATION (1983-84 2-DOOR)

Fuse & Circuit Breaker Identification

  1. 1 - Tail 15 Amp - Inspection Light Socket, Instrument Panel & Interior Lights, Side Marker & License Lights, Parking & Taillights
  2. 2 - Stop Horn 15 Amp - Hazard Flashers, Horns & Stoplights, Electric Engine Cooling Fan (1983)
  3. 3 - Head 15 Amp - Headlights & High Beam Indicator
  4. 4 - Radio 5 Amp - Radio
  5. 5 - Lighter 15 Amp - Cigarette Lighter
  6. 6 - Engine 15 Amp - Emission Control System, Alternator & Fuel Cut Solenoid, Gauges & Warning Lights, Electric Winch Control Switch
  7. 7 - Heater 20 Amp - Front & Rear Heaters
  8. 8 - Turn Wipers 20 Amp - Back-Up & Turn Signal Lights, Wipers & Washers

Scheme 5

Scheme 5: FUSE BOX IDENTIFICATION (1985-87 2-DOOR)
Scheme 5: FUSE BOX IDENTIFICATION (1985-87 2-DOOR)

Fuse & Circuit Breaker Identification

  1. 1 - 10 Amp - Spare
  2. 2 - 20 Amp - Spare
  3. 3 - Charge 7.5 Amp - Charging System, Discharge Warning Light (1985)
  4. 4 - Cig 15 Amp - Cigarette Lighter & Clock, Radio & Cassette Player
  5. 6 - Defog 15 Amp - Rear Window Defogger
  6. 7 - Tail 20 Amp - Taillights & Parking Lights, License & Side Marker Lights, Instrument Panel Lights
  7. 8 - Blank
  8. 9 - Wiper 20 Amp - Wipers & Washers, Back-Up Lights
  9. 10 - Engine 15 Amp - Engine Glow System, Gauges & Warning Lights, Front Drive Control System, Turn Signal Lights (1985)
  10. 11 - Blank
  11. 12 - Blank
  12. 13 - Blank
  13. 14 - Blank
  14. 15 - Blank
  15. 16 - Stop 10 Amp - Stoplights
  16. 17 - Dome 7.5 Amp - Interior Light, Personal Lights, Clock, Key Reminder Buzzer (1985)
  17. 18 - Haz-Horn 15 Amp - Hazard Flashers & Horns
  18. 19 - Head LH 10 Amp - Left Headlight (1985), Left High Beam (1986-87)
  19. 20 - Head RH 10 Amp - Right Headlight (1985), Right High Beam (1986-87)

Scheme 6

Scheme 6: FUSE BOX IDENTIFICATION (1983-87 4-DOOR)
Scheme 6: FUSE BOX IDENTIFICATION (1983-87 4-DOOR)

Fuse & Circuit Breaker Identification

  1. 1 - Head RH 10 Amp - Right Headlight, High Beam Indicator (1983-84)
  2. 2 - Head LH 10 Amp - Left Headlight, High Beam Indicator (1983-84)
  3. 3 - Cig L 15 Amp - Cigarette Lighter, Power Antenna, Digital Clock Display (1985-87), Radio & Cassette Player (1985-87)
  4. 4 - Radio 7.5 Amp - Radio & Cassette Player (1983-84)
  5. 5 - Blank
  6. 6 - Tail 15 Amp - Side Marker Lights, Glove Compartment Light, Instrument Panel Lights, License Lights, Parking Lights, Taillights
  7. 7 - Stop 15 Amp - Stoplights
  8. 8 - Horn Haz 15 Amp - Hazard Flashers & Horns
  9. 9 - 10 Amp - Emission Control System, Outer Vent Control Valve (1983-84), Electric Fan Relay (1983-84), Fuel Cut Solenoid (1983-84), Seat Belt Reminder (1983-84), Charging System (1985-87)
  10. 10 - Blank
  11. 11 - Turn 7.5 Amp - Turn Signal Lights
  12. 12 - Wiper 20 Amp - Back-Up Lights, Wipers & Washers, Electric Winch (1983-85), Park Warning Light (1986-87)
  13. 13 - A/C 10 Amp - Air Conditioner
  14. 14 - Glow 7.5 Amp - Glow Plug System (Diesel)
  15. 15 - Defog 20 Amp - Rear Window Defogger (1985-87)
  16. 16 - Dome 7.5 Amp - Inspection Light Socket, Interior Light, Luggage Compartment Light, Electric Fan Relay (1983-84), Clock (1985-87), Key Reminder Buzzer (1985-87)
  17. 17 - Charge 7.5 Amp - Discharge Warning Light, Charging System (1985-87)
  18. 18 - 7.5 Amp - Gauges & Warning Lights/Buzzers, Heater Main Relay Coil (1983-84), Ignition Main Relay Coil (1983-84), Front Drive Control System (1985-87)
  19. 19 - 7.5 Amp - Spare
  20. 20 - 15 Amp - Spare
  21. 21 - 30 Amp (Circuit Breaker) - Heater Blower Motor
  22. 22 - 30 Amp (Circuit Breaker) - Rear Window Defogger
