Lighting System (Interior) (Service Information): Removal & Installation Lexus LX J200 рестайлинг

REMOVAL [01/2012 - ]

HINT

1. Use the same procedures for the RH and LH side.
2. The procedures listed below are for the RH side.

Scheme 2

Scheme 3

1. REMOVE VISOR BRACKET COVER Detach the 4 claws and remove the visor bracket cover.
2. REMOVE VISOR ASSEMBLY RH Remove the 2 screws and visor.

Scheme 4

1. INSPECT VISOR ASSEMBLY RH (VANITY LIGHT) Measure the resistance according to the value(s) in the table below. STANDARD RESISTANCE Tester Connection Condition Specified Condition 2 (SW) - 1 (GND) Visor raised 10 kohms or higher 2 (SW) - 1 (GND) Visor lowered and mirror cover closed 10 kohms or higher 2 (SW) - 1 (GND) Visor lowered and mirror cover open Below 1 ohms If the result is not as specified, there may be a malfunction in the visor assembly.
2. INSPECT VISOR ASSEMBLY LH (VANITY LIGHT) Measure the resistance according to the value(s) in the table below. STANDARD RESISTANCE Tester Connection Condition Specified Condition 2 (SW) - 1 (GND) Visor raised 10 kohms or higher 2 (SW) - 1 (GND) Visor lowered and mirror cover closed 10 kohms or higher 2 (SW) - 1 (GND) Visor lowered and mirror cover open Below 1 ohms If the result is not as specified, there may be a malfunction in the visor assembly.

INSTALLATION [01/2012 - ]

HINT

1. Use the same procedures for the RH and LH side.
2. The procedures listed below are for the RH side.

1. INSTALL VISOR ASSEMBLY RH Install the visor with the 2 screws.
2. INSTALL VISOR BRACKET COVER Attach the 4 claws to install the visor bracket cover.

Scheme 5

Scheme 6

1. REMOVE NO. 1 INSTRUMENT PANEL UNDER COVER SUB-ASSEMBLY . Refer to REMOVAL [01/2012 - ] - Step 38
2. REMOVE NO. 1 INTERIOR ILLUMINATION LIGHT ASSEMBLY LH Detach the 2 claws and remove the light.

Scheme 7

1. INSPECT NO. 1 INTERIOR ILLUMINATION LIGHT ASSEMBLY LH (PERSONAL LIGHT) Apply battery voltage to the connector and check the LED illumination condition. OK Measurement Condition Specified Condition Battery positive (+) --> Terminal 2 (+B) Battery negative (-) --> Terminal 1 (GND) Light illuminates If the result is not as specified, there may be a malfunction in the light.

1. INSTALL NO. 1 INTERIOR ILLUMINATION LIGHT ASSEMBLY LH Attach the 2 claws to install the light.
2. INSTALL NO. 1 INSTRUMENT PANEL UNDER COVER SUB-ASSEMBLY . Refer to INSTALLATION [01/2012 - ] - Step 29

Scheme 8

Scheme 9

1. REMOVE NO. 2 INSTRUMENT PANEL UNDER COVER SUB-ASSEMBLY . Refer to REMOVAL [01/2012 - ] - Step 47
2. REMOVE NO. 1 INTERIOR ILLUMINATION LIGHT ASSEMBLY RH Detach the 2 claws and remove the light.

1. INSTALL NO. 1 INTERIOR ILLUMINATION LIGHT ASSEMBLY RH Attach the 2 claws to install the light.
2. INSTALL NO. 2 INSTRUMENT PANEL UNDER COVER SUB-ASSEMBLY . Refer to INSTALLATION [01/2012 - ] - Step 20

Scheme 10

Scheme 11

1. REMOVE FRONT SEAT ASSEMBLY LH Remove the front seat assembly LH. Refer to REMOVAL [01/2012 - ] .
2. REMOVE FRONT SEATBACK BOARD SUB-ASSEMBLY LH . Refer to DISASSEMBLY [01/2012 - ] - Step 18
3. REMOVE NO. 1 INTERIOR ILLUMINATION LIGHT ASSEMBLY Detach the 2 claws and remove the light.

1. INSTALL NO. 1 INTERIOR ILLUMINATION LIGHT ASSEMBLY Attach the 2 claws to install the light.
2. INSTALL FRONT SEATBACK BOARD SUB-ASSEMBLY LH . Refer to REASSEMBLY [01/2012 - ] - Step 29
3. INSTALL FRONT SEAT ASSEMBLY LH Install the front seat assembly LH. Refer to INSTALLATION [01/2012 - ] .

Scheme 12

Scheme 13

1. CHECK MAP LIGHT ASSEMBLY (ROOM LIGHT) Remove the map light with the connector connected. Measure the voltage according to the value(s) in the table below. STANDARD VOLTAGE Tester Connection Switch Condition Specified Condition R7-3 (RLSW) - R7-16 (GND9) Rear spot light RH switch off Below 1 V Rear spot light RH switch on 11 to 14 V R7-4 (RRSW) - R7-16 (GND9) Rear spot light LH switch off Below 1 V Rear spot light LH switch on 11 to 14 V R12-18 (RILL) - R7-17 (GND9) Rear dome light off 11 to 14 V Rear dome light on Below 1 V R7-11 (ILLB) - R7-16 (GND9) Always 11 to 14 V R7-6 (+B) - R7-16 (GND9) Always 11 to 14 V R7-27 (DOME) - R7-16 (GND9) Always 11 to 14 V R12-7 (RLMP) - R7-16 (GND9) Always 11 to 14 V R12-8 (RRMP) - R7-16 (GND9) Always 11 to 14 V R12-11 (ILL+) - R7-16 (GND9) Engine switch on (ACC) 11 to 14 V R12-13 (ILL-) - R7-16 (GND9) Headlight dimmer switch off Below 1 V Headlight dimmer switch TAIL 11 to 14 V R12-14 (RRVT) - R7-16 (GND9) Back door closed Below 1 V Back door open 11 to 14 V Measure the resistance according to the value(s) in the table below. STANDARD RESISTANCE Tester Connection Condition Specified Condition R7-16 (GND9) - Body ground Always Below 1 ohms If the result is not as specified, replace the map light.

HINT

When only replacing the room light bulbs, use the following procedures.

Scheme 14

1. REMOVE MAP LIGHT ASSEMBLY . Refer to REMOVAL [01/2012 - ] - Step 32
2. REMOVE MAP LIGHT BULB Turn the 2 map light bulbs in the direction indicated by the arrows and remove them.

HINT

When only replacing the room light bulbs, use the following procedures.

Scheme 15

1. INSTALL MAP LIGHT BULB Turn the 2 map light bulbs in the direction indicated by the arrow to install them.
2. INSTALL MAP LIGHT ASSEMBLY . Refer to INSTALLATION [01/2012 - ] - Step 51

Scheme 16

HINT

When only replacing the room light bulb, use the following procedures.

Scheme 17

Scheme 18

1. REMOVE NO. 3 ROOM LIGHT BULB Detach the 4 claws and remove the light lens. Remove the bulb.

HINT

When only replacing the room light bulb, use the following procedures.

1. INSTALL NO. 3 ROOM LIGHT BULB Install the bulb. Attach the 4 claws to install the light lens.

Scheme 19

Scheme 20

Scheme 21

Scheme 22

1. REMOVE QUARTER TRIM COVER RH Detach the 6 claws and remove the cover.
2. REMOVE NO. 1 LUGGAGE COMPARTMENT LIGHT ASSEMBLY Detach the claw and remove the light. Detach the 4 claws and remove the cover and bulb.

Scheme 23

1. INSPECT NO. 1 LUGGAGE COMPARTMENT LIGHT ASSEMBLY Measure the resistance according to the value(s) in the table below. OK Measurement Condition Specified Condition Battery positive (+) --> Terminal 2 Battery negative (-) --> Terminal 1 Light illuminates If the result is not as specified, replace the No. 1 luggage compartment light assembly.

1. INSTALL NO. 1 LUGGAGE COMPARTMENT LIGHT ASSEMBLY Install the bulb. Attach the 4 claws to install the cover. Attach the claw to install the light.
2. INSTALL QUARTER TRIM COVER RH Attach the 6 claws to install the cover.

Scheme 24

HINT

1. Use the same procedures for the RH and LH side.
2. The procedures listed below are for the LH side.

Scheme 25

1. REMOVE COURTESY LIGHT ASSEMBLY Detach the claw. Remove the courtesy light and then disconnect the connector.
2. REMOVE COURTESY LIGHT BULB Remove the bulb.

Scheme 26

1. INSPECT COURTESY LIGHT ASSEMBLY Measure the resistance according to the value(s) in the table below. OK Measurement Condition Specified Condition Battery positive (+) --> Terminal 2 Battery negative (-) --> Terminal 1 Light illuminates If the result is not as specified, replace the courtesy light assembly.

HINT

1. Use the same procedures for the RH and LH side.
2. The procedures listed below are for the LH side.

1. INSTALL COURTESY LIGHT BULB Install the bulb.
2. INSTALL COURTESY LIGHT ASSEMBLY Connect the connector. Attach the claw of the courtesy light to the front door trim.

Scheme 27

HINT

1. Use the same procedures for the RH and LH side.
2. The procedures listed below are for the LH side.

Scheme 28

1. REMOVE COURTESY LIGHT ASSEMBLY Detach the claw. Remove the courtesy light and then disconnect the connector.
2. REMOVE COURTESY LIGHT BULB Remove the bulb.

Scheme 29

1. INSPECT COURTESY LIGHT ASSEMBLY Measure the resistance according to the value(s) in the table below. OK Measurement Condition Specified Condition Battery positive (+) --> Terminal 2 Battery negative (-) --> Terminal 1 Light illuminates If the result is not as specified, replace the courtesy light assembly.

HINT

1. Use the same procedures for the RH and LH side.
2. The procedures listed below are for the LH side.

1. INSTALL COURTESY LIGHT BULB Install the bulb.
2. INSTALL COURTESY LIGHT ASSEMBLY Connect the connector. Attach the claw of the courtesy light to the rear door trim.

Scheme 30

Scheme 31

1. REMOVE FRONT PASSENGER SIDE KNEE AIRBAG ASSEMBLY Remove the front passenger side knee airbag assembly. Refer to REMOVAL [01/2012 - ] .
2. REMOVE INSTRUMENT PANEL BOX DOOR KNOB . Refer to REMOVAL [01/2012 - ] - Step 50
3. REMOVE LOWER NO. 2 INSTRUMENT PANEL FINISH PANEL . Refer to REMOVAL [01/2012 - ] - Step 51
4. REMOVE GLOVE BOX LIGHT ASSEMBLY Remove the 2 screws and glove box light.

1. INSTALL GLOVE BOX LIGHT ASSEMBLY Install the glove box light with the 2 screws.
2. INSTALL LOWER NO. 2 INSTRUMENT PANEL FINISH PANEL . Refer to INSTALLATION [01/2012 - ] - Step 16
3. INSTALL INSTRUMENT PANEL BOX DOOR KNOB . Refer to INSTALLATION [01/2012 - ] - Step 17
4. INSTALL FRONT PASSENGER SIDE KNEE AIRBAG ASSEMBLY Install the front passenger side knee airbag assembly. Refer to INSTALLATION [01/2012 - ] .

Scheme 32

Scheme 33

1. REMOVE FRONT DOOR LOWER FRAME BRACKET GARNISH LH . Refer to DISASSEMBLY [01/2012 - ] - Step 4
2. REMOVE FRONT DOOR INSIDE HANDLE BEZEL LH . Refer to DISASSEMBLY [01/2012 - ] - Step 7
3. REMOVE FRONT ARMREST UPPER BASE PANEL LH . Refer to DISASSEMBLY [01/2012 - ] - Step 9
4. REMOVE FRONT DOOR TRIM BOARD SUB-ASSEMBLY LH . Refer to DISASSEMBLY [01/2012 - ] - Step 10
5. REMOVE FRONT DOOR INSIDE HANDLE ILLUMINATION LIGHT ASSEMBLY LH Detach the 2 claws and clamp, and remove the light.

Scheme 34

1. INSPECT FRONT DOOR INSIDE HANDLE ILLUMINATION LIGHT ASSEMBLY LH (INSIDE HANDLE LIGHT) Apply battery voltage to the connector and check the LED illumination condition. OK Measurement Condition Specified Condition Battery positive (+) --> Terminal 1 (+B) Battery negative (-) --> Terminal 2 (GND) Light illuminates If the result is not as specified, there may be a malfunction in the light.

1. INSTALL FRONT DOOR INSIDE HANDLE ILLUMINATION LIGHT ASSEMBLY LH Attach the 2 claws and clamp to install the light.
2. INSTALL FRONT DOOR TRIM BOARD SUB-ASSEMBLY LH . Refer to REASSEMBLY [01/2012 - ] - Step 35
3. INSTALL FRONT ARMREST UPPER BASE PANEL LH . Refer to REASSEMBLY [01/2012 - ] - Step 36
4. INSTALL FRONT DOOR INSIDE HANDLE BEZEL LH . Refer to REASSEMBLY [01/2012 - ] - Step 38
5. INSTALL FRONT DOOR LOWER FRAME BRACKET GARNISH LH . Refer to REASSEMBLY [01/2012 - ] - Step 41

Scheme 35

Scheme 36

1. REMOVE REAR DOOR INSIDE HANDLE BEZEL LH . Refer to DISASSEMBLY [01/2012 - ] - Step 6
2. REMOVE POWER WINDOW REGULATOR SWITCH ASSEMBLY . Refer to REMOVAL [01/2012 - ] - Step 2
3. REMOVE REAR DOOR TRIM BOARD SUB-ASSEMBLY LH . Refer to DISASSEMBLY [01/2012 - ] - Step 9
4. REMOVE REAR DOOR INSIDE HANDLE ILLUMINATION LIGHT ASSEMBLY LH Detach the 2 claws and remove the light.

Scheme 37

1. INSPECT REAR DOOR INSIDE HANDLE ILLUMINATION LIGHT ASSEMBLY LH (INSIDE HANDLE LIGHT) Apply battery voltage to the connector and check the LED illumination condition. OK Measurement Condition Specified Condition Battery positive (+) --> Terminal 1 (+B) Battery negative (-) --> Terminal 2 (GND) Light illuminates If the result is not as specified, there may be a malfunction in the light.

1. INSTALL REAR DOOR INSIDE HANDLE ILLUMINATION LIGHT ASSEMBLY LH Attach the 2 claws to install the light.
2. INSTALL REAR DOOR TRIM BOARD SUB-ASSEMBLY LH . Refer to REASSEMBLY [01/2012 - ] - Step 33
3. INSTALL POWER WINDOW REGULATOR SWITCH ASSEMBLY . Refer to INSTALLATION [01/2012 - ] - Step 1
4. INSTALL REAR DOOR INSIDE HANDLE BEZEL LH . Refer to REASSEMBLY [01/2012 - ] - Step 36

Scheme 38

Scheme 39

1. REMOVE FRONT DOOR SCUFF PLATE LH Detach the 7 claws and 4 clips, and remove the scuff plate. Disconnect the connector.

Scheme 40

1. INSPECT FRONT DOOR SCUFF PLATE LH (SCUFF PLATE LIGHT) Apply battery voltage to the connector and check the LED illumination condition. OK Measurement Condition Specified Condition Battery positive (+) --> Terminal 2 (+B) Battery negative (-) --> Terminal 1 (GND) Light illuminates If the result is not as specified, there may be a malfunction in the light.

1. INSTALL FRONT DOOR SCUFF PLATE LH Connect the connector. Attach the 7 claws and 4 clips to install the scuff plate.

Scheme 41

Scheme 42

1. REMOVE FRONT DOOR COURTESY LIGHT SWITCH ASSEMBLY Using a T30 "TORX" socket wrench, remove the screw and switch. Disconnect the connector.

Scheme 43

1. INSPECT FRONT DOOR COURTESY LIGHT SWITCH ASSEMBLY Measure the resistance according to the value(s) in the table below. STANDARD RESISTANCE Tester Connection Switch Condition Specified Condition 1 - Body ground Pin not pushed Below 1 ohms 1 - Body ground Pin pushed 10 kohms or higher If the result is not as specified, there may be a malfunction in the front door courtesy switch.

1. INSTALL FRONT DOOR COURTESY LIGHT SWITCH ASSEMBLY Connect the connector. Using a T30 "TORX" socket wrench, install the switch with the screw.

Scheme 44

Scheme 45

1. REMOVE REAR DOOR COURTESY LIGHT SWITCH ASSEMBLY Using a T30 "TORX" socket wrench, remove the screw and switch. Disconnect the connector.

Scheme 46

1. INSPECT REAR DOOR COURTESY LIGHT SWITCH ASSEMBLY Measure the resistance according to the value(s) in the table below. STANDARD RESISTANCE Tester Connection Switch Condition Specified Condition 1 - Body ground Pin not pushed Below 1 ohms 1 - Body ground Pin pushed 10 kohms or higher If the result is not as specified, there may be a malfunction in the rear door courtesy switch.

1. INSTALL REAR DOOR COURTESY LIGHT SWITCH ASSEMBLY Connect the connector. Using a T30 "TORX" socket wrench, install the switch with the screw.
