CUSTOMIZE PARAMETERS [01/2012 - ]

HINT

The following items can be customized.

Note. When the customer requests a change in a function, first make sure that the function can be customized. Be sure to make a note of the current settings before customizing. When troubleshooting a function, first make sure that the function is set to the default setting.

Scheme 60

Scheme 61

Scheme 62

Scheme 63

1. CUSTOMIZING FUNCTION WITH TECHSTREAM POWER TILT AND POWER TELESCOPIC STEERING COLUMN SYSTEM TILT & TELESCO Display Default Contents Setting Autoaway/Return function ON Turn the auto away/return function ON/OFF ON/OFF INTUITIVE PARKING ASSIST SYSTEM WARNING Display Default Contents Setting Rr Sensor Onset Range Wide Sets the buzzer activation range for the rear sensors. Narrow or Wide Keep Sense Buzzer Avail Makes the buzzer sound when the distance between the vehicle and obstacle does not change for more than 3 seconds. Not Avail or Avail Fr & Rr Buzzer Volume H Changes the buzzer volume setting. L, M1, M2, M3 or H SENSOR Display Default Contents Setting Sensor Condition N Avail Makes the sensors available when the shift lever is in N. Not Avail or Avail Reverse Range Front Sensor F Changes the operation setting for the vehicle front sensors when the shift lever is in R. F or F Stop Non P/R Range Rear Sensor R Stop Changes the operation setting for the vehicle rear sensors when the shift lever is not in P or R. R, Rcrn or R Stop DISPLAY Display Default Contents Setting Approach Display OFF Avail The display when moving away from a previously detected obstacle. Not Avail or Avail Display Mode All The display mode setting (when the intuitive parking assist system is normal). All or Undisp POWER DOOR LOCK CONTROL SYSTEM DOOR LOCK Display Default Contents Setting Unlock Key Twice ON Function that unlocks only the driver side door when the driver side door key cylinder is turned to unlock once, and unlock all doors when it is turned to unlock twice. For the OFF setting, turning it once unlocks all doors. ON/OFF Auto Lock OFF Function that locks all doors when the vehicle speed reaches a certain level. ON/OFF Auto Lock/Shift ON Function that locks all doors when the shift lever is moved from P to any position other than P while the engine running and all doors are closed. ON/OFF Auto Unlock/Shift ON Function that unlocks all doors when the shift lever is moved to P from any position other than P while the engine switch is on (IG). ON/OFF All Unlock/Open-Close OFF Function that unlocks the other doors when the driver side door is opened within 45 seconds after the engine switch is turned off. ON/OFF WIRELESS DOOR LOCK CONTROL SYSTEM WIRELESS DOOR LOCK Display Default Contents Setting Hazard Answer Back ON When the lock switch on the transmitter is pressed, this function illuminates the hazard warning lights once. When the unlock switch is pressed, the hazard warning lights illuminate twice. ON/OFF Wireless Control ON Function that turns the wireless door lock function on or off. ON/OFF Open Door Warning ON If a door is not completely closed and the transmitter lock switch is pressed, this function makes the buzzer sound for 5 seconds. ON/OFF Panic Alarm Function ON Function to operate the theft deterrent system by continuously pressing the panic switch on transmitter for 1 second or more. ON/OFF Unlock 2 Operation ON Function that unlocks the driver side door when the unlock switch on the transmitter is pressed once, and unlocks all doors when the switch is pressed twice. If the setting is OFF, pressing the unlock switch once makes all the doors unlock. ON / OFF Auto Lock Time 60 s Function to change the time until relocking after unlocking with the wireless door lock function. 30 s/60 s/120 s Wireless Auto Lock ON Function to control the automatic relocking of doors after unlocking with the wireless door lock function. ON/OFF Wireless Buzzer Volume Level 7 This function changes the wireless buzzer volume. Level 0/Level 1/Level 2/Level 3/Level 4/Level 5/Level 6/Level 7 PSD&PBD OPERATION Display Default Contents Setting PBD One Motion ON Function to turn on/off the power back door wireless one motion open operation. ON/OFF Wireless PBD SW Operation 0.8s Function to change the way the power back door is operated by the back door switch. 1 TIME/2 TIME/0.8 s/OFF SMART ACCESS SYSTEM WITH PUSH-BUTTON START (for Entry Function) SMART KEY / ACCESS Display Default Contents Setting Park Wait Time*1 2.5s Function that sets the waiting time to permit unlocking the door after the door is locked with the entry lock function. 0.5s/1.5s/2.5s/5s Ignition Area*2 ALL Function to choose the available area for the key to start the engine and cancel the steering lock. FRONT/ALL*3 Back Door Opening Operation*4 LONG The back door opening operation. LONG/TWICE/OFF WARNING Display Default Contents Setting Key Low Battery Warning*5 ON Function that warns the driver that the key battery power is low. ON/OFF HINT: *1: Waiting time to permit unlocking door after locking. *2: Entry ignition available area. *3: "FRONT" means front, and "ALL" means front floor, rear floor and luggage compartment. *4: Back door open mode when vehicle is locked. *5: Warn when key battery becomes weak. ENTRY UNLOCK MODE SWITCHING FUNCTION Check that the power source mode is off and the LED on the key is not blinking. Press the lock switch and one of the other switches on the key at the same time for approximately 5 seconds while the key is in the actuation area. When the switches are pressed and held for 5 seconds, the entry door unlock mode changes in the following order: driver door unlock mode, all door unlock mode. NOTE: After pressing and holding the switches for 5 seconds, wait 5 seconds before performing the same procedure again. Driver door unlock mode (default): When the driver door touch sensor is touched, only the driver door unlocks. When another touch sensor is touched, all doors unlock. All door unlock mode: When a touch sensor is touched, all doors unlock. The certification ECU (smart key ECU assembly) receives this signal from the door control receiver and changes the smart access system with push-button start to the entry unlock mode. >The certification ECU (smart key ECU assembly) sounds the wireless door lock buzzer and combination meter buzzer to inform the user that the mode has been switched. HINT: The function only changes the entry unlock mode of the smart access system with push-button start. It does not switch the unlocking of the wireless door lock control. Driver door unlock mode: All door unlock mode: KEY CANCEL The key cancel operation disables the following functions: Entry Unlock/Lock Key Lock-in Prevention Memory Call Entry Back Door Open Warning Entry Ignition The operation procedures are as follows: Precondition: Engine switch off, driver side door closed and unlocked. Unlock the driver side door once with the unlock switch of the key. Open the driver door within 5 seconds. Unlock the driver side door twice with the unlock switch of the key within 5 seconds. Perform close --> open twice for the driver door within 30 seconds. (Driver door: Open condition --> Close --> Open --> Close --> Open) Unlock the driver side door twice with the unlock switch of the key within 5 seconds. Perform close --> open once for the driver door within 30 seconds. (Driver door: Open condition --> Close --> Open) Close the driver door within 5 seconds. When key cancel is activated, the wireless door lock buzzer sounds twice. To return to the original condition, perform the procedures again. When the original condition is returned, the wireless door lock buzzer sounds once. SMART ACCESS SYSTEM WITH PUSH-BUTTON START (for Start Function) SMART KEY / ACCESS Display Default Content Setting Ignition Available Area All Function to choose the available area for the key to start the engine and cancel the steering lock. Front/All THEFT DETERRENT SYSTEM SECURITY Display Default Contents Setting Passive Mode (Security System) OFF Passive arming mode is a function that switches the theft deterrent system from the arming preparation state to the armed state 30 seconds after the key is not inside vehicle and the driver side door is closed. In passive arming mode, the theft deterrent system will judge that a theft is taking place and switch to the alarm sounding state if one of the following operations is not performed within 14 seconds (see entry delay below) after the door is opened: Unlock any door by a key or wireless operation Turn the engine switch on (IG) ON/OFF Warning by Horn ON Function that allows the vehicle horns and security horn to be used as a warning device. ON/OFF Entry Delay Time 14 s Function that changes the entry delay time (time before warning starts) for passive arming mode. 0 s/14 s/30 s METER AND GAUGE SYSTEM WARNING Display Default Contents Setting Driver Side Seatbelt Warning Buzzer ON To change the seat belt warning buzzer. ON/OFF Front Passenger Side Seatbelt Warning Buzzer ON To change the seat belt warning buzzer. ON/OFF UNIT CONVERSION Display Default Contents Setting Units By Region Different for each vehicle To change the units of the display. Km/l JP / Km/l / Mi/g US / Mi/g UK DISPLAY Display Default Contents Setting ECO Drive Indicator Zone ON To change the eco driving indicator zone display. ON/OFF Language None To change the language of the display. Eng US / Eng UK / French / German / Spanish / Italian / Japanes / CHN Sim / CHN Trd SEAT BELT WARNING SYSTEM SEAT BELT WARNING Display Default Contents Setting Driver Side Seatbelt Warning Buzzer ON If the driver side seat belt is unfastened and the vehicle is driven at approximately 20 km/h (12.5 mph) or more, this system sounds the seat belt warning buzzer. ON/OFF Front Passenger Side Seatbelt Warning Buzzer ON If the front passenger side seat belt is unfastened and the vehicle is driven at approximately 20 km/h (12.5 mph) or more, this system sounds the seat belt warning buzzer. ON/OFF AIR CONDITIONING SYSTEM AIR CONDITIONER Display Default Contents Setting Relevant ECU Set Temperature Shift Normal Function to set the temperature shift. +2 C/+1 C/Normal/-1 C/-2 C Air conditioning amplifier assembly Evaporator Control Automatic Function to set the evaporator control to the automatic position (Automatic) to save power, or to the coldest position (Manual) to dehumidify the air and to prevent the windows from fogging up. Manual/Automatic Air conditioning amplifier assembly Compressor/Air Inlet DEF operation Link Function to automatically turn the A/C on when the front defroster button is pressed. Normal/Link Air conditioning amplifier assembly Compressor Mode Automatic Function to turn the A/C on automatically by pressing the AUTO button when the blower is on and the A/C is off. Manual/Automatic Air conditioning amplifier assembly Air Inlet Mode Automatic Function to automatically change to recirculation mode when the A/C is turned on. Manual/Automatic Air conditioning amplifier assembly Foot/DEF Auto Mode ON Function to turn on the airflow from the front and rear footwell register ducts and center and side defrosters automatically when auto mode is on. ON/OFF Air conditioning amplifier assembly Foot/DEF Automatic Blow Up Function ON Function to change the blower level automatically when the defroster is on. ON/OFF Air conditioning amplifier assembly Ambient Temperature Shift Normal Function to control the shifted ambient temperature in relation to the displayed ambient temperature. +3 C/+2 C/+1 C/Normal/-1 C/-2 C/-3 C Air conditioning amplifier assembly Emission Gas Sensor Shift Normal Function to change the sensitivity of the exhaust gas sensor. Much More/More/Little More/Normal/Little Less/Less/Much Less Air conditioning amplifier assembly Add Foot Air in FACE Mode ON When the FACE mode is selected, an additional amount of air blow to the foot area. Selecting OFF will cancel this additional air flow. ON/OFF Air conditioning amplifier assembly POWER WINDOW CONTROL SYSTEM POWER WINDOW Display Default Contents Setting Door Key P/W Up OFF Function that raises all the power windows when, with the engine switch off, a key is used to hold the driver door key cylinder to the lock position for more than 2.3 sec. ON/OFF Door Key P/W Down OFF Function that lowers all the power windows when, with the engine switch off, a key is used to hold driver door key cylinder to the unlock position for more than 2.3 sec. ON/OFF P/W Down W/ Transmit OFF Function that lowers all the power windows when, with the engine switch off, the unlock switch on the transmitter is pressed and held for more than 3.0 sec. ON/OFF P/W Up W/ Smart OFF Function that raises all the power windows when, with the engine switch off, the entry lock switch on the driver side door outside handle is pressed and held for more than 3.0 sec. ON/OFF SLIDING ROOF SYSTEM SLIDE ROOF Display Default Contents Setting Door Key Related Open ON The function to manually open the sliding roof linked with the power window if holding the driver side door key for 3 seconds or more to unlock position when the engine switch is off. ON/OFF Door Key Related Close ON The function to manually close the sliding roof linked with the power window if holding the driver side door key for 3 seconds or more to lock position when the engine switch is off. ON/OFF Wireless Key Related Open OFF The function to manually open the sliding roof linked with the power window if pressing the transmitter unlock switch for 3 seconds or more when the engine switch is off. ON/OFF Door Handle Lock Button ON The function to manually close the sliding roof linked with the power window if pushing the door lock switch for 3 seconds or more when the engine switch is off and the key is outside vehicle. ON/OFF Door Key Related Operation Slide The function to select tilt up or slide open of manual sliding roof operation linked with the power window activated by holding the driver side door key for 3 seconds or more to unlock position when the engine switch is off. Tilt/Slide Wireless Key Related Operation Slide The function to select tilt up or slide open of manual sliding roof operation linked with the power window activated by pressing on the transmitter unlock switch for 3 seconds or more when the engine switch is off. Tilt/Slide POWER BACK DOOR SYSTEM PSD & PBD OPERATION Display Default Contents Setting PBD Power Operation Valid Makes power back door function ON or OFF Valid/Invalid PBD SW Operation 0.8 s A function that turns the power back door closer switch on when the switch is pushed once or is held down for 0.8 sec. 0.8s/ON PBD Buzzer ON A function that makes the power back door buzzer sound when the power back door is operating. ON/OFF Wireless PBD Operation 0.8 s A function that operates the power back door when the transmitter switch is pressed in a specified way (1 time, 2 times, 0.8 sec. press, or off). 1 time/2 times/0.8 s/OFF LIGHTING SYSTEM ILLUMINATED ENTRY Display Default Content Setting I/L when ACC OFF ON Function to illuminate the interior light when the engine switch is turned from on (IG) or on (ACC) to off. ON/OFF Lighting Time 15s Function to change the lighting time after closing the door. (It will quickly fade out in the case of turning the engine switch on (IG)). 7.5s/15s/30s Light Control ON Function to illuminate the door inside handle illumination light when the engine switch is on (IG) and the shift lever is not in P. ON/OFF I/L ON W/Door Key Unlock ON Function to illuminate the interior light, etc. when the door is unlocked with a transmitter, door key or door lock control switch. ON/OFF Mirr-Foot-Lgt Approached ON Function to illuminate the door mirror foot light and step light when the transmitter enters the key ID detection area. ON/OFF Mirr-Foot-Lgt Unlocked ON Function to illuminate the door mirror foot light and step light when unlocking the doors with the transmitter. ON/OFF Mirr-Foot-Lgt w/Master SW ON Function to illuminate the door mirror foot light and step light when unlocking the doors with the transmitter. ON/OFF Mirror Foot Light Time 15s Door mirror foot light and step light illumination duration. 0s/7.5s/15s/30s Room Light when Aprchd ON Dome light illumination (when key enters key ID detection area). ON/OFF Inside Foot Light ON Interior foot light illumination. ON/OFF Center Console Spot Light ON Center console spot light. ON/OFF LIGHT CONTROL Display Default Content Setting Light Auto OFF Delay 30s Function to illuminate the headlight for a certain period of time after closing all the doors with the engine switch turned from on (IG) to off under the condition that the headlights illuminate with the light control switch at head or AUTO. OFF/30s/60s/90s Sensitivity NORMAL Function to adjust the sensitivity of the lighting illumination*1. Light2/Light1/Normal/Dark1/Dark2 Disp Ex ON Sen NORMAL Changes the brightness when the lights such as the combination meter indicator light, A/C indicator light, and clock light dim. Refer to the illumination*2. LIGHT2/LIGHT1/NORMAL/DARK1/DARK2 Disp Ex OFF Sen NORMAL Adjusts the brightness when lights such as the combination meter indicator light, A/C indicator light and clock light brighten. Refer to illumination*3. LIGHT2/LIGHT1/NORMAL/DARK1/DARK2 DRL Function ON DRL control. ON/OFF Automatic High Beam ON Automatic high beam system ON/OFF Lane CHG Flash CNT 3 times Lane change flasher system OFF/3 times/5 times/7 times/9 times/11 times HINT: The sensitivity adjustment may be difficult to confirm. Check by driving the vehicle of the customer. *1 System Setting Setting Dark2 Dark1 Normal Light1 Light2 HINT: When the setting is closer to the "Light" side, the system turns the lights on even when the surrounding area is relatively bright. When the setting is closer to the "Dark" side, the system waits until the surrounding area is darker before turning on the lights. *2 System Setting Setting DARK2 DARK1 NORMAL LIGHT1 LIGHT2 HINT: When the setting is closer to the "Light" side, the system dims the indicator lights even when the surrounding area is relatively bright. When the setting is closer to the "Dark" side, the system waits until the surrounding area is darker before dimming the indicator lights. *3 System Setting Setting DARK2 DARK1 NORMAL LIGHT1 LIGHT2 HINT: When the setting is closer to the "Dark" side, the system cancels the dimming of the indicator lights even when the surrounding area is relatively dark. When the setting is closer to the "Light" side, the system waits until the surrounding area is brighter before canceling the dimming of the indicator lights. Door linked map light and personal light illumination control Mode 1: When door is opened, map light of opened door illuminates, or personal light illuminates Mode 2: When door is opened, all map lights and personal lights illuminate Mode 3: Map lights and personal lights are not linked to doors To change modes, press the map light assembly DOOR and on switch simultaneously, and then turn the engine switch from off to on (IG). Each engine switch off to on (IG) operation will change the mode (Mode 1 --> Mode 2 --> Mode 3 --> Mode 1). HINT: After changing modes, the map light responds by blinking as follows: Mode 1: once; Mode 2: twice; Mode 3: three times.
2. CUSTOMIZING FUNCTION WITH MULTI-DISPLAY (w/ Multi-display) HINT: The following items can be customized. NOTE: When the customer requests a change in a function, first make sure that the function can be customized. Be sure to make a note of the current settings before customizing. When troubleshooting a function, first make sure that the function is set to the default setting. Turn the engine switch on (IG). Enter the following menus: Setup / Vehicle. Select the setting by referring to the table below. INTUITIVE PARKING ASSIST SYSTEM WARNING Display Default Contents Setting Alert volume 3 Sets the buzzer activation range for the rear center sensors. 1, 2, 3, 4 or 5 Display On The display mode setting (when the intuitive parking assist system is normal). On or Off Distance Wide Sets the buzzer activation range for the rear center sensors. Narrow or Wide SENSOR Display Default Contents Setting Sensor Condition N Avail Makes the sensors available when the shift lever is in N. Not Avail or Avail Reverse Range Front Sensor F Changes the operation setting for the vehicle front sensors when the shift lever is in R. F or F Stop Non P/R Range Rear Sensor R Stop Changes the operation setting for the vehicle rear sensors when the shift lever is not in P or R. R, Rcrn or R Stop DISPLAY Display Default Contents Setting Approach Display OFF Avail The display when moving away from a previously detected obstacle. Not Avail or Avail Display Mode All The display mode setting (when the intuitive parking assist system is normal). All or Undisp POWER DOOR LOCK CONTROL SYSTEM Display Default Content Setting Speed Sensitive Auto Lock On Function that locks all doors when the vehicle speed reaches a certain level. On or Off Shift-Linked Auto Lock On Function that locks all doors when the shift lever is moved out of P, with the engine switch on (IG) and all doors closed. On or Off Shift-Linked Auto Unlock On Function that unlocks all doors when the shift lever is moved to P from any position other than P with the engine switch on (IG). On or Off Driver Door-Linked Unlock Off Function that unlocks the other doors when the driver door is opened within 10 seconds after the engine switch is turned off. On or Off Unlock on Second Key Turn On Function that unlocks only the driver door when the driver door key cylinder is turned to unlock once, and unlocks all doors when it is turned to unlock twice. For the OFF setting, turning it once unlocks all doors. On or Off WIRELESS DOOR LOCK CONTROL SYSTEM Display Default Content Setting Remote 2-Press Unlock On Function that unlocks driver door when unlock switch on electrical key transmitter sub-assembly is pressed once, and unlocks all doors when pressed twice. If setting is Off, pressing unlock switch once makes all doors unlock. On or Off Auto Relock Time Adjust 60 sec. Function that regulates the interval between unlocking and automatic relocking of doors 30 sec., 60 sec. or 120 sec. Lock/Unlock Answer Back On When the doors are locked by wireless operation, the hazard warning lights flash once. When the doors are unlocked by wireless operation, the hazard warning lights flash twice. On or Off Lock Feedback Volume 5 Bars Wireless door lock buzzer volume 0, 1, 2, 3, 4, 5, 6 or 7 Bars SMART KEY SYSTEM (for Entry Function) Display Default Contents Setting Remote 2-Press Unlock On Function that unlocks driver door when unlock switch on electrical key transmitter sub-assembly is pressed once, and unlocks all doors when pressed twice. If setting is Off, pressing unlock switch once makes all doors unlock. On or Off Select Doors to Unlock Driver's Door Function that sets which doors are unlocked by the entry unlock function. All Doors or Driver's Door Auto Relock Time Adjust 60 sec. Function that regulates the interval between unlocking and automatic relocking of doors 30 sec., 60 sec. or 120 sec. Lock/Unlock Answer Back On When the doors are locked by wireless operation, the hazard warning lights flash once. When the doors are unlocked by wireless operation, the hazard warning lights flash twice. On or Off Lock Feedback Volume 5 Bars Wireless door lock buzzer volume 1, 2, 3, 4, 5, 6 or 7 Bars AIR CONDITIONING SYSTEM AIR CONDITIONER Display Default Contents Setting Relevant ECU Auto A/C Mode On Enables or disables the function which automatically turns the air conditioning on according to the state of the AUTO switch. On or Off Air conditioning amplifier assembly Efficient Ventilation Mode On Enables or disables the function which automatically switches between recirculation and fresh air modes when the AUTO switch is on. On or Off Air conditioning amplifier assembly LIGHTING SYSTEM Display Default Contents Setting Light Sensor Sensitivity 0 (middle bar) Adjusts the ambient light sensitivity of the automatic light control system.* -2, -1, 0, +1 or +2 Headlights Off Time 30 s Function to continue illuminating headlights for a certain period of time after closing driver door with the engine switch turned from on (IG) to off under the condition that the headlight dimmer switch is in the AUTO position with the headlights on. Off, 30 s, 60 s or 90 s Daytime Running Lights ON DRL control. ON/OFF Interior Lights Off Time 15 s This function controls the interior lights. OFF, 7.5 s, 15 s or 30 s Exterior Lights Off Time 15 s This function controls the exterior lights. OFF, 7.5 s, 15 s or 30 s Select Turn Flash Counts 3 times Lane change flasher system OFF/3 times/5 times/7 times/9 times/11 times HINT: The sensitivity adjustment may be difficult to confirm. Check by driving the vehicle. * System Setting Setting -2 -1 0 +1 +2 HINT: When the setting is closer to the "Light" side, the system turns the lights on even when the surrounding area is relatively bright. When the setting is closer to the "Dark" side, the system waits until the surrounding area is darker before turning on the lights.

Scheme 64

Scheme 65

Scheme 66

Scheme 67

Scheme 68

Scheme 69

Scheme 70

Scheme 71

Scheme 72

Scheme 73

Scheme 74

Scheme 75

Scheme 76

Scheme 77

Scheme 78

Scheme 79

Scheme 80

Scheme 81

Scheme 82

Scheme 83

Scheme 84

Scheme 85

Scheme 86

Scheme 87

Scheme 88

Scheme 89

Scheme 90

Scheme 91

Scheme 92

Scheme 93

Scheme 94

Scheme 95

Scheme 96

Scheme 97

Scheme 98

Scheme 99

Scheme 100

Scheme 101

Scheme 102

1. PROCEDURES NECESSARY WHEN CABLE IS DISCONNECTED/RECONNECTED TO BATTERY TERMINAL PROCEDURES NECESSARY WHEN CABLE IS DISCONNECTED/RECONNECTED TO BATTERY TERMINAL Necessary Procedures Procedure Details Effects or Inoperative Functions When Necessary Procedures are not Performed Notes Initialization of steering angle sensor Drive the vehicle on a straight road at 35 km/h (22 mph) or more for 5 seconds or more. VGRS system Other related systems cannot operate properly - Servo motors initialization Using the Techstream, perform the servo motor initialization. Air conditioning system does not operate properly During initialization, the AUTO indicator light comes on, and then goes off when initialization has finished. Initialization of power back door system Completely close the back door by hand once. Power back door function Initialization is not necessary if the cable is disconnected and reconnected to the negative (-) battery terminal while the back door is closed. However, the power back door system will not operate if the back door is not unlocked after the cable is reconnected. NOTE: After the engine switch is turned off, the multi-media module receiver assembly records various types of memory and settings. As a result, after turning the engine switch off, make sure to wait for the time specified in the following table before disconnecting the cable from the negative (-) battery terminal. WAITING TIME BEFORE DISCONNECTING CABLE FROM NEGATIVE (-) BATTERY TERMINAL Condition Waiting Time Vehicle enrolled in safety connect system 6 minutes Vehicle not enrolled in safety connect system 1 minute
2. PROCEDURES NECESSARY WHEN ECU OR OTHER PARTS ARE REPLACED PROCEDURES NECESSARY WHEN ECU OR OTHER PARTS ARE REPLACED Replacement Part Necessary Procedures Effects or Inoperative Functions When Necessary Procedures are not Performed Notes ECM Register VIN. DTC P0630 is output - Distance Control ECU Initialization Cannot adjust millimeter wave radar sensor - Millimeter wave radar sensor assembly Adjusting the radar beam axis Dynamic radar cruise control system does not operate normally - Any of shift solenoid valves Reset memory Large shift shock - Suspension control ECU Vehicle height offset calibration Vehicle height sensor date may be affected due to installation position, or vehicle height recognition may be erroneous After vehicle height offset calibration is performed, it is necessary to calibrate the yaw rate sensor Height control sensor Vehicle height offset calibration Vehicle height sensor date may be affected due to installation position, or vehicle height recognition may be erroneous After vehicle height offset calibration is performed, it is necessary to calibrate the yaw rate sensor Valve body and shift solenoid valve Perform the Reset Memory (AT initialization) Large shift shock - Automatic transmission assembly Perform the Reset Memory (AT initialization) Large shift shock - Tire pressure warning ECU Register transmitter IDs. Initialize tire pressure warning system. When DTC detection conditions of "transmitter ID not received" DTC is met, tire pressure warning light blinks for 1 minute, and then illuminates Tire pressure monitoring function - Tire pressure warning valve and transmitter Register transmitter IDs Initialize tire pressure warning system When DTC detection conditions of "transmitter ID not received" DTC is met, tire pressure warning light blinks for 1 minute, and then illuminates Tire pressure monitoring function of replaced wheel Even if only one wheel is replaced, IDs for all 5 wheels must be registered Skid control ECU (Master cylinder solenoid) Yaw rate and acceleration sensor zero point calibration. ABS warning light illumination Slip indicator light illumination - Yaw rate sensor assembly Clearing zero point calibration data. Yaw rate and acceleration sensor zero point calibration. ABS warning light illumination Slip indicator light illumination - Vehicle height adjustment Clearing zero point calibration data. Yaw rate and acceleration sensor zero point calibration. Steering angle sensor initialization VSC system - Steering control ECU Steering column Steering intermediate shaft Steering actuator assembly Calibration VGRS system DTC output - Steering angle sensor Initialization VGRS system Other related systems cannot operate properly - Rear television camera Rear television camera optional axis (Camera position setting) Vehicle width extension lines and expected course are deviated Replace or installation angle of the rear television camera changes because of the removal and installation of the rear television camera Side television camera Side television camera optional axis (Camera position setting) Vehicle parallel lines and expected course are deviated Replace or installation angle of the side television camera changes because of the removal and installation of the side television camera Multi-media Module Receiver Assembly Parking assist ECU Steering angle neutral point in memory Store the left and right maximum steering angles Rear television camera optical axis (Camera position setting) Side television camera optical axis (Camera position setting) Parking assist monitor system Replace or installation angle of the rear television camera changes because of the removal and installation of the rear television camera Inner rear view mirror assembly Registration Garage door does not operative - DCM (Telematics Transceiver) DCM Activation Safety connect system does not operative - ID code box Steering lock ECU ECM Key Certification ECU Registration Wireless door lock operation Entry operation Engine starting Steering unlock - No. 1 seat cushion assembly (occupant classification ECU and occupant detection sensor) Zero point calibration Registration Sensitivity check Occupant classification system Passenger airbag ON/OFF indicator Airbag system (Front passenger side) Seat belt warning system (Front passenger side) - Servo motors Servomotors initialization Air conditioning system does not operate properly During initialization, the AUTO indicator light comes on, and then goes off when initialization has finished. Front Power window regulator motor LH Front Power window regulator motor RH Rear Power window regulator motor LH Rear Power window regulator motor RH Initialize the motor Jam protection function Power window control system DTC B2313 is output - Sliding roof drive gear (Sliding roof ECU) Sliding roof glass Initialize sliding roof system Auto operation Jam protection function Sliding roof operation after engine switch off Wireless door lock control function Key-linked operation function (Driver side door only) Entry lock switch-linked operation - Power back door unit Back door lock Initialize power back door system Power back door system
3. REGISTRATION RELATED TO ECM NOTE: The Vehicle Identification Number (VIN) must be input into the replacement ECM. HINT: The VIN is in the form of a 17-digit alphanumeric vehicle identification number. The Techstream is required to register the VIN. DESCRIPTION HINT: This registration service information consists of two parts: Read VIN and Write VIN. Read VIN: Explains the VIN reading process in a flowchart. This process allows the VIN stored in the ECM to be read in order to confirm that the two VINs, provided with the vehicle and stored in the vehicle ECM, are the same. Write VIN: Explains the VIN writing process in a flowchart. This process allows the VIN to be input into the ECM. If the ECM is changed, or the ECM VIN and vehicle VIN do not match, the VIN can be registered, or overwritten in the ECM by following this procedure. READ VIN Confirm the vehicle VIN. Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Utility / VIN / VIN Read. WRITE VIN Confirm the vehicle VIN. Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Utility / VIN / VIN Write.
4. INITIALIZATION RELATED TO DYNAMIC RADAR CRUISE CONTROL NOTE: After removing and installing or replacing the distance control ECU, be sure to perform the following procedures. INITIALIZE DISTANCE CONTROL ECU Turn the engine switch on (IG). Turn the cruise control main switch on. Depress the brake pedal (brake switch on). With the brake pedal depressed, push the cruise control main switch to +RES 3 times within 3 seconds, and check that the buzzer sounds. NOTE: At this time, do not turn the headlight dimmer switch on. Due to the activation of the beam axis automatic adjustment mode, turning the headlight dimmer switch on may result in an incorrect setting. If the headlight dimmer switch is turned on by mistake, perform the beam axis adjustment again.
5. ADJUSTMENT FOR MILLIMETER WAVE RADAR SENSOR WARNING: Radio frequency radiation exposure Information: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be kept with minimum distance of 20 cm (7.87 in.) between the radiator (antenna) and your body at all times during adjustment. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. ADJUST MILLIMETER WAVE RADAR SENSOR ASSEMBLY NOTE: Perform measurements on a level surface. Make sure that there are no metal objects on the ground or within a 10 m (32.8 ft.) x 14 m (45.9 ft.) area in front of the vehicle. If possible, the surrounding area should also be free of large metal objects. TEXT IN ILLUSTRATION *1 Approx. 10 m *2 Approx. 14 m Before adjusting, perform the following: Remove all cargo from the inside of the vehicle. Adjust the tire pressure to the specified value(s). Adjust the vehicle's height to the standard height. Adjust the vertical direction. Remove any dust and oil from the level rack of the millimeter wave radar sensor assembly. Set a level for use with the sensor in the center of the level rack of the millimeter wave radar sensor assembly. TEXT IN ILLUSTRATION *1 Level Using a screwdriver, adjust the sensor by turning the vertical adjusting bolt of the millimeter wave radar sensor assembly (bolt A) until the air bubble is centered on the red line of the level as shown in the illustration. Standard 0.2° upward HINT: The adjustable range within the red frame of the level is +/-0.2°. ADJUSTMENT: Vertical adjustment Upward direction: Turn bolt A in minus direction Downward direction: Turn bolt A in plus direction For 1 complete turn of screwdriver, sensor moves about 0.12° TEXT IN ILLUSTRATION *1 Level *2 Air Bubble *3 Bolt A *a FR *b LH *c Screwdriver Insertion Hole Adjust SST (reflector) height. SST: 09870-60000 09870-60010 SST: 09870-60040 Adjust SST (reflector) so that the center of SST (reflector) is the same height as the millimeter wave radar sensor assembly. TEXT IN ILLUSTRATION *1 Millimeter Wave Radar Sensor Place SST (reflector). Hang a pointed weight from the center of the front and rear bumpers of the vehicle (center of the emblem) and accurately mark the center points on the ground. Mark a point 5 m (16.4 ft.) in front of the vehicle on the line that connects the front and rear center point marks. HINT: Affix one end of a string to the rear center point mark and extend the string 5 m (16.4 ft.) from the front of the vehicle. Move the other end of the string left and right to align the string with the front center point mark and make a straight line. TEXT IN ILLUSTRATION *1 String *a Adjust Center By Moving String To Right And Left *b Extend String Through Front Center Mark Place SST at a position 12 mm (0.472 in.) from the marked position, to the right of the vehicle. NOTE: Perform the operation as precisely as possible. TEXT IN ILLUSTRATION *a Reflector (SST) Placement Point *b Millimeter Wave Radar Sensor Position Adjust the beam axis. Connect Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream main switch ON, and turn the cruise control main switch ON. Select "Connect to Vehicle". Under "Option", select "RADAR CRUISE". Under "System Selection Menu", select "ALL ECUs". Select "Radar Cruise". HINT: A buzzer will sound for 1 second. Follow the tester display, and continue with the adjustment. Check the following items on the laser cruise divergence data screen. NOTE: While using the Techstream beam axis adjustment mode, the actual direction and angle of the radar sensor may be different from the Techstream data. In such a case, the deviation is displayed on the combination meter's multi-information display Confirm that the distance value is approximately 5 m (16.41 ft.). HINT: A value between 0.0 and 6.3 m (20.67 ft.) is indicated. If the distance is 0 m (0 ft.), the sensor cannot detect the target. Reconfirm that there is no metal in the specified area in front of the vehicle (refer to the NOTICE at the beginning of this adjustment procedure). Confirm that the left/right side value is between 0.0 and 6.3. HINT: If the distance is 0 m (0 ft.), the sensor cannot detect the target. Reconfirm that there is no metal in the specified area in front of the vehicle (refer to the NOTICE at the beginning of this adjustment procedure). Adjust the horizontal direction. Read the current amount of angle deviation. Standard 0° (Both left and right) Based on the results of the beam axis deviation measurement, using a screwdriver, adjust the sensor by turning the horizontal adjusting bolt of the millimeter wave radar sensor assembly (bolt B). ADJUSTMENT: Horizontal adjustment Right direction: Turn bolt B in plus direction Left direction: Turn bolt B in minus direction For 1 complete turn of screwdriver, sensor moves about 0.07° NOTE: If it is difficult to reach a value of 0°, it is possible that the sensor is targeting an object other than SST. Reconfirm that there are no reflective objects in the surrounding area. TEXT IN ILLUSTRATION *1 Bolt B *a Screwdriver Insertion Hole Because the driving learned value will be reset, cover the left half of the sensor with aluminum foil or equivalent (a metal material that blocks electric waves) for a period of approximately 10 seconds. NOTE: At this time, leave SST in place and make sure there are no objects between the right half of the sensor and the reflector. HINT: When the value is reset, the buzzer will sound for 10 seconds, a distance value between 0 and 6.3° and a right side value between 0 and 6.3 m (20.7 ft.) will be displayed on the screen. TEXT IN ILLUSTRATION *1 Aluminum foil Continue the procedure according to the display to complete the beam axis adjustment. Disconnect the Techstream from the vehicle. Reconfirm the vertical direction. Set a level for use with the sensor in the center of the level rack of the millimeter wave radar sensor assembly. TEXT IN ILLUSTRATION *1 Level Using a screwdriver, adjust the sensor by turning the vertical adjusting bolt of the millimeter wave radar sensor assembly (bolt A) until the air bubble is centered on the red line of the level as shown in the illustration. Standard 0.2° upward HINT: The adjustable range within the red frame of the level is +/-0.2°. ADJUSTMENT: Vertical adjustment Upward direction: Turn bolt A in minus direction Downward direction: Turn bolt A in plus direction For 1 complete turn of screwdriver, sensor moves about 0.12° TEXT IN ILLUSTRATION *1 Level *2 Air Bubble *3 Bolt A *a FR *b LH *c Screwdriver Insertion Hole DRIVE TEST Perform the drive test. NOTE: Be sure to perform the driving test after adjusting the millimeter wave radar sensor assembly. Be careful when driving. Drive at 30 km/h (19 mph) on a straight road with good visibility while staying in the center of the lane. NOTE: Because the pre-collision system may activate under the following conditions, avoid conditions like these when performing the test. There are objects on the side of the road at the beginning of a curve. Passing an oncoming vehicle on a curve. Crossing a narrow metal bridge. There are metal objects on the road surface. There is an oncoming vehicle when turning right. Rapidly approaching a vehicle driving in front. On a straight road, when passing an oncoming vehicle with no danger of collision, check that the master warning does not illuminate and that the buzzer does not sound. At the same time, check that "BRAKE!" is not displayed on the display in the combination meter. If "BRAKE!" is displayed, perform the millimeter wave radar sensor assembly adjustment again. HINT: Check the installation condition of the millimeter wave radar sensor assembly. Check that the pre-collision brake switch is not pushed in.
6. INITIALIZATION RELATED TO AUTOMATIC TRANSMISSION RESET MEMORY NOTE: Perform the Reset Memory (AT initialization) when replacing the automatic transmission assembly, valve body assembly or any of the shift solenoid valves. The Reset Memory can only be performed with the Techstream. HINT: The ECM memorizes the control conditions of the automatic transmission assembly and engine assembly. Therefore, when the automatic transmission assembly, valve body assembly or any of the shift solenoid valves has been replaced, it is necessary to reset the memory so that the ECM can memorize the new information. Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Utility / Reset Memory. NOTE: After performing the Reset Memory, be sure to perform the Road Test described earlier. HINT: The ECM learns through the Road Test.
7. INITIALIZATION RELATED TO SUSPENSION DESCRIPTION If replacing the suspension control ECU and/or height control sensor, perform the vehicle height offset calibration. VEHICLE HEIGHT OFFSET CALIBRATION NOTE: Make sure that the pressure of the tires is normal. Make sure that the vehicle is empty. Make sure that the parking brake is released and that the shift lever is in N. Make sure that the easy access mode switch is off. PERFORM VEHICLE HEIGHT INSPECTION Adjust the pressure of the tires. Stabilize the suspension by releasing the parking brake and bouncing the corners of the vehicle up and down. Start the engine. Perform the following operation twice: Set the vehicle height to LO with the height control switch, and then return the vehicle height to NORMAL. Turn the engine switch off. Connect the Techstream to the DLC3. Move the shift lever to N and move the vehicle forward and rearward. Turn the engine switch on (IG) and the Techstream on. HINT: Make sure the engine is not running. Check that the vehicle height is NORMAL. HINT: The N of the multi-information display height control indicator in the combination meter turns on. Perform the vehicle height inspection. Measuring points A Ground clearance of front wheel center B Ground clearance of the front adjusting cam bolt center C Ground clearance of the rear axle shaft center D Ground clearance of the rear lower control arm front side center Standard Vehicle Height Front (A minus B) Rear (C minus D) 101 mm (3.98 in.) 94 mm (3.70 in.) Using a jack, set the vehicle to the standard vehicle height and eliminate any difference in height between the left and right sides of the vehicle. NOTE: The vehicle height may be outside the calibration range if there is a difference in height between the left and right sides of the vehicle. Using the Techstream, enter the following menus: Chassis / AHC / Data List. Then read and record the values for "After Height Adjust" and "Height Adjust" for each wheel. AHC Tester Display Measurement Item/Range Normal Condition Diagnosis Note FR Height Adjust Display of vehicle height offset recorded value of front right wheel / min.: -3276.8 mm (-129 in.) max.: 3276.7 mm (129 in.) - - FL Height Adjust Display of vehicle height offset recorded value of front left wheel / min.: -3276.8 mm (-129 in.) max.: 3276.7 mm (129 in.) - - RR Height Adjust Display of vehicle height offset recorded value of rear right wheel / min.: -3276.8 mm (-129 in.) max.: 3276.7 mm (129 in.) - - RL Height Adjust Display of vehicle height offset recorded value of rear left wheel / min.: -3276.8 mm (-129 in.) max.: 3276.7 mm (129 in.) - - FR After Height Adjust Display of after-calibration vehicle height value of front right wheel / min.: -3276.8 mm (-129 in.) max.: 3276.7 mm (129 in.) - - FL After Height Adjust Display of after-calibration vehicle height value of front left wheel / min.: -3276.8 mm (-129 in.) max.: 3276.7 mm (129 in.) - - RR After Height Adjust Display of after-calibration vehicle height value of rear right wheel / min.: -3276.8 mm (-129 in.) max.: 3276.7 mm (129 in.) - - RL After Height Adjust Display of after-calibration vehicle height value of rear left wheel / min.: -3276.8 mm (-129 in.) max.: 3276.7 mm (129 in.) - - Turn the engine switch off. PERFORM VEHICLE HEIGHT OFFSET CALIBRATION NOTE: The possible vehicle height automatic adjustment value is 20 mm (0.787 in.). If the "Height Adjust value + (Standard value - Measurement value - After Height Adjust value)" is 20 mm (0.787 in.) or more, first perform the vehicle height adjustment for the front side, and for the rear side. Turn the engine switch off. Connect the Techstream to the DLC3. Turn the engine switch on (IG) and the Techstream on. Enter the following menus: Chassis / AHC / Utility / Height offset. For each wheel, follow the instructions on the Techstream screen and input the input value to complete the vehicle height offset calibration. HINT: Input value = Measurement value and standard value Remove the jack. Start the engine. Set the vehicle height to LO and check that LO of the multi-information display height control indicator stops blinking and illuminates. Set the vehicle height to NORMAL and check that N of the height control indicator stops blinking and illuminates. Turn the engine switch off. Perform the vehicle height inspection. Check that the result is within +/-8 mm (+/-0.315 in.) of the standard value. Perform yaw rate and G sensor zero point calibration.
8. REGISTRATION RELATED TO TIRE PRESSURE WARNING DESCRIPTION OF CODE REGISTRATION It is necessary to register the transmitter ID in the tire pressure warning ECU when replacing a tire pressure warning valve and transmitter and/or the tire pressure warning ECU: Prepare all transmitter ID data before starting registration. Before registration In case of tire pressure warning ECU replacement: Read the registered transmitter IDs that are stored in the old ECU using the Techstream and note them down. If reading the stored transmitter IDs is impossible due to malfunctions of components such as the tire pressure warning antenna and receiver, remove the tires from the wheels and check the IDs located on the tire pressure warning valve and transmitters. In case of tire pressure warning valve and transmitter replacement: Take a note of the 7 digit number (transmitter ID) written on the tire pressure warning valve and transmitter. NOTE: The transmitter ID is written on the tire pressure warning valve and transmitter. It will be unable to be read after installing the tire pressure warning valve and transmitter to the tire and wheel. Therefore, take a note of the transmitter ID before installing the tire pressure warning valve and transmitter. REGISTER TRANSMITTER ID (USING TECHSTREAM) Set the air pressure of all tires to the specified value(s). Turn the engine switch off. Connect the Techstream to the DLC3. Turn the engine switch on (IG) and the Techstream on. Enter the following menus: Chassis / Tire Pressure Monitor / Utility / ID Registration. Perform the procedures displayed on the Techstream. HINT: The previously registered IDs will be cleared from the memory when the registration is completed. Registration can be performed during initialization. However, the initialization will be canceled when the registration is started. If this step is not completed within 300 seconds, this mode will be canceled. Confirmation of transmitter ID registration: Enter the following menus: Chassis / Tire Pressure Monitor / Data List. Read the "ID Tire Inflation Pressure" values. Confirm that the tire pressure data of all tires (including the spare tire) is displayed on the Techstream screen. NOTE: It may take up to about 2 or 3 minutes to update the tire pressure data. If the values are not displayed after a few minutes, perform troubleshooting according to the inspection procedure for DTCs C2121/21 to C2125/25. If the IDs have not been registered, DTC C2171/71 is stored in the tire pressure warning ECU after 3 minutes or more. If normal pressure values are displayed, the IDs have been registered correctly. If the tire pressure values are not displayed after a few minutes, the IDs may be incorrect or the system may have a malfunction. The tire pressure information reception condition can also be confirmed through the multi-information display tire pressure display screen. After all IDs are registered, DTC C2126/26 is stored in the tire pressure warning ECU and the tire pressure warning light blinks for 1 minute and then comes on. When the tire pressure warning ECU and receiver successfully receives information from all the transmitters whose IDs are stored in the ECU, DTC C2126/26 is cleared and the tire pressure warning light goes off.
9. INITIALIZATION RELATED TO TIRE PRESSURE WARNING DESCRIPTION OF INITIALIZATION Perform initialization in the following cases: Before delivery of a new vehicle. After replacement of the tire pressure warning ECU.* After replacement of a tire pressure warning valve and transmitter.* Specified tire pressure changes depending on the size or type of tire. Changing the standard tire inflation pressure value due to trailer towing. HINT: *: Perform initialization after the transmitter ID registration is completed. Before initialization Set the tire pressure of all tires to the specified value(s). NOTE: Make sure the tires are cooled down. INITIALIZATION PROCEDURE Turn the engine switch on (IG). Press and hold the tire pressure warning reset switch for 3 seconds or more so that the tire pressure warning light blinks 3 times. Turn the engine switch off. Connect the Techstream to the DLC3. Turn the engine switch on (IG) and turn the Techstream on. Enter the following menus: Chassis / Tire Pressure Monitor / Data List. Check that the initialization has been completed. Confirm that the tire pressure data of all tires is displayed on the Techstream screen. NOTE: The initialization is normally completed within 2 to 3 minutes. If the initialization has not been completed successfully, DTC C2177/77 is stored after a vehicle speed of 8 km/h (5 mph) or more continues for 20 minutes or more. While in test mode, the system will not change to initialization mode even if the tire pressure warning reset switch is pushed. The initialization can be terminated by connecting terminals 13 (TC) and 4 (CG) of the DLC3. TIRE PRESSURE MONITOR Tester Display Measurement Item/Range Normal Condition Diagnostic Note ID 1 Tire Inflation Pressure ID1 tire inflation pressure/ min.: Absolute pressure (abs) / 0.0 kPa (0 kgf/cm 2 , 0 psi), Relative pressure (gauge) / -2.5 kPa (-0.02 kgf/cm 2 , -0.3 psi) max.: Absolute pressure (abs) / 637.5 kPa (6.5 kgf/cm 2 , 92.5 psi), Relative pressure (gauge) / 537.5 kPa (5.4 kgf/cm 2 , 78 psi) Actual tire inflation pressure If N/A is displayed, data has not been received.* ID 2 Tire Inflation Pressure ID2 tire inflation pressure/ min.: Absolute pressure (abs) / 0.0 kPa (0 kgf/cm 2 , 0 psi), Relative pressure (gauge) / -2.5 kPa (-0.02 kgf/cm 2 , -0.3 psi) max.: Absolute pressure (abs) / 637.5 kPa (6.5 kgf/cm 2 , 92.5 psi), Relative pressure (gauge) / 537.5 kPa (5.4 kgf/cm 2 , 78 psi) Actual tire inflation pressure If N/A is displayed, data has not been received.* ID 3 Tire Inflation Pressure ID3 tire inflation pressure/ min.: Absolute pressure (abs) / 0.0 kPa (0 kgf/cm 2 , 0 psi), Relative pressure (gauge) / -2.5 kPa (-0.02 kgf/cm 2 , -0.3 psi) max.: Absolute pressure (abs) / 637.5 kPa (6.5 kgf/cm 2 , 92.5 psi), Relative pressure (gauge) / 537.5 kPa (5.4 kgf/cm 2 , 78 psi) Actual tire inflation pressure If N/A is displayed, data has not been received.* ID 4 Tire Inflation Pressure ID4 tire inflation pressure/ min.: Absolute pressure (abs) / 0.0 kPa (0 kgf/cm 2 , 0 psi), Relative pressure (gauge) / -2.5 kPa (-0.02 kgf/cm 2 , -0.3 psi) max.: Absolute pressure (abs) / 637.5 kPa (6.5 kgf/cm 2 , 92.5 psi), Relative pressure (gauge) / 537.5 kPa (5.4 kgf/cm 2 , 78 psi) Actual tire inflation pressure If N/A is displayed, data has not been received.* ID 5 Tire Inflation Pressure ID5 tire inflation pressure/ min.: Absolute pressure (abs) / 0.0 kPa (0 kgf/cm 2 , 0 psi), Relative pressure (gauge) / -2.5 kPa (-0.02 kgf/cm 2 , -0.3 psi) max.: Absolute pressure (abs) / 637.5 kPa (6.5 kgf/cm 2 , 92.5 psi), Relative pressure (gauge) / 537.5 kPa (5.4 kgf/cm 2 , 78 psi) Actual tire inflation pressure If N/A is displayed, data has not been received.* HINT: The initialization is complete when the Data List "ID Tire Inflation Pressure" display shows the correct pressures. *: It may take about 2 or 3 minutes until the values are displayed. If the values are not displayed after a few minutes, perform troubleshooting according to the inspection procedure for DTCs C2121/21 to C2125/25.
10. CALIBRATION RELATED TO VEHICLE STABILITY CONTROL DESCRIPTION After replacing VSC-related components, clearing and reading the sensor calibration data and system information is necessary. Follow the chart to perform calibration. Replacement/Adjustment Part Necessary Operation Skid Control ECU (Master Cylinder Solenoid) Clearing zero point calibration data Yaw rate and acceleration sensor zero point calibration Yaw Rate Sensor Assembly Clearing zero point calibration data Yaw rate and acceleration sensor zero point calibration Vehicle height adjustment Clearing zero point calibration data Yaw rate and acceleration sensor zero point calibration Steering sensor initialization PERFORM YAW RATE AND ACCELERATION SENSOR ZERO POINT CALIBRATION AND SYSTEM INFORMATION (WHETHER VGRS IS EQUIPPED) (When Using Techstream) NOTE: While obtaining the zero points, keep the vehicle stationary and do not vibrate, tilt, move, or shake it (do not start the engine). Be sure to perform this procedure on a level surface (with an inclination of less than 1%). Clear the zero point calibration and system information data. Turn the engine switch off. Check that the steering wheel is centered. Check that the shift lever is in P. Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Chassis / ABS/VSC/TRAC / Utility / Reset Memory. Select the skid control ECU (master cylinder solenoid) to clear the zero point calibration data using the Techstream. Turn the engine switch off. Perform zero point calibration of the yaw rate and acceleration sensor and store the system information. Turn the engine switch off. Check that the steering wheel is centered. Check that the shift lever is in P. NOTE: DTCs C1210 (Zero Point Calibration of Yaw Rate Sensor Undone) and C1336 (Zero Point Calibration of Acceleration Sensor Undone) are stored if the shift lever is not in P. If a DTC is output that indicates zero point calibration is incomplete, repeat the procedure starting at the step for clearing the zero point calibration data and system information. Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Chassis / ABS/VSC/TRAC / Utility / Test Mode. Keep the vehicle stationary on a level surface for 5 seconds or more. Check that the slip indicator light comes on for several seconds and then blinks in the test mode pattern (0.125 seconds on and 0.125 seconds off). HINT: If the slip indicator light does not blink, perform zero point calibration again. The zero point calibration is performed only once after the system enters test mode. Calibration cannot be performed again until the stored data is cleared. Turn the engine switch off and disconnect the Techstream. Check if DTC C120A (ECU Initial Setting Incomplete) is output. HINT: If DTC C120A is not output, calibration was performed successfully. PERFORM YAW RATE AND ACCELERATION SENSOR ZERO POINT CALIBRATION AND SYSTEM INFORMATION (WHETHER VGRS IS EQUIPPED) (When Using SST Check Wire) NOTE: While obtaining the zero points, keep the vehicle stationary and do not vibrate, tilt, move, or shake it (do not start the engine). Be sure to perform this procedure on a level surface (with an inclination of less than 1%). Clear the zero point calibration and system information data. SST: 09843-18040 Turn the engine switch off. Check that the steering wheel is centered. Check that the shift lever is in P. Turn the engine switch on (IG). Using SST, connect and disconnect terminals 12 (TS) and 4 (CG) of the DLC3 4 times or more within 8 seconds. TEXT IN ILLUSTRATION *a Front view of DLC3 Check that the slip indicator light comes on. Perform zero point calibration of the yaw rate and acceleration sensor and store the system information. SST: 09843-18040 Turn the engine switch off. Check that the steering wheel is centered. Check that the shift lever is in P. NOTE: DTCs 36 (Zero Point Calibration of Yaw Rate Sensor Undone) and 98 (Zero Point Calibration of Acceleration Sensor Undone) are stored if the shift lever is not in P. If a DTC is output that indicates zero point calibration is incomplete, repeat the procedure starting at the step for clearing the zero point calibration data and system information. Using SST, connect terminals 12 (TS) and 4 (CG) of the DLC3. TEXT IN ILLUSTRATION *a Front view of DLC3 Turn the engine switch on (IG). Keep the vehicle stationary on a level surface for 5 seconds or more. Check that the slip indicator light comes on for several seconds and then blinks in the test mode pattern (0.125 seconds on and 0.125 seconds off). HINT: If the slip indicator light does not blink, perform zero point calibration again. The zero point calibration is performed only once after the system enters test mode. Calibration cannot be performed again until the stored data is cleared. Turn the engine switch off and disconnect SST from the DLC3. Check if DTC 13 (ECU Initial Setting Incomplete) is output. HINT: If DTC 13 is not output, calibration was performed successfully.
11. INITIALIZATION RELATED TO VARIABLE GEAR RATIO STEERING STEERING ANGLE SENSOR INITIALIZATION (to obtain a tire angle (during straight-ahead driving) signal) Turn the engine switch on (IG), and check that the master warning light illuminates for a few seconds. NOTE: If the warning light remains on, repair the applicable system. Drive the vehicle on a straight road at 35 km/h (22 mph) or more for 5 seconds or more. HINT: At this point, the steering wheel will still remain off-center by 5 to 10°. In this step, the neutral position of the steering wheel is restored from the steering control ECU memory. Confirm that steering angle sensor initialization is completed (using the Techstream). Enter the VGRS menu using the Techstream. Select "Straight Angle Valid Flag" from "Data List". Check if the steering angle sensor has obtained a tire angle (during straight-ahead driving) signal. Standard "Valid" is displayed on the Techstream screen. Confirm that steering angle sensor initialization is completed (not using the Techstream). Stop the vehicle (engine running). Slowly turn the steering wheel from lock to lock. If it turns approximately 2.7 turns, steering angle sensor initialization is completed. If it turns approximately 3.2 turns, steering angle sensor initialization is not completed. NOTE: If the steering wheel turns approximately 3.2 turns, drive the vehicle on a straight road at 35 km/h (22 mph) or more for 5 seconds or more. Then confirm the initialization again.
12. CALIBRATION RELATED TO VARIABLE GEAR RATIO STEERING NOTE: Use this procedure to center the steering wheel if: The steering actuator assembly has been replaced. The steering control ECU has been replaced. The steering column or steering intermediate shaft has been disconnected. The steering wheel is still off-center after completing the steering angle sensor initialization. VGRS SYSTEM CALIBRATION PROCEDURE (WHEN USING SST CHECK WIRE) FACE TIRES STRAIGHT AHEAD (Procedure A) NOTE: Drive the vehicle to confirm that the steering wheel is centered. CHECK DTC (Procedure B) Check for DTCs. RESULT Result Proceed to DTC C1591/51 is not output Procedure C DTC C1591/51 is output Procedure D PERFORM ACTUATOR ANGLE INITIALIZATION (Procedure C) SST: 09843-18040 NOTE: If the procedures from *1 to *2 are not completed within 1 minute, or if errors are made during these procedures, perform the initialization again from the beginning. Start the engine. Center the steering wheel. Using SST, connect terminals 12 (TS) and 4 (CG), and 13 (TC) and 4 (CG) of the DLC3.*1 Disconnect SST from terminal 12 (TS) of the DLC3, and turn the steering wheel to the left 180° or more. Connect SST to terminal 12 (TS) of the DLC3. Disconnect SST from terminal 13 (TC) of the DLC3, and turn the steering wheel to the right 180° or more. Connect SST to terminal 13 (TC) of the DLC3.*2 HINT: If the master warning light comes on, DTC C1591/51 is stored. Disconnect SST from the DLC3. Turn the engine switch off. FACE TIRES STRAIGHT AHEAD (Procedure D) Confirm that the steering wheel is centered when facing the tires straight ahead. NOTE: Drive the vehicle to confirm that the steering wheel is centered. RESULT Result Proceed to Steering wheel is off-center Procedure E Steering wheel is centered Procedure H UNLOCK STEERING ACTUATOR (Procedure E) NOTE: Make sure the engine is not running. Turn the engine switch off. Disconnect the cable from the negative (-) battery terminal. NOTE: w/ Navigation system After the engine switch is turned off, the HDD navigation system requires approximately 6 minutes to record various types of memory and settings. As a result, after turning the engine switch off, wait 6 minutes or more before disconnecting the cable from the negative (-) battery terminal. Disconnect the E85 connector from the steering actuator. Connect a jumper wire from terminal 7 (LV+) of the steering actuator to the positive (+) 12 V battery terminal and another jumper wire from terminal 16 (LG+) of the steering actuator to the negative (-) 12 V battery terminal. NOTE: Do not apply voltage for more than 3 minutes. STEERING CENTER ADJUSTMENT (Procedure F) Center the steering wheel. NOTE: If the centering of the spiral cable was not confirmed when the steering wheel was installed, confirm the centering of the spiral cable. LOCK STEERING ACTUATOR (Procedure G) Disconnect the positive (+) and negative (-) 12 V battery jumper wires from the steering actuator. Connect the E85 connector to the steering actuator. Connect the cable to the negative (-) battery terminal. Turn the steering wheel approximately 3° to the left and right. Confirm that the reaction force can be felt. NOTE: If the above procedures are not followed correctly, a DTC will be stored. If a DTC is stored, perform the above procedures again and then check for DTCs. Perform these procedures with the engine switch off. ADJUST ACTUATOR ANGLE (Procedure H) SST: 09843-18040 HINT: Activating and ending test mode will complete actuator angle adjustment. Make sure the engine switch is off. NOTE: Do not touch the steering wheel during these procedures. Using SST, connect terminals 12 (TS) and 4 (CG) of the DLC3. Turn the engine switch on (IG). Confirm that "VGRS Test Mode" is displayed on the multi-information display when test mode is activated. HINT: Wait approximately 5 seconds. Turn the engine switch off. Disconnect SST from terminals 12 (TS) and 4 (CG) of the DLC3. Turn the engine switch on (IG) again. CHECK MASTER WARNING LIGHT (Procedure I) Confirm that the master warning light is off. Turn the engine switch off, then on (IG). Confirm that the master warning light is operating normally. CHECK STEERING WHEEL OPERATION (Procedure J) Start the engine. Perform the steering angle sensor initialization. Turn the steering wheel from lock to lock and check that it rotates approximately 2.7 turns. Drive the vehicle and confirm that the steering wheel is centered. VGRS SYSTEM CALIBRATION PROCEDURE (WHEN USING TECHSTREAM) FACE TIRES STRAIGHT AHEAD NOTE: Drive the vehicle to confirm that the steering wheel is centered. PERFORM VGRS SYSTEM CALIBRATION (Procedure A) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Chassis / VGRS / Utility / Steering Angle Adjust. Perform the following procedures displayed on the Techstream. HINT: Refer to the Techstream operator's manual for further details. CHECK MASTER WARNING LIGHT (Procedure B) Confirm that the master warning light is off. Turn the engine switch off. Disconnect the Techstream from the DLC3. Turn the engine switch on (IG). Confirm that the master warning light is operating normally. CHECK STEERING WHEEL OPERATION (Procedure C) Start the engine. Perform the steering angle sensor initialization. Turn the steering wheel from lock to lock and check that it rotates approximately 2.7 turns. Drive the vehicle and confirm that the steering wheel is centered.
13. INITIALIZATION RELATED TO PARKING ASSIST MONITOR SYSTEM INITIALIZE PARKING ASSIST MONITOR SYSTEM When "System initializing" is displayed on the multi-display assembly, correct the steering angle neutral point using the following method. Fully turn the steering wheel to the right and left on flat ground. NOTE: Memorizing the steering angle neutral point must be carried out with the engine started. Apply the parking brake, depress the brake pedal, check that the shift lever is in P, and ensure that the vehicle is not moving. HINT: The "?" button is displayed at the same time as "System initializing". If the "?" button is selected, this method is displayed.
14. CALIBRATION RELATED TO PARKING ASSIST MONITOR SYSTEM ADJUST PARKING ASSIST MONITOR SYSTEM This parking assist monitor system can be set from the diagnostic screen of the multi-display assembly. If the following operations are performed, it is necessary to perform adjustments and checks on the diagnostic screen. Part Name Operation Adjustment Item Proceed to Steering sensor Removal and installation of the Steering angle sensor Removal and installation of the connector of the steering sensor Steering angle neutral point (Initialize parking assist monitor system) - Steering angle setting Procedure 2 Replacement Steering angle neutral point (Initialize parking assist monitor system) - Steering angle setting Procedure 2 Multi-media module receiver assembly Replacement DCM activation - Parking assist ECU Replacement Parking assist ECU initialization Procedure 1 Suspension, tires, etc. The vehicle height changes because of suspension or tire replacement Rear television camera optical axis (Back camera position setting) Procedure 3 Side television camera optical axis (Side camera position setting) - Rear television camera assembly Replacement Installation angle of the rear television camera changes because of the removal and installation of the rear television camera, etc. Rear television camera optical axis (Back camera position setting) Procedure 3 NOTE: After the engine switch is turned off, the multi-media module receiver assembly records various types of memory and settings. As a result, after turning the engine switch off, be sure to wait for the time specified in the following table before disconnecting the cable from the negative (-) battery terminal. WAITING TIME BEFORE DISCONNECTING CABLE FROM NEGATIVE (-) BATTERY TERMINAL Condition Waiting Time Vehicle enrolled in safety connected system 6 minutes Vehicle not enrolled in safety connected system 1 minute HINT: The adjustment values stored while performing parking assist monitor system calibration are stored in the parking assist ECU. PARKING ASSIST ECU INITIALIZATION (Procedure 1) HINT: Be sure to check for DTCs before performing this procedure. Preparation for adjustment Park the vehicle with the steering wheel centered. Set a target bar for optical axis adjustment of the rear television camera. HINT: Only when adjusting the optical axis of the camera, create a target bar for adjustment. Dimension Area Specification A 825 to 835 mm (2.71 to 2.74 ft.) B 1995 to 2005 mm (6.55 to 6.58 ft.) TEXT IN ILLUSTRATION *a Vehicle Center *b Target Bar for Back Camera Adjustment *c Vehicle End *d Front Side HINT: Set a piece of tape on the ground as the target bar for adjustment. Its width and length are 20 to 30 mm (0.787 to 1.18 in.) and 1995 to 2005 mm (6.55 to 6.58 ft.), respectively. Check the color on the multi-display assembly and choose a tape color which can be easily seen. Before parking the vehicle, be sure to move the vehicle forward and in reverse to check that the tires are facing straight ahead with the steering wheel centered. Check that the back door is fully closed. Set a target bar for optical axis adjustment of the side television camera. HINT: Only when adjusting the optical axis of the camera, create a target bar for adjustment. TEXT IN ILLUSTRATION *a Target Bar for Side Camera Adjustment *b Front Wheel Axis *c Front Side *d Vehicle Center Dimension A B C D E F 1183 mm (3.88 ft.) 1181 mm (3.87 ft.) 500 mm (1.64 ft.) 500 mm (1.64 ft.) 500 mm (1.64 ft.) 180 mm (7.09 in.) HINT: Target bars for side camera adjustment should be made with 2 pieces of 2.5 cm wide tape; one piece should be 100 cm (3.28 ft.) (C+D) and the other should be 68 cm (2.23 ft.) (E+F) long. Check the tape color on the multi-media module receiver assembly and choose a tape color which can be easily seen. Start diagnostic mode. NOTE: Alignment must be performed with the engine running. For this reason, it is necessary to apply the parking brake, depress the brake pedal, and move the shift lever into the P position, and to exercise all other necessary caution to ensure that the vehicle does not begin moving unexpectedly. HINT: The displayed items may differ depending on vehicle specifications. Select "Function Check/Setting" on the [Service Menu] screen. Select "Camera Setting" on the [Function Check/Setting] screen. Select "Next" on the [Signal Check] screen. NOTE: When "CHK" (red) is displayed for any items on the [Signal Check] screen, selecting "Next" will not change the screen to the [Side Camera Position Setting] screen. When "CHK" (red) is displayed for any items on the [Signal Check] screen, perform inspections using the [Signal Check] screen. HINT: When the outer mirrors are retracted, selecting "Next" will not change the screen to the [Side Camera Position Setting] screen. If the screen does not change to the [Side Camera Position Setting] screen even though the outer mirrors are extended, perform the "MIRROR SW" check on the [Signal Check] screen. If the screen does not change to the [Side Camera Position Setting] screen even after "OK" (blue) is displayed as a result of the MIRROR SW check on the [Signal Check] screen, replace the parking assist ECU. Side Camera Position Setting: HINT: Colors used on the [Side Camera Position Setting] screen TEXT IN ILLUSTRATION *a Target Adjustment Bar for Side Camera Position Setting *b Red Frame *c Yellow Frame Perform the roll angle adjustment. Select switches A and B to rotate C so that it is parallel to the target adjustment bar. Perform the vertical and horizontal position adjustment. Select the directional switches D, E, F and G to move C so that the target adjustment bar is centered in C. Select "Next" to display [Side Verify Mode]. Side Verify Mode: Check that the red cross and the target adjustment bar are aligned. HINT: If they are not aligned, select "Back" and perform [Side Camera Position Setting] again. Select "Next" to display [Side Camera Signal Check]. Side Camera Signal Check: Select "Next" to store the side camera aiming adjustment value and change the screen to the [Steering Angle Setting] screen. HINT: When "Next" is selected, a beep will sound to confirm that the side camera aiming adjustment values have been stored. The adjustment value will not be stored unless "Next" is selected. Steering Angle Setting: Perform the "STEERING CENTER MEMORIZE" operation. Check that the steering wheel is centered, and then select "STEERING CENTER MEMORIZE". HINT: When performing removal and installation, or replacement of the television camera, steering angle adjustment is not required. Perform the "MAX STEERING ANGLE MEMORIZE" operation. After adjusting the steering angle neutral point, turn the steering wheel to the left and right lock positions and select "MAX STEERING ANGLE MEMORIZE". The maximum steering angle is then stored and the screen changes to the [Back Camera Position Setting] screen. HINT: The "Next" button does not respond until the system stores the steering angle neutral point and maximum steering angle. It is also possible to start by initially turning the steering to the right side. When "MAX STEERING ANGLE MEMORIZE" is selected, a beep will sound to confirm that the steering adjustment values have been stored. The adjustment value will not be stored unless "MAX STEERING ANGLE MEMORIZE" is selected after turning the steering wheel side to side. When "Back" is selected, the screen changes to [Side Verify Mode] without storing the set values. Even if no DTCs are detected, selecting "MAX STEERING ANGLE MEMORIZE" may not cause the adjustment value to be stored if the steering sensor is malfunctioning. If selecting "MAX STEERING ANGLE MEMORIZE" does not cause the adjustment value to be stored after adjusting the steering angle, replace the steering sensor. Back Camera Position Setting: HINT: When the back door is open, the "Back door is open. Do not use the rear view monitor when the back door is not completely closed." message will be displayed and camera position setting will not be possible. If the "Back door is open. Do not use the rear view monitor when the back door is not completely closed." message is displayed even when the back door is closed, perform inspections according to Problem Symptoms Table (A back door open warning message is displayed even after back door is closed). Perform the roll angle adjustment. Select switches A and B to rotate C so that it is parallel to the target adjustment bar. Perform the vertical and horizontal position adjustment. Select the directional switches D, E, F and G to move C so that the target adjustment bar is centered in C. Select the "Next" to display [Back Verify Mode]. Back Verify Mode: Check that A and the target adjustment bar are overlapping. If the steering angle neutral point is not aligned, perform the "STEERING CENTER MEMORIZE" and "MAX STEERING ANGLE MEMORIZE" operations. If A and the target adjustment bar are not aligned even if the tires are aligned straight ahead, perform the camera position setting operation. Selecting "OK" will return the screen to the [Service Menu] screen, and complete the adjustment. HINT: The update is not completed until "OK" is selected. When "OK" is selected, a beep will sound to confirm that the rear camera aiming adjustment values have been stored. Finish diagnostic mode. STEERING ANGLE SETTING (Procedure 2) Preparation for adjustment Park the vehicle with the steering wheel centered. Start diagnostic mode. NOTE: Alignment must be performed with the engine running. For this reason, it is necessary to apply the parking brake, depress the brake pedal, and move the shift lever into the P position, and to exercise all other necessary caution to ensure that the vehicle does not begin moving unexpectedly. HINT: The displayed items may differ depending on vehicle specifications. Select "Function Check/Setting" on the [Service Menu] screen. Select "Camera Setting" on the [Function Check/Setting] screen. Select "Steering Angle Setting" on the [Mode Setting] screen. HINT: To select a grayed out item, select and hold the item for 2 seconds or more. Select "Next" on the [Signal Check] screen. NOTE: When "CHK" (red) is displayed for any items on the [Signal Check] screen, selecting "Next" will not change the screen to the [Steering Angle Setting] screen. When "CHK" (red) is displayed for any items on the [Signal Check] screen, perform inspections using the [Signal Check] screen. Steering Angle Setting: Perform the "STEERING CENTER MEMORIZE" operation. Check that the steering wheel is centered, and then select "STEERING CENTER MEMORIZE". HINT: When performing removal and installation, or replacement of the television camera, steering angle adjustment is not required. Perform the "MAX STEERING ANGLE MEMORIZE" operation. After adjusting the steering angle neutral point, turn the steering wheel to the left and right lock positions and select "MAX STEERING ANGLE MEMORIZE". The maximum steering angle is then stored and the screen changes to the [Mode Setting] screen. HINT: The "Next" button does not respond until the system stores the steering angle neutral point and maximum steering angle. It is also possible to start by initially turning the steering to the right side. When "MAX STEERING ANGLE MEMORIZE" is selected, a beep will sound to confirm that the steering adjustment values have been stored. The adjustment value will not be stored unless "MAX STEERING ANGLE MEMORIZE" is selected after turning the steering wheel side to side. When "Back" is selected, the screen changes to [Signal Check] without storing the set values. Even if no DTCs are detected, selecting "MAX STEERING ANGLE MEMORIZE" may not cause the adjustment value to be stored if the steering sensor is malfunctioning. If selecting "MAX STEERING ANGLE MEMORIZE" does not cause the adjustment value to be stored after adjusting the steering angle, replace the steering sensor. Select "OK" to display [Mode Setting]. Finish diagnostic mode. Confirm steering angle adjustment. HINT: If the steering angle has been adjusted, confirm the steering angle adjustment on the parking assist monitor screen after finishing diagnostic mode. Check on the parking assist screen that the predicted path line moves until the steering wheel is fully turned to either the left or right. HINT: If the predicted path line stops moving before the steering wheel is fully turned to either the left or right, the steering angle adjustment values have not been stored correctly. In this case, perform "STEERING CENTER MEMORIZE" and "MAX STEERING ANGLE MEMORIZE" again. BACK CAMERA POSITION SETTING (Procedure 3) HINT: Be sure to check for DTCs before performing this procedure. Preparation for adjustment Park the vehicle with the steering wheel centered. Set a target bar for optical axis adjustment of the rear television camera. HINT: Only when adjusting the optical axis of the camera, create a target bar for adjustment. Dimension Area Specification A 825 to 835 mm (2.71 to 2.74 ft.) B 1995 to 2005 mm (6.55 to 6.58 ft.) TEXT IN ILLUSTRATION *a Vehicle Center *b Target Bar for Back Camera Adjustment *c Vehicle End *d Front Side HINT: Set a piece of tape on the ground as the target bar for adjustment. Its width and length should be 20 to 30 mm (0.787 to 1.18 in.) and 1995 to 2005 mm (6.55 to 6.58 ft.), respectively. Check the color on the multi-display and choose a tape color which can be easily seen. Before parking the vehicle, be sure to move the vehicle forward and in reverse to check that the tires are facing straight ahead with the steering wheel centered. Check that the back door is fully closed. Start diagnostic mode. NOTE: Alignment must be performed with the engine running. For this reason, it is necessary to apply the parking brake, depress the brake pedal, and move the shift lever into the P position, and to exercise all other necessary caution to ensure that the vehicle does not begin moving unexpectedly. HINT: The displayed items may differ depending on vehicle specifications. Select "Function Check/Setting" on the [Service Menu] screen. Select "Camera Setting" on the [Function Check/Setting] screen. Select "Back Camera Setting" on the [Mode Setting] screen. HINT: To select a grayed out item, select and hold the item for 2 seconds or more. Select "Next" on the [Signal Check] screen. NOTE: When "CHK" (red) is displayed for any items on the [Signal Check] screen, selecting "Next" will not change the screen to the [Back Camera Position Setting] screen. When "CHK" (red) is displayed for any items on the [Signal Check] screen, perform inspections using the [Signal Check] screen. Back Camera Position Setting: HINT: When the back door is open, the "Back door is open. Do not use the rear view monitor when the back door is not completely closed." message will be displayed and camera position setting will not be possible. If the "Back door is open. Do not use the rear view monitor when the back door is not completely closed." message is displayed even when the back door is closed, perform inspections according to Problem Symptoms Table (A back door open warning message is displayed even after back door is closed). Perform the roll angle adjustment. Select switches A and B to rotate C so that it is parallel to the target adjustment bar. Perform the vertical and horizontal position adjustment. Select the directional switches D, E, F and G to move C so that the target adjustment bar is centered in C. Select the "Next" button on the [Back Camera Position Setting] screen. Back Verify Mode: Check that A and the target adjustment bar are overlapping. If the steering angle neutral point is not aligned, perform the "STEERING CENTER MEMORIZE" and "MAX STEERING ANGLE MEMORIZE" operations. If A and the target adjustment bar are not aligned even if the tires are aligned straight ahead, perform the camera position setting operation. Selecting "OK" will return the screen to the [Service Menu], and complete the adjustment. HINT: The update is not completed until "OK" is selected. When "OK" is selected, a beep will sound to confirm that the rear camera aiming adjustment values have been stored. Finish diagnostic mode.
15. INITIALIZATION RELATED TO SIDE MONITOR SYSTEM INITIALIZE SIDE MONITOR SYSTEM When "System initializing" is displayed on the multimedia module receiver assembly, correct the steering angle neutral point using the following method. Fully turn the steering wheel to the right and left on the flat ground. NOTE: Memorizing the steering angle neutral point must be carried out with the engine started. Apply the parking brake, depress the brake pedal, move the shift lever to P and make sure that the vehicle is not moving. HINT: "?" button is displayed at the same time as "System initializing". If the "?" button is selected, this method is displayed.
16. CALIBRATION RELATED TO SIDE MONITOR SYSTEM ADJUST SIDE MONITOR SYSTEM This side monitor system can be set from the diagnostic screen of the multi-display assembly. If the following operations are performed, it is necessary to perform adjustments and checks on the diagnostic screen. Part Name Operation Adjustment Item Proceed to Steering sensor Removal and installation of the Steering angle sensor Removal and installation of the connector of the Steering angle sensor Replacement Steering angle neutral point - Steering angle setting - Multi-media module receiver assembly Replacement DCM activation - Parking assist ECU Replacement Parking assist ECU initialization - Suspension, tires, etc. The vehicle height changes because of suspension or tire replacement Rear television camera optical axis (Camera position setting) - Side television camera optical axis (Camera position setting) Procedure 1 Side television camera assembly Replacement Installation angle of the side television camera changes because of the removal and installation of the side television camera, etc. Side television camera optical axis (Camera position setting) Procedure 1 Outer rear view mirror assembly Replacement Side television camera optical axis (Camera position setting) Procedure 1 NOTE: After the engine switch is turned off, the multi-media module receiver assembly records various types of memory and settings. As a result, after turning the engine switch off, be sure to wait for the time specified in the following table before disconnecting the cable from the negative (-) battery terminal. WAITING TIME BEFORE DISCONNECTING CABLE FROM NEGATIVE (-) BATTERY TERMINAL Condition Waiting Time Vehicle enrolled in safety connected system 6 minutes Vehicle not enrolled in safety connected system 1 minute HINT: The adjustment values stored while performing side monitor system calibration are stored in the parking assist ECU. SIDE CAMERA SETTING (Procedure 1) HINT: Be sure to check for DTCs before performing this procedure. Preparation for adjustment Park the vehicle with the steering wheel centered. Set a target bar for optical axis adjustment of the rear television camera. HINT: Only when adjusting the optical axis of the camera, create a target bar for adjustment. Dimension Area Specification A 825 to 835 mm (2.71 to 2.74 ft.) B 1995 to 2005 mm (6.45 to 6.58 ft.) TEXT IN ILLUSTRATION *a Vehicle Center *b Target Bar for Back Camera Adjustment *c Vehicle End *d Front Side HINT: Set a piece of tape on the ground as the target bar for adjustment. Its width and length are 20 to 30 mm (0.787 to 1.18 in.) and 1995 to 2005 mm (6.55 to 6.58 ft.), respectively. Check the color on the multi-display assembly and choose a tape color which can be easily seen. Before parking the vehicle, be sure to move the vehicle forward and in reverse to check that the tires are facing straight ahead with the steering wheel centered. Check that the back door is fully closed. Set a target bar for optical axis adjustment of the side television camera. HINT: Only when adjusting the optical axis of the camera, create a target bar for adjustment. TEXT IN ILLUSTRATION *a Target Bar for Side Camera Adjustment *b Front Wheel Axis *c Front Side *d Vehicle Center Dimension A B C D E F 1183 mm (3.88 ft.) 1181 mm (3.87 ft.) 500 mm (1.64 ft.) 500 mm (1.64 ft.) 500 mm (1.64 ft.) 180 mm (7.09 in.) HINT: Target bars for side camera adjustment should be made with 2 pieces of 2.5 cm wide tape; one piece should be 100 cm (3.28 ft.) (C+D) and the other should be 68 cm (2.23 ft.) (E+F) long. Check the tape color on the multi-display assembly and choose a tape color which can be easily seen. Start diagnostic mode. NOTE: Alignment must be performed with the engine running. For this reason, it is necessary to apply the parking brake, depress the brake pedal, and move the shift lever into the P position, and to exercise all other necessary caution to ensure that the vehicle does not begin moving unexpectedly. HINT: The displayed items may differ depending on vehicle specifications. Select "Function Check/Setting" on the [Service Menu] screen. Select "Camera Setting" on the [Function Check/Setting] screen. Select "Side Camera Setting" on the [Mode Setting] screen. HINT: To select a grayed out item, select and hold the item for 2 seconds or more. Select "Next" on the [Signal Check] screen. NOTE: When "CHK" (red) is displayed for any items on the [Signal Check] screen, selecting "Next" will not change the screen to the [Side Camera Position Setting] screen. When "CHK" (red) is displayed for any items on the [Signal Check] screen, perform inspections using the [Signal Check] screen. HINT: When the outer mirrors are retracted, selecting "Next" will not change the screen to the [Side Camera Position Setting] screen. If the screen does not change to the [Side Camera Position Setting] screen even though the outer mirrors are extended, perform the "MIRROR SW" check on the [Signal Check] screen. If the screen does not change to the [Side Camera Position Setting] screen even after "OK" (blue) is displayed as a result of the MIRROR SW check on the [Signal Check] screen, replace the parking assist ECU. Side Camera Position Setting: HINT: Colors used on the [Side Camera Position Setting] screen TEXT IN ILLUSTRATION *a Target Adjustment Bar for Side Camera Position Setting *b Red Frame *c Yellow Frame Perform the roll angle adjustment. Select switches A and B to rotate C so that it is parallel to the target adjustment bar. Perform the vertical and horizontal position adjustment. Select the directional switches D, E, F and G to move C so that the target adjustment bar is centered in C. Select "Next" to display [Side Verify Mode]. Side Verify Mode: Check that the red cross and the target adjustment bar are aligned. HINT: If they are not aligned, select "Back" and perform [Side Camera Position Setting] again. Select "Next" to display [Side Camera Signal Check]. Side Camera Signal Check: Select "OK" to store the side camera aiming adjustment value and change the screen to the [Service Menu] screen. HINT: When "OK" is selected, a beep will sound to confirm that the side camera aiming adjustment values have been stored. The adjustment value will not be stored unless "Back" is selected. Finish diagnostic mode.
17. REGISTRATION RELATED TO GARAGE DOOR OPENER REGISTER TRANSMITTER CODE HINT: The vehicle garage door opener records transmitter codes for systems such as garage doors, gates, entry gates, door locks, home lighting systems, security systems or other transmitter code based systems. The garage door opener is built into the inner rear view mirror assembly. If replacing the inner rear view mirror assembly, transmitter codes for any systems previously registered in the garage door opener must be reregistered. Reregister systems in the garage door opener registration mode. WARNING: Do not perform transmitter code registration for a system if people or objects are near the system. When registering transmitter codes for a system, injury or damage can occur because the system may open, close, unlock or otherwise operate. NOTE: Before transmitter code registration, confirm that all the electrical systems (headlight, blower motor, rear defogger, etc.) are turned off and no key is in the vehicle. The garage door opener cannot be used with systems that: 1) were manufactured before April 1, 1982; or 2) do not meet Federal Standards (for example, garage doors without a jam protection function). HINT: 3 transmitter codes can be registered with the garage door opener, one transmitter code for each of the 3 garage door opener ("HomeLink") switches. Disconnecting the battery will not clear the transmitter codes registered with the garage door opener. An attempt to overwrite a previously registered transmitter code with a transmitter code of a new system may fail. In this situation, the previously registered transmitter code will not be cleared. Select a garage door opener ("HomeLink") switch for transmitter code registration. Press and hold the selected switch for 20 seconds.* The garage door opener will enter registration mode. TEXT IN ILLUSTRATION *1 LED *2 These "HomeLink" Switches HINT: *: This procedure is only necessary when reregistering transmitter codes after replacing parts, etc. Before entering registration mode, the LED illuminates. After entering registration mode, the LED flashes at a cycle of 1 Hz (slowly). For a "rolling code" type system, after entering registration mode, the LED flashes at a cycle of 8.8 Hz (very rapidly) for 1.6 seconds, and then the LED flashes at a cycle of 1 Hz. After the garage door opener has entered registration mode, bring the original transmitter of the system to be registered within 1 inches of the garage door opener ("HomeLink") switch, and press and hold one of the garage door opener ("HomeLink") switches. Then press the original transmitter switch. TEXT IN ILLUSTRATION *1 Original Transmitter *2 "HomeLink" Switch Press If the transmitter code registration was successful, the LED of the garage door opener flashes at a cycle of 5.6 Hz (rapidly). If no malfunction occurs, release both the garage door opener ("HomeLink") switch and original transmitter switch. HINT: If transmitter code registration fails: 1) the original transmitter battery may be low or need to be replaced, or 2) the system you are trying to register may not be compatible with the garage door opener. Some transmitter signals stop after 1 to 2 seconds. For these types of transmitters: 1) press and hold one of the garage door opener ("HomeLink") switches, and 2) press and release (cycle) the transmitter switch every 2 seconds. Check if the transmitter code was successfully registered. After entering the garage door opener registration mode, transmitter code registration must be completed within 90 seconds. If 75 seconds elapse, the garage door opener will enter low power mode (refer to "Low Power Mode" below). Clear transmitter codes in the garage door opener clear mode. TEXT IN ILLUSTRATION *1 LED *2 "HomeLink" Switch 1 *3 "HomeLink" Switch 3 HINT: All 3 registered transmitter codes will be cleared. No option exists for only erasing one transmitter code. Press and hold the left and right switches of the garage door opener for 10 seconds. The LED will begin to flash at a cycle of 5.6 Hz. Releasing the switches will end clear mode. HINT: If the switches are released within 10 seconds after the transmitter codes have been cleared, the garage door opener will enter registration mode.
18. DCM ACTIVATION This function should be used to activate the DCM (Telematics Transceiver) after a new DCM (Telematics Transceiver) has been installed. During the DCM Activation process, Techstream automatically provides the telematics service provider with the new DCM (Telematics Transceiver) information and deletes the old DCM (Telematics Transceiver) information associated with the vehicle. The DCM (Telematics Transceiver) that was replaced should be returned to the parts department. Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Choose "Telematics" from the System Selection Menu, and then click "Utility". Click "DCM Service" on the Utility Selection Menu. Choose "Activate DCM" and then click "Next" on the DCM Service Utility. Follow the instructions on the Techstream. HINT: If PRL is not latest version, utility will report that a PRL update must be performed before DCM Activation can be completed. If a fault occurs during DCM Activation, a specific fault message will be displayed with procedure guidelines. The manual (SOS) switch green indicator will turn on if activation is successful. Fault Code Reason 20 System timeout. 61 DCM (Telematics Transceiver) has been identified as a previously used part. 62 VIN not recognized by telematics provider. 63 DCM (Telematics Transceiver) already associated with a vehicle. Use another authorized service part. 64 DCM (Telematics Transceiver) not recognized. 66 DCM (Telematics Transceiver) is not a service part. Use only an authorized service part. 67 Unable to activate at this time. HINT: If the one these fault code is present, follow the procedure indicated in the following list. Fault 20: Try DCM Activation again. Fault 61: Replace the DCM (Telematics Transceiver) with a new service part and perform DCM Activation. Fault 62*: Verify VIN is correct in ECM. Run Vehicle Inquiry and verify VIN. Fault 63: Replace the DCM (Telematics Transceiver) with a new service part and perform DCM Activation. Fault 64*: Verify that the DCM (Telematics Transceiver) is a new service part. Fault 66*: Replace the DCM (Telematics Transceiver) with a new service part and perform DCM Activation. Fault 67: Try DCM Activation again. If the fault occurs again, wait and try again later. *: As the fault could also be caused by a problem in communicating with the call center, before replacing the DCM, check with the call center to determine it there is a database or communication problem. (Call Center number for LEXUS vehicle: 800-255-3987) Push the manual (SOS) switch to call an operator and confirm that the DCM (Telematics Transceiver) is activated.
19. REGISTRATION RELATED TO SMART WITH PUSH BUTTON START DESCRIPTION OF CODE REGISTRATION HINT: The engine immobilizer function ID code is the same as the recognition code for the smart access system with push-button start and wireless transmitter. Registering an ID code enables the smart access system with push-button start, wireless door lock control function and engine immobilizer function to be operated. Code registration is needed when the certification ECU (smart key ECU assembly), ID code box (immobilizer code ECU), steering lock ECU, ECM or key is replaced with a new one. This vehicle does not have a key slot. Therefore, touch the logo of the key to the engine switch to register the key, as shown in the illustration. KEY REGISTRATION PROCEDURES WHEN ADDING OR REPLACING KEY OR WHEN KEY IS LOST HINT: The following procedures require the use of the Techstream: - New key ID registration - Additional key ID registration - Key ID erasure A maximum of 7 keys can be registered. Registration Procedure Condition Procedure Refer to Registering an additional key Customer must bring at least 1 key 1. Register additional keys as necessary (additional key ID registration) PROCEDURE "C" Replacing a key Making a lost key unable HINT: After key ID erasure, any remaining keys that are not registered at this time cannot be used. Therefore, after key ID erasure, register all remaining keys. Customer must bring at least 1 key 1. Using remaining key, clear all registered keys except one (key ID erasure) PROCEDURE "D" 2. Register additional keys as necessary (additional key ID registration) PROCEDURE "C" All keys are lost - 1. Reset all keys (all keys ID erasure (key code reset)) PROCEDURE "E" 2. Register all keys (new key ID registration) PROCEDURE "A" PART REPLACEMENT AND KEY REGISTRATION PROCEDURES If a malfunctioning ECU is discovered through troubleshooting of the smart key system, use the ECU replacement and key registration procedures in the table below. HINT: The following procedures require the use of the Techstream: - New key ID registration - Additional key ID registration - Key ID erasure - ECU code registration A maximum of 7 keys can be registered. Malfunctioning ECU Condition Procedure Refer to Certification ECU (smart key ECU assembly) Customer has brought all keys 1. Replace certification ECU (smart key ECU assembly) - 2. Reregister all keys (new key ID registration) PROCEDURE "B" Some keys are lost Key ID codes can be registered and cleared 1. Clear key codes (key ID erasure) PROCEDURE "D" 2. Perform additional key registration procedure (additional key ID registration) HINT: If some keys are not registered during above steps, they will be disabled because they cannot be registered later. PROCEDURE "C" 3. Replace certification ECU (smart key ECU assembly) - 4. Reregister all keys (new key ID registration) PROCEDURE "B" Key ID codes cannot be either registered or cleared 1. Replace certification ECU (smart key ECU assembly) - 2. Replace ID code box (immobilizer code ECU) - 3. Reregister all keys (new key ID registration) HINT: If key codes cannot be cleared or additional keys cannot be registered due to a malfunction in certification ECU (smart key ECU assembly), replace ID code box (immobilizer code ECU) and certification ECU (smart key ECU assembly). If some keys are not registered during above steps, they will be disabled because they cannot be registered later. PROCEDURE "A" 4. ECU communication ID registration PROCEDURE "G" All keys are lost 1. Replace certification ECU (smart key ECU assembly) - 2. Replace ID code box (immobilizer code ECU) - 3. Register all keys (new key ID registration) PROCEDURE "A" 4. ECU communication ID registration PROCEDURE "G" ID code box (immobilizer code ECU) Customer has brought at least 1 key 1. Replace ID code box (immobilizer code ECU) - 2. Register recognition codes in ECUs (ECU code registration) PROCEDURE "F" 3. ECU communication ID registration PROCEDURE "G" All keys are lost 1. Replace certification ECU (smart key ECU assembly) - 2. Replace ID code box (immobilizer code ECU) - 3. Register all keys (new key ID registration) PROCEDURE "A" 4. ECU communication ID registration PROCEDURE "G" Steering lock ECU Customer has brought at least 1 key 1. Replace steering lock ECU - 2. Register recognition codes in ECUs (ECU code registration) PROCEDURE "F" All keys are lost 1. Replace certification ECU (smart key ECU assembly) - 2. Replace ID code box (immobilizer code ECU) - 3. Replace steering lock ECU - 4. Register all keys (new key ID registration) PROCEDURE "A" 5. ECU communication ID registration PROCEDURE "G" Main body ECU No condition required - - ECM No condition required 1. Replace ECM - 2. ECU communication ID registration HINT: Only perform procedure above when replacing with used ECM. PROCEDURE "H" KEY REGISTRATION PROCEDURES PROCEDURE "A" New key ID registration (when replacing certification ECU (smart key ECU assembly) and ID code box (immobilizer code ECU), or certification ECU (smart key ECU assembly), ID code box (immobilizer code ECU) and steering lock ECU), or when performing all keys ID erasure (key code reset): Process Procedure 1. Start of registration Connect the Techstream to DLC3 Turn the engine switch on (IG) HINT: The engine switch cannot be turned on (IG) more than 10 times. To continue the key registration procedure with the engine switch off, after connecting the Techstream, turn the Techstream on while turning the driver side door courtesy light switch on and off repeatedly at intervals of 1.5 seconds. Turn the Techstream on Enter the following menus: Smart Access / Utility / Key Code Registration 2. Confirmation of ECU code Perform operation according to prompts on the Techstream screen HINT: Mode is automatically selected by the Techstream (new registration mode or add mode). 3. Verification of unregistered key* Touch logo of unregistered key to engine switch Confirm that wireless door lock buzzer sounds once (short beep) Place unregistered key on front passenger side seat Confirm that wireless door lock buzzer sounds once (short beep) 4. Registration of ID code Perform operation according to prompts on the Techstream screen 5. End of registration Finish new key ID code registration HINT: *: Repeat this process for each key which is to be registered to the vehicle. Finish the procedure for each key within 30 seconds. If the procedure for any of the keys has not been finished within the specified time, perform the registration from process 1 again. Make sure that only 1 key is in the cabin during registration. If 2 or more keys are in the cabin simultaneously, the electric waves will interfere with each other, preventing normal registration. PROCEDURE "B" New key ID registration (when replacing certification ECU (smart key ECU assembly)): Process Procedure 1. Start of registration Connect the Techstream to DLC3 Turn the engine switch on (IG) HINT: The engine switch cannot be turned on (IG) more than 10 times. To continue the key registration procedure with the engine switch off, after connecting the Techstream, turn the Techstream on while turning the driver side door courtesy light switch on and off repeatedly at intervals of 1.5 seconds. Turn the Techstream on Enter the following menus: Smart Access / Utility / Key Code Registration 2. Confirmation of ECU code Perform operation according to prompts on the Techstream screen HINT: Mode is automatically selected by the Techstream (new registration mode or add mode). 3. Confirmation of all registered keys*1 Touch logo of registered key to engine switch Confirm that wireless door lock buzzer sounds once (short beep) 4. Confirmation of ECU code Perform operation according to prompts on the Techstream screen 5. Verification of unregistered key*2 Touch logo of unregistered key to engine switch Confirm that wireless door lock buzzer sounds once (short beep) Place unregistered key on front passenger side seat Confirm that wireless door lock buzzer sounds once (short beep) 6. Registration of ID code Perform operation according to prompts on the Techstream screen 7. End of registration Finish new key ID code registration HINT: *1: Repeat this process for each key registered to the vehicle. Finish the procedure for each key within 30 seconds. If the procedure for any of the keys has not been finished within the specified time, perform the registration from process 1 again. When performing the key confirmation procedure for a key, the security indicator light comes on and remains on until all the keys are confirmed. *2: Repeat this process for each key which is to be registered to the vehicle. Finish the procedure for each key within 30 seconds. If the procedure for any of the keys has not been finished within the specified time, perform the registration from process 1 again. Make sure that only 1 key is in the cabin during registration. If 2 or more keys are in the cabin simultaneously, the electric waves will interfere with each other, preventing normal registration. PROCEDURE "C" Additional key ID registration: Process Procedure 1. Start of registration Connect the Techstream to DLC3 Turn the engine switch on (IG) HINT: The engine switch cannot be turned on (IG) more than 10 times. To continue the key registration procedure with the engine switch off, after connecting the Techstream, turn the Techstream on while turning the driver side door courtesy light switch on and off repeatedly at intervals of 1.5 seconds. Turn the Techstream on Enter the following menus: Smart Access / Utility / Key Code Registration 2. Confirmation of registered key*1 Perform operation according to prompts on the Techstream screen Touch logo of registered key to engine switch Confirm that wireless door lock buzzer sounds once (short beep) 3. Confirmation of ECU code Perform operation according to prompts on the Techstream screen 4. Verification of unregistered key*2 Touch logo of unregistered key to engine switch Confirm that wireless door lock buzzer sounds once (short beep) Place unregistered key on front passenger side seat Confirm that wireless door lock buzzer sounds once (short beep) 5. Registration of ID code Perform operation according to prompts on the Techstream screen 6. End of registration Finish key ID code registration HINT: *1: Perform this process for one of the keys registered to the vehicle. Finish the procedure within 30 seconds. If the procedure has not been finished within the specified time, perform the registration from process 1 again. *2: Repeat this process for each key which is to be registered to the vehicle. Finish the procedure for each key within 30 seconds. If the procedure for any of the keys has not been finished within the specified time, perform the registration from process 1 again. Make sure that only 1 key is in the cabin during registration. If 2 or more keys are in the cabin simultaneously, the electric waves will interfere with each other, preventing normal registration. PROCEDURE "D" Key ID erasure (clear all registered key codes except one): Process Procedure 1. Start of erasure Connect the Techstream to DLC3 Turn the engine switch on (IG) HINT: The engine switch cannot be turned on (IG) more than 10 times. To continue the key ID erasure procedure with the engine switch off, after connecting the Techstream, turn the Techstream on while turning the driver side door courtesy light switch on and off repeatedly at intervals of 1.5 seconds. Turn the Techstream on Enter the following menus: Smart Access / Utility / Key Code Erasure 2. Confirmation of registered key* Perform operation according to prompts on the Techstream screen Touch logo of registered key to engine switch Confirm that wireless door lock buzzer sounds once (short beep) 3. Erasure of ID code Perform operation according to prompts on the Techstream screen 4. End of erasure Finish key ID code erasure HINT: *: Perform this process for one of the keys registered to the vehicle. Finish the procedure within 30 seconds. If the procedure has not been finished within the specified time, perform the erasure from process 1 again. PROCEDURE "E" All keys ID erasure: Process Procedure 1. Start of erasure Connect the Techstream to DLC3 Turn the engine switch on (IG) HINT: The engine switch cannot be turned on (IG) more than 10 times. To continue all keys ID erasure procedure with the engine switch off, after connecting the Techstream, turn the Techstream on while turning the driver side door courtesy light switch on and off repeatedly at intervals of 1.5 seconds. Turn the Techstream on Enter the following menus: Smart Access / Utility / Key Code Reset Read "Seed Number" sent from TIS according to the Techstream screen 2. Erasure of ID code Perform operation according to prompts on the Techstream screen 3. End of erasure Finish key ID code erasure PROCEDURE "F" ECU code registration: Process Procedure 1. Start of registration Connect the Techstream to DLC3 Turn the engine switch on (IG) HINT: The engine switch cannot be turned on (IG) more than 10 times. To continue the ECU code registration procedure with the engine switch off, after connecting the Techstream, turn the Techstream on while turning the driver side door courtesy light switch on and off repeatedly at intervals of 1.5 seconds. Turn the Techstream on Enter the following menus: Smart Access / Utility / ECU Communication ID Registration / ID code box (immobilizer code ECU) and Steering Lock Read "Seed Number" sent from TIS according to the Techstream screen 2. Confirmation of registered key* Touch logo of registered key to engine switch Confirm that wireless door lock buzzer sounds once (short beep) 3. Registration of ECU code Perform operation according to prompts on the Techstream screen 4. End of registration Finish ECU code registration HINT: *: Perform this process for one of the keys registered to the vehicle. Finish the procedure within 30 seconds. If the procedure has not been finished within the specified time, perform the registration from process 1 again. PROCEDURE "G" ECU communication ID registration: NOTE: The ECU communication ID should be registered when the ID code box (immobilizer code ECU), steering lock ECU or ECM is replaced in order to match the ECU communication ID. The engine cannot be started unless ECU communication ID is registered. After the registration, pressing the engine switch may not start the engine on the first try. If so, press the engine switch again. After the engine is started, clear DTC B2799 (code for ECM immobilizer communication error) using either of the following methods: - Use the Techstream. - Disconnect the cable from the negative (-) battery terminal for 30 seconds. SST: 09843-18040 Using SST, connect terminals 13 (TC) and 4 (CG) of the DLC3. Turn the engine switch on (IG) (do not start the engine) and leave it as is for 30 minutes. Turn the engine switch off and disconnect terminals 13 (TC) and 4 (CG). Check that the engine starts and stays on for more than 3 seconds. PROCEDURE "H" ECU communication ID reregistration: NOTE: The ECU communication ID should be registered when the ECM is replaced in order to match the ECU communication ID. Procedure Time Security Indicator Light Condition 1. Start - Off 2. While holding registered key, turn the engine switch on (IG) with brake pedal depressed 3. Check that engine starts and stays on for more than 3 seconds 4. End
20. REGISTRATION RELATED TO OCCUPANT CLASSIFICATION REGISTRATION NOTE: If any DTCs related to the occupant classification ECU are output, troubleshoot those DTCs by referring to the Diagnostic Trouble Code Chart. When ECU data saving or loading operations cannot be performed, replace the No. 1 seat cushion (occupant classification ECU and occupant detection sensor). HINT: When the No. 1 seat cushion (occupant classification ECU) is replaced, the previous ECU data must be saved in the Techstream and loaded into the new ECU by following the flowchart below. Until the data from the previous ECU are loaded into the new occupant classification ECU, these data are not cleared even when the Techstream is turned off. Connect the Techstream to the DLC3. Turn the engine switch on (IG). Store the occupant classification ECU data in the Techstream by following the prompts on the Techstream screen. HINT: If the ECU data cannot be stored in the Techstream, replace the No. 1 seat cushion (occupant classification ECU and occupant detection sensor). Turn the engine switch on (IG). Disconnect the cable from the negative (-) battery terminal, and wait for at least 90 seconds. Replace the No. 1 seat cushion (occupant classification ECU). Connect the cable to the negative (-) battery terminal. Turn the engine switch on (IG). Load the data from the previous ECU stored in the Techstream into the newly installed ECU by following the prompts on the Techstream screen. Turn the engine switch off. Turn the engine switch on (IG). Clear the DTCs stored in the memory. HINT: If DTCs are not cleared at this time, past DTCs will remain.
21. INITIALIZATION RELATED TO OCCUPANT CLASSIFICATION NOTE: Make sure that the front passenger seat is not occupied before performing the operation. HINT: Perform zero point calibration if any of the following conditions is met: The No. 1 seat cushion (occupant classification ECU) is replaced. The passenger airbag ON/OFF indicator indicates ("OFF") when the front passenger seat is not occupied. The vehicle is brought to the workshop for repair due to an accident or a collision. ZERO POINT CALIBRATION Zero point calibration procedures Check that all of the following conditions are met: The vehicle is parked on a level surface. No objects are placed on the front passenger seat. The front passenger seat belt buckle switch is off. Adjust the seat position according to the table below. Adjustment Item Position Slide Direction Rear most position Reclining Angle Upright position Front vertical Height Upper most position Lifter Height Lower most position Connect the Techstream to the DLC3. Turn the engine switch on (IG). Perform zero point calibration by following the prompts on the Techstream screen. HINT: Refer to the Techstream operator's manual for further details. If the zero point calibration is performed when the calibration conditions are not satisfied, DTC B1797 is output. If the zero point calibration has failed, DTC B1797 is output. If After Exchange is selected before the previous ECU data are stored in the Techstream, the display screen returns to System Select: Body Electrical / Occupant Detection. OK "Zero Point Calibration is complete" is displayed. Item Procedure DTC Check for DTCs and perform troubleshooting Write error Replace No. 1 seat cushion (occupant classification ECU and occupant detection sensor) Temperature Check value of Thermistor temperature output in Data List Pressure Check value of Filtered pressure sensor output in Data List Crash counter - SENSITIVITY CHECK Sensitivity check procedures Turn the engine switch off. Place a weight of 20 kg (44.0 lb) on the front passenger seat. NOTE: Do not allow the weight to come into contact with the seatback when placing it on the seat cushion. Place the weight in the area shown in the illustration. Turn the engine switch on (IG), and wait for at least 6 seconds. Check that the passenger airbag ON/OFF indicator indicates ("OFF"). OK Passenger airbag ON/OFF indicator indicates ("OFF"). Add a weight of 30 kg (66.1 lb) to the front passenger seat (total 50 kg (110.2 lb)). NOTE: Do not allow the weight to come into contact with the seatback when placing it on the seat cushion. Check that the passenger airbag ON/OFF indicator indicates ("ON"). OK Passenger airbag ON/OFF indicator indicates ("ON").
22. INITIALIZATION RELATED TO AIR CONDITIONING SYSTEM INITIALIZATION SERVO MOTOR Turn the engine switch off. Connect the Techstream to the DLC3. Turn the engine switch on (IG). Press the blower OFF switch. Turn the Techstream on. Enter the following menus: Body Electrical / Air Conditioner / Utility / Servomotor Initialization. According to the Techstream display, perform servomotor initialization. HINT: During initialization, the AUTO indicator light comes on, and then goes off when initialization has finished. According to the Techstream display, select the "Exit" switch to finish initialization.
23. INITIALIZATION RELATED TO POWER WINDOW INITIALIZE POWER WINDOW CONTROL SYSTEM (POWER WINDOW REGULATOR MOTOR (ALL DOORS)) WARNING: When the power window regulator motor is reinstalled or replaced, the power window control system must be initialized. Functions such as the auto up/down, jam protection and key-off do not operate if the initialization is not performed. HINT: When the battery is replaced, it is not necessary to initialize the power window regulator motor. NOTE: When the power window regulator motor is replaced, DTC B2313 is output. Clear the DTC after the initialization. When performing initialization, do not perform any other procedures. After a door glass or a door glass run has been replaced, the jam protection function may operate unexpectedly when the auto up function is used, due to detection of a value different from the operation learned value of the door glass movement speed. In such cases, the auto up function can be resumed by repeating the following operation at least 5 times: Open the power window by fully pushing down the power window switch. Close the power window by fully pulling up the power window switch and holding it at the auto up position. If the initialization is not completed properly, the LIN communication system may have a malfunction. Initialization procedures when replacing the power window regulator motor with a new one: Connect the battery and turn the engine switch on (IG) (at this time, the LED on the power window switch blinks to indicate that it is ready for initialization). Fully open the window by fully pushing the power window switch, and hold the switch for 1 second or more after the window is fully opened. Fully close the power window by fully pulling the power window switch, and hold the switch for 1 second or more after the window is fully closed to reset the glass position. The LED on the power window switch stops blinking and illuminates to indicate that the initialization is complete. Initialization procedures when removing/installing the power window regulator motor: Connect the battery and turn the engine switch on (IG). Fully close the power window by fully pulling the power window switch, and hold the switch for 6 seconds or more after the window is fully closed (if the power window does not move or stops halfway even when the switch is fully pulled, release the switch and fully pull it again). Fully open the window by pushing down the power window switch, and hold the switch for 1 second or more after the window is fully opened. Release the power window switch. Then fully push and hold the switch for 4 seconds or more. Fully close the power window by fully pulling the power window switch, and hold the switch for 1 second or more after the window is fully closed to reset the glass position and complete the initialization. Initialization procedures when the power window does not fully open: Connect the battery and turn the engine switch on (IG). Fully close the power window by fully pulling the power window switch, and hold the switch for 6 seconds or more after the window is fully closed (if the power window does not move or stops halfway even when the switch is fully pulled, release the switch and fully pull it again). Fully open the window by pushing down the power window switch, and hold the switch for 1 second or more after the window is fully opened. Release the power window switch. Then fully push and hold the switch for 4 seconds or more. Fully close the power window by fully pulling the power window switch, and hold the switch for 1 second or more after the window is fully closed to reset the glass position and complete the initialization.
24. INITIALIZATION RELATED TO SLIDING ROOF INITIALIZE SLIDING ROOF DRIVE GEAR NOTE: When the sliding roof glass is replaced or removed and installed, or the drive gear assembly is replaced, the sliding roof drive gear requires initialization (pulse sensor initial position setting), as the glass position cannot be determined. If initialization is not performed, the auto slide open and close/tilt up and down function may not operate, or the sliding roof may move in reverse or become misaligned. During initialization, do not apply a physical shock, such as opening/closing a door or driving the vehicle at 5 km/h (3.10 mph) or more, to the vehicle and do not perform the following electrical operations: Cranking the engine Turning the engine switch from on (IG) to off Operating the power window switches Operating the window defogger switch Operating the blower switch Locking/Unlocking the door Operating the headlight dimmer switch HINT: When the cable is disconnected and reconnected to the negative (-) battery terminal or the drive gear connector is disconnected and reconnected, the sliding roof drive gear (pulse sensor initial position setting) initialization is not necessary. Perform initialization according to the table below. Condition of Sliding Roof Proceed to Auto slide open and close/tilt up and down function does not operate Procedure A Sliding roof moves in reverse direction during tilt down operation Procedure B Sliding roof moves in reverse direction during slide close operation Procedure C Procedure A Turn the engine switch on (IG). Open the sliding roof to the fully tilt up position. Press and hold the UP switch to perform the following operations: tilt up --> approximately 10 second pause --> tilt down --> slide open --> slide close. NOTE: Make sure not to release the switch during the initialization. If the switch is released, perform the initialization again. Continue to hold the switch for 1 second or more after the sliding roof stops in the fully closed position, and then release it. The initialization is completed. Procedure B Turn the engine switch on (IG). Press the UP switch until the sliding roof stops. HINT: If the glass becomes misaligned or does not fully tilt up, perform the following operations: Operate the CLOSE switch until the sliding roof stops moving. Operate the UP switch until the sliding roof stops moving, then proceed to the next step. Release the switch. Press and hold the UP switch to perform the following operations: tilt up --> approximately 10 second pause --> tilt down --> slide open --> slide close. NOTE: Make sure not to release the switch during the initialization. If the switch is released, perform the initialization again. Continue to hold the switch for 1 second or more after the sliding roof stops in the fully closed position, and then release it. The initialization is completed. Procedure C Turn the engine switch on (IG). Press and hold the CLOSE switch to perform the following operations: slide close --> move in reverse direction --> 10 second pause --> slide close --> tilt up --> tilt down --> slide open --> slide close. NOTE: Make sure not to release the switch during the initialization. If the switch is released, perform the initialization again. Continue to hold the switch for 1 second or more after the sliding roof stops in the fully closed position, and then release it. Check if the auto function is operative.
25. INITIALIZATION RELATED TO POWER BACK DOOR RESET BACK DOOR CLOSE POSITION NOTE: Perform initialization of the power back door system (power back door ECU initialization) if one of the following is performed: 1) The cable is disconnected from the negative (-) battery terminal; 2) a wire harness, the power back door unit or back door lock is replaced or removed/installed; or 3) the ECU-B2 fuse is replaced or removed/installed. If initialization is not performed, the power back door system will not operate. When the back door is open and the cable is disconnected and reconnected to the negative (-) battery terminal, fully close the back door by hand. HINT: Initialization is not necessary if the cable is disconnected and reconnected to the negative (-) battery terminal while the back door is closed. However, because the power back door ECU recognizes that the back door is locked, the power back door system will not operate if the back door is not unlocked. CHECK POWER BACK DOOR FUNCTION HINT: Proceed to Operation Check. If the power back door system does not operate and/or the back door does not open, disconnect the cable from the negative (-) battery terminal. Then wait 10 seconds, reconnect the cable and perform initialization of the power back door system again.
