Scheme 1
Scheme 1: REPLACEMENT [01/2012 - ]
Scheme 2
Scheme 3
- REMOVE ENGINE ROOM SIDE COVER LH. Refer to «REMOVAL [01/2012 - ] - Step 1»
- REMOVE ENGINE ROOM SIDE COVER RH. Refer to «REMOVAL [01/2012 - ] - Step 2»
- REMOVE UPPER RADIATOR SUPPORT SEAL. Refer to «REMOVAL [01/2012 - ] - Step 3»
- REMOVE FRONT FENDER SPLASH SHIELD SUB-ASSEMBLY LH. Refer to «REMOVAL [01/2012 - ] - Step 3»
- REMOVE FRONT FENDER SPLASH SHIELD SUB-ASSEMBLY RH. Refer to «REMOVAL [01/2012 - ] - Step 4»
- REMOVE NO. 1 ENGINE UNDER COVER SUB-ASSEMBLY . Refer to «REMOVAL [01/2012 - ] - Step 6»(/lexus/lx/j200-2012-2015/remont/exhaust/#intake-system-exhaust-system-service-information)
- DRAIN ENGINE COOLANT WARNING: Do not remove the radiator cap while the engine and radiator are still hot. Pressurized, hot engine coolant and steam may be released and cause serious burns. Loosen the radiator drain cock plug. HINT: Collect the coolant in a container and dispose of it according to the regulations in your area. Remove the radiator cap. Then drain the coolant from the radiator. Loosen the 2 cylinder block drain cock plugs. Then drain the coolant from the engine. Tighten the 2 cylinder block drain cock plugs. Torque: 13 N*m (130 kgf*cm, 10 ft.*lbf) Tighten the radiator drain cock plug by hand.
- ADD ENGINE COOLANT Add engine coolant. Standard Capacity 16.7 liters (17.6 US qts, 14.7 Imp. qts) NOTE: Do not substitute plain water for engine coolant. HINT: TOYOTA vehicles are filled with TOYOTA SLLC at the factory. In order to avoid damage to the engine cooling system and other technical problems, only use TOYOTA SLLC or similar high quality ethylene glycol based non-silicate, non-amine, non-nitrite, non-borate coolant with long-life hybrid organic acid technology (coolant with long-life hybrid organic acid technology consists of a combination of low phosphates and organic acids). Slowly pour coolant into the radiator reservoir until it reaches the F line. Install the reservoir cap. Press the No. 1 and No. 2 radiator hoses several times by hand, and then check the coolant level. If the coolant level is low, add coolant. Install the radiator cap. Start the engine and warm it up until the thermostat opens. NOTE: Switch off the A/C. Maintain the engine speed at 2000 to 2500 rpm. NOTE: Make sure that the radiator reservoir still has some coolant in it. Pay attention to the needle of the water temperature meter. Make sure that the needle does not show an abnormally high temperature. If there is not enough coolant, the engine may burn out or overheat. Immediately after starting the engine, if the radiator reservoir does not have any coolant, perform the following: 1) stop the engine, 2) wait until the coolant has cooled down, and 3) add coolant until the coolant is filled to the F line. Run the engine at 2000 rpm until the coolant level has stabilized. Press the No. 1 and No. 2 radiator hoses several times by hand to bleed air. WARNING: Wear protective gloves. Be careful as the radiator hoses are hot. Keep your hands away from the fan. Stop the engine, and wait until the engine coolant cools down to ambient temperature. WARNING: Do not remove the radiator cap while the engine and radiator are still hot. Pressurized, hot engine coolant and steam may be released and cause serious burns. Check that the coolant level is between the F and L lines. If the coolant level is below the L line, repeat all of the procedures above. If the coolant level is above the F line, drain coolant so that the coolant level is between the F and L lines.
- INSPECT FOR COOLANT LEAK . Refer to «ON-VEHICLE INSPECTION [01/2012 - ] - Step 1»(/lexus/lx/j200-2012-2015/remont/cooling-system-mechanical/#engine-cooling-system-inspection)
- INSTALL NO. 1 ENGINE UNDER COVER SUB-ASSEMBLY . Refer to «INSTALLATION [01/2012 - ] - Step 19»(/lexus/lx/j200-2012-2015/remont/exhaust/#intake-system-exhaust-system-service-information)
- INSTALL FRONT FENDER SPLASH SHIELD SUB-ASSEMBLY LH. Refer to «INSTALLATION [01/2012 - ] - Step 16»
- INSTALL FRONT FENDER SPLASH SHIELD SUB-ASSEMBLY RH. Refer to «INSTALLATION [01/2012 - ] - Step 17»
- INSPECT ENGINE COOLANT LEVEL . Refer to «ON-VEHICLE INSPECTION [01/2012 - ] - Step 2»(/lexus/lx/j200-2012-2015/remont/cooling-system-mechanical/#engine-cooling-system-inspection)
- INSTALL UPPER RADIATOR SUPPORT SEAL. Refer to «INSTALLATION [01/2012 - ] - Step 2»
- INSTALL ENGINE ROOM SIDE COVER RH. Refer to «INSTALLATION [01/2012 - ] - Step 4»
- INSTALL ENGINE ROOM SIDE COVER LH. Refer to «INSTALLATION [01/2012 - ] - Step 3»
Scheme 4
Scheme 5
Scheme 6
Scheme 7
Scheme 7: ON-VEHICLE INSPECTION [01/2012 - ]
Scheme 8
- INSPECT WATER PUMP ASSEMBLY Turn the pulley and check that the water pump bearing moves smoothly and quietly. If necessary, replace the water pump assembly. Visually check the air hole and drain hole for coolant leakage. If leakage is found, replace the water pump assembly.
Scheme 9
Scheme 9: REMOVAL [01/2012 - ]
Scheme 10
Scheme 11
Scheme 12
Scheme 13
Scheme 14
- REMOVE V-BANK COVER SUB-ASSEMBLY . Refer to «REMOVAL [01/2012 - ] - Step 4»(/lexus/lx/j200-2012-2015/remont/mechanical/#engine-mechanical-service-information)
- REMOVE ENGINE ROOM SIDE COVER LH. Refer to «REMOVAL [01/2012 - ] - Step 1»
- REMOVE ENGINE ROOM SIDE COVER RH. Refer to «REMOVAL [01/2012 - ] - Step 2»
- REMOVE UPPER RADIATOR SUPPORT SEAL. Refer to «REMOVAL [01/2012 - ] - Step 3»
- REMOVE FRONT FENDER SPLASH SHIELD SUB-ASSEMBLY LH. Refer to «REMOVAL [01/2012 - ] - Step 3»
- REMOVE FRONT FENDER SPLASH SHIELD SUB-ASSEMBLY RH. Refer to «REMOVAL [01/2012 - ] - Step 4»
- REMOVE NO. 1 ENGINE UNDER COVER SUB-ASSEMBLY . Refer to «REMOVAL [01/2012 - ] - Step 6»(/lexus/lx/j200-2012-2015/remont/exhaust/#intake-system-exhaust-system-service-information)
- DRAIN ENGINE COOLANT See step 7
- REMOVE AIR CLEANER HOSE ASSEMBLY . Refer to «REMOVAL [01/2012 - ] - Step 11»(/lexus/lx/j200-2012-2015/remont/exhaust/#intake-system-exhaust-system-service-information)
- REMOVE AIR CLEANER ASSEMBLY . Refer to «REMOVAL [01/2012 - ] - Step 29»(/lexus/lx/j200-2012-2015/remont/mechanical/#engine-mechanical-service-information)
- REMOVE NO. 1 RADIATOR HOSE
- REMOVE NO. 2 RADIATOR HOSE
- REMOVE FAN SHROUD See step 15
- REMOVE NO. 1 WATER BY-PASS HOSE. Refer to «REMOVAL [01/2012 - ] - Step 38»
- DISCONNECT NO. 2 WATER BY-PASS PIPE SUB-ASSEMBLY (w/ Oil Cooler) Disconnect the No. 6 water by-pass hose. Remove the 3 bolts. Disconnect the water by-pass pipe with water hose.
- REMOVE WATER INLET HOUSING Disconnect the No. 2 and No. 3 air hoses. Disconnect the air pump connector. Disconnect the air pump connector clamp holder. Using a clip remover, detach the wire harness clamp. Disconnect the No. 5 water by-pass hose. Remove the air tube bracket bolt. Disconnect the No. 3 water by-pass hose and remove the 3 bolts and water inlet housing. Remove the gasket from the water pump.
- REMOVE WATER PUMP PULLEY Using SST, hold the water pump pulley. SST: 09960-10010 09962-01000 09963-01000 Remove the 4 bolts and water pump pulley.
- REMOVE WATER PUMP ASSEMBLY Remove the 8 bolts, water pump and gasket.
Scheme 15
Scheme 15: INSTALLATION [01/2012 - ]
Scheme 16
Scheme 17
Scheme 18
Scheme 19
- INSTALL WATER PUMP ASSEMBLY Install a new gasket and the water pump with the 8 bolts shown in the illustration. for bolt A Torque: 47 N*m (479 kgf*cm, 35 ft.*lbf) for bolt B Torque: 23 N*m (235 kgf*cm, 17 ft.*lbf) for bolt C Torque: 20 N*m (204 kgf*cm, 15 ft.*lbf) Standard Bolt Item Length Thread Diameter Bolt A 80 mm (3.15 in.) 10 mm (0.394 in.) Bolt B 70 mm (2.76 in.) 8 mm (0.315 in.) Bolt C 25 mm (0.984 in.) 8 mm (0.315 in.)
- INSTALL WATER PUMP PULLEY Temporarily install the pulley with the 4 bolts. Using SST, hold the pulley and tighten the 4 bolts. SST: 09960-10010 09962-01000 09963-01000 Torque: 21 N*m (214 kgf*cm, 15 ft.*lbf)
- INSTALL WATER INLET HOUSING Install a new gasket to the water pump. Install the water inlet housing with the 3 bolts and connect the No. 3 water by-pass hose. Torque: 21 N*m (214 kgf*cm, 15 ft.*lbf) HINT: Install the hose so that the direction of the hose clamp is as indicated in the illustration. Install the air tube bracket bolt. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf) Connect the No. 5 water by-pass hose. HINT: Install the hose so that the direction of the hose clamp is as indicated in the illustration. Connect the air pump connector clamp holder. Attach the wire harness clamp. Connect the air pump connector. Connect the No. 2 and No. 3 air hoses.
- CONNECT NO. 2 WATER BY-PASS PIPE SUB-ASSEMBLY (w/ Oil Cooler) Connect the water by-pass pipe with water hose. HINT: Install the hose so that the direction of the hose clamp is as indicated in the illustration. Install the 3 bolts. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf) Connect the No. 6 water by-pass hose.
- INSTALL NO. 1 WATER BY-PASS HOSE. Refer to «INSTALLATION [01/2012 - ] - Step 18»
- INSTALL FAN SHROUD See step 2
- INSTALL NO. 1 RADIATOR HOSE
- INSTALL NO. 2 RADIATOR HOSE
- INSTALL AIR CLEANER ASSEMBLY . Refer to «INSTALLATION [01/2012 - ] - Step 37»(/lexus/lx/j200-2012-2015/remont/mechanical/#engine-mechanical-service-information)
- INSTALL AIR CLEANER HOSE ASSEMBLY . Refer to «INSTALLATION [01/2012 - ] - Step 10»(/lexus/lx/j200-2012-2015/remont/exhaust/#intake-system-exhaust-system-service-information)
- ADD ENGINE COOLANT See step 8
- INSPECT FOR COOLANT LEAK . Refer to «ON-VEHICLE INSPECTION [01/2012 - ] - Step 1»(/lexus/lx/j200-2012-2015/remont/cooling-system-mechanical/#engine-cooling-system-inspection)
- INSTALL UPPER RADIATOR SUPPORT SEAL. Refer to «INSTALLATION [01/2012 - ] - Step 2»
- INSTALL ENGINE ROOM SIDE COVER RH. Refer to «INSTALLATION [01/2012 - ] - Step 4»
- INSTALL ENGINE ROOM SIDE COVER LH. Refer to «INSTALLATION [01/2012 - ] - Step 3»
- INSTALL V-BANK COVER SUB-ASSEMBLY . Refer to «INSTALLATION [01/2012 - ] - Step 72»(/lexus/lx/j200-2012-2015/remont/mechanical/#engine-mechanical-service-information)
- INSTALL NO. 1 ENGINE UNDER COVER SUB-ASSEMBLY . Refer to «INSTALLATION [01/2012 - ] - Step 19»(/lexus/lx/j200-2012-2015/remont/exhaust/#intake-system-exhaust-system-service-information)
- INSTALL FRONT FENDER SPLASH SHIELD SUB-ASSEMBLY LH. Refer to «INSTALLATION [01/2012 - ] - Step 16»
- INSTALL FRONT FENDER SPLASH SHIELD SUB-ASSEMBLY RH. Refer to «INSTALLATION [01/2012 - ] - Step 17»
