Standard Bolt (General Information): Other Lexus LX J200

HOW TO DETERMINE BOLT STRENGTH

BOLT TYPE Hexagon Head Bolt Stud Bolt Weld Bolt Class Normal Recess Bolt Deep Recess Bolt No Mark No Mark No Mark 4T - - 5T w/ Washer w/ Washer - 6T - - 7T - 8T - - 9T - - 10T - - 11T

Scheme 1

Scheme 2

Scheme 3

Scheme 4

Scheme 5

HOW TO DETERMINE NUT STRENGTH

NUT TYPE Present Standard Hexagon Nut Old Standard Hexagon Nut Class Cold Forging Nut Cutting Processed Nut No Mark - - 4N No Mark (w/ Washer) No Mark (w/ Washer) No Mark 5N (4T) - - 6N - 7N (5T) - - 8N No Mark 10N (7T) - - 11N - - 12N

Scheme 6

Scheme 7

HINT

1. *: Nut with 1 or more marks on one side surface of the nut.
2. Use a nut with the same nut strength classification number (or more) as the bolt strength classification number when tightening parts with a bolt and nut.

1. Bolt = 4T
2. Nut = 4N or more
