Monitor (Service Information): Overview Lexus LX J200

Scheme 220

Scheme 221

Scheme 222

1. REMOVE ENGINE ROOM SIDE COVER LH . Refer to «REMOVAL - Step 1»(ref-385214-S26241195972011021400000)
2. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL WARNING: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to disable the SRS system. NOTE: w/ Navigation System: After the engine switch is turned off, the HDD navigation system requires approximately 6 minutes to record various types of memory and settings. As a result, after turning the engine switch off, wait 6 minutes or more before disconnecting the cable from the negative (-) battery terminal. When disconnecting the cable, some systems need to be initialized after the cable is reconnected. Refer to «INITIALIZATION»(ref-385196-S36681500272011021400000) .
3. REMOVE INSTRUMENT SIDE PANEL LH . Refer to «REMOVAL - Step 31»(ref-385215-S25883065762011021400000)
4. REMOVE NO. 1 SWITCH HOLE BASE . Refer to «REMOVAL - Step 32»(ref-385215-S25883065762011021400000)
5. REMOVE LOWER INSTRUMENT PANEL PAD SUB-ASSEMBLY LH . Refer to «REMOVAL - Step 17»(ref-385215-S25883065762011021400000)
6. REMOVE NO. 1 INSTRUMENT PANEL UNDER COVER SUB-ASSEMBLY . Refer to «REMOVAL - Step 38»(ref-385215-S25883065762011021400000)
7. REMOVE LOWER NO. 1 INSTRUMENT PANEL FINISH PANEL . Refer to «REMOVAL - Step 40»(ref-385215-S25883065762011021400000)
8. REMOVE DRIVER SIDE KNEE AIRBAG ASSEMBLY . Refer to «REMOVAL - Step 9»(ref-385228-S28731646412011021400000)
9. REMOVE NO. 1 CLEARANCE WARNING BUZZER Disconnect the connector. Using a clip remover, detach the clip and remove the No. 1 clearance warning buzzer.
