Fuel (Service Information): Overview Lexus LX J200

Scheme 1

Scheme 2

Scheme 3

Scheme 4

Scheme 5

Scheme 6

Scheme 7

Scheme 8

Scheme 9

Scheme 10

Scheme 11

Scheme 12

Scheme 13

Scheme 14

Scheme 15

Scheme 16

1. REMOVE ENGINE ROOM SIDE COVER LH. Refer to «REMOVAL - Step 1»
2. REMOVE ENGINE ROOM SIDE COVER RH. Refer to «REMOVAL - Step 2»
3. REMOVE UPPER RADIATOR SUPPORT SEAL. Refer to «REMOVAL - Step 3»
4. REMOVE V-BANK COVER SUB-ASSEMBLY . Refer to «REMOVAL - Step 4»(/lexus/lx/j200-2007-2012/remont/mechanical/#engine-mechanical-service-information)
5. DISCHARGE FUEL SYSTEM PRESSURE Discharge the fuel system pressure. Refer to «PRECAUTION»(/lexus/lx/j200-2007-2012/remont/fuel-system/#fuel-inspection__precaution) .
6. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL NOTE: w/ Navigation System: After the engine switch is turned off, the HDD navigation system requires approximately 6 minutes to record various types of memory and settings. As a result, after turning the engine switch off, wait 6 minutes or more before disconnecting the cable from the negative (-) battery terminal. When disconnecting the cable, some systems need to be initialized after the cable is reconnected. Refer to «INITIALIZATION».
7. REMOVE AIR CLEANER HOSE ASSEMBLY . Refer to «REMOVAL - Step 11»(/lexus/lx/j200-2007-2012/remont/exhaust/#exhaust-service-information)
8. REMOVE NO. 1 ENGINE COVER SUB-ASSEMBLY Remove the No. 1 engine cover sub-assembly.
9. REMOVE NO. 3 ENGINE COVER Remove the No. 3 engine cover.
10. DISCONNECT NO. 2 FUEL TUBE Disconnect the No. 2 fuel tube from the fuel pressure regulator. Refer to «PRECAUTION»(/lexus/lx/j200-2007-2012/remont/fuel-system/#fuel-inspection__precaution) .
11. DISCONNECT NO. 1 FUEL TUBE RH Side: Disconnect the No. 1 fuel tube from the fuel delivery pipe RH. Refer to «PRECAUTION»(/lexus/lx/j200-2007-2012/remont/fuel-system/#fuel-inspection__precaution) . LH Side: Disconnect the No. 1 fuel tube from the fuel delivery pipe LH. Refer to «PRECAUTION»(/lexus/lx/j200-2007-2012/remont/fuel-system/#fuel-inspection__precaution) .
12. DISCONNECT NO. 1 FUEL HOSE Disconnect the fuel hose from the fuel delivery pipe LH. Refer to «PRECAUTION»(/lexus/lx/j200-2007-2012/remont/fuel-system/#fuel-inspection__precaution) .
13. REMOVE FUEL DELIVERY PIPE SUB-ASSEMBLY RH Disconnect the ventilation hose and No. 6 wire harness connector. Remove the 2 bolts and fuel delivery pipe RH. NOTE: When removing the delivery pipe, hold the pipe by both ends and pull it straight upward. Remove the 2 delivery pipe spacers and 4 insulators from the cylinder head RH.
14. REMOVE FUEL DELIVERY PIPE SUB-ASSEMBLY LH Disconnect the No. 7 wire harness connector. Remove the 2 bolts and fuel delivery pipe LH. NOTE: When removing the delivery pipe, hold the pipe by both ends and pull it straight upward. Remove the 2 delivery pipe spacers and 4 insulators from the cylinder head LH.
15. REMOVE FUEL INJECTOR ASSEMBLY Remove the fuel injector from the fuel delivery pipe, and then disconnect the injector connector. NOTE: For reinstallation, attach a tag or label to the injector shaft. Remove the O-ring from the fuel injector. Detach the 3 clamps and then remove the No. 6 wire harness from the delivery pipe RH. Detach the 3 clamps and then remove the No. 7 wire harness from the delivery pipe LH.

Scheme 17

Scheme 18

Scheme 19

Scheme 20

Scheme 21

Scheme 22

Scheme 23

1. INSPECT FUEL INJECTOR ASSEMBLY Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 1 - 2 20°C (68°F) 11.6 to 12.4 ohms If the result is not as specified, replace the injector assembly. Inspect the injection volume. WARNING: This test involves high-pressure fuel and electricity. Take all precautions regarding safe handling of both the fuel and the electricity. Perform this test in a safe area, and avoid any sparks or flames. Do not smoke. Remove the fuel pipe clamp. Disconnect the fuel tube. Connect SST to the fuel pipe (the vehicle side). Install the O-ring to the fuel injector. Install SST and the tube to the fuel injector. SST: 09268-31012 09268-41300 09268-41500 09268-41600 90467-13001 95336-08070 Put the injector into a graduated cylinder. WARNING: Install a strong rubber tube onto the injector to prevent gasoline from splashing. Operate the fuel pump (turn the engine switch on (IG)). Connect SST (wire) to the injector and the battery for 15 seconds, and measure the injection volume with the graduated cylinder. Test each injector 2 or 3 times. SST: 09842-30090 Standard injection volume 83 to 99 cm 3 (5.0 to 6.0 cu in.) per 15 seconds Difference between each injector 16 cm 3 (1.0 cu in.) or less If the injection volume is not as specified, replace the injector assembly. Check for fuel drop. In the condition above, disconnect the tester probes of SST (wire) from the battery and check for fuel drop from the injector. Standard fuel drop 1 drop or less in 12 minutes If the fuel drop is not as specified, replace the injector assembly.

Scheme 24

Scheme 25

Scheme 26

Scheme 27

1. INSTALL FUEL INJECTOR ASSEMBLY Attach the 3 clamps to install the No. 6 wire harness to the delivery pipe RH. Attach the 3 clamps to install the No. 7 wire harness to the delivery pipe LH. Apply gasoline or spindle oil to a new O-ring and install it to the injector. NOTE: Make sure that there is no damage or foreign material in the groove of the injector when installing the O-ring. Connect the injector connector. Install the injector to the delivery pipe as shown in the illustration. NOTE: Make sure that there are no scratches or foreign matter in or around the insertion hole of the delivery pipe. When inserting the injector, be careful not to damage the O-ring. Attach the part of the injector labeled B between the parts of the delivery pipe labeled A. Check that each injector is installed to the delivery pipe facing the direction shown in the illustration.
2. INSTALL FUEL DELIVERY PIPE SUB-ASSEMBLY LH Install the 2 delivery pipe spacers and 4 insulators to the cylinder head LH. Install the delivery pipe (with injectors) to the cylinder head LH. Install the 2 bolts. Torque: 21 N*m ( 214 kgf*cm, 15 ft.*lbf) NOTE: Make sure that the part of the injector labeled B is between the parts of the delivery pipe labeled A. Connect the No. 7 wire harness connector.
3. INSTALL FUEL DELIVERY PIPE SUB-ASSEMBLY RH Install the 2 delivery pipe spacers and 4 insulators to the cylinder head RH. Install the delivery pipe (with injectors) to the cylinder head RH. Install the 2 bolts. Torque: 21 N*m ( 214 kgf*cm, 15 ft.*lbf) NOTE: Make sure that the part of the injector labeled B is between the parts of the delivery pipe labeled A. Connect the No. 6 wire harness connector. Connect the ventilation hose.
4. CONNECT NO. 1 FUEL HOSE Connect the No. 1 fuel hose to the fuel delivery pipe LH. Refer to «PRECAUTION»(/lexus/lx/j200-2007-2012/remont/fuel-system/#fuel-inspection__precaution) .
5. CONNECT NO. 1 FUEL TUBE LH Side: Connect the No. 1 fuel tube to the delivery pipe LH. Refer to «PRECAUTION»(/lexus/lx/j200-2007-2012/remont/fuel-system/#fuel-inspection__precaution) . RH Side: Connect the No. 1 fuel tube to the delivery pipe RH. Refer to «PRECAUTION»(/lexus/lx/j200-2007-2012/remont/fuel-system/#fuel-inspection__precaution) .
6. CONNECT NO. 2 FUEL TUBE Connect the No. 2 fuel tube to the fuel pressure regulator. Refer to «PRECAUTION»(/lexus/lx/j200-2007-2012/remont/fuel-system/#fuel-inspection__precaution) .
7. INSTALL NO. 1 ENGINE COVER SUB-ASSEMBLY Install the No. 1 engine cover sub-assembly.
8. INSTALL NO. 3 ENGINE COVER Install the No. 3 engine cover.
9. INSTALL AIR CLEANER HOSE ASSEMBLY . Refer to «INSTALLATION - Step 10»(/lexus/lx/j200-2007-2012/remont/exhaust/#exhaust-service-information)
10. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL NOTE: When disconnecting the cable, some systems need to be initialized after the cable is reconnected. Refer to «INITIALIZATION».
11. INSPECT FOR FUEL LEAK Connect the Techstream to the DLC3. Turn the engine switch on (IG) and Techstream main switch on. NOTE: Do not start the engine. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the Fuel Pump / Speed. Check that there are no fuel leaks after doing maintenance anywhere on the fuel system.
12. INSTALL V-BANK COVER SUB-ASSEMBLY . Refer to «INSTALLATION - Step 72»(/lexus/lx/j200-2007-2012/remont/mechanical/#engine-mechanical-service-information)
13. INSTALL UPPER RADIATOR SUPPORT SEAL. Refer to «INSTALLATION - Step 2»
14. INSTALL ENGINE ROOM SIDE COVER LH. Refer to «INSTALLATION - Step 3»
15. INSTALL ENGINE ROOM SIDE COVER RH. Refer to «INSTALLATION - Step 4»

Scheme 28

Scheme 29

Scheme 30

Scheme 31

1. REMOVE ENGINE ROOM SIDE COVER LH. Refer to «REMOVAL - Step 1»
2. REMOVE ENGINE ROOM SIDE COVER RH. Refer to «REMOVAL - Step 2»
3. REMOVE UPPER RADIATOR SUPPORT SEAL. Refer to «REMOVAL - Step 3»
4. REMOVE V-BANK COVER SUB-ASSEMBLY . Refer to «REMOVAL - Step 4»(/lexus/lx/j200-2007-2012/remont/mechanical/#engine-mechanical-service-information)
5. DISCHARGE FUEL SYSTEM PRESSURE See step 5
6. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL See step 6
7. REMOVE AIR CLEANER HOSE ASSEMBLY . Refer to «REMOVAL - Step 11»(/lexus/lx/j200-2007-2012/remont/exhaust/#exhaust-service-information)
8. REMOVE FUEL PRESSURE REGULATOR ASSEMBLY Disconnect the No. 2 fuel tube from the pressure regulator. Refer to «PRECAUTION»(/lexus/lx/j200-2007-2012/remont/fuel-system/#fuel-inspection__precaution) . WARNING: Put a cloth or equivalent under the pressure regulator. Disconnect the vacuum sensing hose from the pressure regulator. Remove the 2 bolts, and pull out the pressure regulator. Remove the O-ring from the pressure regulator.

Scheme 32

1. INSTALL FUEL PRESSURE REGULATOR ASSEMBLY Apply a light coat of gasoline or spindle oil to a new O-ring, and install it to the pressure regulator. NOTE: Make sure that there are no scratches or foreign matter in or around the insertion hole of the delivery pipe. When inserting the injector, be careful not to damage the O-ring. While turning the pressure regulator left and right, install it to the delivery pipe. Install the 2 bolts. Torque: 10 N*m ( 107 kgf*cm, 7 ft.*lbf) Connect the vacuum sensing hose to the pressure regulator. Connect the No. 2 fuel tube to the pressure regulator. Refer to «PRECAUTION»(/lexus/lx/j200-2007-2012/remont/fuel-system/#fuel-inspection__precaution) .
2. INSTALL AIR CLEANER HOSE ASSEMBLY . Refer to «INSTALLATION - Step 10»(/lexus/lx/j200-2007-2012/remont/exhaust/#exhaust-service-information)
3. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL See step 10
4. INSPECT FOR FUEL LEAK See step 11
5. INSTALL V-BANK COVER SUB-ASSEMBLY . Refer to «INSTALLATION - Step 72»(/lexus/lx/j200-2007-2012/remont/mechanical/#engine-mechanical-service-information)
6. INSTALL UPPER RADIATOR SUPPORT SEAL. Refer to «INSTALLATION - Step 2»
7. INSTALL ENGINE ROOM SIDE COVER LH. Refer to «INSTALLATION - Step 3»
8. INSTALL ENGINE ROOM SIDE COVER RH. Refer to «INSTALLATION - Step 4»

Scheme 33

Scheme 34

Scheme 35

Scheme 36

1. REMOVE FUEL SUCTION WITH PUMP AND GAUGE TUBE ASSEMBLY Remove the fuel suction with pump and gauge tube assembly. Refer to «REMOVAL».
2. REMOVE FUEL SENDER GAUGE ASSEMBLY See step 2
3. REMOVE NO. 1 FUEL SUB-TANK See step 2
4. REMOVE FUEL PUMP See step 3
5. REMOVE FUEL MAIN VALVE ASSEMBLY Remove the fuel main valve from the fuel filter case. Remove the 2 O-rings from the fuel main valve.
6. REMOVE NO. 1 FUEL SUCTION SUPPORT Detach the 2 claws from the claw holes.
7. INSTALL NO. 1 FUEL SUCTION SUPPORT Attach the 2 claws to the claw holes.
8. INSTALL FUEL MAIN VALVE ASSEMBLY Apply a light coat of gasoline to 2 new O-rings, and install them onto the fuel main valve. Install the fuel main valve to the fuel filter case. NOTE: Make sure the O-rings are not cut or pinched during the installation.
9. INSTALL FUEL PUMP See step 3
10. INSTALL NO. 1 FUEL SUB-TANK See step 4
11. INSTALL FUEL SENDER GAUGE ASSEMBLY See step 1
12. INSTALL FUEL SUCTION WITH PUMP AND GAUGE TUBE ASSEMBLY Install the fuel suction with pump and gauge tube assembly. Refer to «INSTALLATION».

Scheme 37

Scheme 38

1. REMOVE FUEL TANK SUB-ASSEMBLY Remove the fuel tank sub-assembly. Refer to «REMOVAL».
2. REMOVE FUEL SUCTION WITH PUMP AND GAUGE TUBE ASSEMBLY Using SST, loosen the retainer. SST: 09808-14020 HINT: Fit the tips of SST onto the ribs of the retainer. NOTE: When the retainer is loosened, be careful as the pump and gauge tube will spring upward from the force of the spring. Remove foreign matter around the fuel suction with pump and gauge before this operation. Remove the retainer. Remove the fuel suction with pump and gauge tube assembly from the fuel tank. NOTE: Be careful not to bend the arm of the fuel sender gauge. Remove the gasket from the fuel tank.
