Power Outlets (Interior) (Service Information): Overview Lexus LX J200

Body Electrical 4 illustrations ~265 words

Scheme 38

Scheme 38: ILLUSTRATION

Scheme 39

Scheme 39: ON-VEHICLE INSPECTION

Scheme 40

Scheme 40
  1. INSPECT VOLTAGE INVERTER ASSEMBLY HINT: Remove interior parts so that the voltage inverter can be seen. Disconnect the voltage inverter connector. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Switch Condition Specified Condition K16-1 (IG) - K16-4 (GND) Engine switch on (IG) 10 to 16 V GND (K16-4) - Body ground K16-4 (GND) - Body ground Always Below 1 V If the result is not as specified, repair or replace the harness or connector. Reconnect the voltage inverter connector. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Switch Condition Specified Condition K16-3 (AC1) - K16-7 (AC2) Engine switch on (IG) Main switch on AC 115 V If the result is not as specified, replace the voltage inverter.

Scheme 41

Scheme 41: REMOVAL
  1. REMOVE REAR NO. 2 SEAT ASSEMBLY LH Remove the rear No. 2 seat assembly LH. Refer to «REMOVAL»(ref-385219-S15497833712011021400000) .
  2. REMOVE REAR STEP COVER . Refer to «REMOVAL - Step 8»(ref-385215-S31941166542011021400000)
  3. REMOVE REAR DOOR SCUFF PLATE LH . Refer to «REMOVAL - Step 9»(ref-385215-S31941166542011021400000)
  4. REMOVE REAR FLOOR MAT REAR SUPPORT PLATE . Refer to «REMOVAL - Step 11»(ref-385215-S31941166542011021400000)
  5. REMOVE NO. 1 LUGGAGE COMPARTMENT TRIM HOOK . Refer to «REMOVAL - Step 22»(ref-385215-S31941166542011021400000)
  6. REMOVE REAR SEAT COVER CAP (for Rear No. 2 Seat with Manual Folding-up Function) . Refer to «REMOVAL - Step 23»(ref-385215-S31941166542011021400000)
  7. REMOVE FRONT QUARTER TRIM PANEL ASSEMBLY LH . Refer to «REMOVAL - Step 24»(ref-385215-S31941166542011021400000)
  8. REMOVE VOLTAGE INVERTER ASSEMBLY Disconnect the connector. Remove the 2 bolts and voltage inverter.
