Upper Back Door Lexus LX J100 facelift

Exterior/interior Trim 16 illustrations ~480 words

Scheme 47

Scheme 47: COMPONENTS

Scheme 48

Scheme 48: DISASSEMBLY

Scheme 49

Scheme 49

Scheme 50

Scheme 50

Scheme 51

Scheme 51

Scheme 52

Scheme 52

Scheme 53

Scheme 53

Scheme 54

Scheme 54

Scheme 55

Scheme 55

Scheme 56

Scheme 56

Scheme 57

Scheme 57

Scheme 58

Scheme 58
  1. REMOVE ASSIST GRIP Using a screwdriver, remove the 2 assist grip plugs. HINT: Tape up the screwdriver tip before use. Remove the 2 screws and the assist grip.
  2. REMOVE INSIDE HANDLE BEZEL
  3. REMOVE CENTER BACK DOOR GARNISH Using a screwdriver, remove the center back door garnish. HINT: Tape up the screwdriver tip before use.
  4. REMOVE BACK DOOR GARNISH Using a screwdriver, remove the back door garnish. HINT: Tape up the screwdriver tip before use.
  5. REMOVE REAR WIPER ARM Open the cover. Remove the nut and the rear wiper arm. Torque: 5.4 N.m (55 kgf.cm, 48 in.lbf) Remove the grommet.
  6. REMOVE REAR WIPER MOTOR AND LINK ASSEMBLY Disconnect the connector. Remove the 2 bolts. Unfasten the 3 bolts and remove the rear wiper motor and link assembly. Torque: 5.0 N.m (51 kgf.cm, 44 in.lbf)
  7. REMOVE BACK DOOR WEATHERSTRIP Remove the back door weatherstrip. NOTE: Do not pull the weatherstrip out by force as it may tear.
  8. REMOVE BACK DOOR INSIDE HANDLE Remove the 2 bolts. Disconnect the back door lock locking rod and the back door lock inside opening link, then remove the back door inside handle.
  9. REMOVE BACK DOOR CONTROL Disconnect the links. Remove the 3 bolts. Torque: 5.0 N.m (51 kgf.cm, 44 in.lbf) Disconnect the connector, then remove the back door control. HINT: At the time of reassembly, please refer to the following item. Apply MP grease to the sliding surface of the back door control.
  10. REMOVE BACK DOOR OUTSIDE HANDLE ASSEMBLY Using a screwdriver, remove the back door outside handle. HINT: Tape up the screwdriver tip before use. Remove the 3 bolts and the back door outside handle assembly. Torque: 5.0 N.m (51 kgf.cm, 44 in.lbf)
  11. REMOVE LICENSE PLATE LIGHTS
  12. REMOVE BACK DOOR LOCK Remove the 4 bolts and the back door lock. Torque: 7.0 N.m (71 ft.lbf, 62 in.lbf)
  13. REMOVE BACK DOOR LINK PROTECTOR

Scheme 59

Scheme 59: ADJUSTMENT

Scheme 60

Scheme 60

Scheme 61

Scheme 61

Scheme 62

Scheme 62
  1. ADJUST DOOR IN LEFT/RIGHT AND VERTICAL DIRECTIONS Loosen the door side hinge bolts to adjust it. Torque: 28 N.m (286 kgf.cm, 21 ft.lbf)
  2. ADJUST DOOR IN FORWARD/REARWARD AND VERTICAL DIRECTIONS Loosen the body side hinge nuts to adjust it. Torque: 31 N.m (316 kgf.cm, 23 ft.lbf)
  3. ADJUST DOOR LOCK STRIKER Check that the door fits, and door linkages are adjusted correctly. Using a Torx wrench, loosen the door lock striker mounting screws. Torx wrench: T40 (Part No. 09042-00020 or locally manufactured tool) Torque: 11.5 N.m (117 kgf.cm, 8 ft.lbf) Using a plastic hammer, tap the door lock striker to adjust it.
  4. ADJUST LOWER STOPPER Loosen the stopper mounting bolt to adjust. Use the same manner described above to the other side it.

REASSEMBLY

Reassembly is in the reverse order of disassembly (See DISASSEMBLY ).
