TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) |
|---|
| Accumulator-To-Booster Pump Motor | 36 (54) |
| Brake Booster Clevis Lock Nut | 19 (25) |
| Brake Booster-To-Pedal Bracket | 11 (15) |
| Brake Line Union Nut | 11 (15) |
| Brake Pedal Assembly Bolts | 14 (20) |
| Flexible Hose-To-Brake Caliper | 22 (30) |
| Front Brake Caliper Mounting Bolts | 90 (123) |
| Front Brake Disc-To-Front Axle Hub | 54 (74) |
| Front Brake Mounting Bolt-To-Steering Knuckle | 90 (123) |
| Hydraulic Brake Booster Assembly | 11 (15) |
| Rear Brake Caliper Installation Bolts | 20 (26) |
| Rear Brake Torque Plate-To-Rear Backing Plate | 76 (103) |
| Master Cylinder Pressure Sensor | 60 (81) |
| Wheel Lug Nuts | 97 (131) |
| INCH Lbs. (N.m) |
| ABS & TRAC & VSC ECU Nuts | 44 (5) |
| Parking Brake Lock Nut | 48 (5.4) |
| Reservoir Set Screw | 16 (2) |
DISC BRAKE SPECIFICATIONS
| Application | In. (mm) |
|---|
| Front Disc |
| Original Disc Thickness | 1.26 (32) |
| Minimum Refinish Thickness | 1.181 (30) |
| Maximum Disc Runout | .0028 (.07) |
| Brake Pad Thickness |
| Standard Thickness | .453 (11.5) |
| Minimum Thickness | .039 (1.0) |
| Rear Disc |
| Original Disc Thickness | .709 (18) |
| Minimum Refinish Thickness | .629 (16) |
| Maximum Disc Runout | .0039 (.1) |
| Brake Pad Thickness |
| Standard Thickness | .472 (12) |
| Minimum Thickness | .039 (1.0) |
| Rear Disc Parking Brake Drum (1) |
| Brake Shoe-To-Lever Clearance | Less Than .0098 (.25) |
| Drum Diameter |
| Original Diameter | 9.06 (230) |
| Maximum Diameter | 9.09 (231) |
| Parking Brake Shoe Lining Thickness (2) |
| Standard Thickness | .157 (4.0) |
| Minimum Thickness | .039 (1.0) |
| (1) This is the drum for the parking brake on the inside of the rear disc. (2) This is brake lining for the parking brake on the inside of the rear disc. |
| (1) | This is the drum for the parking brake on the inside of the rear disc. |
| (2) | This is brake lining for the parking brake on the inside of the rear disc. |
DISC BRAKE SPECIFICATIONS
Scheme 1
Scheme 2
