Ignition: Removal & Installation Lexus LX J100 рестайлинг

INSTALLATION

Installation is in the reverse order of removal. (See REMOVAL )

Scheme 16

Scheme 17

1. REMOVE V-BANK COVER
2. DRAIN ENGINE COOLANT
3. DISCONNECT UPPER RADIATOR HOSE
4. REMOVE LH NO. 3 TIMING BELT COVER (See «REMOVAL»(ref-209781-S38297666172005121100000) )
5. REMOVE CAMSHAFT POSITION SENSOR Remove the bolt, stud bolt and camshaft position sensor.

Scheme 18

1. INSTALL CAMSHAFT POSITION SENSOR Install the camshaft position sensor with the bolt and stud bolt Torque: 7.5 N.m (80 kgf.cm, 66 in.lbf)
2. INSTALL LH NO. 3 TIMING BELT COVER (See «INSTALLATION»(ref-209781-S20467061782005121100000) )
3. CONNECT RADIATOR HOSE
4. INSTALL V-BANK COVER
5. FILL ENGINE COOLANT (See «REPLACEMENT»(ref-209799-S34252525562005121100000) )
6. CHECK ENGINE COOLANT FOR LEAKS
7. CHECK IGNITION TIMING (See «INSPECTION»(ref-209781-S11643013912005121100000) )

Scheme 19

Scheme 20

1. REMOVE NO. 2 ENGINE UNDER COVER
2. REMOVE CRANKSHAFT POSITION SENSOR Disconnect the crankshaft position sensor connector. Remove the bolt and crankshaft position sensor. Torque: 6.5 N.m (65 kgf.cm, 58 in.lbf)

Installation is in the reverse order of removal. (See REMOVAL )
