Fuses & Circuit Breakers: Component Locations Lexus LX J100 рестайлинг

Component Locations

1. Engine compartment fusible link block is located at left side of engine compartment near battery. For identification of protected circuits (Scheme 3) For wiring diagrams of circuits, see POWER DISTRIBUTION in SYSTEM WIRING DIAGRAMS article.
2. Engine compartment junction/relay block is located at left inner fender panel. For identification of fuses and relays (Scheme 4)and (Scheme 5). For identification of protected circuits (Scheme 6)and (Scheme 7). For wiring diagrams of circuits, see POWER DISTRIBUTION in appropriate SYSTEM WIRING DIAGRAMS article.
3. If equipped, daytime running light relay No. 3 is located on right side of engine compartment. (Scheme 1) For wiring diagram of circuit, see HEADLIGHTS in appropriate SYSTEM WIRING DIAGRAMS article.
4. Headlight cleaner control relay is located on left front side of engine compartment behind headlight. (Scheme 1) For wiring diagram of circuit, see WIPER/WASHER in appropriate SYSTEM WIRING DIAGRAMS article.

Scheme 1

Scheme 2

Scheme 3

Scheme 4

Scheme 5

Scheme 6

Scheme 7

1. Active Height Control Suspension (AHC) main relay is located behind instrument panel. (Scheme 8)
2. Auto antenna control relay is located behind glove box. (Scheme 8) For wiring diagram of circuit, see RADIO in appropriate SYSTEM WIRING DIAGRAMS article.
3. Center differential lock control relay is located behind right side of dash. (Scheme 8) For wiring diagram of circuit, see TRANSMISSION in appropriate SYSTEM WIRING DIAGRAMS article.
4. Left kick panel junction block is located behind instrument panel. (Scheme 8) For identification of fuses and relays (Scheme 10)and (Scheme 11). For identification of protected circuits (Scheme 12)- (Scheme 14). For wiring diagram of circuits, see POWER DISTRIBUTION in appropriate SYSTEM WIRING DIAGRAMS article.
5. Rear cooler relay is located in right rear corner of vehicle in cargo area. (Scheme 9) For wiring diagram of circuit, see AIR CONDITIONING in appropriate SYSTEM WIRING DIAGRAMS article.
6. Right kick panel junction block is located behind instrument panel. (Scheme 8) For identification of fuses and relays (Scheme 15)and (Scheme 16). For identification of protected circuits (Scheme 17)- (Scheme 19). For wiring diagram of circuits, see POWER DISTRIBUTION in appropriate SYSTEM WIRING DIAGRAMS article.
7. Towing converter relay is located in left rear of cargo area. (Scheme 9)
8. Towing hitch relay is located in left rear of cargo area. (Scheme 9)

Scheme 8

Scheme 9

Scheme 10

Scheme 11

Scheme 12

Scheme 13

Scheme 14

Scheme 15

Scheme 16

Scheme 17
