TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) |
|---|
| Avalon & Sienna |
| Generator Adjusting Bolt | 13 (18) |
| Generator Pivot Bolt | 41 (56) |
| Generator Pulley Nut | 81 (110) |
| Camry & Camry Solara |
| 4-Cylinder |
| Generator Adjusting Bolt | 13 (18) |
| Generator Pivot Bolt | 38 (52) |
| Generator Pulley Nut | 81 (110) |
| V6 |
| Generator Adjusting Bolt | 13 (18) |
| Generator Pivot Bolt | 41 (56) |
| Generator Pulley Nut | 81 (110) |
| Celica |
| Generator Adjusting Bolt | 14 (19) |
| Generator Pivot Bolt | 40 (54) |
| Generator Pulley Nut | 81 (110) |
| Corolla |
| Generator Adjusting Bolt | 18 (24) |
| Generator Pivot Bolt |
| 1ZZ-FE Engine | 40 (54) |
| 2ZZ-GE Engine | 43 (58) |
| Generator Pulley Nut | 81 (110) |
| ECHO |
| Generator Adjusting Bolt | 14 (19) |
| Generator Pivot Bolt | 40 (54) |
| Generator Pulley Nut | 81 (110) |
| Land Cruiser |
| Generator Mounting Bolts | 29 (39) |
| Generator Pulley Nut | 81 (110) |
| Power Steering Pulley Nut | 32 (43) |
| MR2 |
| Generator Mounting Bolts | 18 (25) |
| Generator Pulley Nut | 40 (54) |
| Power Steering Pulley Nut | 81 (110) |
| RAV4 |
| Generator Adjusting Bolt | 13 (18) |
| Generator Pivot Bolt | 38 (51) |
| Generator Pulley Nut | 81 (110) |
| Tacoma & 4Runner |
| 4-Cylinder |
| Generator Adjusting Lock Bolt | 21 (28) |
| Generator Pivot Bolt | 43 (58) |
| Generator Pulley Nut | 81 (110) |
| V6 |
| Generator Adjusting Lock Bolt | 25 (34) |
| Generator Pivot Bolt | 38 (51) |
| Generator Pulley Nut | 81 (110) |
| Tundra |
| V6 |
| Generator Adjusting Lock Bolt | 25 (34) |
| Generator Pivot Bolt | 38 (51) |
| Generator Pulley Nut | 81 (110) |
| V8 |
| Generator Mounting Bolts | 29 (39) |
| Generator Pulley Nut | 81 (110) |
| Power Steering Pulley Nut | 32 (43) |
Charging System Wiring Diagram (Avalon). Scheme 1
Scheme 1: Charging System Wiring Diagram (Avalon)
Charging System Wiring Diagram (Camry - 2.2L & 3.0L). Scheme 2
Scheme 2: Charging System Wiring Diagram (Camry - 2.2L & 3.0L)
Charging System Wiring Diagram (Camry - 2.2L CNG). Scheme 3
Scheme 3: Charging System Wiring Diagram (Camry - 2.2L CNG)
Charging System Wiring Diagram (Camry Solara). Scheme 4
Scheme 4: Charging System Wiring Diagram (Camry Solara)
Charging System Wiring Diagram (Celica). Scheme 5
Scheme 5: Charging System Wiring Diagram (Celica)
Charging System Wiring Diagram (Corolla). Scheme 6
Scheme 6: Charging System Wiring Diagram (Corolla)
Charging System Wiring Diagram (ECHO). Scheme 7
Scheme 7: Charging System Wiring Diagram (ECHO)
Charging System Wiring Diagram (Land Cruiser). Scheme 8
Scheme 8: Charging System Wiring Diagram (Land Cruiser)
Charging System Wiring Diagram (Lexus LX470). Scheme 9
Scheme 9: Charging System Wiring Diagram (Lexus LX470)
Charging System Wiring Diagram (MR2). Scheme 10
Scheme 10: Charging System Wiring Diagram (MR2)
Charging System Wiring Diagram (RAV4). Scheme 11
Scheme 11: Charging System Wiring Diagram (RAV4)
Charging System Wiring Diagram (Sienna). Scheme 12
Scheme 12: Charging System Wiring Diagram (Sienna)
Charging System Wiring Diagram (Tacoma). Scheme 13
Scheme 13: Charging System Wiring Diagram (Tacoma)
Charging System Wiring Diagram (Tundra). Scheme 14
Scheme 14: Charging System Wiring Diagram (Tundra)
Charging System Wiring Diagram (4Runner). Scheme 15
Scheme 15: Charging System Wiring Diagram (4Runner)
