SPECIFICATIONS
| Application | Specification |
|---|
| Compressor Type | Nippondenso 10PA20 10-Cyl. |
| Compressor Belt Tension | (1) |
| Compressor Oil Capacity | (2) |
| Refrigerant (R-134a) Capacity | 35.3-38.8 ozs. |
| System Operating Pressures (3) |
| High Side | 199-228 psi (14-16 kg/cm 2 ) |
| Low Side | 21-36 psi (1.5-2.5 kg/cm 2 ) |
| (1) Belt tension is automatically controlled by spring tensioner. (2) Use ND-OIL 8 refrigerant oil. Refer to underhood label for refrigerant quantity. (3) Specification is with ambient temperature at 86-95°F (30-35°C) and engine speed at 1500 RPM. |
| (1) | Belt tension is automatically controlled by spring tensioner. |
| (2) | Use ND-OIL 8 refrigerant oil. Refer to underhood label for refrigerant quantity. |
| (3) | Specification is with ambient temperature at 86-95°F (30-35°C) and engine speed at 1500 RPM. |
TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) |
|---|
| Compressor Bolts | 36 (49) |
| Discharge Line Nut | 16 (22) |
| Instrument Panel Bolts | 15 (20) |
| Seat Mounting Bolts |
| Front | 27 (37) |
| Rear | 31 (42) |
| Seat Belt Anchor Bolt | 32 (43) |
| Steering Wheel Center Nut | 37 (50) |
| Suction Line Nut | 24 (32) |
| INCH Lbs. (N.m) |
| Compressor Clutch Center Bolt | 117 (13) |
| Front Expansion Valve-To-Evaporator Bolt | 30 (3.4) |
| Passenger Side Air Bag Mounting Bolts | 53 (6.3) |
| Rear Cooling Unit Liquid/Suction Lines | 84 (10) |
| Rear Expansion Valve-To-Evaporator Bolt | 48 (5.4) |
| Refrigerant Hoses/Lines |
| Liquid Line Bolt | 84 (10) |
| Liquid Line Nut | 124 (14) |
| Suction Line Bolt | 84 (10) |
Automatic A/C-Heater System Wiring Diagram (2000-01 LX 470 W/O Navigation System - 1 Of 2). Scheme 15
Scheme 15: Automatic A/C-Heater System Wiring Diagram (2000-01 LX 470 W/O Navigation System - 1 Of 2)
Automatic A/C-Heater System Wiring Diagram (2000-01 LX 470 W/O Navigation System - 2 Of 2). Scheme 16
Scheme 16: Automatic A/C-Heater System Wiring Diagram (2000-01 LX 470 W/O Navigation System - 2 Of 2)
Automatic A/C-Heater System Wiring Diagram (2001 LX 470 W/ Navigation System - 1 Of 2). Scheme 17
Scheme 17: Automatic A/C-Heater System Wiring Diagram (2001 LX 470 W/ Navigation System - 1 Of 2)
Automatic A/C-Heater System Wiring Diagram (2001 LX 470 W/ Navigation System - 2 Of 2). Scheme 18
Scheme 18: Automatic A/C-Heater System Wiring Diagram (2001 LX 470 W/ Navigation System - 2 Of 2)
Rear A/C System Wiring Diagram (2000-01 LX 470 - 1 Of 2). Scheme 19
Scheme 19: Rear A/C System Wiring Diagram (2000-01 LX 470 - 1 Of 2)
Rear A/C System Wiring Diagram (2000-01 LX 470 - 2 Of 2). Scheme 20
Scheme 20: Rear A/C System Wiring Diagram (2000-01 LX 470 - 2 Of 2)
