Suspension: Removal & Installation Lexus LS IV

REMOVAL

HINT

1. Use the same procedures for the RH side and LH side.
2. The procedures listed below are for the LH side.

Scheme 41

Scheme 42

1. REMOVE FRONT WHEEL
2. DISCONNECT SPEED SENSOR CONNECTOR (See «REMOVAL»(ref-349749-S38905054652009120800000) )
3. DISCONNECT FRONT DISC BRAKE CALIPER ASSEMBLY LH (See «REMOVAL»(ref-349749-S38905054652009120800000) )
4. REMOVE FRONT DISC (See «REMOVAL»(ref-349719-S21827681662009120800000) )
5. REMOVE FRONT DISC BRAKE DUST COVER LH (See «REMOVAL»(ref-349749-S38905054652009120800000) )
6. DISCONNECT TIE ROD ASSEMBLY LH (See «REMOVAL»(ref-349733-S36942300362009120800000) )
7. DISCONNECT FRONT NO. 1 SUSPENSION LOWER ARM ASSEMBLY LH (See «REMOVAL»(ref-349749-S38905054652009120800000) )
8. DISCONNECT FRONT HEIGHT CONTROL SENSOR SUB-ASSEMBLY LH (See «REMOVAL»(ref-349722-S31569215582009120800000) )
9. REMOVE FRONT STABILIZER LINK ASSEMBLY LH (See «REMOVAL»(ref-349722-S31569215582009120800000) )
10. DISCONNECT FRONT NO. 2 SUSPENSION LOWER ARM ASSEMBLY LH (See «REMOVAL»(ref-349722-S17020118902009120800000) )
11. REMOVE AIR CLEANER INLET COVER SUB-ASSEMBLY
12. REMOVE ENGINE ROOM SIDE COVER LH (See «REMOVAL»(ref-349714-S31912998822009120800000) )
13. REMOVE FRONT SHOCK ABSORBER ASSEMBLY LH Loosen the lock nut of the front shock absorber. NOTE: Do not remove the lock nut. Loosen the lock nut only when disassembling the front shock absorber with coil spring. Remove the 3 nuts from the upper side of the front suspension support. Slowly lower the jack. Remove the bolt from the lower side to remove the front shock absorber with coil spring.

Note. Be sure to read the "PRECAUTION" thoroughly before servicing (see SUSPENSION CONTROL SYSTEM ).

HINT

1. Use the same procedures for the RH side and LH side.
2. The procedures listed below are for the LH side.

Scheme 43

Scheme 44

Scheme 45

Scheme 46

Scheme 47

Scheme 48

Scheme 49

Scheme 50

Scheme 51

Scheme 52

Scheme 53

Scheme 54

Scheme 55

Scheme 56

Scheme 57

Scheme 58

Scheme 59

1. REMOVE COWL TOP VENTILATOR LOUVER RH (See «REMOVAL»(ref-349732-S04425564642009120800000) )
2. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL (See «REMOVAL»(ref-349714-S10589957032009120800000) )
3. REMOVE FRONT WHEEL
4. REMOVE FRONT AXLE SHAFT NUT LH (for AWD) (See «REMOVAL»(ref-349749-S15701984032009120800000) )
5. DISCONNECT SPEED SENSOR CONNECTOR (for 2WD) (See «REMOVAL»(ref-349749-S38905054652009120800000) )
6. DISCONNECT FRONT DISC BRAKE CALIPER ASSEMBLY LH (See «REMOVAL»(ref-349749-S38905054652009120800000) )
7. REMOVE FRONT DISC (See «REMOVAL»(ref-349719-S21827681662009120800000) )
8. REMOVE FRONT DISC BRAKE DUST COVER LH (See «REMOVAL»(ref-349749-S38905054652009120800000) )
9. DISCONNECT SKID CONTROL SENSOR WIRE (for AWD) (See «REMOVAL»(ref-349749-S15701984032009120800000) )
10. REMOVE FRONT SPEED SENSOR LH (for AWD) (See «REMOVAL»(ref-349749-S15701984032009120800000) )
11. DISCONNECT TIE ROD ASSEMBLY LH (See «REMOVAL»(ref-349733-S36942300362009120800000) )
12. DISCONNECT FRONT NO. 1 SUSPENSION UPPER ARM ASSEMBLY LH (for AWD) (See «REMOVAL»(ref-349749-S15701984032009120800000) )
13. DISCONNECT FRONT NO. 2 SUSPENSION UPPER ARM ASSEMBLY LH (for AWD) (See «REMOVAL»(ref-349749-S15701984032009120800000) )
14. REMOVE STEERING KNUCKLE SUB-ASSEMBLY LH (for AWD) (See «REMOVAL»(ref-349749-S07227301112009120800000) )
15. DISCONNECT FRONT NO. 1 SUSPENSION LOWER ARM ASSEMBLY LH (for 2WD) (See «REMOVAL»(ref-349749-S38905054652009120800000) )
16. DISCONNECT FRONT HEIGHT CONTROL SENSOR SUB-ASSEMBLY LH (for 2WD) (See «REMOVAL»(ref-349722-S31569215582009120800000) )
17. DISCONNECT FRONT HEIGHT CONTROL SENSOR SUB-ASSEMBLY LH (for AWD) Remove the nut, and then remove the bracket of the front height control sensor LH.
18. REMOVE FRONT STABILIZER LINK ASSEMBLY LH (for 2WD) (See «REMOVAL»(ref-349722-S31569215582009120800000) )
19. REMOVE FRONT STABILIZER LINK ASSEMBLY LH (for AWD) (See «REMOVAL»(ref-349722-S25719349322009120800000) )
20. REMOVE AIR CONNECTOR CLIP HOLDER Pinch and pull the air connector clip holder to release the connector No. 1.
21. DISCONNECT NO. 4 HEIGHT CONTROL TUBE Pinch and pull the connector No. 1 to release it. Using SST, disconnect the No. 4 height control tube from the pneumatic front LH with shock absorber cylinder assembly. SST 09730-00010 NOTE: After pulling out the height control tube, replace the O-ring and plate with new ones.
22. DISCONNECT FRONT NO. 2 SUSPENSION LOWER ARM ASSEMBLY LH (for 2WD) Support the steering knuckle LH with a jack and wooden block. Remove the bolt and nut, and then disconnect the bottom side of the pneumatic front LH with shock absorber cylinder assembly from the front No. 2 suspension lower arm LH. Remove the nut and clip. Install 2 spacers (SST spacer A) onto the front No. 2 suspension lower arm assembly LH so that there is a space of approximately 1 mm (0.0394 in.) between the arm and spacers. SST 09960-20010 (09961 -02050) NOTE: Make sure install the spacers (SST spacer A) as the steering knuckle spacer may shift. As SST may become damaged, make sure the space between the arm and spacers is not 1 mm (0.0394 in.) or less. Using SST, disconnect the No. 2 suspension lower arm LH from the steering knuckle LH. SST 09960-20010 (09961 -02010) NOTE: Do not damage the dust cover. As the dust cover may be damaged, adjust SST with the center nut so that the body and crow are parallel. Make sure to tie the string of SST to the vehicle to prevent SST from dropping. Loosen the nut of the No. 2 suspension lower arm.
23. REMOVE AIR CLEANER INLET COVER SUB-ASSEMBLY (for 2WD) Remove the 4 clips and air cleaner inlet cover.
24. REMOVE AIR CLEANER INLET COVER SUB-ASSEMBLY (for AWD) (See «REMOVAL»(ref-349724-S31319866602009120800000) )
25. REMOVE ENGINE ROOM SIDE COVER LH (for 2WD) (See «REMOVAL»(ref-349714-S31912998822009120800000) )
26. REMOVE ENGINE ROOM SIDE COVER LH (for AWD) (See «REMOVAL»(ref-349714-S10589957032009120800000) )
27. REMOVE FRONT SHOCK ABSORBER CAP LH (for 2WD) Remove the 3 nuts and front shock absorber cap LH. Disconnect the connector.
28. REMOVE FRONT SHOCK ABSORBER CAP LH (for AWD) Remove the 3 nuts and front shock absorber cap LH. Disconnect the connector.
29. REMOVE ABSORBER CONTROL ACTUATOR Turn the absorber control actuator counterclockwise 40° and remove it from the pneumatic front LH with shock absorber cylinder assembly.
30. REMOVE PNEUMATIC FRONT WITH SHOCK ABSORBER CYLINDER ASSEMBLY LH (for 2WD) Remove the 3 nuts and pneumatic front LH with shock absorber cylinder assembly. NOTE: Hold the pneumatic front LH with shock absorber cylinder assembly to prevent it from dropping.
31. REMOVE PNEUMATIC FRONT WITH SHOCK ABSORBER CYLINDER ASSEMBLY LH (for AWD) Remove the nut and upper front shock absorber bracket plate, and disconnect the lower front shock absorber bracket sub-assembly LH from the front No. 1 suspension lower arm LH. Remove the bolt, and disconnect the skid control sensor wire from the front pneumatic shock absorber with cylinder assembly LH. Remove the 3 nuts and front pneumatic shock absorber with cylinder assembly LH. NOTE: Hold the front pneumatic shock absorber with cylinder assembly LH to prevent it from dropping.
32. REMOVE LOWER FRONT SHOCK ABSORBER BRACKET SUB-ASSEMBLY LH (for AWD) Remove the bolt and lower front shock absorber bracket sub-assembly LH.
33. REMOVE FRONT PNEUMATIC CYLINDER LH O-RING HINT: If replacing the pneumatic front LH with shock absorber cylinder assembly with a new one, this procedure is not necessary. Using a screwdriver, detach the 2 clips and remove the tube connector. Using a screwdriver, remove the plate and 2 O-rings.

Scheme 60

Scheme 61

1. INSPECT PNEUMATIC FRONT LH WITH SHOCK ABSORBER CYLINDER ASSEMBLY Extend the pneumatic cylinder with shock absorber and check that it is as described below. OK: While extending the cylinder at a constant speed, the load is constant for each stroke and there is no abnormal feedback or noises. Also, the cylinder returns at a constant speed when extended. If an abnormality is found, replace the pneumatic cylinder with shock absorber with a new one. NOTE: When extending the pneumatic cylinder with shock absorber front LH, do not block the air inlet/outlet opening. While adjusting the damping force control rod to hard, semihard, medium, soft and semisoft, inspect the pneumatic front LH with shock absorber cylinder assembly by compressing and extending it. OK: There is a difference in the damping force.

INSTALLATION

HINT

1. Use the same procedures for the RH side and LH side.
2. The procedures listed below are for the LH side.
3. A bolt without a torque specification is shown in the standard bolt chart (see «SPECIFIED TORQUE FOR STANDARD BOLTS»(ref-349708-S13378942112009120800000) ).

Scheme 62

Scheme 63

Scheme 64

Scheme 65

Scheme 66

Scheme 67

Scheme 68

Scheme 69

Scheme 70

Scheme 71

Scheme 72

Scheme 73

1. INSTALL FRONT PNEUMATIC CYLINDER LH O-RING HINT: It is unnecessary to perform the following procedures if the pneumatic cylinder with shock absorber has been replaced with a new one. Lightly coat 2 new O-rings with MP grease. Install the 2 new O-rings and a new plate to a straight tube or equivalent, as shown in the illustration. Insert the tube end with the 2 O-rings and plate into the pneumatic cylinder with shock absorber rear LH. Then, lightly push in the O-rings and plate with a thick piece of paper. While holding the O-rings and plate in place with the paper, slowly pull out the tube. Install a new tube connector. NOTE: Push in the tube connector until a "click" sound is heard.
2. INSTALL PNEUMATIC FRONT LH WITH SHOCK ABSORBER CYLINDER ASSEMBLY (for 2WD) Install the pneumatic front LH with shock absorber cylinder assembly on the vehicle by installing the 3 nuts on the suspension support side. Torque: 67 N*m (683 kgf*cm, 49 ft.*lbf)
3. INSTALL LOWER FRONT SHOCK ABSORBER BRACKET SUB-ASSEMBLY LH (for AWD) Install the lower front shock absorber bracket sub-assembly LH to the front pneumatic shock absorber with cylinder assembly LH with the bolt. Torque: 48 N*m (489 kgf*cm, 35 ft.*lbf)
4. INSTALL PNEUMATIC FRONT LH W/SHOCK ABSORBER CYLINDER ASSY (for AWD) Install the front pneumatic shock absorber with cylinder assembly LH on the vehicle by installing the 3 nuts on the suspension support side. Torque: 67 N*m (683 kgf*cm, 49 ft.*lbf)
5. INSTALL ABSORBER CONTROL ACTUATOR Check that the control rod of the pneumatic front LH with shock absorber cylinder assembly is in the position shown in the illustration. NOTE: If the control rod is not in the position shown in the illustration, turn the control rod to adjust the position and install the absorber control actuator. Install the absorber control actuator to the actuator support bracket. Turn the actuator clockwise approximately 40° until a click is felt. NOTE: Do not excessively turn the actuator.
6. INSTALL FRONT SHOCK ABSORBER CAP LH (for 2WD) Connect the connector to the shock absorber control actuator. Install the shock absorber cap with the 3 nuts. Torque: 20 N*m (204 kgf*cm, 15 ft.*lbf)
7. INSTALL FRONT SHOCK ABSORBER CAP LH (for AWD) Connect the connector to the shock absorber control actuator. Install the shock absorber cap with the 3 nuts. Torque: 20 N*m (204 kgf*cm, 15 ft.*lbf)
8. INSTALL ENGINE ROOM SIDE COVER LH (for 2WD) (See «INSTALLATION»(ref-349714-S23488176532009120800000) )
9. INSTALL ENGINE ROOM SIDE COVER LH (for AWD) (See «INSTALLATION»(ref-349714-S27537239552009120800000) )
10. INSTALL AIR CLEANER INLET COVER SUB-ASSEMBLY (for 2WD) Install the 4 clips and air cleaner inlet cover.
11. INSTALL AIR CLEANER INLET COVER SUB-ASSEMBLY (for AWD) (See «INSTALLATION»(ref-349724-S09859827162009120800000) )
12. TEMPORARILY TIGHTEN FRONT NO. 2 SUSPENSION LOWER ARM ASSEMBLY LH (for 2WD) Temporarily install the front No. 2 suspension lower arm with the nut. HINT: Tighten the nut after the vehicle is stabilized. Temporarily install the front No. 2 suspension lower arm LH to the steering knuckle with the nut. HINT: Tighten the nut after the vehicle is stabilized. Install the bottom side of the pneumatic front LH with shock absorber cylinder assembly to the No. 2 suspension lower arm LH. Then insert the bolt from the rear of the vehicle and temporarily install it with the nut. HINT: Tighten the nut after the vehicle is stabilized.
13. TEMPORARILY INSTALL LOWER FRONT SHOCK ABSORBER BRACKET SUB-ASSEMBLY LH (for AWD) Install the lower front shock absorber bracket sub-assembly LH to the front No. 1 suspension lower arm LH. Align the protrusion of the front shock absorber upper bracket plate with cutout of the lower front shock absorber bracket sub-assembly LH, and temporarily install the nut. Install the skid control sensor wire to the front pneumatic shock absorber with cylinder assembly LH with the bolt. NOTE: Do not twist the skid control sensor wire. When installing the bolt, do not deform the front pneumatic shock absorber with cylinder assembly LH.
14. CONNECT NO. 4 HEIGHT CONTROL TUBE Connect the No. 4 height control tube to the cylinder. Connect the No. 1 tube connector.
15. INSTALL AIR CONNECTOR CLIP HOLDER Install the air connector clip holder to the No. 1 tube connector.
16. INSTALL FRONT STABILIZER LINK ASSEMBLY LH (for 2WD) (See «INSTALLATION»(ref-349722-S02097916402009120800000) )
17. INSTALL FRONT STABILIZER LINK ASSEMBLY LH (for AWD) (See «INSTALLATION»(ref-349722-S39141787312009120800000) )
18. CONNECT FRONT HEIGHT CONTROL SENSOR SUB-ASSEMBLY LH (for 2WD) (See «INSTALLATION»(ref-349722-S02097916402009120800000) )
19. CONNECT FRONT HEIGHT CONTROL SENSOR SUB-ASSEMBLY LH (for AWD) Install the bracket of the front height control sensor LH to the front No. 1 suspension lower arm LH with the bolt. Torque: 5.4 N*m (55 kgf*cm, 48 ft.*lbf)
20. CONNECT FRONT NO. 1 SUSPENSION LOWER ARM ASSEMBLY LH (for 2WD) (See «INSTALLATION»(ref-349749-S39253153892009120800000) )
21. INSTALL STEERING KNUCKLE SUB-ASSEMBLY LH (for AWD) (See «INSTALLATION»(ref-349749-S19109048572009120800000) )
22. CONNECT FRONT NO. 1 SUSPENSION UPPER ARM ASSEMBLY LH (for AWD) (See «INSTALLATION»(ref-349749-S19109048572009120800000) )
23. CONNECT FRONT NO. 2 SUSPENSION UPPER ARM ASSEMBLY LH (for AWD) (See «INSTALLATION»(ref-349749-S19109048572009120800000) )
24. CONNECT TIE ROD ASSEMBLY LH (See «INSTALLATION»(ref-349733-S30676435532009120800000) )
25. INSTALL FRONT SPEED SENSOR LH (for AWD) (See «INSTALLATION»(ref-349749-S19109048572009120800000) )
26. CONNECT SKID CONTROL SENSOR WIRE (for AWD) (See «INSTALLATION»(ref-349749-S19109048572009120800000) )
27. INSTALL FRONT DISC BRAKE DUST COVER LH (See «INSTALLATION»(ref-349749-S39253153892009120800000) )
28. INSTALL FRONT DISC (See «INSTALLATION»(ref-349719-S33447390982009120800000) )
29. CONNECT FRONT DISC BRAKE CALIPER ASSEMBLY LH (See «INSTALLATION»(ref-349749-S39253153892009120800000) )
30. CONNECT SPEED SENSOR CONNECTOR (for 2WD) (See «INSTALLATION»(ref-349749-S39253153892009120800000) )
31. INSTALL FRONT AXLE SHAFT NUT LH (for AWD) (See «INSTALLATION»(ref-349722-S15655817482009120800000) )
32. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
33. INSTALL COWL TOP VENTILATOR LOUVER RH (See «INSTALLATION»(ref-349732-S09051375432009120800000) )
34. PERFORM INITIALIZATION Perform the initialization (see «INITIALIZATION»(ref-349706-S07943075812009120800000) ). NOTE: Certain systems need to be initialized after disconnecting and reconnecting the cable from the negative (-) battery terminal.
35. STABILIZE SUSPENSION (for 2WD) Install the front wheel. Torque: 140 N*m (1428 kgf*cm, 103 ft.*lbf) Lower the vehicle and start the engine. Then fill the pneumatic front LH with shock absorber cylinder assembly with air. Bounce the vehicle up and down several times to stabilize the front suspension. Remove the front wheel. NOTE: Do not turn the engine switch on (IG). Jack up the front suspension lower arm with a wooden block between the jack and front suspension lower arm. Apply a load to the front suspension so that the front suspension lower arm is placed in a horizontal position.
36. STABILIZE SUSPENSION (for AWD) Install the front wheels. Torque: 140 N*m (1428 kgf*cm, 103 ft.*lbf) Lower the vehicle and start the engine. Then fill the front pneumatic shock absorber with cylinder assembly LH with air. HINT: If the vehicle height is not restored within 2 minutes, stop the engine and then start the engine again. Bounce the vehicle up and down several times to stabilize the front suspension. Remove the front wheels. NOTE: Do not turn the power switch ON (IG). Jack up the front suspension lower arm with a wooden block between the jack and front suspension lower arm. Apply a load to the front suspension so that the front suspension lower arm is horizontal.
37. TIGHTEN FRONT NO. 2 SUSPENSION LOWER ARM ASSEMBLY LH (for 2WD) (See «INSTALLATION»(ref-349722-S02097916402009120800000) )
38. TIGHTEN LOWER FRONT SHOCK ABSORBER BRACKET SUB-ASSEMBLY LH (for AWD) Tighten the lower side nut of the lower front shock absorber bracket sub-assembly LH. Torque: 112 N*m (1142 kgf*cm, 83 ft.*lbf)
39. INSTALL FRONT WHEEL Torque: 140 N*m (1428 kgf*cm, 103 ft.*lbf)
40. INSPECT AND ADJUST FRONT WHEEL ALIGNMENT (for 2WD) Check and adjust the front wheel alignment (See «ADJUSTMENT»(ref-349722-S12260449942009120800000) ).
41. INSPECT AND ADJUST FRONT WHEEL ALIGNMENT (for AWD) Check and adjust the front wheel alignment (See «ADJUSTMENT»(ref-349722-S22766536012009120800000) ).
42. INSPECT FOR AIR LEAK Inspect for air leak (See «OPERATION CHECK»(ref-349750-S12258921322009120800000) ).
43. ADJUST VEHICLE HEIGHT Adjust the vehicle height (See «ADJUSTMENT»(ref-349750-S01070563512009120800000) ).
44. ADJUST HEADLIGHT ASSEMBLY Adjust the headlight assembly (See «ADJUSTMENT»(ref-349731-S09246046722009120800000) ).

Scheme 74

1. DISPOSE OF PNEUMATIC FRONT LH WITH SHOCK ABSORBER CYLINDER ASSEMBLY Fully extend the front shock absorber rod. Using a drill, make a hole in the cylinder somewhere between A and B shown in the illustration to discharge the gas inside. CAUTION: Be careful as the cylinder is a high-pressure gas type which is at a higher pressure than normal shock absorbers. Also be careful with high temperatures as the cylinder's pressure becomes even higher. NOTE: The gas is colorless, odorless and harmless.

Scheme 75

Scheme 76

Scheme 77

Scheme 78

1. INSPECT FRONT SUSPENSION UPPER ARM BALL JOINT RATTLE Jack up the vehicle. Move the front suspension upper arm up and down by hand, and check for rattle. OK: No rattle.

Note. Be sure to read the "PRECAUTION" thoroughly before servicing (see SUSPENSION CONTROL SYSTEM ).

HINT

1. Use the same procedures for the RH side and LH side.
2. The procedures listed below are for the LH side.

Scheme 79

Scheme 80

1. REMOVE COWL TOP VENTILATOR LOUVER RH (See «REMOVAL»(ref-349732-S04425564642009120800000) )
2. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL (See «REMOVAL»(ref-349714-S31912998822009120800000) )
3. REMOVE FRONT WHEEL
4. DISCONNECT SPEED SENSOR CONNECTOR (See «REMOVAL»(ref-349749-S38905054652009120800000) )
5. DISCONNECT FRONT DISC BRAKE CALIPER ASSEMBLY LH (See «REMOVAL»(ref-349749-S38905054652009120800000) )
6. REMOVE FRONT DISC (See «REMOVAL»(ref-349719-S21827681662009120800000) )
7. REMOVE FRONT DISC BRAKE DUST COVER LH (See «REMOVAL»(ref-349749-S38905054652009120800000) )
8. DISCONNECT TIE ROD ASSEMBLY LH (See «REMOVAL»(ref-349733-S36942300362009120800000) )
9. DISCONNECT FRONT NO. 1 SUSPENSION LOWER ARM ASSEMBLY LH (See «REMOVAL»(ref-349749-S38905054652009120800000) )
10. DISCONNECT FRONT HEIGHT CONTROL SENSOR SUB-ASSEMBLY LH (See «REMOVAL»(ref-349722-S31569215582009120800000) )
11. REMOVE FRONT STABILIZER LINK ASSEMBLY LH (See «REMOVAL»(ref-349722-S31569215582009120800000) )
12. REMOVE AIR CONNECTOR CLIP HOLDER (w/ Air Suspension) (See «REMOVAL»(ref-349722-S17020118902009120800000) )
13. DISCONNECT NO. 8 HEIGHT CONTROL TUBE (w/ Air Suspension) (See «REMOVAL»(ref-349722-S17020118902009120800000) )
14. DISCONNECT FRONT NO. 2 SUSPENSION LOWER ARM ASSEMBLY LH (See «REMOVAL»(ref-349722-S17020118902009120800000) )
15. REMOVE AIR CLEANER INLET COVER SUB-ASSEMBLY (See «REMOVAL»(ref-349722-S17020118902009120800000) )
16. REMOVE ENGINE ROOM SIDE COVER LH (See «REMOVAL»(ref-349714-S31912998822009120800000) )
17. REMOVE FRONT SHOCK ABSORBER CAP LH (w/ Air Suspension) (See «REMOVAL»(ref-349722-S17020118902009120800000) )
18. REMOVE ABSORBER CONTROL ACTUATOR (w/ Air Suspension) (See «REMOVAL»(ref-349722-S17020118902009120800000) )
19. REMOVE FRONT SHOCK ABSORBER ASSEMBLY LH (w/o Air Suspension) (See «REMOVAL»(ref-349722-S29297925512009120800000) )
20. REMOVE PNEUMATIC FRONT LH WITH SHOCK ABSORBER CYLINDER ASSEMBLY (w/ Air Suspension) (See «REMOVAL»(ref-349722-S17020118902009120800000) )
21. REMOVE FRONT PNEUMATIC CYLINDER LH O-RING (w/ Air Suspension) (See «REMOVAL»(ref-349722-S17020118902009120800000) )
22. REMOVE STEERING KNUCKLE SUB-ASSEMBLY LH (See «REMOVAL»(ref-349749-S38905054652009120800000) )
23. REMOVE NO. 1 ARM ATTACHMENT PLATE INNER LH Remove the 3 bolts and No. 1 arm attachment plate inner LH.
24. REMOVE NO. 2 ARM ATTACHMENT PLATE INNER LH Remove the 2 bolts and No. 2 arm attachment plate inner LH.
25. REMOVE FRONT NO. 1 SUSPENSION UPPER ARM ASSEMBLY LH Remove the bolt and nut, and then remove the front No. 1 suspension upper arm assembly LH from the No. 1 arm attachment plate inner LH.
26. REMOVE FRONT NO. 2 SUSPENSION UPPER ARM ASSEMBLY LH Remove the bolt and nut, and then remove the front No. 2 suspension upper arm assembly LH from the No. 2 arm attachment plate inner LH.

Scheme 81

Scheme 82

1. INSPECT FRONT NO. 1 SUSPENSION UPPER ARM ASSEMBLY LH Inspect the turning of the upper ball joint. Install the installation nut to the ball joint stud. Move the stud back and forth 5 times. Using a torque wrench, turn the nut continuously at a rate of 3 to 5 seconds per turn and take the torque reading on the fifth turn. Standard turning torque: 3.5 N*m (36 kgf*cm, 31 in.*lbf) or less If the value is not within the specified range, replace the front suspension upper arm with a new one. Check the dust boots for cracks or grease leakage.
2. INSPECT FRONT NO. 2 SUSPENSION UPPER ARM ASSEMBLY LH Inspect the turning of the upper ball joint. Install the installation nut to the ball joint stud. Move the stud back and forth 5 times. Using a torque wrench, turn the nut continuously at a rate of 3 to 5 seconds per turn and take the torque reading on the fifth turn. Standard turning torque: 3.5 N*m (36 kgf*cm, 31 in.*lbf) or less If the value is not within the specified range, replace the front suspension upper arm with a new one. Check the dust boots for cracks or grease leakage.

HINT

1. Use the same procedures for the RH side and LH side.
2. The procedures listed below are for the LH side.
3. A bolt without a torque specification is shown in the standard bolt chart (see «SPECIFIED TORQUE FOR STANDARD BOLTS»(ref-349708-S13378942112009120800000) ).

Scheme 83

Scheme 84

Scheme 85

Scheme 86

Scheme 87

Scheme 88

1. TEMPORARILY TIGHTEN FRONT NO. 1 SUSPENSION UPPER ARM ASSEMBLY LH Insert the bolt as shown in the illustration. Then temporarily install the front No. 1 suspension upper arm assembly LH to the No. 1 arm attachment plate inner LH with the nut.
2. TEMPORARILY TIGHTEN FRONT NO. 2 SUSPENSION UPPER ARM ASSEMBLY LH Insert the bolt as shown in the illustration. Then temporarily install the front No. 2 suspension upper arm assembly LH to the No. 2 arm attachment plate inner LH with the nut.
3. INSTALL NO. 1 ARM ATTACHMENT PLATE INNER LH Install the No. 1 arm attachment plate inner LH with the 3 bolts and spacers. Torque: 32 N*m (326 kgf*cm, 24 ft.*lbf)
4. INSTALL NO. 2 ARM ATTACHMENT PLATE INNER LH Install the No. 2 arm attachment plate inner LH with the 2 bolts and spacer. Torque: 32 N*m (326 kgf*cm, 24 ft.*lbf)
5. INSTALL STEERING KNUCKLE SUB-ASSEMBLY LH (See «INSTALLATION»(ref-349749-S39253153892009120800000) )
6. INSTALL FRONT PNEUMATIC CYLINDER LH O-RING (w/ Air Suspension) (See «INSTALLATION»(ref-349722-S36481182872009120800000) )
7. INSTALL FRONT SHOCK ABSORBER ASSEMBLY LH (w/o Air Suspension) (See «REASSEMBLY»(ref-349722-S29526097872009120800000) )
8. INSTALL PNEUMATIC FRONT LH WITH SHOCK ABSORBER CYLINDER ASSEMBLY (w/ Air Suspension) (See «INSTALLATION»(ref-349722-S36481182872009120800000) )
9. INSTALL ABSORBER CONTROL ACTUATOR (w/ Air Suspension) (See «INSTALLATION»(ref-349722-S36481182872009120800000) )
10. INSTALL FRONT SHOCK ABSORBER CAP LH (w/ Air Suspension) (See «INSTALLATION»(ref-349722-S36481182872009120800000) )
11. INSTALL ENGINE ROOM SIDE COVER LH (See «INSTALLATION»(ref-349714-S23488176532009120800000) )
12. INSTALL AIR CLEANER INLET COVER SUB-ASSEMBLY (See «INSTALLATION»(ref-349722-S36481182872009120800000) )
13. TEMPORARILY TIGHTEN FRONT NO. 2 SUSPENSION LOWER ARM ASSEMBLY LH (See «INSTALLATION»(ref-349722-S36481182872009120800000) )
14. CONNECT NO. 8 HEIGHT CONTROL TUBE (w/ Air Suspension) (See «INSTALLATION»(ref-349722-S36481182872009120800000) )
15. REPAIR AIR CONNECTOR CLIP HOLDER (w/ Air Suspension) (See «INSTALLATION»(ref-349722-S36481182872009120800000) )
16. INSTALL FRONT STABILIZER LINK ASSEMBLY LH (See «INSTALLATION»(ref-349722-S02097916402009120800000) )
17. CONNECT FRONT HEIGHT CONTROL SENSOR SUB-ASSEMBLY LH (See «INSTALLATION»(ref-349722-S02097916402009120800000) )
18. CONNECT FRONT NO. 1 SUSPENSION LOWER ARM ASSEMBLY LH (See «INSTALLATION»(ref-349749-S39253153892009120800000) )
19. CONNECT TIE ROD ASSEMBLY LH (See «INSTALLATION»(ref-349733-S30676435532009120800000) )
20. INSTALL FRONT DISC BRAKE DUST COVER LH (See «INSTALLATION»(ref-349749-S39253153892009120800000) )
21. INSTALL FRONT DISC (See «INSTALLATION»(ref-349719-S33447390982009120800000) )
22. CONNECT FRONT DISC BRAKE CALIPER ASSEMBLY LH (See «INSTALLATION»(ref-349749-S39253153892009120800000) )
23. CONNECT SPEED SENSOR CONNECTOR (See «INSTALLATION»(ref-349749-S39253153892009120800000) )
24. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
25. INSTALL COWL TOP VENTILATOR LOUVER RH (See «INSTALLATION»(ref-349732-S09051375432009120800000) )
26. PERFORM INITIALIZATION (See «INSTALLATION»(ref-349722-S36481182872009120800000) )
27. STABILIZE SUSPENSION (w/o Air Suspension) (See «INSTALLATION»(ref-349722-S25641696382009120800000) )
28. STABILIZE SUSPENSION (w/ Air Suspension) (See «INSTALLATION»(ref-349722-S36481182872009120800000) )
29. TIGHTEN FRONT NO. 1 SUSPENSION UPPER ARM ASSEMBLY LH Tighten the installation nut of the front No. 1 suspension upper arm assembly LH. Torque: 50 N*m (510 kgf*cm, 37 ft.*lbf)
30. TIGHTEN FRONT NO. 2 SUSPENSION UPPER ARM ASSEMBLY LH Tighten the installation nut of the front No. 2 suspension upper arm assembly LH. Torque: 50 N*m (510 kgf*cm, 37 ft.*lbf)
31. TIGHTEN FRONT NO. 2 SUSPENSION LOWER ARM ASSEMBLY LH (See «INSTALLATION»(ref-349722-S02097916402009120800000) )
32. INSTALL FRONT WHEEL Torque: 140 N*m (1428 kgf*cm, 103 ft.*lbf)
33. INSPECT AND ADJUST FRONT WHEEL ALIGNMENT (See «INSTALLATION»(ref-349722-S36481182872009120800000) )
34. ADJUST VEHICLE HEIGHT (See «INSTALLATION»(ref-349722-S36481182872009120800000) )
35. INSPECT FOR AIR LEAK (See «INSTALLATION»(ref-349722-S36481182872009120800000) )
36. VEHICLE PREPARATION FOR HEADLIGHT AIMING ADJUSTMENT (See «ADJUSTMENT»(ref-349731-S09246046722009120800000) )
37. PREPARATION FOR HEADLIGHT AIMING (Using a screen) (See «ADJUSTMENT»(ref-349731-S09246046722009120800000) )
38. HEADLIGHT AIMING INSPECTION (See «ADJUSTMENT»(ref-349731-S09246046722009120800000) )
39. HEADLIGHT AIMING ADJUSTMENT (See «ADJUSTMENT»(ref-349731-S09246046722009120800000) )

Scheme 89

Scheme 90

Scheme 91

Note. Be sure to read the "PRECAUTION" thoroughly before servicing (see SUSPENSION CONTROL SYSTEM ).

HINT

1. Use the same procedures for the RH side and LH side.
2. The procedures listed below are for the LH side.

1. REMOVE COWL TOP VENTILATOR LOUVER RH (See «REMOVAL»(ref-349735-S07548571092009120800000) )
2. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL (See «REMOVAL»(ref-349714-S10589957032009120800000) )
3. REMOVE FRONT WHEEL
4. REMOVE FRONT AXLE SHAFT NUT LH (See «REMOVAL»(ref-349749-S15701984032009120800000) )
5. DISCONNECT FRONT DISC BRAKE CALIPER ASSEMBLY LH (See «REMOVAL»(ref-349749-S15701984032009120800000) )
6. REMOVE FRONT DISC (See «REMOVAL»(ref-349719-S21827681662009120800000) )
7. REMOVE FRONT DISC BRAKE DUST COVER LH (See «REMOVAL»(ref-349749-S15701984032009120800000) )
8. DISCONNECT SKID CONTROL SENSOR WIRE (See «REMOVAL»(ref-349749-S15701984032009120800000) )
9. REMOVE FRONT SPEED SENSOR LH (See «REMOVAL»(ref-349749-S15701984032009120800000) )
10. DISCONNECT TIE ROD ASSEMBLY LH (See «REMOVAL»(ref-349749-S15701984032009120800000) )
11. DISCONNECT FRONT NO. 1 SUSPENSION UPPER ARM ASSEMBLY LH (See «REMOVAL»(ref-349749-S15701984032009120800000) )
12. DISCONNECT FRONT NO. 2 SUSPENSION UPPER ARM ASSEMBLY LH (See «REMOVAL»(ref-349749-S15701984032009120800000) )
13. REMOVE STEERING KNUCKLE SUB-ASSEMBLY LH (See «REMOVAL»(ref-349749-S15701984032009120800000) )
14. DISCONNECT FRONT HEIGHT CONTROL SENSOR SUB-ASSEMBLY LH (See «REMOVAL»(ref-349722-S17020118902009120800000) )
15. REMOVE FRONT STABILIZER LINK ASSEMBLY LH (See «REMOVAL»(ref-349722-S25719349322009120800000) )
16. REMOVE AIR CONNECTOR CLIP HOLDER (See «REMOVAL»(ref-349722-S17020118902009120800000) )
17. DISCONNECT NO. 4 HEIGHT CONTROL TUBE (See «REMOVAL»(ref-349722-S17020118902009120800000) )
18. REMOVE AIR CLEANER INLET COVER SUB-ASSEMBLY (See «REMOVAL»(ref-349724-S31319866602009120800000) )
19. REMOVE ENGINE ROOM SIDE COVER LH (See «REMOVAL»(ref-349714-S10589957032009120800000) )
20. REMOVE FRONT SHOCK ABSORBER CAP LH (See «REMOVAL»(ref-349722-S17020118902009120800000) )
21. REMOVE ABSORBER CONTROL ACTUATOR (See «REMOVAL»(ref-349722-S17020118902009120800000) )
22. REMOVE FRONT PNEUMATIC SHOCK ABSORBER WITH CYLINDER ASSEMBLY LH (See «REMOVAL»(ref-349722-S17020118902009120800000) )
23. REMOVE FRONT PNEUMATIC CYLINDER O-RING LH (See «REMOVAL»(ref-349722-S17020118902009120800000) )
24. REMOVE INNER NO. 1 ARM ATTACHMENT PLATE LH Remove the 3 bolts and inner No. 1 arm attachment plate LH.
25. REMOVE INNER NO. 2 ARM ATTACHMENT PLATE LH Remove the 2 bolts and inner No. 2 arm attachment plate LH.
26. REMOVE FRONT NO. 1 SUSPENSION UPPER ARM ASSEMBLY LH Remove the bolt and nut, and then remove the front No. 1 suspension upper arm assembly LH from the inner No. 1 arm attachment plate LH.
27. REMOVE FRONT NO. 2 SUSPENSION UPPER ARM ASSEMBLY LH Remove the bolt and nut, and then remove the front No. 2 suspension upper arm assembly LH from the inner No. 2 arm attachment plate LH.

HINT

1. Use the same procedures for the RH side and LH side.
2. The procedures listed below are for the LH side.
3. A bolt without a torque specification is shown in the standard bolt chart (see «SPECIFIED TORQUE FOR STANDARD BOLTS»(ref-349708-S13378942112009120800000) ).

Scheme 92

Scheme 93

1. TEMPORARILY INSTALL FRONT NO. 1 SUSPENSION UPPER ARM ASSEMBLY LH Insert the bolt as shown in the illustration. Then temporarily install the front No. 1 suspension upper arm assembly LH to the inner No. 1 arm attachment plate LH with the nut.
2. TEMPORARILY INSTALL FRONT NO. 2 SUSPENSION UPPER ARM ASSEMBLY LH Insert the bolt as shown in the illustration. Then temporarily install the front No. 2 suspension upper arm assembly LH to the inner No. 2 arm attachment plate LH with the nut.
3. INSTALL INNER NO. 1 ARM ATTACHMENT PLATE LH Install the inner No. 1 arm attachment plate LH and spacers with the 3 bolts. Torque: 32 N*m (326 kgf*cm, 24 ft.*lbf)
4. INSTALL INNER NO. 2 ARM ATTACHMENT PLATE LH Install the inner No. 2 arm attachment plate LH and spacer with the 2 bolts. Torque: 32 N*m (326 kgf*cm, 24 ft.*lbf)
5. INSTALL FRONT PNEUMATIC CYLINDER O-RING LH (See «INSTALLATION»(ref-349722-S36481182872009120800000) )
6. INSTALL FRONT PNEUMATIC SHOCK ABSORBER WITH CYLINDER ASSEMBLY LH (See «INSTALLATION»(ref-349722-S36481182872009120800000) )
7. INSTALL ABSORBER CONTROL ACTUATOR (See «INSTALLATION»(ref-349722-S36481182872009120800000) )
8. INSTALL FRONT SHOCK ABSORBER CAP LH (See «INSTALLATION»(ref-349722-S36481182872009120800000) )
9. INSTALL ENGINE ROOM SIDE COVER LH (See «INSTALLATION»(ref-349714-S27537239552009120800000) )
10. INSTALL AIR CLEANER INLET COVER SUB-ASSEMBLY (See «INSTALLATION»(ref-349724-S09859827162009120800000) )
11. TEMPORARILY INSTALL LOWER FRONT SHOCK ABSORBER BRACKET SUB-ASSEMBLY LH (See «INSTALLATION»(ref-349722-S36481182872009120800000) )
12. CONNECT NO. 4 HEIGHT CONTROL TUBE (See «INSTALLATION»(ref-349722-S36481182872009120800000) )
13. INSTALL AIR CONNECTOR CLIP HOLDER (See «INSTALLATION»(ref-349722-S36481182872009120800000) )
14. INSTALL FRONT STABILIZER LINK ASSEMBLY LH (See «INSTALLATION»(ref-349722-S39141787312009120800000) )
15. CONNECT FRONT HEIGHT CONTROL SENSOR SUB-ASSEMBLY LH (See «INSTALLATION»(ref-349722-S36481182872009120800000) )
16. INSTALL STEERING KNUCKLE SUB-ASSEMBLY LH (See «INSTALLATION»(ref-349749-S19109048572009120800000) )
17. CONNECT FRONT NO. 1 SUSPENSION UPPER ARM ASSEMBLY LH (See «INSTALLATION»(ref-349749-S19109048572009120800000) )
18. CONNECT FRONT NO. 2 SUSPENSION UPPER ARM ASSEMBLY LH (See «INSTALLATION»(ref-349749-S19109048572009120800000) )
19. CONNECT TIE ROD ASSEMBLY LH (See «INSTALLATION»(ref-349733-S30676435532009120800000) )
20. INSTALL FRONT SPEED SENSOR LH (See «INSTALLATION»(ref-349749-S19109048572009120800000) )
21. CONNECT SKID CONTROL SENSOR WIRE (See «INSTALLATION»(ref-349749-S19109048572009120800000) )
22. INSTALL FRONT DISC BRAKE DUST COVER LH (See «INSTALLATION»(ref-349749-S39253153892009120800000) )
23. INSTALL FRONT DISC (See «INSTALLATION»(ref-349719-S33447390982009120800000) )
24. CONNECT FRONT DISC BRAKE CALIPER ASSEMBLY LH (See «INSTALLATION»(ref-349749-S39253153892009120800000) )
25. INSTALL FRONT AXLE SHAFT NUT LH (See «INSTALLATION»(ref-349722-S15655817482009120800000) )
26. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
27. PERFORM INITIALIZATION Perform the initialization (See «INITIALIZATION»(ref-349706-S07943075812009120800000) ). NOTE: Certain systems need to be initialized after disconnecting and reconnecting the cable from the negative (-) battery terminal.
28. STABILIZE SUSPENSION (See «INSTALLATION»(ref-349722-S36481182872009120800000) )
29. TIGHTEN FRONT NO. 1 SUSPENSION UPPER ARM ASSEMBLY LH Tighten the installation nut of the front No. 1 suspension upper arm assembly LH. Torque: 50 N*m (510 kgf*cm, 37 ft.*lbf)
30. TIGHTEN FRONT NO. 2 SUSPENSION UPPER ARM ASSEMBLY LH Tighten the installation nut of the front No. 2 suspension upper arm assembly LH. Torque: 50 N*m (510 kgf*cm, 37 ft.*lbf)
31. TIGHTEN LOWER FRONT SHOCK ABSORBER BRACKET SUB-ASSEMBLY LH (See «INSTALLATION»(ref-349722-S36481182872009120800000) )
32. INSTALL FRONT WHEEL (See «INSTALLATION»(ref-349722-S36481182872009120800000) )
33. INSPECT AND ADJUST FRONT WHEEL ALIGNMENT Inspect and adjust the front wheel alignment (See «ADJUSTMENT»(ref-349722-S22766536012009120800000) ).
34. CHECK SUSPENSION CONTROL SYSTEM Check the suspension control system (See «SUSPENSION CONTROL SYSTEM»(ref-349750-S33159283862009120800000) ).
35. INSPECT FOR AIR LEAK Inspect for air leak (See «OPERATION CHECK»(ref-349750-S12258921322009120800000) ).
36. ADJUST VEHICLE HEIGHT Adjust the vehicle height (See «ADJUSTMENT»(ref-349750-S01070563512009120800000) ).
37. ADJUST HEADLIGHT ASSEMBLY Adjust the headlight assembly (See «ADJUSTMENT»(ref-349731-S09246046722009120800000) ).

Scheme 94

Scheme 95

Scheme 96

1. INSPECT FRONT LOWER SUSPENSION ARM BALL JOINT RATTLE Jack up the vehicle. Move the front No. 1 suspension lower arm up and down by hand, and check for rattle. OK: No rattle.

HINT

1. Use the same procedures for the RH side and LH side.
2. The procedures listed below are for the LH side.

Scheme 97

Scheme 98

Scheme 99

Scheme 100

Scheme 101

Scheme 102

1. PLACE FRONT WHEELS FACING STRAIGHT AHEAD
2. REMOVE COWL TOP VENTILATOR LOUVER LH (See «REMOVAL»(ref-349732-S04425564642009120800000) )
3. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL (See «REMOVAL»(ref-349733-S36942300362009120800000) )
4. REMOVE FRONT WHEELS
5. REMOVE NO. 1 ENGINE UNDER COVER (See «COOLANT»(ref-349716-S00642260722009120800000) )
6. REMOVE FRONT SUSPENSION MEMBER PROTECTOR LOWER (See «REMOVAL»(ref-349714-S31912998822009120800000) )
7. REMOVE NO. 2 ENGINE UNDER COVER (See «REMOVAL»(ref-349714-S31912998822009120800000) )
8. DISCONNECT STEERING SLIDING YOKE WITH SHAFT SUB-ASSEMBLY (See «REMOVAL»(ref-349720-S38166401772009120800000) )
9. DISCONNECT TIE ROD ASSEMBLY LH (See «REMOVAL»(ref-349733-S36942300362009120800000) )
10. DISCONNECT TIE ROD ASSEMBLY RH (See «REMOVAL»(ref-349733-S36942300362009120800000) )
11. REMOVE POWER STEERING LINK ASSEMBLY (See «REMOVAL»(ref-349733-S36942300362009120800000) )
12. DISCONNECT SPEED SENSOR CONNECTOR (See «REMOVAL»(ref-349749-S38905054652009120800000) )
13. DISCONNECT FRONT DISC BRAKE CALIPER ASSEMBLY LH (See «REMOVAL»(ref-349749-S38905054652009120800000) )
14. REMOVE FRONT DISC (See «REMOVAL»(ref-349719-S21827681662009120800000) )
15. REMOVE FRONT DISC BRAKE DUST COVER LH (See «REMOVAL»(ref-349749-S38905054652009120800000) )
16. REMOVE FRONT NO. 1 SUSPENSION LOWER ARM ASSEMBLY LH Remove the clip and nut. Install 2 spacers (SST spacer A) onto the front No. 1 suspension lower arm assembly LH so that there is a space of approximately 1 mm (0.0394 in.) between the arm and spacers. SST 09960-20010(09961-02050) NOTE: Make sure to install the spacers (SST spacer A) as the steering knuckle spacer may shift. As SST may become damaged, make sure the space between the arm and spacers is not 1 mm (0.0394 in.) or less. Using SST, disconnect the front No. 1 suspension lower arm assembly LH from the steering knuckle. SST 09960-20010 (09961 -02010) NOTE: Do not damage the dust cover of the lower arm No. 1. As the dust cover may be damaged, adjust SST with the center nut so that the body and crow are parallel. Make sure to tie the string of SST to the vehicle, to prevent SST from dropping. Remove the bolt and nut, and then remove the No. 1 suspension lower arm LH.
17. DISCONNECT FRONT HEIGHT CONTROL SENSOR SUB-ASSEMBLY LH Remove the bolt, and then remove the bracket of the front height control sensor LH.
18. REMOVE FRONT STABILIZER LINK ASSEMBLY LH Remove the 2 nuts and front stabilizer link assembly LH. HINT: If the stud bolt turns with the nut, use a 6 mm hexagon wrench to hold the stud.
19. REMOVE FRONT NO. 2 SUSPENSION LOWER ARM ASSEMBLY LH Support the steering knuckle LH with a jack and wooden block. Remove the bolt and nut, and then disconnect the bottom side of the pneumatic front LH with shock absorber cylinder assembly from the front No. 2 suspension lower arm LH. Remove the nut and clip. Install 2 spacers (SST spacer A) onto the front No. 2 suspension lower arm assembly LH so that there is a space of approximately 1 mm (0.0394 in.) between the arm and spacers. SST 09960-20010(09961-02050) NOTE: Make sure to install the spacers (SST spacer A) as the steering knuckle spacer may shift. As SST may become damaged, make sure the space between the arm and spacers is not 1 mm (0.0394 in.) or less. Using SST, disconnect the front No. 2 suspension lower arm assembly LH from the steering knuckle. SST 09960-20010 (09961 -02010) NOTE: Do not damage the dust cover of the No. 2 lower arm. As the dust cover may be damaged, adjust SST with the center nut so that the body and crow are parallel. Make sure to tie the string of SST to the vehicle, to prevent SST from dropping. Remove the bolt and nut, and then remove the No. 2 suspension lower arm LH.

Scheme 103

1. INSPECT FRONT NO. 1 SUSPENSION LOWER ARM ASSEMBLY LH Temporarily install the nut, and flip the ball joint stud back and forth 5 times as shown in the illustration. Use a torque wrench to turn the nut continuously at a rate of 3 to 5 seconds per turn. Take the torque reading on the fifth turn. Standard turning torque: 3.0 N*m (31 kgf*cm, 27 in.*lbf)

HINT

1. Use the same procedures for the RH side and LH side.
2. The procedures listed below are for the LH side.
3. A bolt without a torque specification is shown in the standard bolt chart (see «SPECIFIED TORQUE FOR STANDARD BOLTS»(ref-349708-S13378942112009120800000) ).

Scheme 104

Scheme 105

Scheme 106

Scheme 107

1. TEMPORARILY TIGHTEN FRONT NO. 2 SUSPENSION LOWER ARM ASSEMBLY LH Insert the bolt from the front of the vehicle. Then temporarily install the front No. 2 suspension lower arm LH with the nut. HINT: Tighten the nut after the vehicle is stabilized. Temporarily install the front No. 2 suspension lower arm LH to the steering knuckle with the nut. HINT: Tighten the nut after the vehicle is stabilized. Install the bottom side of the pneumatic front LH with shock absorber cylinder assembly to the No. 2 suspension lower arm LH. Then insert the bolt from the rear of the vehicle and temporarily install it with the nut. HINT: Tighten the bolt after the vehicle is stabilized.
2. INSTALL FRONT STABILIZER LINK ASSEMBLY LH Install the front stabilizer link with the 2 nuts. Torque: 84 N*m (857 kgf*cm, 62 ft.*lbf) HINT: If the ball joint turns together with the nut, use a 6 mm hexagon wrench to hold the stud.
3. CONNECT FRONT HEIGHT CONTROL SENSOR SUB-ASSEMBLY LH Install the bracket of the front height control sensor LH to the front No. 2 suspension lower arm LH with the bolt. Torque: 5.4 N*m (55 kgf*cm, 48 in.*lbf)
4. TEMPORARILY TIGHTEN FRONT NO. 1 SUSPENSION LOWER ARM ASSEMBLY LH Insert the bolt from the back of the vehicle. Temporarily install the front No. 1 suspension lower arm LH with the nut. HINT: Tighten the nut after the vehicle is stabilized. Temporarily install the front No. 1 suspension lower arm LH to the steering knuckle with the nut. HINT: Tighten the nut after the vehicle is stabilized.
5. INSTALL FRONT DISC BRAKE DUST COVER LH (See «INSTALLATION»(ref-349749-S39253153892009120800000) )
6. INSTALL FRONT DISC (See «INSTALLATION»(ref-349719-S33447390982009120800000) )
7. CONNECT FRONT DISC BRAKE CALIPER ASSEMBLY LH (See «INSTALLATION»(ref-349749-S39253153892009120800000) )
8. CONNECT SPEED SENSOR CONNECTOR (See «INSTALLATION»(ref-349749-S39253153892009120800000) )
9. INSTALL POWER STEERING LINK ASSEMBLY (See «INSTALLATION»(ref-349733-S30676435532009120800000) )
10. CONNECT TIE ROD ASSEMBLY LH (See «INSTALLATION»(ref-349733-S30676435532009120800000) )
11. CONNECT TIE ROD ASSEMBLY RH (See «INSTALLATION»(ref-349733-S30676435532009120800000) )
12. CONNECT STEERING SLIDING YOKE WITH SHAFT SUB-ASSEMBLY (See «INSTALLATION»(ref-349720-S01586454122009120800000) )
13. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
14. INSTALL COWL TOP VENTILATOR LOUVER RH (See «INSTALLATION»(ref-349732-S09051375432009120800000) )
15. STABILIZE SUSPENSION (w/o Air Suspension) (See «INSTALLATION»(ref-349722-S25641696382009120800000) )
16. STABILIZE SUSPENSION (w/ Air Suspension) (See «INSTALLATION»(ref-349722-S36481182872009120800000) )
17. TIGHTEN FRONT NO. 2 SUSPENSION LOWER ARM ASSEMBLY LH Tighten the installation nut of the front No. 2 suspension lower arm assembly LH. Torque: 145 N*m (1479 kgf*cm, 107 ft.*lbf) Tighten the installation nut of the steering knuckle. Torque: 145 N*m (1479 kgf*cm, 107 ft.*lbf) NOTE: If it is necessary to align the holes for the clips after installing the nuts, the nuts can be tightened up to 60° more. Install a new clip. Tighten the installation bolt of the shock absorber cylinder. Torque: 108 N*m (1101 kgf*cm, 80 ft.*lbf)
18. TIGHTEN FRONT NO. 1 SUSPENSION LOWER ARM ASSEMBLY LH Tighten the installation nut of the front No. 1 suspension upper arm assembly LH. Torque: 145 N*m (1479 kgf*cm, 107 ft.*lbf) Tighten the installation nut of the steering knuckle side. Torque: 145 N*m (1479 kgf*cm, 107 ft.*lbf) NOTE: If it is necessary to align the holes for the clips after installing the nuts, the nuts can be tightened up to 60° more. Install a new clip.
19. INSTALL FRONT WHEELS
20. INSTALL NO. 2 ENGINE UNDER COVER (See «INSTALLATION»(ref-349714-S23488176532009120800000) )
21. INSTALL FRONT SUSPENSION MEMBER PROTECTOR LOWER (See «INSTALLATION»(ref-349714-S23488176532009120800000) )
22. INSTALL NO. 1 ENGINE UNDER COVER (See «REPLACEMENT»(ref-349716-S35220647352009120800000) )
23. PLACE FRONT WHEELS FACING STRAIGHT AHEAD
24. INSPECT AND ADJUST FRONT WHEEL ALIGNMENT Inspect and adjust the front wheel alignment (see «ADJUSTMENT»(ref-349722-S12260449942009120800000) ).
25. INITIALIZE ROTATION ANGLE SENSOR AND CALIBRATE TORQUE SENSOR ZERO POINT (See «CALIBRATION»(ref-349733-S15208904932009120800000) )
26. PERFORM INITIALIZATION Perform the initialization (see «INITIALIZATION»(ref-349706-S07943075812009120800000) ).
27. VEHICLE PREPARATION FOR HEADLIGHT AIMING ADJUSTMENT (See «ADJUSTMENT»(ref-349731-S09246046722009120800000) )
28. PREPARATION FOR HEADLIGHT AIMING (Using a screen) (See «ADJUSTMENT»(ref-349731-S09246046722009120800000) )
29. HEADLIGHT AIMING INSPECTION (See «ADJUSTMENT»(ref-349731-S09246046722009120800000) )
30. HEADLIGHT AIMING ADJUSTMENT (See «ADJUSTMENT»(ref-349731-S09246046722009120800000) )

Scheme 108

Scheme 109

HINT

Scheme 110

1. Use the same procedures for the RH side and LH side.
2. The procedures listed below are for the LH side.

Scheme 111

Scheme 112

Scheme 113

Scheme 114

Scheme 115

Scheme 116

Scheme 117

Scheme 118

1. REMOVE FRONT WHEEL
2. REMOVE FRONT AXLE SHAFT NUT LH Using SST and a hammer, release the staked part of the front axle shaft nut. SST 09930-00010 NOTE: Release the staked part of the nut completely, otherwise the threads of the drive shaft may be damaged. While applying the brakes, remove the front axle shaft nut.
3. DISCONNECT FRONT DISC BRAKE CALIPER ASSEMBLY LH (See «REMOVAL»(ref-349749-S15701984032009120800000) )
4. REMOVE FRONT DISC (See «REMOVAL»(ref-349719-S21827681662009120800000) )
5. REMOVE FRONT DISC BRAKE DUST COVER LH (See «REMOVAL»(ref-349749-S15701984032009120800000) )
6. DISCONNECT FRONT HEIGHT CONTROL SENSOR SUB-ASSEMBLY LH (See «REMOVAL»(ref-349722-S17020118902009120800000) )
7. REMOVE FRONT NO. 2 SUSPENSION LOWER ARM LH Remove the clip and nut. Install 2 spacers (SST spacer A) onto the front No. 2 suspension lower arm LH so that there is a space of approximately 1 mm (0.0394 in.) between the arm and spacers. SST 09960-20010(09961-02050) NOTE: Make sure to install the spacers (SST spacer A) as the steering knuckle spacer may shift. As SST may become damaged, make sure the space between the arm and spacers is not less than 1 mm (0.0394 in.). Using SST, disconnect the front No. 2 suspension lower arm LH from the front lower ball joint assembly LH. SST 09960-20010 (09961 -02010) NOTE: Do not damage the dust cover of the lower arm No. 2. As the dust cover may be damaged, adjust SST with the center nut so that the body and claw are parallel. Make sure to tie the string of SST to the vehicle to prevent SST from dropping. Put matchmarks on the front suspension toe adjusting cam and front frame assembly. Put matchmarks on the front suspension No. 2 toe adjusting plate and front frame assembly. Remove the nut, front suspension No. 2 toe adjusting plate and bolt. Remove the front suspension toe adjusting cam and the front suspension lower arm LH.
8. DISCONNECT SKID CONTROL SENSOR WIRE (See «REMOVAL»(ref-349749-S15701984032009120800000) )
9. REMOVE FRONT SPEED SENSOR LH (See «REMOVAL»(ref-349749-S15701984032009120800000) )
10. DISCONNECT TIE ROD ASSEMBLY LH (See «REMOVAL»(ref-349749-S15701984032009120800000) )
11. DISCONNECT FRONT NO. 1 SUSPENSION UPPER ARM ASSEMBLY LH (See «REMOVAL»(ref-349749-S15701984032009120800000) )
12. DISCONNECT FRONT NO. 2 SUSPENSION UPPER ARM ASSEMBLY LH (See «REMOVAL»(ref-349749-S15701984032009120800000) )
13. REMOVE STEERING KNUCKLE LH (See «REMOVAL»(ref-349749-S15701984032009120800000) )
14. REMOVE FRONT LOWER BALL JOINT ASSEMBLY LH Remove the clip and nut. Install 2 spacers (SST spacer A) onto the front lower ball joint assembly LH so that there is a space of approximately 1 mm (0.0394 in.) between the arm and spacers. SST 09960-20010 (09961-02050) NOTE: Make sure to install the spacers (SST spacer A) as the steering knuckle spacer may shift. As SST may become damaged, make sure the space between the arm and spacers is not less than 1 mm (0.0394 in.). Using SST, disconnect the front No. 2 suspension lower arm assembly LH from the steering knuckle. SST 09960-20010(09961-02010) NOTE: Do not damage the dust cover of the lower arm. As the dust cover may be damaged, adjust SST with the center nut so that the body and claw are parallel. Make sure to tie the string of SST to the vehicle to prevent SST from dropping.
15. REMOVE FRONT STABILIZER LINK ASSEMBLY LH (See «REMOVAL»(ref-349722-S25719349322009120800000) )
16. DISCONNECT LOWER FRONT SHOCK ABSORBER BRACKET SUB-ASSEMBLY LH Remove the nut and front shock absorber upper bracket plate, and disconnect the front shock absorber lower bracket from the front suspension lower arm LH.
17. REMOVE FRONT SUSPENSION LOWER ARM ASSEMBLY LH Put matchmarks on the camber adjusting cam and front frame assembly. Put matchmarks on the No. 2 camber adjusting cam and front frame assembly. Remove the nut and No. 2 camber adjusting cam. Remove the camber adjusting cam and front suspension lower arm LH.

HINT

1. Use the same procedures for the RH side and LH side.
2. The procedures listed below are for the LH side.
3. A bolt without a torque specification is shown in the standard bolt chart (see «SPECIFIED TORQUE FOR STANDARD BOLTS»(ref-349708-S13378942112009120800000) ).

Scheme 119

Scheme 120

Scheme 121

Scheme 122

Scheme 123

Scheme 124

Scheme 125

Scheme 126

1. TEMPORARILY INSTALL FRONT SUSPENSION LOWER ARM ASSEMBLY LH Temporarily install the front suspension lower arm LH, and insert the camber adjusting cam from the rear of the vehicle. Install the No. 2 camber adjusting cam and temporarily install the nut. HINT: After stabilizing the suspension, tighten the nut. Align the matchmarks of the camber adjusting cam, No. 2 camber adjusting cam and front frame assembly.
2. CONNECT LOWER FRONT SHOCK ABSORBER BRACKET SUB-ASSEMBLY LH Connect the front shock absorber lower bracket to the front suspension lower arm LH. Align the protrusion of the front shock absorber upper bracket plate with the cutout of the front shock absorber lower bracket, and temporarily install the plate with the nut. HINT: After stabilizing the suspension, tighten the nut.
3. INSTALL FRONT STABILIZER LINK ASSEMBLY LH (See «INSTALLATION»(ref-349722-S39141787312009120800000) )
4. INSTALL FRONT LOWER BALL JOINT ASSEMBLY LH Install the front lower ball joint LH to the front suspension lower arm with the nut. Torque: 145 N*m (1479 kgf*cm, 107 ft.*lbf) NOTE: If it is necessary to align the holes for the clips after installing the nuts, the nuts can be tightened up to 60° more. Install a new clip.
5. INSTALL STEERING KNUCKLE LH (See «INSTALLATION»(ref-349749-S19109048572009120800000) )
6. CONNECT FRONT NO. 1 SUSPENSION UPPER ARM ASSEMBLY LH (See «INSTALLATION»(ref-349749-S19109048572009120800000) )
7. CONNECT FRONT NO. 2 SUSPENSION UPPER ARM ASSEMBLY LH (See «INSTALLATION»(ref-349749-S19109048572009120800000) )
8. CONNECT TIE ROD ASSEMBLY LH (See «INSTALLATION»(ref-349733-S30676435532009120800000) )
9. INSTALL FRONT SPEED SENSOR LH (See «INSTALLATION»(ref-349749-S19109048572009120800000) )
10. CONNECT SKID CONTROL SENSOR WIRE (See «INSTALLATION»(ref-349749-S19109048572009120800000) )
11. TEMPORARILY INSTALL FRONT NO. 2 SUSPENSION LOWER ARM LH Temporarily install the front No. 2 suspension lower arm LH, and insert the toe adjusting cam from the rear of the vehicle. Install the bolt, No. 2 toe adjusting plate and temporarily install the nut. HINT: After stabilizing the suspension, tighten the nut. Align the matchmarks of the camber adjusting cam, No. 2 camber adjusting cam and front frame assembly. Connect the front suspension lower arm LH to the front lower ball joint with the nut. Torque: 145 N*m (1479 kgf*cm, 107 ft.*lbf) NOTE: If it is necessary to align the holes for the clips after installing the nuts, the nuts can be tightened up to 60° more. Install a new clip.
12. CONNECT FRONT HEIGHT CONTROL SENSOR SUB-ASSEMBLY LH (See «INSTALLATION»(ref-349722-S36481182872009120800000) )
13. INSTALL FRONT DISC BRAKE DUST COVER LH (See «INSTALLATION»(ref-349749-S39253153892009120800000) )
14. INSTALL FRONT DISC (See «INSTALLATION»(ref-349719-S33447390982009120800000) )
15. CONNECT FRONT DISC BRAKE CALIPER ASSEMBLY LH (See «INSTALLATION»(ref-349749-S39253153892009120800000) )
16. INSTALL FRONT AXLE SHAFT NUT LH Clean the threaded parts on the drive shaft and axle shaft nut using a non-residue solvent. NOTE: Be sure to perform this work for a new drive shaft. Keep the threaded parts free of oil and foreign objects. Using a 30 mm socket wrench, install a new axle shaft nut. Torque: 294 N*m (2998 kgf*cm, 217 ft.*lbf) Using a chisel and hammer, stake the front axle shaft nut.
17. STABILIZE SUSPENSION (See «INSTALLATION»(ref-349722-S36481182872009120800000) )
18. TIGHTEN FRONT SUSPENSION LOWER ARM ASSEMBLY LH Tighten the nut of the front No. 2 suspension lower arm LH. Torque: 210 N*m (2141 kgf*cm, 155 ft.*lbf) NOTE: Tighten the nut while making sure that the marks are aligned.
19. TIGHTEN FRONT SHOCK ABSORBER LOWER BRACKET SUB-ASSEMBLY LH Tighten the nut of the lower front shock absorber bracket. Torque: 112 N*m (1142 kgf*cm, 83 ft.*lbf)
20. TIGHTEN FRONT NO. 2 SUSPENSION LOWER ARM LH Tighten the nut of the front No. 2 suspension lower arm LH. Torque: 210 N*m (2141 kgf*cm, 155 ft.*lbf) NOTE: Tighten the nut while making sure that the marks are aligned.
21. INSTALL FRONT WHEEL Torque: 140 N*m (1428 kgf*cm, 103 ft.*lbf)
22. INSPECT AND ADJUST FRONT WHEEL ALIGNMENT Inspect and adjust the front wheel alignment (see «ADJUSTMENT»(ref-349722-S12260449942009120800000) ).
23. CHECK SUSPENSION CONTROL SYSTEM Check the suspension control system (see «OPERATION CHECK»(ref-349750-S12258921322009120800000) ).
24. ADJUST HEADLIGHT ASSEMBLY Adjust the headlight assembly (see «ADJUSTMENT»(ref-349731-S09246046722009120800000) ).

Scheme 127

HINT

1. Use the same procedures for the RH side and LH side.
2. The procedures listed below are for the LH side.

1. REMOVE FRONT WHEEL
2. REMOVE FRONT AXLE SHAFT NUT LH (See «REMOVAL»(ref-349722-S31983009762009120800000) )
3. REMOVE FRONT DISC BRAKE CALIPER ASSEMBLY LH (See «REMOVAL»(ref-349749-S15701984032009120800000) )
4. REMOVE FRONT DISC (See «REMOVAL»(ref-349719-S21827681662009120800000) )
5. REMOVE FRONT DISC BRAKE DUST COVER LH (See «REMOVAL»(ref-349749-S15701984032009120800000) )
6. DISCONNECT FRONT HEIGHT CONTROL SENSOR SUB-ASSEMBLY LH (See «REMOVAL»(ref-349722-S17020118902009120800000) )
7. DISCONNECT FRONT NO. 2 SUSPENSION LOWER ARM LH Remove the clip and nut. Install 2 spacers (SST spacer A) onto the front No. 2 suspension lower arm LH so that there is a space of approximately 1 mm (0.0394 in.) between the arm and spacers. SST 09960-20010(09961-02050) NOTE: Make sure to install the spacers (SST spacer A) as the steering knuckle spacer may shift. As SST may become damaged, make sure the space between the arm and spacers is not less than 1 mm (0.0394 in.). Using SST, disconnect the front No. 2 suspension lower arm LH from the front lower ball joint assembly LH. SST 09960-20010 (09961 -02010) NOTE: Do not damage the dust cover of the No. 2 lower arm. As the dust cover may be damaged, adjust SST with the center nut so that the body and claw are parallel. Make sure to tie the string of SST to the vehicle to prevent SST from dropping.
8. DISCONNECT SKID CONTROL SENSOR WIRE (See «REMOVAL»(ref-349749-S15701984032009120800000) )
9. REMOVE FRONT SPEED SENSOR LH (See «REMOVAL»(ref-349749-S15701984032009120800000) )
10. DISCONNECT TIE ROD ASSEMBLY LH (See «REMOVAL»(ref-349749-S15701984032009120800000) )
11. DISCONNECT FRONT NO. 1 SUSPENSION UPPER ARM ASSEMBLY LH (See «REMOVAL»(ref-349749-S15701984032009120800000) )
12. DISCONNECT FRONT NO. 2 SUSPENSION UPPER ARM ASSEMBLY LH (See «REMOVAL»(ref-349749-S15701984032009120800000) )
13. REMOVE STEERING KNUCKLE SUB-ASSEMBLY LH (See «REMOVAL»(ref-349749-S15701984032009120800000) )
14. REMOVE FRONT LOWER BALL JOINT ASSEMBLY LH Remove the clip and nut. Install 2 spacers (SST spacer A) onto the front lower ball joint assembly LH so that there is a space of approximately 1 mm (0.0394 in.) between the arm and spacers. SST 09960-20010(09961-02050) NOTE: Make sure to install the spacers (SST spacer A) as the steering knuckle spacer may shift. As SST may become damaged, make sure the space between the arm and spacers is not less than 1 mm (0.0394 in.). Using SST, disconnect the lower ball joint from the lower arm. SST 09960-20010 (09961 -02010) NOTE: Do not damage the dust cover of the lower ball joint. As the dust cover may be damaged, adjust SST with the center nut so that the body and claw are parallel. Make sure to tie the string of SST to the vehicle to prevent SST from dropping.

Scheme 128

1. INSPECT FRONT LOWER BALL JOINT ASSEMBLY Inspect the turning of the front lower ball joint. Flip the ball joint stud back and forth 5 times as shown in the illustration. Temporarily install the nut, and use a torque wrench to turn the nut continuously at a rate of 3 to 5 seconds per turn. Take the torque reading on the 5th turn. Standard turning torque: 6.0 N*m (61.1 kgf*cm, 53.1 in.*lbf) or less If the result is not as specified, replace the front lower ball joint assembly. Check the dust boot for cracks or grease leakage.

HINT

1. Use the same procedures for the RH side and LH side.
2. The procedures listed below are for the LH side.
3. A bolt without a torque specification is shown in the standard bolt chart (see «SPECIFIED TORQUE FOR STANDARD BOLTS»(ref-349708-S13378942112009120800000) ).

Scheme 129

Scheme 130

1. INSTALL FRONT LOWER BALL JOINT ASSEMBLY LH Install the front lower ball joint LH to the front suspension lower arm with the nut. Torque: 145 N*m (1479 kgf*cm, 107 ft.*lbf) NOTE: If it is necessary to align the holes for the clips after installing the nuts, the nuts can be tightened up to 60° more. Install a new clip.
2. INSTALL STEERING KNUCKLE SUB-ASSEMBLY LH (See «INSTALLATION»(ref-349749-S19109048572009120800000) )
3. CONNECT FRONT NO. 1 SUSPENSION UPPER ARM ASSEMBLY LH (See «INSTALLATION»(ref-349749-S19109048572009120800000) )
4. CONNECT FRONT NO. 2 SUSPENSION UPPER ARM ASSEMBLY LH (See «INSTALLATION»(ref-349749-S19109048572009120800000) )
5. CONNECT TIE ROD ASSEMBLY LH (See «INSTALLATION»(ref-349733-S30676435532009120800000) )
6. INSTALL FRONT SPEED SENSOR LH (See «INSTALLATION»(ref-349749-S19109048572009120800000) )
7. CONNECT SKID CONTROL SENSOR WIRE (See «INSTALLATION»(ref-349749-S19109048572009120800000) )
8. CONNECT FRONT NO. 2 SUSPENSION LOWER ARM LH Connect the front suspension lower arm LH to the front lower ball joint with the nut. Torque: 145 N*m (1479 kgf*cm, 107 ft.*lbf) NOTE: If it is necessary to align the holes for the clips after installing the nuts, the nuts can be tightened up to 60° more. Install a new clip.
9. CONNECT FRONT HEIGHT CONTROL SENSOR SUB-ASSEMBLY LH (See «INSTALLATION»(ref-349722-S36481182872009120800000) )
10. INSTALL FRONT DISC BRAKE DUST COVER LH (See «INSTALLATION»(ref-349749-S39253153892009120800000) )
11. INSTALL FRONT DISC (See «INSTALLATION»(ref-349719-S33447390982009120800000) )
12. INSTALL FRONT DISC BRAKE CALIPER ASSEMBLY LH (See «INSTALLATION»(ref-349749-S39253153892009120800000) )
13. INSTALL FRONT AXLE SHAFT NUT LH (See «INSTALLATION»(ref-349722-S15655817482009120800000) )
14. INSTALL FRONT WHEEL Torque: 140 N*m (1428 kgf*cm, 103 ft.*lbf)
15. INSPECT AND ADJUST FRONT WHEEL ALIGNMENT Inspect and adjust the front wheel alignment (see «ADJUSTMENT»(ref-349722-S12260449942009120800000) ).
16. CHECK SUSPENSION CONTROL SYSTEM Check the suspension control system (see «OPERATION CHECK»(ref-349750-S12258921322009120800000) ).
17. ADJUST HEADLIGHT ASSEMBLY Adjust the headlight assembly (see «ADJUSTMENT»(ref-349731-S09246046722009120800000) ).

Scheme 131

Scheme 132

Scheme 133

Scheme 134

Scheme 135

Scheme 136

1. REMOVE FRONT WHEEL
2. REMOVE NO. 2 ENGINE UNDER COVER Remove the 8 bolts and the No. 2 engine under cover.
3. REMOVE FRONT STABILIZER LINK ASSEMBLY LH Remove the 2 nuts and the front stabilizer link. HINT: If the ball joint turns together with the nut, use a 6 mm hexagon wrench to hold the stud.
4. REMOVE FRONT STABILIZER LINK ASSEMBLY RH HINT: Remove the RH side following the same procedures as the LH side.
5. REMOVE ENGINE UNDER COVER SUB-ASSEMBLY LH Remove the 2 screws and the engine under cover sub-assembly LH from the front suspension member reinforcement LH.
6. REMOVE ENGINE UNDER COVER SUB-ASSEMBLY RH HINT: Remove the RH side following the same procedures as the LH side.
7. REMOVE ENGINE UNDER COVER REAR LH Remove the 2 screws and the engine under cover rear LH.
8. REMOVE ENGINE UNDER COVER REAR RH HINT: Remove the RH side following the same procedures as the LH side.
9. REMOVE FRONT NO. 1 STABILIZER BRACKET LH Remove the 2 bolts and the front No. 1 stabilizer bracket LH from the front suspension crossmember.
10. REMOVE FRONT NO. 1 STABILIZER BRACKET RH HINT: Remove the RH side following the same procedures as the LH side.
11. REMOVE FRONT STABILIZER BAR Remove the front stabilizer bar from the vehicle.
12. REMOVE FRONT NO. 1 STABILIZER BAR BUSH Remove the 2 front No. 1 stabilizer bar bushes from the front stabilizer bar.
13. REMOVE FRONT SUSPENSION MEMBER REINFORCEMENT LH Remove the 4 bolts and front suspension member reinforcement LH from the vehicle.
14. REMOVE FRONT SUSPENSION MEMBER REINFORCEMENT RH HINT: Remove the RH side following the same procedures as the LH side.

Scheme 137

1. INSPECT FRONT STABILIZER LINK ASSEMBLY Flip the ball joint stud back and forth 5 times as shown in the illustration. Temporarily install the nut, use a torque wrench to turn the nut continuously at a rate of 2 to 4 seconds per turn. Take the torque reading on the 5th turn. Standard turning torque: 1.96 N*m (20 kgf*cm, 17 in.*lbf) or less If the value is not within the specified range, replace the rear suspension toe control link with a new one. Check the dust boot for cracks or grease leakage.

HINT

A bolt without a torque specification is shown in the standard bolt chart (see SPECIFIED TORQUE FOR STANDARD BOLTS ).

Scheme 138

Scheme 139

Scheme 140

Scheme 141

1. INSTALL FRONT SUSPENSION MEMBER REINFORCEMENT LH Install the front suspension member reinforcement LH to the vehicle with the 4 bolts. Torque: 50 N*m (510 kgf*cm, 37 ft.*lbf)
2. INSTALL FRONT SUSPENSION MEMBER REINFORCEMENT RH HINT: Install the RH side following the same procedures as the LH side.
3. INSTALL FRONT NO. 1 STABILIZER BAR BUSH Install the 2 front No. 1 stabilizer bar bushes outside of the bush stoppers on the front stabilizer bar as shown in the illustration. NOTE: Be sure to install the front No. 1 stabilizer bar bushes so that the cutouts face the front of the vehicle.
4. TEMPORARILY TIGHTEN FRONT STABILIZER BAR Temporarily install the front stabilizer bar with the 4 bolts and the front No. 1 stabilizer bracket LH and RH. NOTE: Install the front stabilizer bar so that the identification mark face vehicle right side.
5. TIGHTEN FRONT NO. 1 STABILIZER BRACKET LH Tighten the front No. 1 stabilizer bracket LH with the 2 bolts. Torque: 49 N*m (500 kgf*cm, 36 ft.*lbf)
6. TIGHTEN FRONT NO. 1 STABILIZER BRACKET RH HINT: Install the RH side following the same procedures as the LH side.
7. INSTALL ENGINE UNDER COVER REAR LH Install the engine under cover rear LH with the 2 screws.
8. INSTALL ENGINE UNDER COVER REAR RH HINT: Install the RH side following the same procedures as the LH side.
9. INSTALL ENGINE UNDER COVER SUB-ASSEMBLY LH Install the engine under cover sub-assembly LH with the 2 screws.
10. INSTALL ENGINE UNDER COVER SUB-ASSEMBLY RH HINT: Install the RH side following the same procedures as the LH side.
11. INSTALL FRONT STABILIZER LINK ASSEMBLY LH Install the front stabilizer link with the 2 nuts. Torque: 84 N*m (857 kgf*cm, 62 ft.*lbf) HINT: If the ball joint turns together with the nut, use a 6 mm hexagon wrench to hold the stud.
12. INSTALL FRONT STABILIZER LINK ASSEMBLY RH HINT: Install the RH side following the same procedures as the LH side.
13. INSTALL NO. 2 ENGINE UNDER COVER Install the No. 2 engine under cover with the 8 bolts. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf) (for bolt A) 27 N*m (275 kgf*cm, 20 ft.*lbf) (for bolt B)
14. INSTALL FRONT WHEEL
15. INSPECT AND ADJUST FRONT WHEEL ALIGNMENT (See «INSTALLATION»(ref-349722-S36481182872009120800000) )
16. VEHICLE PREPARATION FOR HEADLIGHT AIMING ADJUSTMENT (See «ADJUSTMENT»(ref-349731-S09246046722009120800000) )
17. PREPARATION FOR HEADLIGHT AIMING (Using a screen) (See «ADJUSTMENT»(ref-349731-S09246046722009120800000) )
18. HEADLIGHT AIMING INSPECTION (See «ADJUSTMENT»(ref-349731-S09246046722009120800000) )
19. HEADLIGHT AIMING ADJUSTMENT (See «ADJUSTMENT»(ref-349731-S09246046722009120800000) )

Scheme 142

Scheme 143

Scheme 144

Scheme 145

1. REMOVE FRONT CENTER FLOOR COVER (See «REMOVAL»(ref-349714-S10589957032009120800000) )
2. REMOVE NO. 2 ENGINE UNDER COVER (See «REMOVAL»(ref-349714-S10589957032009120800000) )
3. REMOVE FRONT WHEEL OPENING EXTENSION PAD LH (See «REMOVAL»(ref-349736-S30791494642009120800000) )
4. REMOVE FRONT WHEEL OPENING EXTENSION PAD RH (See «REMOVAL»(ref-349736-S30791494642009120800000) )
5. REMOVE NO. 1 ENGINE UNDER COVER (See «COOLANT»(ref-349716-S00642260722009120800000) )
6. REMOVE FRONT LOWER SUSPENSION MEMBER PROTECTOR (See «REMOVAL»(ref-349714-S10589957032009120800000) )
7. REMOVE FRONT STABILIZER LINK ASSEMBLY LH Remove the 2 nuts and front stabilizer link. HINT: If the ball joint turns together with the nut, use a 6 mm hexagon wrench to hold the stud bolt.
8. REMOVE FRONT STABILIZER LINK ASSEMBLY RH HINT: Remove the RH side following the same procedures as the LH side.
9. REMOVE FRONT NO. 1 STABILIZER BRACKET LH Remove the bolt and wire harness bracket. Remove the 2 bolts and front No. 1 stabilizer bracket LH from the front frame assembly.
10. REMOVE FRONT NO. 1 STABILIZER BRACKET RH Remove the 2 bolts and the front No. 1 stabilizer bracket RH from the front frame assembly.
11. REMOVE FRONT STABILIZER BAR Remove the front stabilizer bar from the vehicle.
12. REMOVE FRONT NO. 1 STABILIZER BAR BUSH Remove the 2 front No. 1 stabilizer bar bushes from the front stabilizer bar.

Scheme 146

1. INSPECT FRONT STABILIZER LINK ASSEMBLY Flip the ball joint stud back and forth 5 times as shown in the illustration. Temporarily install the nut, and use a torque wrench to turn the nut continuously at a rate of 2 to 4 seconds per turn. Take the torque reading on the 5th turn. Standard turning torque: 1.96 N*m (20 kgf*cm, 17.3 in.*lbf) or less If the value is not within the specified range, replace the front stabilizer link assembly. Check the dust boot for cracks or grease leakage.

HINT

A bolt without a torque specification is shown in the standard bolt chart (see SPECIFIED TORQUE FOR STANDARD BOLTS ).

Scheme 147

Scheme 148

Scheme 149

Scheme 150

1. INSTALL FRONT NO. 1 STABILIZER BAR BUSH Install the 2 front No. 1 stabilizer bar bushes outside of the bush stoppers on the front stabilizer bar as shown in the illustration. NOTE: Make sure to face the front No. 1 stabilizer bar bush's seam to the lower rear of the vehicle.
2. TEMPORARILY INSTALL FRONT STABILIZER BAR Temporarily install the front stabilizer bar and front No. 1 stabilizer bracket LH and RH with the 4 bolts in the direction shown in the illustration.
3. INSTALL FRONT NO. 1 STABILIZER BRACKET LH Install the front No. 1 stabilizer bracket LH with the 2 bolts. Torque: 95 N*m (969 kgf*cm, 70 ft.*lbf) Install the wire harness bracket with the bolt. Torque: 22 N*m (224 kgf*cm, 16 ft.*lbf)
4. INSTALL FRONT NO. 1 STABILIZER BRACKET RH Install the front No. 1 stabilizer bracket RH with the 2 bolts. Torque: 95 N*m (969 kgf*cm, 70 ft.*lbf)
5. INSTALL FRONT STABILIZER LINK ASSEMBLY LH Install the front stabilizer link with the 2 nuts. Torque: 85 N*m (867 kgf*cm, 63 ft.*lbf) HINT: If the ball joint turns together with the nut, use a 6 mm hexagon wrench to hold the stud bolt.
6. INSTALL FRONT STABILIZER LINK ASSEMBLY RH HINT: Install the RH side following the same procedures as the LH side.
7. INSTALL FRONT LOWER SUSPENSION MEMBER PROTECTOR (See «INSTALLATION»(ref-349714-S27537239552009120800000) )
8. INSTALL NO. 1 ENGINE UNDER COVER (See «REPLACEMENT»(ref-349716-S35220647352009120800000) )
9. INSTALL FRONT WHEEL OPENING EXTENSION PAD LH (See «INSTALLATION»(ref-349736-S16181480572009120800000) )
10. INSTALL FRONT WHEEL OPENING EXTENSION PAD RH (See «INSTALLATION»(ref-349736-S16181480572009120800000) )
11. INSTALL NO. 2 ENGINE UNDER COVER (See «INSTALLATION»(ref-349714-S27537239552009120800000) )
12. INSTALL FRONT CENTER FLOOR COVER (See «INSTALLATION»(ref-349714-S27537239552009120800000) )

Scheme 151

Scheme 152

Scheme 153

Scheme 154

Scheme 155

Scheme 156

HINT

1. Use the same procedures for the RH side and LH side.
2. The procedures listed below are for the LH side.

Scheme 157

Scheme 158

Scheme 159

Scheme 160

1. REMOVE COWL TOP VENTILATOR LOUVER RH (See «REMOVAL»(ref-349732-S04425564642009120800000) )
2. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation. NOTE: After the engine switch is turned off, the HDD navigation system requires approximately 6 minutes to record various types of memory and settings. As a result, after turning the engine switch off, wait 6 minutes or more before disconnecting the cable from the negative (-) battery terminal.
3. REMOVE REAR WHEEL
4. REMOVE REAR SEAT CUSHION ASSEMBLY LH Remove the seat cushion for power seat (see «REMOVAL»(ref-349741-S26853688812009120800000) ). Remove the seat cushion for ottoman (see «REMOVAL»(ref-349741-S19112888892009120800000) ).
5. REMOVE REAR SEAT CUSHION ASSEMBLY RH HINT: Use the same procedures described for the LH side.
6. REMOVE REAR SEAT CUSHION ASSEMBLY CENTER (for Power Seat) (See «REMOVAL»(ref-349741-S26853688812009120800000) )
7. REMOVE REAR SEATBACK ASSEMBLY LH Remove the seatback for power seat (see «REMOVAL»(ref-349741-S26853688812009120800000) ). Remove the seatback for ottoman (see «REMOVAL»(ref-349741-S19112888892009120800000) ).
8. REMOVE REAR SEAT CONSOLE BOX ASSEMBLY (for Ottoman) (See «REMOVAL»(ref-349734-S01444193102009120800000) )
9. REMOVE REAR SEATBACK ASSEMBLY RH Remove the seatback for power seat (see «REMOVAL»(ref-349741-S26853688812009120800000) ). Remove the seatback for ottoman (see «REMOVAL»(ref-349741-S19112888892009120800000) ).
10. REMOVE REAR SEATBACK ASSEMBLY CENTER (for Power Seat) (See «REMOVAL»(ref-349741-S26853688812009120800000) )
11. REMOVE REAR SEAT CUSHION ASSEMBLY (for Fixed Seat Type) (See «REMOVAL»(ref-349741-S36365163922009120800000) )
12. REMOVE REAR SEATBACK ASSEMBLY (for Fixed Seat Type) (See «REMOVAL»(ref-349741-S36365163922009120800000) )
13. REMOVE NO. 6 ROCKER PANEL MOLDING PROTECTOR (See «REMOVAL»(ref-349729-S00174219962009120800000) )
14. REMOVE REAR WHEEL HOUSE LINER LH Remove the 3 screws, 11 nuts and 2 clips from the liner.
15. REMOVE REAR DOOR SCUFF PLATE LH Remove the scuff plate for standard body (see «REMOVAL»(ref-349734-S03706653952009120800000) ). Remove the scuff plate for long body (see «REMOVAL»(ref-349734-S29426050782009120800000) ).
16. REMOVE REAR DOOR SCUFF PLATE RH HINT: Use the same procedures described for the LH side.
17. REMOVE REAR SEAT SIDE GARNISH LH Remove the garnish for standard body (see «REMOVAL»(ref-349734-S03706653952009120800000) ). Remove the garnish for long body (see «REMOVAL»(ref-349734-S29426050782009120800000) ).
18. REMOVE REAR SEAT SIDE GARNISH RH HINT: Use the same procedures described for the LH side.
19. REMOVE ROOF SIDE GARNISH INNER LH Remove the side garnish for standard body (see «REMOVAL»(ref-349734-S03706653952009120800000) ). Remove the side garnish for long body (see «REMOVAL»(ref-349734-S29426050782009120800000) ).
20. REMOVE ROOF SIDE GARNISH INNER RH HINT: Use the same procedures described for the LH side.
21. REMOVE PACKAGE TRAY TRIM PANEL ASSEMBLY (See «REMOVAL»(ref-349734-S29129796022009120800000) )
22. REMOVE REAR SPEED SENSOR LH (See «REMOVAL»(ref-349740-S34655650882009120800000) )
23. REMOVE LOAD SENSING VALVE SENSOR BRACKET (See «REMOVAL»(ref-349750-S09225287992009120800000) )
24. DISCONNECT REAR UPPER NO. 2 CONTROL ARM ASSEMBLY LH (See «REMOVAL»(ref-349749-S08887431922009120800000) )
25. DISCONNECT REAR UPPER NO. 1 CONTROL ARM ASSEMBLY LH (See «REMOVAL»(ref-349749-S08887431922009120800000) )
26. DISCONNECT TOE CONTROL LINK SUB-ASSEMBLY LH (See «REMOVAL»(ref-349749-S08887431922009120800000) )
27. REMOVE REAR AXLE SHAFT LH NUT (See «REMOVAL»(ref-349749-S08887431922009120800000) )
28. REMOVE REAR SHOCK ABSORBER CAP LH Remove the 3 nuts and cap.
29. REMOVE REAR SHOCK ABSORBER ASSEMBLY LH Remove the 3 nuts on the upper side of the shock absorber. Remove the nut from the shock absorber lower side. Angle the axle carrier's upper tip toward the vehicle's outer side, and remove the shock absorber.

HINT

1. Use the same procedures for the RH side and LH side.
2. The procedures listed below are for the LH side.
3. A bolt without a torque specification is shown in the standard bolt chart (see «SPECIFIED TORQUE FOR STANDARD BOLTS»(ref-349708-S13378942112009120800000) ).

Scheme 161

Scheme 162

1. TEMPORARILY INSTALL REAR SHOCK ABSORBER ASSEMBLY LH Install the rear shock absorber on the vehicle by installing the 3 nuts on the suspension support side. Torque: 64 N*m (653 kgf*cm, 47 ft.*lbf) NOTE: When installing the shock absorber, make sure the lower coil spring bottom tip is on the vehicle's front side. Temporarily install the rear shock absorber lower side with a new nut and washer to the axle carrier. Tighten the new lock nut. Torque: 27 N*m (275 kgf*cm, 20 ft.*lbf)
2. INSTALL REAR SHOCK ABSORBER CAP LH Install the cap with the 3 nuts to the shock absorber. Torque: 14 N*m (143 kgf*cm, 10 ft.*lbf)
3. CONNECT TOE CONTROL LINK SUB-ASSEMBLY LH (See «INSTALLATION»(ref-349749-S36272118122009120800000) )
4. CONNECT REAR UPPER NO. 2 CONTROL ARM ASSEMBLY LH (See «INSTALLATION»(ref-349749-S36272118122009120800000) )
5. CONNECT REAR UPPER NO. 1 CONTROL ARM ASSEMBLY LH (See «INSTALLATION»(ref-349749-S36272118122009120800000) )
6. STAKE REAR AXLE SHAFT LH NUT (See «INSTALLATION»(ref-349749-S36272118122009120800000) )
7. INSTALL LOAD SENSING VALVE SENSOR BRACKET (See «INSTALLATION»(ref-349750-S07311517802009120800000) )
8. INSTALL REAR SPEED SENSOR LH (See «INSTALLATION»(ref-349740-S10659840852009120800000) )
9. INSTALL PACKAGE TRAY TRIM PANEL ASSEMBLY (See «INSTALLATION»(ref-349734-S21460801522009120800000) )
10. INSTALL ROOF SIDE GARNISH INNER LH Install the garnish for standard body (see «INSTALLATION»(ref-349734-S14494944522009120800000) ). Install the garnish for long body (see «INSTALLATION»(ref-349734-S24814211142009120800000) ).
11. INSTALL ROOF SIDE GARNISH INNER RH HINT: Use the same procedures described for the LH side.
12. INSTALL REAR SEAT SIDE GARNISH LH Install the garnish for standard body (see «INSTALLATION»(ref-349734-S14494944522009120800000) ). Install the garnish for long body (see «INSTALLATION»(ref-349734-S24814211142009120800000) ).
13. INSTALL REAR SEAT SIDE GARNISH RH HINT: Use the same procedures described for the LH side.
14. INSTALL REAR DOOR SCUFF PLATE LH Install the scuff plate for standard body (see «INSTALLATION»(ref-349734-S14494944522009120800000) ). Install the scuff plate for long body (see «INSTALLATION»(ref-349734-S24814211142009120800000) ).
15. INSTALL REAR DOOR SCUFF PLATE RH HINT: Use the same procedures described for the LH side.
16. INSTALL REAR SEATBACK ASSEMBLY (for Fixed Seat Type) (See «INSTALLATION»(ref-349741-S36437420052009120800000) )
17. INSTALL REAR SEAT CUSHION ASSEMBLY (for Fixed Seat Type) (See «INSTALLATION»(ref-349741-S36437420052009120800000) )
18. INSTALL REAR SEATBACK ASSEMBLY CENTER (for Power Seat) (See «INSTALLATION»(ref-349741-S24840229242009120800000) )
19. INSTALL REAR SEATBACK ASSEMBLY RH Install the rear seatback for power seat (see «INSTALLATION»(ref-349741-S24840229242009120800000) ). Install the rear seatback for ottoman (see «INSTALLATION»(ref-349741-S09487469022009120800000) ).
20. INSTALL REAR SEAT CONSOLE BOX ASSEMBLY (for Ottoman) (See «INSTALLATION»(ref-349734-S14024558482009120800000) )
21. INSTALL REAR SEATBACK ASSEMBLY LH Install the rear seatback for power seat (see «INSTALLATION»(ref-349741-S24840229242009120800000) ). Install the rear seatback for ottoman (see «INSTALLATION»(ref-349741-S09487469022009120800000) ).
22. INSTALL REAR SEAT CUSHION ASSEMBLY CENTER (for Power Seat) (See «INSTALLATION»(ref-349741-S24840229242009120800000) )
23. INSTALL REAR SEAT CUSHION ASSEMBLY RH Install the seat cushion for power seat (see «INSTALLATION»(ref-349741-S24840229242009120800000) ). Install the seat cushion for ottoman (see «INSTALLATION»(ref-349741-S09487469022009120800000) ).
24. INSTALL REAR SEAT CUSHION ASSEMBLY LH Install the seat cushion for power seat (see «INSTALLATION»(ref-349741-S24840229242009120800000) ). Install the seat cushion for ottoman (see «INSTALLATION»(ref-349741-S09487469022009120800000) ).
25. INSTALL REAR WHEEL HOUSE LINER LH Install the liner with the 3 screws, 11 nuts, 2 clips to the vehicle side.
26. INSTALL NO. 6 ROCKER PANEL MOLDING PROTECTOR (See «INSTALLATION»(ref-349729-S37582603882009120800000) )
27. STABILIZE SUSPENSION Install the rear tires. Torque: 140 N*m (1428 kgf*cm, 104 ft.*lbf) Lower the vehicle and bounce it up and down several times to stabilize the rear suspension. Remove the rear tires. Jack up the axle carrier with a wooden block between the jack and axle carrier. Apply a load to the rear suspension so that the rear drive shaft assembly becomes level.
28. TIGHTEN REAR SHOCK ABSORBER ASSEMBLY LH Tighten the nut on the axle carrier. Torque: 80 N*m (816 kgf*cm, 59 ft.*lbf)
29. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
30. INSTALL COWL TOP VENTILATOR LOUVER RH (See «INSTALLATION»(ref-349732-S09051375432009120800000) )
31. PERFORM INITIALIZATION Perform initialization (see «INITIALIZATION»(ref-349706-S07943075812009120800000) ). NOTE: Certain systems need to be initialized after disconnecting and reconnecting the cable from the negative (-) battery terminal.
32. INSTALL REAR WHEEL Torque: 140 N*m (1428 kgf*cm, 104 ft.*lbf)
33. INSPECT AND ADJUST REAR WHEEL ALIGNMENT Inspect and adjust the rear wheel alignment (see «ADJUSTMENT»(ref-349722-S07390225572009120800000) ).
34. CHECK SPEED SENSOR SIGNAL Check the speed sensor signal (see «TEST MODE PROCEDURE»(ref-349740-S02170830312009120800000) ).
35. ADJUST HEADLIGHT ASSEMBLY Adjust the headlight (see «ADJUSTMENT»(ref-349731-S09246046722009120800000) ).

Scheme 163

1. DISPOSE OF REAR SHOCK ABSORBER ASSEMBLY LH Fully extend the rear shock absorber rod. Using a drill, make a hole in the cylinder between A and B shown in the illustration to discharge the gas inside. CAUTION: Be careful when drilling because shards of metal may fly about. Always use the proper safety equipment. NOTE: The gas is colorless, odorless and nonpoisonous.

Scheme 164

HINT

1. Use the same procedures for the RH side and LH side.
2. The procedures listed below are for the LH side.

Scheme 165

Scheme 166

Scheme 167

Scheme 168

Scheme 169

Scheme 170

Scheme 171

1. REMOVE COWL TOP VENTILATOR LOUVER RH (See «REMOVAL»(ref-349732-S04425564642009120800000) )
2. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait at least 90 seconds alter disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation. NOTE: After the engine switch is turned off, the HDD navigation system requires approximately 6 minutes to record various types of memory and settings. As a result, after turning the engine switch off, wait 6 minutes or more before disconnecting the cable from the negative (-) battery terminal.
3. REMOVE REAR WHEEL
4. REMOVE REAR SEAT CUSHION ASSEMBLY LH Remove the seat cushion for power seat (see «REMOVAL»(ref-349741-S26853688812009120800000) ). Remove the seat cushion for ottoman (see «REMOVAL»(ref-349741-S19112888892009120800000) ).
5. REMOVE REAR SEAT CUSHION ASSEMBLY RH Remove the seat cushion for power seat (see «REMOVAL»(ref-349741-S26853688812009120800000) ). Remove the seat cushion for ottoman (see «REMOVAL»(ref-349741-S19112888892009120800000) ).
6. REMOVE REAR SEAT CUSHION ASSEMBLY CENTER (for Power Seat) (See «REMOVAL»(ref-349741-S26853688812009120800000) )
7. REMOVE REAR SEATBACK ASSEMBLY LH Remove the seatback for power seat (see «REMOVAL»(ref-349741-S26853688812009120800000) ). Remove the seatback for ottoman (see «REMOVAL»(ref-349741-S19112888892009120800000) ).
8. REMOVE REAR SEAT CONSOLE BOX ASSEMBLY (for Ottoman) (See «REMOVAL»(ref-349734-S01444193102009120800000) )
9. REMOVE REAR SEATBACK ASSEMBLY RH Remove the seatback for power seat (see «REMOVAL»(ref-349741-S26853688812009120800000) ). Remove the seatback for ottoman (see «REMOVAL»(ref-349741-S19112888892009120800000) ).
10. REMOVE REAR SEATBACK ASSEMBLY CENTER (for Power Seat) (See «REMOVAL»(ref-349741-S26853688812009120800000) )
11. REMOVE REAR SEAT CUSHION ASSEMBLY (for Fixed Seat Type) (See «REMOVAL»(ref-349741-S36365163922009120800000) )
12. REMOVE REAR SEATBACK ASSEMBLY (for Fixed Seat Type) (See «REMOVAL»(ref-349741-S36365163922009120800000) )
13. REMOVE NO. 6 ROCKER PANEL MOLDING PROTECTOR (See «REMOVAL»(ref-349729-S00174219962009120800000) )
14. REMOVE REAR WHEEL HOUSE LINER LH (See «REMOVAL»(ref-349722-S01414464432009120800000) )
15. REMOVE REAR DOOR SCUFF PLATE LH Remove the scuff plate for standard body (see «REMOVAL»(ref-349734-S03706653952009120800000) ). Remove the scuff plate for long body (see «REMOVAL»(ref-349734-S29426050782009120800000) ).
16. REMOVE REAR DOOR SCUFF PLATE RH HINT: Use the same procedures described for the LH side.
17. REMOVE REAR SEAT SIDE GARNISH LH Remove the side garnish for standard body (see «REMOVAL»(ref-349734-S03706653952009120800000) ). Remove the side garnish for long body (see «REMOVAL»(ref-349734-S29426050782009120800000) ).
18. REMOVE REAR SEAT SIDE GARNISH RH HINT: Use the same procedures described for the LH side.
19. REMOVE ROOF SIDE GARNISH INNER LH Remove the garnish for standard body (see «REMOVAL»(ref-349734-S03706653952009120800000) ). Remove the garnish for long body (see «REMOVAL»(ref-349734-S29426050782009120800000) ).
20. REMOVE ROOF SIDE GARNISH INNER RH HINT: Use the same procedures described for the LH side.
21. REMOVE PACKAGE TRAY TRIM PANEL ASSEMBLY (See «REMOVAL»(ref-349734-S29129796022009120800000) )
22. REMOVE REAR SPEED SENSOR LH (See «REMOVAL»(ref-349740-S34655650882009120800000) )
23. REMOVE LOAD SENSING VALVE SENSOR BRACKET (See «REMOVAL»(ref-349750-S09225287992009120800000) )
24. DISCONNECT REAR UPPER NO. 2 CONTROL ARM ASSEMBLY LH (See «REMOVAL»(ref-349749-S08887431922009120800000) )
25. DISCONNECT REAR UPPER NO. 1 CONTROL ARM ASSEMBLY LH (See «REMOVAL»(ref-349749-S08887431922009120800000) )
26. DISCONNECT TOE CONTROL LINK SUB-ASSEMBLY LH (See «REMOVAL»(ref-349749-S08887431922009120800000) )
27. REMOVE REAR AXLE SHAFT LH NUT (See «REMOVAL»(ref-349749-S08887431922009120800000) )
28. REMOVE REAR SHOCK ABSORBER CAP LH Remove the 3 nuts and cap.
29. DISCONNECT CONNECTOR Disconnect the connector from the absorber actuator.
30. REMOVE ABSORBER CONTROL ACTUATOR Turn the absorber control actuator counterclockwise approximately 40° and remove it.
31. REMOVE PNEUMATIC CYLINDER WITH REAR SHOCK ABSORBER ASSEMBLY LH Pinch and pull the No. 1 connector to release it. Using SST, pull out the height control tube from the pneumatic cylinder with shock absorber. SST 09730-00010 NOTE: After pulling out the height control tube, replace the O-ring and plate with new ones. Remove the 3 nuts on the upper side of the shock absorber. Remove the nut from the shock absorber lower side. Angle the axle carrier's upper tip toward the vehicle's outer side, and remove the shock absorber.
32. REMOVE HEIGHT CONTROL VALVE O-RING HINT: It is unnecessary to perform the following procedures if the pneumatic cylinder with shock absorber has been replaced with a new one. Using a screwdriver, detach the 2 clips and remove the tube connector. Using a screwdriver, remove the plate and 2 O-rings.

Scheme 172

Scheme 173

1. INSPECT PNEUMATIC CYLINDER WITH REAR SHOCK ABSORBER ASSEMBLY LH Extend the pneumatic cylinder with shock absorber and check that it is as described below. Standard: While extending the cylinder at a constant speed, the load is constant for each stroke and there is no abnormal feedback or noises. Also, the cylinder returns at a constant speed when extended. If an abnormality is found, replace the pneumatic cylinder with shock absorber with a new one. NOTE: When extending the pneumatic cylinder with shock absorber rear LH, do not block the air inlet/outlet opening. While adjusting the damping force control rod to hard, semihard, medium, soft and semisoft, inspect the pneumatic cylinder assembly with rear shock absorber LH by compressing and extending it. Standard: The damping forces are not the same.

HINT

1. Use the same procedures for the RH side and LH side.
2. The procedures listed below are for the LH side.
3. A bolt without a torque specification is shown in the standard bolt chart (see «SPECIFIED TORQUE FOR STANDARD BOLTS»(ref-349708-S13378942112009120800000) ).

Scheme 174

Scheme 175

Scheme 176

Scheme 177

1. INSTALL HEIGHT CONTROL VALVE O-RING HINT: It is unnecessary to perform the following procedures if the pneumatic cylinder with shock absorber has been replaced with a new one. Apply a light coat of MP grease No. 2 to 2 new O-rings. Install the 2 O-rings and a new plate to a height control tube or equivalent, as shown in the illustration. NOTE: Set the plate between the 2 O-rings. Insert the tube end with the 2 O-rings and plate into the pneumatic cylinder with shock absorber. Then, lightly push in the O-rings and plate with a thick piece of paper. While holding the O-rings and plate in place with the paper, slowly pull out the tube. Install a new tube connector. NOTE: Push in the tube connector until a "click" sound is heard.
2. TEMPORARILY INSTALL PNEUMATIC CYLINDER WITH REAR SHOCK ABSORBER ASSEMBLY LH Install the rear shock absorber on the vehicle by installing the 3 nuts on the suspension support side. Torque: 64 N*m (653 kgf*cm, 47 ft.*lbf) Temporarily install the rear shock absorber lower side on the rear axle carrier with the washer and new nut. Insert the height control tube into the pneumatic cylinder with shock absorber. Pinch the connector No. 1 and set its tips into the groove of the shock absorber.
3. INSTALL ABSORBER CONTROL ACTUATOR Check that the control rod of the rear shock absorber is in the position shown in the illustration. NOTE: If the control rod is not in the position shown in the illustration, turn the control rod to adjust the position and install the absorber control actuator. Install the absorber control actuator to the actuator support bracket. Turn the actuator clockwise approximately 40° until a click is felt. NOTE: Do not excessively turn the actuator.
4. CONNECT CONNECTOR Connect the connector to the shock absorber control actuator.
5. INSTALL REAR SHOCK ABSORBER CAP LH Install the shock absorber cap with the 3 nuts. Torque: 14 N*m (143 kgf*cm, 10 ft.*lbf)
6. CONNECT TOE CONTROL LINK SUB-ASSEMBLY LH (See «INSTALLATION»(ref-349749-S36272118122009120800000) )
7. CONNECT REAR UPPER NO. 1 CONTROL ARM ASSEMBLY LH (See «INSTALLATION»(ref-349749-S36272118122009120800000) )
8. CONNECT REAR UPPER NO. 2 CONTROL ARM ASSEMBLY LH (See «INSTALLATION»(ref-349749-S36272118122009120800000) )
9. STAKE REAR AXLE SHAFT LH NUT (See «INSTALLATION»(ref-349749-S36272118122009120800000) )
10. INSTALL LOAD SENSING VALVE SENSOR BRACKET (See «INSTALLATION»(ref-349750-S07311517802009120800000) )
11. INSTALL REAR SPEED SENSOR LH (See «INSTALLATION»(ref-349740-S10659840852009120800000) )
12. INSTALL PACKAGE TRAY TRIM PANEL ASSEMBLY (See «INSTALLATION»(ref-349734-S21460801522009120800000) )
13. INSTALL ROOF SIDE GARNISH INNER LH Install the side garnish for standard body (see «INSTALLATION»(ref-349734-S14494944522009120800000) ). Install the side garnish for long body (see «INSTALLATION»(ref-349734-S24814211142009120800000) ).
14. INSTALL ROOF SIDE GARNISH INNER RH HINT: Use the same procedures described for the LH side.
15. INSTALL REAR SEAT SIDE GARNISH LH Install the garnish for standard body (see «INSTALLATION»(ref-349734-S14494944522009120800000) ). Install the garnish for long body (see «INSTALLATION»(ref-349734-S24814211142009120800000) ).
16. INSTALL REAR SEAT SIDE GARNISH RH HINT: Use the same procedures described for the LH side.
17. INSTALL REAR DOOR SCUFF PLATE LH Install the scuff plate for standard body (see «INSTALLATION»(ref-349734-S14494944522009120800000) ). Install the scuff plate for long body (see «INSTALLATION»(ref-349734-S24814211142009120800000) ).
18. INSTALL REAR DOOR SCUFF PLATE RH HINT: Use the same procedures described for the LH side.
19. INSTALL REAR SEATBACK ASSEMBLY (for Fixed Seat Type) (See «INSTALLATION»(ref-349741-S36437420052009120800000) )
20. INSTALL REAR SEAT CUSHION ASSEMBLY (for Fixed Seat Type) (See «INSTALLATION»(ref-349741-S36437420052009120800000) )
21. INSTALL REAR SEATBACK ASSEMBLY CENTER (for Power Seat) (See «INSTALLATION»(ref-349741-S24840229242009120800000) )
22. INSTALL REAR SEATBACK ASSEMBLY RH Install the seatback for power seat (see «INSTALLATION»(ref-349741-S24840229242009120800000) ). Install the seatback for ottoman (see «INSTALLATION»(ref-349741-S09487469022009120800000) ).
23. INSTALL REAR SEAT CONSOLE BOX ASSEMBLY (for Ottoman) (See «INSTALLATION»(ref-349734-S14024558482009120800000) )
24. INSTALL REAR SEATBACK ASSEMBLY LH Install the seatback for power seat (see «INSTALLATION»(ref-349741-S24840229242009120800000) ). Install the seatback for ottoman (see «INSTALLATION»(ref-349741-S09487469022009120800000) ).
25. INSTALL REAR SEAT CUSHION ASSEMBLY CENTER (for Power Seat) (See «INSTALLATION»(ref-349741-S24840229242009120800000) )
26. INSTALL REAR SEAT CUSHION ASSEMBLY RH Install the seat cushion for power seat (see «INSTALLATION»(ref-349741-S24840229242009120800000) ). Install the seat cushion for ottoman (see «INSTALLATION»(ref-349741-S09487469022009120800000) ).
27. INSTALL REAR SEAT CUSHION ASSEMBLY LH Install the seat cushion for power seat (see «INSTALLATION»(ref-349741-S24840229242009120800000) ). Install the seat cushion for ottoman (see «INSTALLATION»(ref-349741-S09487469022009120800000) ).
28. INSTALL REAR WHEEL HOUSE LINER LH (See «INSTALLATION»(ref-349722-S37097628642009120800000) )
29. INSTALL NO. 6 ROCKER PANEL MOLDING PROTECTOR (See «INSTALLATION»(ref-349729-S37582603882009120800000) )
30. STABILIZE SUSPENSION Install the rear tires. Torque: 140 N*m (1428 kgf*cm, 104 ft.*lbf) Lower the vehicle and start the engine. Then fill the pneumatic cylinder assembly with rear shock absorber with air. Lower the vehicle and bounce it up and down several times to stabilize the rear suspension. Remove the rear tires. Jack up the axle carrier with a wooden block between the jack and axle carrier. Apply a load to the suspension so that the rear drive shaft assembly is placed in a horizontal position.
31. TIGHTEN PNEUMATIC CYLINDER WITH REAR SHOCK ABSORBER ASSEMBLY LH Tighten the nut on the axle carrier. Torque: 80 N*m (816 kgf*cm, 59 ft.*lbf)
32. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
33. INSTALL COWL TOP VENTILATOR LOUVER RH (See «INSTALLATION»(ref-349732-S09051375432009120800000) )
34. PERFORM INITIALIZATION Perform initialization (see «INITIALIZATION»(ref-349706-S07943075812009120800000) ). NOTE: Certain systems need to be initialized after disconnecting and reconnecting the cable from the negative (-) battery terminal.
35. INSTALL REAR WHEEL Torque: 140 N*m (1428 kgf*cm, 104 ft.*lbf)
36. CHECK CONNECTIONS OF TUBES FOR AIR LEAKAGE Check the connection of the tubes for air leakage (see «OPERATION CHECK»(ref-349750-S12258921322009120800000) ).
37. CHECK SUSPENSION CONTROL SYSTEM Check the suspension control system (see «OPERATION CHECK»(ref-349750-S12258921322009120800000) ).
38. INSPECT AND ADJUST REAR WHEEL ALIGNMENT Inspect and adjust the rear wheel alignment (see «ADJUSTMENT»(ref-349722-S07390225572009120800000) ).
39. CHECK SPEED SENSOR SIGNAL Check the speed sensor signal (see «TEST MODE PROCEDURE»(ref-349740-S02170830312009120800000) ).
40. ADJUST HEADLIGHT ASSEMBLY Adjust the headlight (see «ADJUSTMENT»(ref-349731-S09246046722009120800000) ).

Scheme 178

1. DISPOSE OF PNEUMATIC CYLINDER WITH REAR SHOCK ABSORBER ASSEMBLY Fully extend the rear shock absorber rod. Using a drill, make a hole in the cylinder somewhere between A and B shown in the illustration to discharge the gas inside. CAUTION: Be careful as the cylinder is a high-pressure gas type which is at a higher pressure than normal shock absorbers. Also be careful with high temperatures as the cylinder's pressure becomes even higher. NOTE: The gas is colorless, odorless and harmless.

Scheme 179

Scheme 180

Scheme 181

1. INSPECT REAR UPPER NO. 1 CONTROL ARM BALL JOINT RATTLE Jack up the vehicle. Shake the suspension arm by hand and check for rattle. Standard rattle: No rattle is felt
2. INSPECT REAR UPPER NO. 2 CONTROL ARM BALL JOINT RATTLE Jack up the vehicle. Shake the suspension arm by hand and check for rattle. Standard rattle: No rattle is felt

HINT

1. Use the same procedures for the RH side and LH side.
2. The procedures listed below are for the LH side.

Scheme 182

Scheme 183

Scheme 184

Scheme 185

1. REMOVE REAR WHEEL
2. REMOVE REAR DISC BRAKE CALIPER ASSEMBLY LH (See «REMOVAL»(ref-349719-S20561870172009120800000) )
3. REMOVE REAR STABILIZER LINK ASSEMBLY LH (See «REMOVAL»(ref-349722-S38160074692009120800000) )
4. DISCONNECT REAR SHOCK ABSORBER ASSEMBLY LH (w/o Air Suspension) Remove the nut and disconnect the shock absorber from axle carrier side.
5. DISCONNECT PNEUMATIC CYLINDER WITH REAR SHOCK ABSORBER ASSEMBLY LH (w/ Air Suspension) Remove the nut and disconnect the pneumatic cylinder from axle carrier side.
6. REMOVE REAR NO. 2 SUSPENSION ARM ASSEMBLY LH (See «REMOVAL»(ref-349722-S23958881582009120800000) )
7. DISCONNECT REAR NO. 1 SUSPENSION ARM ASSEMBLY LH (See «REMOVAL»(ref-349749-S08887431922009120800000) )
8. DISCONNECT TOE CONTROL LINK SUB-ASSEMBLY LH (See «REMOVAL»(ref-349749-S08887431922009120800000) )
9. REMOVE REAR UPPER NO. 1 CONTROL ARM ASSEMBLY LH Remove the nut on the rear axle carrier side. Install 2 spacers (SST spacer A) onto the rear upper No. 1 control arm so that there is a space of approximately 1 mm (0.039 in.) between the arm and spacers. SST 09960-20010 (09961-02050) NOTE: Make sure to install the spacers (SST spacer A) as the axle carrier spacer may shift. As SST may become damaged, make sure the space between the arm and spacers is not 1 mm (0.039 in.) or less. Using SST, disconnect the rear upper No. 1 control arm from the axle carrier. SST 09960-20010 (09961 -02010) NOTE: Do not damage the dust cover. As the dust cover may be damaged, adjust SST with the center nut so that the body and crow are parallel. Make sure to tie the string of to the vehicle to prevent SST from dropping. Remove the nut and washer, bolt and control arm from the rear suspension member.
10. REMOVE REAR UPPER NO. 2 CONTROL ARM ASSEMBLY LH Remove the nut on the rear axle carrier side. Install 2 spacers (SST spacer A) onto the rear upper No. 2 control arm so that there is a space of approximately 1 mm (0.039 in.) between the arm and spacers. SST 09960-20010(09961-02050) NOTE: Make sure to install the spacers (SST spacer A) as the axle carrier spacer may shift. As SST may become damaged, make sure the space between the arm and spacers is not 1 mm (0.039 in.) or less. Using SST, disconnect the rear upper No. 2 control arm from the axle carrier. SST 09960-20010 (09961 -02010) NOTE: Do not damage the dust cover. As the dust cover may be damaged, adjust SST with the center nut so that the body and crow are parallel. Make sure to tie the string of to the vehicle to prevent SST from dropping. Remove the nut and washer, bolt and rear control arm from the rear suspension member.

Scheme 186

Scheme 187

1. INSPECT REAR UPPER NO. 1 CONTROL ARM ASSEMBLY LH Temporarily install the nut, and flip the ball joint stud back and forth 5 times as shown in the illustration. Use a torque wrench to turn the nut continuously at a rate of 3 to 5 seconds per turn. Take the torque reading on the fifth turn. Standard turning torque: 3.5 N*m (36 kgf*cm, 31 in.*lbf) or less
2. INSPECT REAR UPPER NO. 2 CONTROL ARM ASSEMBLY LH Temporarily install the nut, and flip the ball joint stud back and forth 5 times as shown in the illustration. Use a torque wrench to turn the nut continuously at a rate of 3 to 5 seconds per turn. Take the torque reading on the fifth turn. Standard turning torque: 9.0 N*m (92 kgf*cm, 80 in.*lbf) or less

HINT

1. Use the same procedures for the RH side and LH side.
2. The procedures listed below are for the LH side.
3. A bolt without a torque specification is shown in the standard bolt chart (see «SPECIFIED TORQUE FOR STANDARD BOLTS»(ref-349708-S13378942112009120800000) ).

Scheme 188

Scheme 189

1. TEMPORARILY CONNECT REAR SHOCK ABSORBER ASSEMBLY LH (w/o Air Suspension) Temporarily connect the rear shock absorber lower side with a new nut and washer to the axle carrier.
2. TEMPORARILY CONNECT PNEUMATIC CYLINDER WITH REAR SHOCK ABSORBER ASSEMBLY LH (w/ Air Suspension) Temporarily connect the pneumatic cylinder lower side with a new nut and washer to the axle carrier.
3. TEMPORARILY INSTALL REAR UPPER NO. 1 CONTROL ARM ASSEMBLY LH Temporarily install the control arm with the bolt, nut and washer to the suspension member. Install the stud of the control arm, and temporarily install a new nut to the axle carrier. HINT: Push the axle carrier downward.
4. TIGHTEN REAR UPPER NO. 1 CONTROL ARM ASSEMBLY LH Tighten the nuts on the control arm. Torque: 150 N*m (1530 kgf*cm, 111 ft.*lbf) for suspension member side 160 N*m (1632 kgf*cm, 118 ft.*lbf) for axle carrier side
5. TEMPORARILY INSTALL REAR UPPER NO. 2 CONTROL ARM ASSEMBLY LH Temporarily install the control arm with the bolt, nut and washer to the suspension member. Install the stud of the control arm, and temporarily install a new nut to the axle carrier. HINT: Push the axle carrier downward.
6. TIGHTEN REAR UPPER NO. 2 CONTROL ARM ASSEMBLY LH Tighten the nuts on the rear control arm. Torque: 225 N*m (2294 kgf*cm, 166 ft.*lbf) for suspension member side 160 N*m (1632 kgf*cm, 118 ft.*lbf) for axle carrier side
7. TEMPORARILY INSTALL REAR NO. 2 SUSPENSION ARM ASSEMBLY LH (See «INSTALLATION»(ref-349722-S08282873212009120800000) )
8. CONNECT TOE CONTROL LINK SUB-ASSEMBLY LH (See «INSTALLATION»(ref-349749-S36272118122009120800000) )
9. CONNECT REAR NO. 1 SUSPENSION ARM ASSEMBLY LH (See «INSTALLATION»(ref-349749-S36272118122009120800000) )
10. INSTALL REAR DISC BRAKE CALIPER ASSEMBLY LH (See «INSTALLATION»(ref-349719-S30633082262009120800000) )
11. STABILIZE SUSPENSION Stabilize the suspension for coil suspension (see «INSTALLATION»(ref-349722-S25641696382009120800000) ). Stabilize the suspension for air suspension (see «INSTALLATION»(ref-349722-S27364139402009120800000) ).
12. TIGHTEN REAR NO. 2 SUSPENSION ARM ASSEMBLY LH (See «INSTALLATION»(ref-349722-S08282873212009120800000) )
13. CONNECT REAR SHOCK ABSORBER ASSEMBLY LH (w/o Air Suspension) Connect the nut on the axle carrier. Torque: 80 N*m (816 kgf*cm, 59 ft.*lbf)
14. CONNECT PNEUMATIC CYLINDER WITH REAR SHOCK ABSORBER ASSEMBLY LH (w/ Air Suspension) Connect the nut on the axle carrier. Torque: 80 N*m (816 kgf*cm, 59 ft.*lbf)
15. INSTALL REAR STABILIZER LINK ASSEMBLY LH (See «INSTALLATION»(ref-349722-S41432804982009120800000) )
16. INSTALL REAR WHEEL Torque: 140 N*m (1428 kgf*cm, 104 ft.*lbf)
17. CHECK SUSPENSION CONTROL SYSTEM (w/ Air Suspension) Check the suspension control system (see «OPERATION CHECK»(ref-349750-S12258921322009120800000) ).
18. INSPECT AND ADJUST REAR WHEEL ALIGNMENT Inspect and adjust the rear wheel alignment (see «ADJUSTMENT»(ref-349722-S07390225572009120800000) ).
19. ADJUST HEADLIGHT ASSEMBLY Adjust the headlight (see «ADJUSTMENT»(ref-349731-S09246046722009120800000) ).

Scheme 190

Scheme 191

1. INSPECT REAR NO. 1 SUSPENSION ARM BALL JOINT RATTLE Jack up the vehicle. Shake the suspension arm by hand and check for rattle. Standard rattle: No rattle is felt

HINT

1. Use the same procedures for the RH side and LH side
2. The procedures listed below are for the LH side.

Scheme 192

Scheme 193

Scheme 194

Scheme 195

Scheme 196

1. REMOVE REAR WHEEL
2. REMOVE NO. 2 DIFFERENTIAL SUPPORT PROTECTOR (See «REMOVAL»(ref-349739-S24282521242009120800000) )
3. REMOVE REAR SPEED SENSOR LH (See «REMOVAL»(ref-349740-S34655650882009120800000) )
4. REMOVE LOAD SENSING VALVE SENSOR BRACKET (See «REMOVAL»(ref-349750-S09225287992009120800000) )
5. REMOVE REAR STABILIZER LINK ASSEMBLY LH (See «REMOVAL»(ref-349722-S38160074692009120800000) )
6. DISCONNECT REAR SHOCK ABSORBER ASSEMBLY LH (w/o Air Suspension) (See «REMOVAL»(ref-349722-S36340836592009120800000) )
7. DISCONNECT PNEUMATIC CYLINDER WITH REAR SHOCK ABSORBER ASSEMBLY LH (w/ Air Suspension) (See «REMOVAL»(ref-349722-S36340836592009120800000) )
8. REMOVE REAR NO. 2 SUSPENSION ARM ASSEMBLY LH Using a plastic-faced hammer or equivalent, strike the part labeled A from the rear of the vehicle to maintain the clearance at the slide pin area. NOTE: Be careful not to damage the arm. Remove the nut, washer, bolt and No. 2 suspension arm from the axle carrier. Remove the nut, No. 2 suspension toe adjust plate, rear suspension attachment and No. 2 suspension arm from the suspension member.
9. REMOVE REAR NO. 1 SUSPENSION ARM ASSEMBLY LH Remove the nut on the rear axle carrier side. Install 2 spacers (SST spacer B) onto the rear No. 1 suspension arm so that there is a space of approximately 1 mm (0.039 in.) between the arm and spacers. SST 09960-20010(09961-02060) NOTE: Make sure to install the spacers (SST spacer B) as the axle carrier spacer may shift. As SST may become damaged, make sure the space between the arm and spacers is not 1 mm (0.039 in.) or less. Using SST, disconnect the rear No. 1 control arm from the axle carrier. SST 09960-20010 (09961 -02010) NOTE: Do not damage the dust cover. As the dust cover may be damaged, adjust SST with the center nut so that the body and crow are parallel. Make sure to tie the string of to the vehicle to prevent SST from dropping. Remove the bolt, nut and No. 1 suspension arm from the suspension member.

Scheme 197

1. INSPECT REAR NO. 1 SUSPENSION ARM ASSEMBLY LH Temporarily install the nut, and flip the ball joint stud back and forth 5 times as shown in the illustration. Use a torque wrench to turn the nut continuously at a rate of 3 to 5 seconds per turn. Take the torque reading on the fifth turn. Standard turning torque: 5.0 N*m (51 kgf*cm, 44 in.*lbf) or less

HINT

1. Use the same procedures for the RH side and LH side.
2. The procedures listed below are for the LH side.
3. A bolt without a torque specification is shown in the standard bolt chart (see «SPECIFIED TORQUE FOR STANDARD BOLTS»(ref-349708-S13378942112009120800000) ).

Scheme 198

Scheme 199

1. TEMPORARILY INSTALL REAR NO. 2 SUSPENSION ARM ASSEMBLY LH Temporarily install the No. 2 suspension arm with the No. 2 suspension toe adjust plate, rear suspension attachment and nut to the suspension member. Install the stud of the suspension arm, and temporarily install a washer, nut and the bolt to the axle carrier.
2. TEMPORARILY INSTALL REAR NO. 1 SUSPENSION ARM ASSEMBLY LH Temporarily install the No. 1 suspension arm with the bolt and nut to the suspension member. Install the stud of the suspension arm, and temporarily install a new nut to the axle carrier.
3. TIGHTEN REAR NO. 1 SUSPENSION ARM ASSEMBLY LH Tighten the bolt and nut. Torque: 72 N*m (734 kgf*cm, 53 ft.*lbf) for bolt 118 N*m (1203 kgf*cm, 87 ft.*lbf) for nut
4. TEMPORARILY CONNECT REAR SHOCK ABSORBER ASSEMBLY LH (w/o Air Suspension) (See «INSTALLATION»(ref-349722-S11477672232009120800000) )
5. TEMPORARILY CONNECT PNEUMATIC CYLINDER WITH REAR SHOCK ABSORBER ASSEMBLY LH (w/ Air Suspension) (See «INSTALLATION»(ref-349722-S11477672232009120800000) )
6. INSTALL REAR STABILIZER LINK ASSEMBLY LH (See «INSTALLATION»(ref-349722-S41432804982009120800000) )
7. STABILIZE SUSPENSION Stabilize the suspension for coil suspension (see «INSTALLATION»(ref-349722-S37097628642009120800000) ). Stabilize the suspension for air suspension (see «INSTALLATION»(ref-349722-S27364139402009120800000) ).
8. TIGHTEN REAR NO. 2 SUSPENSION ARM ASSEMBLY LH Tighten the 2 nuts. Torque: 150 N*m (1530 kgf*cm, 111 ft.*lbf) for suspension member side 225 N*m (2294 kgf*cm, 166 ft.*lbf) for axle carrier side
9. CONNECT REAR SHOCK ABSORBER ASSEMBLY LH (w/o Air Suspension) (See «INSTALLATION»(ref-349722-S11477672232009120800000) )
10. CONNECT PNEUMATIC CYLINDER WITH REAR SHOCK ABSORBER ASSEMBLY LH (w/ Air Suspension) (See «INSTALLATION»(ref-349722-S11477672232009120800000) )
11. INSTALL REAR SPEED SENSOR LH (See «INSTALLATION»(ref-349740-S10659840852009120800000) )
12. INSTALL LOAD SENSING VALVE SENSOR BRACKET (See «INSTALLATION»(ref-349750-S07311517802009120800000) )
13. INSTALL NO. 2 DIFFERENTIAL SUPPORT PROTECTOR (See «INSTALLATION»(ref-349739-S27293288612009120800000) )
14. INSTALL REAR WHEEL Torque: 140 N*m (1428 kgf*cm, 104 ft.*lbf)
15. CHECK SUSPENSION CONTROL SYSTEM (for Air suspension) Check the suspension control system (see «OPERATION CHECK»(ref-349750-S12258921322009120800000) ).
16. INSPECT AND ADJUST REAR WHEEL ALIGNMENT Inspect and adjust the rear wheel alignment (see «ADJUSTMENT»(ref-349722-S07390225572009120800000) ).
17. CHECK SPEED SENSOR SIGNAL Check the speed sensor signal (see «TEST MODE PROCEDURE»(ref-349740-S02170830312009120800000) ).
18. ADJUST HEADLIGHT ASSEMBLY Adjust the headlight (see «ADJUSTMENT»(ref-349731-S09246046722009120800000) ).

Scheme 200

Scheme 201

1. INSPECT TOE CONTROL LINK BALL JOINT RATTLE Jack up the vehicle. Shake the suspension link by hand and check for rattle. Standard rattle: No rattle is felt

HINT

1. Use the same procedures for the RH side and LH side.
2. The procedures listed below are for the LH side.

Scheme 202

Scheme 203

1. REMOVE REAR WHEEL
2. REMOVE REAR SPEED SENSOR LH (See «REMOVAL»(ref-349740-S34655650882009120800000) )
3. REMOVE LOAD SENSING VALVE SENSOR BRACKET (See «REMOVAL»(ref-349750-S09225287992009120800000) )
4. REMOVE TOE CONTROL LINK SUB-ASSEMBLY LH Remove the nut on the rear axle carrier side. Install 2 spacers (SST spacer B) onto the toe control link so that there is a space of approximately 1 mm (0.039 in.) between the arm and spacers. SST 09960-20010(09961-02060) NOTE: Make sure to install the spacers (SST spacer B) as the axle carrier spacer may shift. As SST may become damaged, make sure the space between the arm and spacers is not 1 mm (0.039 in.) or less. Using SST, disconnect the toe control link from the axle carrier. SST 09960-20010 (09961 -02010) NOTE: Do not damage the dust cover. As the dust cover may be damaged, adjust SST with the center nut so that the body and crow are parallel. Make sure to tie the string of to the vehicle to prevent SST from dropping. Place matchmarks on the No. 2 suspension toe adjust plate and suspension member. Remove the nut, No. 2 toe adjust plate, toe adjust cam and toe control link from the suspension member.

Scheme 204

1. INSPECT TOE CONTROL LINK SUB-ASSEMBLY LH Temporarily install the nut, and flip the ball joint stud back and forth 5 times as shown in the illustration. Use a torque wrench to turn the nut continuously at a rate of 3 to 5 seconds per turn. Take the torque reading on the fifth turn. Standard turning torque: 6.0 N*m (61 kgf*cm, 53 in.*lbf) or less If the value is not within the specified range, replace the rear suspension toe control link with a new one. Check the dust boot for cracks or grease leakage.

HINT

1. Use the same procedures for the RH side and LH side.
2. The procedures listed below are for the LH side.
3. A bolt without a torque specification is shown in the standard bolt chart (see «SPECIFIED TORQUE FOR STANDARD BOLTS»(ref-349708-S13378942112009120800000) ).

Scheme 205

Scheme 206

1. TEMPORARILY INSTALL TOE CONTROL LINK SUB-ASSEMBLY LH Insert the toe adjust cam from the rear of the vehicle and connect the toe control link. Then temporarily install the No. 2 suspension toe adjust plate with the nut. NOTE: Align the matchmarks of the No. 2 suspension toe adjust plate and suspension member. Temporarily install the toe control arm with the new nut to the axle carrier.
2. TIGHTEN TOE CONTROL LINK SUB-ASSEMBLY LH Tighten the 2 nuts. Torque: 60 N*m (612 kgf*cm, 44 ft.*lbf) for suspension member side 118 N*m (1203 kgf*cm, 87 ft.*lbf) for axle carrier side
3. INSTALL REAR SPEED SENSOR LH (See «INSTALLATION»(ref-349740-S10659840852009120800000) )
4. INSTALL LOAD SENSING VALVE SENSOR BRACKET (See «INSTALLATION»(ref-349750-S07311517802009120800000) )
5. SABILIZE SUSPENSION Stabilize the suspension (w/o Air Suspension) (see «INSTALLATION»(ref-349722-S37097628642009120800000) ). Stabilize the suspension (w/ Air Suspension) (see «INSTALLATION»(ref-349722-S27364139402009120800000) ).
6. INSTALL REAR WHEEL Torque: 140 N*m (1428 kgf*cm, 104 ft.*lbf)
7. CHECK SUSPENSION CONTROL SYSTEM (w/ Air Suspension) Check the suspension control system (see «OPERATION CHECK»(ref-349750-S12258921322009120800000) ).
8. INSPECT AND ADJUST REAR WHEEL ALIGNMENT Inspect and adjust the rear wheel alignment (see «ADJUSTMENT»(ref-349722-S07390225572009120800000) ).
9. CHECK SPEED SENSOR SIGNAL Check the speed sensor signal (see «TEST MODE PROCEDURE»(ref-349740-S02170830312009120800000) ).
10. ADJUST HEADLIGHT ASSEMBLY Adjust the headlight (see «ADJUSTMENT»(ref-349731-S09246046722009120800000) ).

Scheme 207

Scheme 208

Scheme 209

Scheme 210

Scheme 211

Scheme 212

Scheme 213

Scheme 214

Scheme 215

Scheme 216

Scheme 217

Scheme 218

Scheme 219

1. REMOVE COWL TOP VENTILATOR LOUVER RH (See «REMOVAL»(ref-349732-S04425564642009120800000) )
2. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation. NOTE: After the engine switch is turned off, the HDD navigation system requires approximately 6 minutes to record various types of memory and settings. As a result, after turning the engine switch off, wait 6 minutes or more before disconnecting the cable from the negative (-) battery terminal.
3. REMOVE REAR WHEEL
4. REMOVE LUGGAGE COMPARTMENT MAT SUB-ASSEMBLY (See «REMOVAL»(ref-349743-S29102114712009120800000) )
5. REMOVE DECK TRIM SIDE BOARD LH (See «REMOVAL»(ref-349743-S29102114712009120800000) )
6. REMOVE REAR FLOOR FINISH PLATE (See «REMOVAL»(ref-349743-S29102114712009120800000) )
7. REMOVE LUGGAGE COMPARTMENT TRIM COVER ASSEMBLY LH (See «REMOVAL»(ref-349743-S29102114712009120800000) )
8. REMOVE NO. 2 DIFFERENTIAL SUPPORT PROTECTOR (See «REMOVAL»(ref-349739-S24282521242009120800000) )
9. REMOVE NO. 1 DIFFERENTIAL SUPPORT PROTECTOR (See «REMOVAL»(ref-349739-S24282521242009120800000) )
10. REMOVE NO. 6 ROCKER PANEL MOLDING PROTECTOR (See «REMOVAL»(ref-349729-S00174219962009120800000) )
11. REMOVE NO. 5 ROCKER PANEL MOLDING PROTECTOR (See «REMOVAL»(ref-349729-S00174219962009120800000) )
12. REMOVE REAR FLOOR SIDE MEMBER COVER LH (See «REMOVAL»(ref-349729-S00174219962009120800000) )
13. REMOVE REAR FLOOR SIDE MEMBER COVER RH (See «REMOVAL»(ref-349729-S00174219962009120800000) )
14. REMOVE REAR WHEEL HOUSE LINER LH (See «REMOVAL»(ref-349722-S01414464432009120800000) )
15. REMOVE REAR WHEEL HOUSE LINER RH HINT: Use the same procedures described for the LH side.
16. REMOVE FLOOR NO. 1 UNDER COVER (See «REMOVAL»(ref-349717-S41633666492009120800000) )
17. REMOVE REAR SPEED SENSOR LH (See «REMOVAL»(ref-349740-S34655650882009120800000) )
18. REMOVE REAR SPEED SENSOR RH HINT: Use the same procedures described for the LH side.
19. DISCONNECT NO. 1 ACTUATOR HARNESS CLAMP Disconnect the 2 clamps and connector.
20. REMOVE PARKING BRAKE CABLE Remove the 2 nuts and disconnect the cable from the vehicle side.
21. REMOVE FRONT FLOOR BRACE CENTER (See «REMOVAL»(ref-349729-S00174219962009120800000) )
22. REMOVE HEATED OXYGEN SENSOR (for Sensor 2) (See «REMOVAL»(ref-349729-S00174219962009120800000) )
23. REMOVE FRONT EXHAUST PIPE ASSEMBLY (See «REMOVAL»(ref-349729-S00174219962009120800000) )
24. REMOVE TAILPIPE LH (See «REMOVAL»(ref-349729-S00174219962009120800000) )
25. REMOVE TAILPIPE RH (See «REMOVAL»(ref-349729-S00174219962009120800000) )
26. REMOVE FRONT FLOOR NO. 1 HEAT INSULATOR (See «REMOVAL»(ref-349737-S17698100612009120800000) )
27. REMOVE PROPELLER SHAFT HEAT INSULATOR (See «REMOVAL»(ref-349737-S17698100612009120800000) )
28. REMOVE PROPELLER WITH CENTER BEARING SHAFT ASSEMBLY (See «REMOVAL»(ref-349737-S17698100612009120800000) )
29. REMOVE REAR DISC BRAKE CALIPER ASSEMBLY LH (See «REMOVAL»(ref-349719-S20561870172009120800000) )
30. REMOVE REAR DISC BRAKE CALIPER ASSEMBLY RH HINT: Use the same procedures described for the LH side.
31. REMOVE REAR STABILIZER LINK ASSEMBLY LH Remove the nut and disconnect the stabilizer link from the stabilizer bar. Remove the bolt, nut and stabilizer link from the rear No. 2 suspension arm.
32. REMOVE REAR STABILIZER LINK ASSEMBLY RH HINT: Use the same procedures described for the LH side.
33. DISCONNECT REAR SHOCK ABSORBER ASSEMBLY LH (w/o Air Suspension) (See «REMOVAL»(ref-349722-S36340836592009120800000) )
34. DISCONNECT REAR SHOCK ABSORBER ASSEMBLY RH (w/o Air Suspension) HINT: Use the same procedures described for the LH side.
35. DISCONNECT PNEUMATIC CYLINDER WITH REAR SHOCK ABSORBER ASSEMBLY LH (w/ Air Suspension) (See «REMOVAL»(ref-349722-S36340836592009120800000) )
36. DISCONNECT PNEUMATIC CYLINDER WITH REAR SHOCK ABSORBER ASSEMBLY RH (w/ Air Suspension) HINT: Use the same procedures described for the LH side.
37. REMOVE REAR SUSPENSION MEMBER SUB-ASSEMBLY Support the crossmember with the jack. for Sports package Remove the 4 bolts labeled A. Remove the 4 bolts labeled B and 2 suspension member stoppers. Slowly lower the jack, and disconnect the suspension member from the vehicle. for Standard Remove the 4 bolts. Slowly lower the jack, and disconnect the suspension member from the vehicle.
38. REMOVE STABILIZER BAR REAR Remove the 4 bolts and stabilizer bar from the suspension member. HINT: The stabilizer bracket and bush are built onto the stabilizer bar. If the bracket and/or bush detach from the bar, replace the bar.

Scheme 220

1. INSPECT REAR STABILIZER LINK ASSEMBLY LH Temporarily install the nut, and flip the ball joint stud back and forth 5 times as shown in the illustration. Use a torque wrench to turn the nut continuously at a rate of 3 to 5 seconds per turn. Take the torque reading on the fifth turn. Standard turning torque: 1.96 N*m (20 kgf*cm, 17 in.*lbf) or less If the value is not within the specified range, replace the rear suspension toe control link with a new one Check the dust boot for cracks or grease leakage.

HINT

A bolt without a torque specification is shown in the standard bolt chart (see SPECIFIED TORQUE FOR STANDARD BOLTS ).

Scheme 221

Scheme 222

1. INSTALL STABILIZER BAR REAR Make sure the bracket's arrows face the front of the vehicle. First temporarily install bolt 1. Then install bolts 2, 3 and 4. Then tighten bolt 5. Torque: 48 N*m (489 kgf*cm, 35 ft.*lbf)
2. INSTALL REAR STABILIZER LINK ASSEMBLY LH Install the stabilizer link with the 2 nuts and bolt. Torque: 89 N*m (908 kgf*cm, 66 ft.*lbf) for stabilizer bar side 26 N*m (265 kgf*cm, 19 ft.*lbf) for No. 2 suspension arm side
3. INSTALL REAR STABILIZER LINK ASSEMBLY RH HINT: Use the same procedures described for the LH side.
4. INSTALL REAR SUSPENSION MEMBER SUB-ASSEMBLY Slowly raise the suspension member jack, and install the suspension member to the body. for Sports package Install the 2 member stoppers with the 4 bolts labeled B, and install the 4 bolts labeled A. Torque: 19 N*m (194 kgf*cm, 14 ft.*lbf) for bolt labeled A 127 N*m (1295 kgf*cm, 94 ft.*lbf) for bolt labeled B for Standard Install the 4 bolts labeled B. Torque: 127 N*m (1295 kgf*cm, 94 ft.*lbf)
5. CONNECT PNEUMATIC CYLINDER WITH REAR SHOCK ABSORBER ASSEMBLY LH (w/ Air Suspension) (See «INSTALLATION»(ref-349722-S11477672232009120800000) )
6. CONNECT PNEUMATIC CYLINDER WITH REAR SHOCK ABSORBER ASSEMBLY RH (w/ Air Suspension) HINT: Use the same procedures described for the LH side.
7. CONNECT REAR SHOCK ABSORBER ASSEMBLY LH (w/o Air Suspension) (See «INSTALLATION»(ref-349722-S11477672232009120800000) )
8. CONNECT REAR SHOCK ABSORBER ASSEMBLY RH (w/o Air Suspension) HINT: Use the same procedures described for the LH side.
9. INSTALL REAR DISC BRAKE CALIPER ASSEMBLY LH (See «INSTALLATION»(ref-349719-S30633082262009120800000) )
10. INSTALL REAR DISC BRAKE CALIPER ASSEMBLY RH HINT: Use the same procedures described for the LH side.
11. INSTALL PROPELLER WITH CENTER BEARING SHAFT ASSEMBLY (See «INSTALLATION»(ref-349737-S23487538942009120800000) )
12. INSPECT AND ADJUST NO. 2 AND NO. 3 JOINT ANGLE (See «INSTALLATION»(ref-349737-S23487538942009120800000) )
13. INSTALL PROPELLER SHAFT HEAT INSULATOR (See «INSTALLATION»(ref-349737-S23487538942009120800000) )
14. INSTALL FRONT FLOOR NO. 1 HEAT INSULATOR (See «INSTALLATION»(ref-349737-S23487538942009120800000) )
15. INSTALL TAILPIPE RH (See «INSTALLATION»(ref-349729-S37582603882009120800000) )
16. INSTALL TAILPIPE LH (See «INSTALLATION»(ref-349729-S37582603882009120800000) )
17. INSTALL FRONT EXHAUST PIPE ASSEMBLY (See «INSTALLATION»(ref-349729-S37582603882009120800000) )
18. INSTALL FRONT FLOOR BRACE CENTER (See «INSTALLATION»(ref-349729-S37582603882009120800000) )
19. INSTALL HEATED OXYGEN SENSOR (for Sensor 2) (See «INSTALLATION»(ref-349729-S37582603882009120800000) )
20. INSPECT FOR GAS LEAK
21. INSTALL PARKING BRAKE CABLE Install the cable with the 2 nuts to the vehicle side. Torque: 8.0 N*m (82 kgf*cm, 71 in.*lbf)
22. CONNECT NO. 1 ACTUATOR HARNESS CLAMP Connect the 2 clamps and connector.
23. INSTALL REAR SPEED SENSOR LH (See «INSTALLATION»(ref-349740-S10659840852009120800000) )
24. INSTALL REAR SPEED SENSOR RH HINT: Use the same procedures described for the LH side.
25. INSTALL REAR WHEEL HOUSE LINER LH Install the liner with the 3 screws, 11 nuts, 2 clips to the vehicle side.
26. INSTALL REAR WHEEL HOUSE LINER RH HINT: Use the same procedures described for the LH side.
27. INSTALL REAR FLOOR SIDE MEMBER COVER RH (See «INSTALLATION»(ref-349729-S37582603882009120800000) )
28. INSTALL REAR FLOOR SIDE MEMBER COVER LH (See «INSTALLATION»(ref-349729-S37582603882009120800000) )
29. INSTALL NO. 5 ROCKER PANEL MOLDING PROTECTOR (See «INSTALLATION»(ref-349729-S37582603882009120800000) )
30. INSTALL NO. 6 ROCKER PANEL MOLDING PROTECTOR (See «INSTALLATION»(ref-349729-S37582603882009120800000) )
31. INSTALL NO. 1 DIFFERENTIAL SUPPORT PROTECTOR (See «INSTALLATION»(ref-349739-S27293288612009120800000) )
32. INSTALL NO. 2 DIFFERENTIAL SUPPORT PROTECTOR (See «INSTALLATION»(ref-349739-S27293288612009120800000) )
33. INSTALL FLOOR NO. 1 UNDER COVER (See «INSTALLATION»(ref-349717-S33420032622009120800000) )
34. INSTALL LUGGAGE COMPARTMENT TRIM COVER ASSEMBLY LH (See «INSTALLATION»(ref-349743-S30157791022009120800000) )
35. INSTALL REAR FLOOR FINISH PLATE (See «INSTALLATION»(ref-349743-S30157791022009120800000) )
36. INSTALL DECK TRIM SIDE BOARD LH (See «INSTALLATION»(ref-349743-S30157791022009120800000) )
37. INSTALL LUGGAGE COMPARTMENT MAT SUB-ASSEMBLY (See «INSTALLATION»(ref-349743-S30157791022009120800000) )
38. INSTALL REAR WHEEL Torque: 140 N*m (1428 kgf*cm, 104 ft.*lbf)
39. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
40. INSTALL COWL TOP VENTILATOR LOUVER RH (See «INSTALLATION»(ref-349732-S09051375432009120800000) )
41. PERFORM INITIALIZATION Perform initialization (see «INITIALIZATION»(ref-349706-S07943075812009120800000) ). NOTE: Certain systems need to be initialized after disconnecting and reconnecting the cable from the negative (-) battery terminal.
42. CHECK SUSPENSION CONTROL SYSTEM (w/ Air Suspension) Check the suspension control system (see «OPERATION CHECK»(ref-349750-S12258921322009120800000) ).
43. INSPECT AND ADJUST REAR WHEEL ALIGNMENT Inspect and adjust the rear wheel alignment (see «ADJUSTMENT»(ref-349722-S07390225572009120800000) ).
44. CHECK SPEED SENSOR SIGNAL Check the speed sensor signal (see «TEST MODE PROCEDURE»(ref-349740-S02170830312009120800000) ).
45. ADJUST HEADLIGHT ASSEMBLY Adjust the headlight (see «ADJUSTMENT»(ref-349731-S09246046722009120800000) ).
